ViewRec VR-101 Series User Manual

VR-101 series

HD 720P

High Definition Handheld Driving Recorder

User Manual

Please read the user manual carefully before use and keep for future reference.
All rights reserved. © Mitech Technologies Co., Ltd. This user manual is subject to change without prior notice.

Safety Precautions

Please use this device according to the operation instructions and warnings on the user manual. Before you

cleanse the device, make sure the power is switched off and Micro SD card is removed.

Warnings：

 Do not use this device in a humid (relative humidity above 80%), gaseous conductive environment.
 Do not drop the device in case it might break.
 Do not block or cover the ventilation holes on the device.
 Please put this device on a well-ventilated place and do not put other objects in the device.
 Do not use the device for a long time or put the device in an overheated environment (over 45°C), this will

affect product lifetime.

 Warranty period of the product is 1 year, (battery is 6 months). Battery life will be shortened if operated in

an overheated environment.

 Please make sure the cigarette lighter receptacle voltage match the mini USB power cable voltage.
 Danger：Do not constantly watch the LCD screen on the device while driving.

Pre-operation Instruction

Instructions：

 Make sure power is switched off before you cleanse the device.
 Please use neutral cleaner to cleanse the device.
 Please remove power cable when device is not in use.
 Please switch the device off and remove power cable when you leave your car; also put the device in a

place that is not exposed to direct sunlight or high temperature.

 Do not put the device on overheated places.
 Due to this product is a camera device, it is subject to various conditions such as when entering tunnels,

daytime backlighting or lack of lighting. These might affect the recording quality.

 When the lighting conditions are less than ideal, please turn on the headlight for a better recording quality.
 Please be noted that stained or over-colored windshield might affect the recording quality, such as unclear

or distorted images.

 Please be noted that removing Micro SD card without switching off the device might cause loss or damage

of data. Please stop recording before you remove Micro SD card.

 It is recommended to store important data to other storage devices such as PC/Laptop, removable hard

drive or CD/DVD discs. We are not responsible for any loss of data whatsoever.

 We are not responsible for any unexplained reasons of improper operating environment or operating

methods.

 Please do not remove or adjust the mounting bracket for your driving safety.

1

Things to be avoided：

 Do not block or cover the ventilation holes and slots on the device.
 When removing the device from the mounting bracket, please be careful not to break the mortise and

tenon.

 When unexpected shutdown happens, simply long press power switch to turn the device on. Do not try to

disassemble and repair the device. Possible reasons for unexpected shutdown include (1) incompatible

memory card, (2) severe vibration while driving, (3) battery is low, (4) unsteady voltage.

 When the device is out of order, please contact distributor for repair or replacement service. Warranty shall

not apply to the following conditions: improper maintaining or cleaning, modification or repair by the

customer.

 Avoid dropping, crushing the device. Avoid water or liquids that may penetrate inside the device.
 Battery：

 Do not disassemble or expose battery to overheated environment (over 45°C). It is recommended not

to use the device in a car that has an interior temperature over 40°C.

 Do not incinerate battery or discard batter in the fire.
 Please use the genuine power cable for battery charging.
 For environmental protection, please recycle used battery. Do not litter.

Product Introduction

Features：

This product is a camcorder device used when driving vehicles and it has the following features：

 HD 1.3 Mega pixel camera. Ultra wide angle (130°), clear video resolution, and no blind spots from left to

right views.

 2”HD LCD full color screen.
 Resolution options: 1280x720 (default), 848x480, 320x240.
 HD 720P Mode @ 30 FPS. H.264 video compression
 HD 720P HD video. Support HDMI output.
 Low Lux enhanced image processing for better recording quality at night time.
 Built-in time and date display on recorded videos.
 Built-in high-speed video processing technology.
 Support Zoom 4X (Max.)
 Storage: 4GB above Class 6 SDHC memory cards. Support up to 32 GB.
 Power supply and charging battery via mini USB power cable (5 Vdc). If connected to PC/Laptop, it can

recharge the battery and download the videos/photos from the memory card.

 Automatic loop recording when car starts. Automatically stop recording when car stops.
 Loop recording time span options: 5/10/15 Minutes.
 Support battery life detection and battery protective circuit for safety.

2

 Built-in audio and video recording can be played simultaneously.
 Built-in photo shooting.
 Multi-language interface: Traditional/Simplified Chinese, English, French, German, Spanish, Italian,

Portuguese and Japanese.

Accessories：

 HD Smart DVR Driving Recorder(1)
 Mini USB power cable (1)
 Mounting Bracket (1)
 User Manual (1)
 4GB Micro SD Card (Class 6 ) (1) (Note: optional accessory for dealers only)

Exterior Overview

3
