Page 1
The Life Light
VLP121221-1
FlexPro
USER GUIDE
www.vielight.com
VieLight Inc., Toronto, Canada
Page 2
The Life Light
INTRODUCTION
VieLight FlexPro is a versatile light therapy device that is user-friendly, safe and
reliable.
The treatment lamps comprise of red and blue Light Emitting Diodes (LEDs) of
specific light wavelengths suitable for a range of treatments. The lamp assembly is
made up of 4 lamp panels in a hinged system to allow for a flat, curved or spaced
arrangement, so that different parts of the body can be treated.
The narrowband LEDs provide treatment for a wide range of dermatological and
physiological conditions. The red LEDs are intended for hair loss treatment, skin
rejuvenation, acne treatment, wound healing and pain management. The blue LEDs
are suitable for acne treatment.
The device automatically switches off after expiry of a programmable pre-set
treatment time.
BEFORE YOU START - CAUTION
The lamps are bright. Therefore, avoid direct eye exposure. Before treating the
face, put on the eye shields provided.
Exercise care when manipulating mechanical hinges.
Use only the power adapter provided to avoid damaging the equipment.
MAINTENANCE
To clean, wipe the treatment lamps with a soft, damp, non-abrasive cloth.
CAUTION
Do not use alcohol, acetone or other harsh chemicals.
Be careful not to spill any liquid onto the lamp housing.
SPECIFICATION
Red LED: 655 nm @ 5 mW/cm2 x 216 nos.
Blue LED: 415 nm @10 mW/cm2 x 312 nos.
Programmable Auto Timer: 10, 15, 20 minutes
Power Supply: Input: 100 - 240 VAC 1.5A 50 / 60Hz
Output: 24VDC 2.65A
VLP121221-1
1
6
www.vielight.com
VieLight Inc., Toronto, Canada
Your product is warranted to be free of defect in material
and workmanship under normal use.
This warranty is limited for a period of one year from its
original purchase date in which repairs or exchange of
parts according to what is deemed necessary by the
company will be made free of charge.
This warranty does not cover damage by the following;
a. Misuse, abuse or alteration to the product
b. Damage caused by accident or neglect
c. Servicing or repairs made by unauthorized persons
WE SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL,
SPECIAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT.
WARRANTY
Hinges: Adjustment Range: 220
o
Adjustment Increment: 10
o
Page 3
It is recommended that the combination of RED and BLUE lights is used for the
treatment of acne. Clean the face thoroughly before treatment. Use eye shields to
ensure that the eyes are completely covered.
Skin Rejuvenation (RED light)
Clean the face thoroughly, removing all traces of makeup.
Use the eye shields to ensure that the eyes are completely covered.
Set the timer to 20 minutes. Press the start Switch to begin the treatment.
After the treatment, apply moisturising / anti-aging or sun block cream.
20 minutes per session.
8 sessions with RED lights twice weekly for a period of 4 weeks.
Subsequently, once a week for maintenance.
1.
2.
3.
4.
Mild to Moderate Acne Treatment (RED & BLUE light)
Treatment with BLUE light
Treatment with RED light
Place the lamp close to the treatment area, adjusting the panels according to the
facial contour to be treated. The lamp housing may rest on the skin surface.
Press the start button TWICE and the BLUE lights will switch on.
Set the timer to 20 minutes.
Place the lamp close to the treatment area, adjusting the panels according to the
facial contour to be treated. The lamp housing may rest on the skin surface.
Press the start button ONCE and the RED lights will switch on.
Set the timer to 20 minutes.
20 minutes per session.
Two sessions a week alternating between BLUE light for one session and
RED light for the next session for the first 4 weeks. Subsequently, once a
week, again alternating between BLUE and RED lights for maintenance.
Continue with any topical treatment that you have started with for
managing the acne.
1.
2.
3.
1.
2.
3.
TREATMENT PROTOCOLS
3
4
ADJUSTING THE LAMPS
The 4-lamp configuration may be adjusted for treatment on different body parts.
Recommended treatment schedule:
Recommended treatment schedule:
Detaching the Lamp
Pull detent pin out and slide
the lamp out from the hinge.
Adjusting the Hinges
The hinges are locked into position.
Release the lock by pressing the pad
located on the side of the hinge. Lift the
lamp slightly before unlocking the hinge.
Page 4
Hair Rejuvenation (RED light)
Place the lamp above the head, and adjust the lamp panels accordingly.
Set the timer to 10 minutes.
Press the start button and the RED lights will switch on.
The lamp will switch off automatically after 10 minutes.
1.
2.
3.
4.
Skin Rejuvenation (RED light)
Clean the face thoroughly, removing all traces of makeup.
Use the eye shields to ensure that the eyes are completely covered.
Set the timer to 20 minutes. Press the start Switch to begin the treatment.
After the treatment, apply moisturising / anti-aging or sun block cream.
20 minutes per session.
8 sessions with RED lights twice weekly for a period of 4 weeks.
Subsequently, once a week for maintenance.
1.
2.
3.
4.
Continue with any topical treatment that you have started with for
managing the acne.
TREATMENT PROTOCOLS
Pain Reduction, Quicker Wound Healing and Muscular Fatigue /
Strain Recovery (RED light)
Place the light source over the affected area. Set the timer for 20 minutes. Apply
this treatment once a day until the pain has subsided or the wound is healed.
3
4
5
Recommended treatment schedule:
Recommended treatment schedule:
10 minutes per session.
2 sessions a week for 4 months.
Subsequently, once or twice a month for maintenance.
Directions:
Plug the power adapter to the adapter socket and into a wall power socket.
Position the lamp accordingly by adjusting the two hinges. The lamp is
detachable to provide for more flexibility.
It is safe for the lamp surface to be in contact with the skin during treatment.
Switch on the device by pressing the Switch located at the top of the lamp
housing, and the red LEDs will switch ON.
The blue LEDs will be switched ON when the Switch is pressed again.
To switch OFF, press the Switch again.
The lamp is auto-timed to switch OFF after the timer expires. There will be an
audible beep every 5 minutes.
The timer may be set to 5, 10 or 20 minutes.
Adapter Plug
Adapter Socket
Weighted Stand
Lamp
Hinge
Hinge
Power Adapter
Plug into AC
power socket
OPERATING INSTRUCTIONS
2
Press ONCE to switch on RED light
Press TWICE to switch on BLUE light
Press again to switch OFF
Press for 3 seconds to initiate a change of
treatment time. Release the switch when
indictor light flashes. Press again to set the
time. Hold for 3 seconds to confirm the
setting.
Detaching the Lamp
Pull detent pin out and slide
the lamp out from the hinge.
Press to adjust hinge
Timer
LEDs
Top view
