ViewSonic EP1031r User Guide
EP1031r/EP1032r-T
Multimedia Digital Poster
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specic languages using the Regional selection
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”
Model No. VS15683
Compliance Information
NOTE: This section addresses all connected requirements and statements regarding
regulations. Confirmed corresponding applications shall refer to nameplate labels
and relevant markings on unit.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for
a Class A/Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: To comply with the limits for the Class A/Class B digital device, pursuant
to Part 15 of the FCC Rules, this device must be installed in computer equipment
certified to comply with the Class A/Class B limits. All cables used to connect the
computer and peripherals must be shielded and grounded. Operation with noncertified computers or non-shielded cables may result in interference to radio or
television reception. Changes and modifications not expressly approved by the
manufacturer could void the user’s authority to operate this equipment.
RF exposure warning statement
This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter. End-users and
installers must be provide with antenna installation instructions and transmitter
operating conditions for satisfying RF exposure compliance.
i
The equipment complies with FCC RF exposure limits set forth for an uncontrolled
environment.
The equipment must not be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment must be installed and operated in accordance with provided
instructions and must not be co-located or operating in conjunction with any other
antenna or transmitter. End-users and installers must be provide with antenna
installation instructions and transmitter operating conditions for satisfying RF
exposure compliance.
For Canada
CAN ICES-3 (A/B)/NMB-3(A/B)
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose of the equipment as
unsorted municipal waste, but use the return and collection systems
according to local law.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery
has a heavy metal content of more than 0.0005% Mercury or more than,
0.002% Cadmium, or more than 0.004% Lead.
Industry Canada Notice
This device complies with Canadian RSS-210.To prevent radio interference to the
licensed service, this device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or its transmitting antenna) that
is installed outdoors is subject to licensing. The installer of this radio equipment must
ensure that the antenna is located or pointed such that it does not emit RF field in
excess of Health Canada limits for the general population; consult Safety Code 6,
obtainable from Health Canada’s website www.hc-sc.gc.ca/rpb.
ii
R&TTE Compliance Statement
This device complies with the Essential Requirements of the R&TTE Directive of
the European Union (1999/5/EC). This equipment meets the following conformance
standards:
ETSI EN 300 328
EN 301 489-01
EN 301 489-17
EN 62311
Notified Countries: Germany, UK, Netherlands, Belgium, Sweden, Denmark,
Finland, France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg,
Estonia, Latvia, Lithuania, Czech Republic, Slovakia, Slovenia, Hungary, Poland and
Malta.
iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr
Polybrominated biphenyls
(PBB)
Polybrominated diphenyl ethers
(PBDE)
6+
) 0,1% < 0,1%
0,1% < 0,1%
0,1% < 0,1%
Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. Mercury in cold cathode uorescent lamps and external electrode uorescent
lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.
(3) Long length (＞1,500 mm): maximum 13 mg per lamp.
2. Lead in glass of cathode ray tubes.
3. Lead in glass of uorescent tubes not exceeding 0.2% by weight.
4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
iv
Safety Precautions
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN
SETTING UP AND USING THE LCD COLOR MONITOR:
• DO NOT REMOVE MONITOR BACK COVER. There are no user serviceable
parts inside and opening or removing covers may expose you to dangerous
shock hazards or other risks. Refer all servicing to qualified service personnel.
• Do not spill any liquids into the cabinet or use your monitor near water.
• Do not insert objects of any kind into the cabinet slots, as they may touch
dangerous voltage points, which can be harmful or fatal or may cause electric
shock, fire or equipment failure.
• Do not place any heavy objects on the power cord. Damage to the cord may
cause shock or fire.
• Do not place this product on a sloping or unstable cart, stand or table, as the
monitor may fall, causing serious damage to the monitor.
• Do not place any objects onto the monitor and do not use the monitor outdoors.
• The inside of the fluorescent tube located within the LCD monitor contains
mercury. Please follow the laws or rules of your municipality to dispose of the
tube properly.
• Do not bend power cord.
• Do not use monitor in high temperature, humid, dusty, or oily areas.
• If monitor or glass is broken, do not come in contact with the liquid crystal and
handle with care.
• Allow adequate ventilation around the monitor, so that heat can properly
dissipate. Do not block ventilated openings or place the monitor near a radiator
or other heat sources. Do not put anything on top of the monitor.
• The power cable connector is the primary means of detaching the system from
the power supply. The monitor should be installed close to a power outlet, which
is easily accessible.
• Handle with care when transporting. Save packaging for transporting.
• Please clean the holes of back cabinet to reject dirt and dust at least once a year
because of set reliability.
• If using the cooling fan continuously, it’s recommended to wipe holes a minimum
of once a month.
• When installing the remote control batteries;
- Align the batteries according to the (+) and (-) indications inside the case.
- Align the (-) indication of the battery first inside the case.
v
CAUTION:
Immediately unplug your monitor from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet damaged.
• If the monitor does not operate normally by following operating instructions.
Recommended Use
CAUTION:
• For optimum performance, allow 20 minutes for warm-up.
• Rest your eyes periodically by focusing on an object at least 5 feet away. Blink
often.
• Position the monitor at a 90° angle to windows and other light sources to
minimize glare and reflections.
• Clean the LCD monitor surface with a lint-free, nonabrasive cloth. Avoid using
any cleaning solution or glass cleaner!
• Adjust the monitor’s brightness, contrast and sharpness controls to enhance
readability.
• Avoid displaying fixed patterns on the monitor for long periods of time to avoid
image persistence (after image effects).
• Get regular eye checkups.
Ergonomics
To realize the maximum ergonomic benefits, we recommend the following:
• Use the preset Size and Position controls with standard signals.
• Use the preset Color Setting.
• Use non-interlaced signals.
• Do not use primary color blue on a dark background, as it is difficult to see and
may produce eye fatigue due to insufficient contrast.
vi
Contents
Compliance Information
FCC Statement .................................................................................... i
For Canada .........................................................................................ii
CE Conformity for European Countries ...............................................ii
Industry Canada Notice .......................................................................ii
R&TTE Compliance Statement ..........................................................iii
Declaration of RoHS2 Compliance .....................................................iv
Safety Precautions ............................................................................. v
Recommended Use ............................................................................vi
Ergonomics ........................................................................................vi
Copyright Information
Product Registration ........................................................................... 2
For Your Records ............................................................................... 2
1. Introduction
1.1 Features ....................................................................................... 3
1.2 Package contents ......................................................................... 3
1.3 Physical view and features ........................................................... 4
1.4 Installation .................................................................................... 5
2. Configuring the EP1031r/EP1032r-T
2.1 System connections ..................................................................... 6
2.2 Basic settings ............................................................................... 7
2.3 Connecting the EP1031r/EP1032r-T to your network .................. 7
2.4 Time zone settings ..................................................................... 10
2.5 Content settings ......................................................................... 11
2.6 Player information ...................................................................... 12
2.7 Content configuration – AppStart ............................................... 13
2.8 Content configuration – FailSafe ................................................ 14
2.9 Content configuration – EasyPlay .............................................. 15
2.10 Display settings ........................................................................ 17
2.11 Sound settings .......................................................................... 21
2.12 System configuration – Time Server ........................................ 22
vii
2.13 System configuration – Scheduled reboot ................................ 23
2.14 System configuration - Firmware upgrades .............................. 24
2.15 System configuration - Factory reset ........................................ 25
2.16 System configuration – Power save ......................................... 26
2.17 System configuration – Expand Storage by using SD card ..... 26
3. Content Management
4. Authoring in HTML5
5. Working with SMIL
5.1 Input Source ............................................................................... 27
5.2 www.a-smil.org for developers ................................................... 27
6. Technical Data
6.1 Specifications ............................................................................. 28
7. Troubleshooting
Other Information
Customer Support ............................................................................ 32
Limited Warranty .............................................................................. 33
viii
Copyright Information
Copyright © ViewSonic Corporation, 2014. All rights reserved.
©
ViewSonic
Corporation.
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection
Agency (EPA). As an ENERGY STAR® partner, ViewSonic Corporation has
determined that this product meetsthe ENERGY STAR
efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
the right to change product specifications without notice. Information in this
document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic Corporation.
and the three birds logo are registered trademarks of ViewSonic
®
guidelines for energy
1
Product Registration
To meet your future needs, and to receive any additional product information as it
becomes available, please register your product on the Internet at:
www.viewsonic.com.
The ViewSonic® Wizard CD-ROM also provides an opportunity for you to print the
registration form, which you may mail or fax to ViewSonic.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing.
Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
EP1031r/EP1032r-T
ViewSonic Multimedia Digital Poster
VS15683
EP1031r/EP1032r-T_UG_ENG Rev. 1B 05-23-14
_______________________________________
_______________________________________
2
1. Introduction
1.1 Features
EP1031r
• 10.1-inch widescreen LCD display and stereo speakers
• 4GB on-board flash local storage with SD card slot
• Built-in motion sensors and 6 touch buttons
• Built-in wireless b/g/n network and Ethernet
• Power over Ethernet
• Supports full POPAI Screen Media Formats Standards profiles S1 to S12, and
E1 to E8
• Multiple 3rd party software solution compatibility
• Industry leading W3C SMIL support for developers
EP1032r-T
• 10-inch multi-touch widescreen LCD display and stereo speakers
• 4GB on-board flash local storage with SD card slot
• Built-in wireless b/g/n network and Ethernet
• Power over Ethernet
• Supports full POPAI Screen Media Formats Standards profiles S1 to S12, and
• E1 to E8
• Multiple 3rd party software solution compatibility
• Industry leading W3C SMIL support for developers
1.2 Package contents
Main Unit AC Adapter Ethernet Cable Standard 3.5mm to
Display stand and
screws
Note: A USB mouse is required for system setup.
Quick Start Guide Documentation CD Software Setup
RCA AV Adapter
Guide
3
1.3 Physical view and features
EP1031r
Motion Sensor
Wireless
antenna post
VESA mount
(MIS-D 75)
Audio out jack
Ethernet
EP1032r-T
SD card slot
Touch buttons
Reset
USB x2
Cover
Kensington lock
DC IN
ADB
Compatible with HDMI
Wireless
antenna post
VESA mount
(MIS-D 75)
Audio out jack
Ethernet
SD card slot
Reset
USB x2
Cover
Kensington lock
DC IN
ADB
Compatible with HDMI
4
1.4 Installation
Fix the display stand
1. Put the supplied display stand onto the screw socket.
2. Insert the two supplied screws.
3. Fasten the screws.
Fix the Kensington lock
1. Press the Kensington lock’s button and insert it into the lock slot.
2. Plug the lock into the lock hole, and then release the button.
Open the back cover
1. Remove the screw from the back cover.
2. To release the back cover, slide the cover in the direction shown here, and then
pull up.
5
Loading...
