www.view-master.com
DTH61
4
CHOKING HAZARD
– Small parts.
Not for children under 3 years.
WARNING:
View-Master® Deluxe VR Viewer works best with
the following smartphone devices:
WHAT’S INSIDE? COMPATIBLE DEVICES
Samsung Galaxy S7
Samsung Galaxy S6
Samsung Galaxy S6 Edge+
Samsung Galaxy S5
Samsung Galaxy Note 5
Samsung Galaxy Note 4
HTC One®
Huawei Nexus 6P
Motorola Nexus 6™
Motorola Moto X (2014)
Motorola Droid Turbo
LG G5
LG G4™
LG G3
LG Nexus 5X
LG Nexus 5
iPhone® 6s Plus
iPhone 6s
iPhone 6 Plus
iPhone 6
iPhone 5s
iPhone 5c*
iPhone 5*
iOS 8.1 and above
NOTE: View-Master® Deluxe VR Viewer may also work
with newer model Android™ smartphones not listed
above that have screens between 5 and 6 inches.
*View-Master® VR apps may not be optimized for
iPhone 5 and iPhone 5C.
1 2
4
3
2
1
If you lose the preview reel, you can get the image
tag to view Augmented Reality (AR) content at:
www.view-master.com/preview-reel
1 View-Master® Deluxe VR Viewer
1 View-Master® Preview Reel
1 Headphone Connector
1 Small Cap
1. DOWNLOAD APP
3 4
First, download any of the View-Master®
Experience Pack apps from the App Store or
Google Play. Take your pick from:
The preview reel will allow you to
unlock sample content from the
Experience Packs.
Full content of an Experience Pack is available by
purchasing the Experience Pack at retail or by
making an in-app purchase.
Each sold separately, subject to availability.
We reserve the right to terminate the Experience apps. See termination date on each Experience pack.
Standard data rates may apply.
View-Master® Batman: The Animated Series™
View-Master® Masters of the Universe®
View-Master® Discovery Underwater
View-Master® Nat Geo Dinosaurs
Switch Viewer
• Tap on “Switch Viewer”
• If the app asks for camera permissions, allow
access to your camera.
5 6
2. VIEWER PROFILE
DO THIS FIRST FOR OPTIMAL PERFORMANCE!
• Be sure you’ve downloaded the most recent
version of your View-Master® app.
• Follow the on-screen prompts to enter VR mode.
• After you’ve been prompted to turn your phone
horizontally, tap on the small gear icon located at
the bottom of the screen.
• Scan the QR code on the inside bottom of the
View-Master® Deluxe VR viewer.
LOCATING THE QR CODE INSIDE YOUR VIEWER
QR Code
Small Gear Icon
Smartphone and headphones not included.
7 8
Locate your smartphone’s headphone port (if applicable)
and align the headphone connector on the same side.
Press the button to open.
Remove any case from your smartphone then place
it between the clamps in the View-Master® Deluxe VR
Viewer so the screen is facing you. The top of your
phone should be to the left.
3. CONNECT HEADPHONES
Insert the connector into your smartphone. Insert
the other end of the cable into the space shown.
Insert the cap into the headphone connector space
not being used.
Plug your headphones into the headphone jack on
the outside of the View-Master
®
. Make sure you are
plugging your headphones into the same side the
headphone jack extender is plugged into.
ForMotorola Nexus 6™, place edge of phone under the upper clamps first, push up to spread clamps,
then place bottom edge of phone into the lower clamp.
Note: For optimal performance, do not use with a screen protector on your phone.
Built-in Adapter
Center these
two white lines.
5. FOCUS IMAGE
9 10
To bring images into focus, simply move the
Focus Wheel right or left until the image is sharp.
For iPhone 5s, iPhone 5c or iPhone 5, flip up the
built-in adapter.
4. INSTALL SMARTPHONE
Aligning Your Viewer: It is very important that you
center your device in the View-Master® Deluxe VR
Viewer. Line up the divider in the middle of the screen
with the white mark on the lower clamp.
11 12
TO ADJUST THE VOLUME – before placing your
smartphone in the viewer, you can use either the
physical volume buttons on the phone or go to
SETTINGS in the app.
IF THE AR ICONS DON’T APPEAR WHEN YOU
LOOK AT THE REEL – move the viewer closer to the
reel (less than 10 inches).
NOTE: AR icons work best when looking straight
down at the reel, and in a well-lit room.
IF THE TINTED WINDOW POPS FROM THE
VIEWER – orient the window so the View-Master®
icon is positioned at the top then push the window
into the back of the viewer until it snaps into place.
IF THE 3D EFFECT IS BLURRY –
Use the Focus
Wheel. If this does not work, open the View-Master®
Deluxe VR Viewer and re-center your device. Also, be
sure you have followed the instructions under “Viewer
Profile” in this booklet and scanned the QR code.
25cm (10 inches)
•
Make sure a View-Master® Experience app is launched.
• Place the preview reel on a flat surface.
• Look through the viewer at the reel from a distance
of 10 inches or less.
• Digital icons will appear above the reel. This eect
is called Augmented Reality, or AR.
Select which experience you want to explore by looking
at the appropriate AR icon and pulling the lever.
Now it’s time to see the world in a whole new way. Enjoy!
6. USING THE PREVIEW REEL
For additional help visit www.view-master.com/troubleshooting
TROUBLESHOOTING
13 14
DTH61-0970G1
1100893964-DOM
LEGAL
©2016 Mattel. All Rights Reserved. Mattel, Inc., 636 Girard Avenue, East Aurora, NY 14052, U.S.A. Consumer Services
1-800-524-8697. Mattel U.K. Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline 01628 500303. Mattel Australia
Pty Ltd., Richmond, Victoria. 3121. Consumer Advisory Service - 1300 135 312. Mattel East Asia Ltd., Room 503-09, North
Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Tel: (852) 3185-6500. Diimport & Diedarkan Oleh:
Mattel Southeast Asia Pte. Ltd. , No 19-1, Tower 3 Avenue 7, Bangsar South City, No 8, Jalan Kerinchi, 59200 Kuala
Lumpur, Malaysia. Tel: 03-78803817, Fax: 03-78803867. Mattel Europa B.V., Gondel 1, 1186 MJ Amstelveen, Nederland.
Apple, the Apple logo and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a
service mark of Apple Inc.
Google Cardboard, Android and Google Play™ are trademarks of Google Inc.
Nexus is a trademark of Google Inc.
Samsung Galaxy and Galaxy Note are trademarks of Samsung Electronics Co. Ltd.
LG and the LG logo are registered trademarks of LG Electronics, Inc. G3 and G4 are trademarks of LG Electronics, Inc.
MOTOROLA, MOTO X and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings,
LLC. DROID is a trademark of Lucaslm Ltd.
HTC, HTC ONE, and the HTC logo are trademarks of HTC Corporation.
WARNINGS
Calls or other incoming notifications may interrupt your experience.
CAUTION: This viewer is intended for viewing 3D content. Some users may
experience motion sickness while viewing 3D images. If you experience dizziness
or disorientation, immediately discontinue use of this device until the discomfort
subsides.
NOTE: Please be aware of your surroundings. Users should remain stationary
while using this product. Standing in a single spot is optimal.
THE VIEW-MASTER® DELUXE VR VIEWER IS NOT A PROTECTIVE CASE.
Works with specially formatted content only.
Images appear on your device touch screen.
Mattel is not responsible for content distributed through the App Store or Google
Play™, except for Mattel generated content. Please refer to Apple Inc. and Google
Terms of Service.
WARNING
Prevent serious injury.
Periodically check electronic device for cracks, broken glass or other damage. If
damaged, immediately remove from this product.
© 2016 National Geographic Partners LLC.
All rights reserved. NATIONAL GEOGRAPHIC and
Yellow Border Design are trademarks of the
National Geographic Society, used under license.
©2016 Discovery Communications, LLC. Discovery
Channel and the Discovery Channel logo are
trademarks of Discovery Communications, LLC, used
under license. All rights reserved. discovery.com
Images courtesy NASA/JPL - Caltech.
www.esa.int
BATMAN and all related characters and elements © & ™ DC
Comics and Warner Bros. Entertainment Inc. The DC LOGO:
TM & © DC. WB SHIELD: TM & © WBEI.
(s16)
© 2016 Viacom International Inc. All Rights Reserved. Nickelodeon, Teenage Mutant Ninja Turtles and all related titles,
logos and characters are trademarks of Viacom International Inc.
