INTRODUCTION

» Introduction to the Vidikron PlasmaView™

VP-42 / VP-42HD / VP-50 / VP-60 Flat Panel Display Monitor

Vidikron presents a full line-up of high performance plasma display monitors, perfect for every application. Three models, 42, 50 and
60 inch, all share common style, engineering and design, features and state-of-the-art performance.

These three popular sizes all feature HDTV capable, 16:9 native resolution display panels with advanced engineering innovations to
give you the brightest, clearest images possible. Vidikron’s superior video processing with 3:2 film detection circuitry is built into
the monitors and provides exceptional detail and artifact-free video enhancement, elevating even standard NTSC material to near HD
quality.

Multiple aspect ratio control includes Vidikron’s IntelliWide mode, offering the ability to view standard video formats in widescreen
without loss of image quality. IR and discrete RS-232 controls facilitate glitch-free custom installation, while Dynamic Pixel
Protection™ helps to protect the plasma panel from stationery image burn.

A generous number of inputs and the sleekest styling around make these flat panel display monitors a great value and the ideal choice
for discerning viewers.

2

Introduction

» The features you’ll enjoy include:

• 16:9 Native Resolution:
853 x 480 (VP-42)
1024 x 768 (VP-42HD)
1365 x 768 (VP-50, VP-60)

• DVI Input with HDCP

• IR and discrete RS-232 Control for custom installation integration

• Dynamic Pixel Protection™ to help prevent stationary image burn

• HDTV Ready

• Less than 5 inches thin

Contents of the package:

• Plasma display monitor

• Power cord

• Remote control with two AAA batteries

• User’s manual

• Safety metal ttings*

• Screws for safety metal ttings*

• Ferrite core (small x 2. large x 2), bands

• Cable clamps

* These are ttings for fastening the unit to a wall to prevent tipping
due to external shock when using the tablestand (optional). Fasten
the safety ttings to the holes in the back of the plasma using the
safety tting mount screws.

Options:

• Wall mount unit

• Tilt mount unit

• Tablestand

3

IMPORTANT INFORMATION

!

» Precautions

Please read this manual carefully before using your plasma
monitor and keep the manual handy for future reference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO DO
NOT USE THIS UNIT’S POLARIZED PLUG WITH AN
EXTENSION CORD RECEPTACLE OR OTHER OUTLETS,
UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE
ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER. NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

This symbol warns the user that uninsulated
voltage within the unit may have sufcient
magnitude, it is dangerous to make any kind of
contact with any part inside this unit.

This symbol alerts the user that important
literature concerning the operation and
maintenance of this unit has been included.
Therefore, it should be read carefully in order to
avoid any problems.

4

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.

WARNING

Important Information

» Warnings and Safety Precautions

No maintenance other than cleaning is required. Please see the section “Plasma monitor cleaning procedure” on page 7.
The plasma display panel consists of ne picture elements (cells). There may be some cells that do not produce light or remain lit.
For operating safety and to avoid damage to the unit, read carefully and observe the following instructions. To avoid shock and re
hazards:

1. Provide adequate space for ventilation to avoid internal heat build-up. Do not cover rear vents or install the unit in a closed cabinet or
shelves. If you install the unit in an enclosure, make sure there is adequate space at the top of the unit to allow hot air to rise and escape.
If the monitor becomes too hot, the overheat protector will be activated and the monitor will be turned off. If this happens, turn off the
power to the monitor and unplug the power cord. If the room where the monitor is installed is particularly hot, move the monitor to a
cooler location, and wait for 60 minutes to cool the monitor. If the problem persists, contact your dealer for service.

2. Do not use this unit’s polarized plug with extension cords or outlets unless the prongs can be completely inserted.

3. Do not expose the unit to water or moisture.

4. Avoid damage to the power cord, and do not attempt to modify the power cord.

5. Unplug the power cord during electrical storms or if the unit will not be used over a long period.

6. Do not open the cabinet which has potentially dangerous high voltage components inside. If the unit is damaged in this way the
warranty will be void. Moreover, there is a serious risk of electric shock.

7. Do not attempt to service or repair the unit. The manufacturer is not liable for any bodily harm or damage caused if unqualified persons
attempt service or open the back cover. Refer all service to authorized Service Centers.

5

Important Information

DVI cable (not supplied)

core (small)

core (small)

Connecto

r

band

band

Power cable (supplied)

core (large)

core (large)

NOTE:
When you connect a computer to this monitor, use an RGB cable
including the ferrite core on both ends of the cable. And regarding
DVI and power cable, attach the supplied ferrite cores. If you do not
do this, the monitor will not conform to mandatory FCC standards.
Attaching the ferrite cores: Set the ferrite cores on both ends of
the DVI cable (not supplied), and both ends of the power cable
(supplied). Close the lid tightly until the clamps click. Use the
band to fasten the ferrite core (supplied) to the DVI cable.

» To avoid damage and prolong operating life:

1. Use only with 120V 50/60Hz AC power supply. Continued
operation at line voltages greater than 120 Volts AC will shorten
the life of the unit, and might even cause a re hazard.

2. Handle the unit carefully when installing it and do not drop.

3. Set the unit away from heat, excessive dust, and direct sunlight.

4. Protect the inside of the unit from liquids and small metal
objects. In case of accident, unplug the power cord and have it
serviced by an authorized Service Center.

5. Do not hit or scratch the panel surface as this causes aws on
the surface of the screen.

6. For correct installation and mounting it is strongly recommended
to use a trained, authorized dealer.

7. As is the case with any phosphor-based display (like a CRT
monitor, for example) light output will gradually decrease over
the life of a Plasma Display Panel.

8. To avoid sulfurization it is strongly recommended not to place
the unit in a dressing room in a public bath or hot spring bath.

6

Important Information

» Plasma monitor cleaning procedure:

1. Use a soft dry cloth to clean the front panel and bezel area.
Never use solvents such as alcohol or thinner to clean these
surfaces.

2. Clean plasma ventilation areas with a vacuum cleaner with a
soft brush nozzle attachment.

3. To ensure proper ventilation, cleaning of the ventilation areas
must be carried out monthly. More frequent cleaning may be
necessary depending on the environment in which the plasma
monitor is installed.

Recommendations to avoid or minimize phosphor burn-in:
Like all phosphor-based display devices and all other gas plasma
displays, plasma monitors can be susceptible to phosphor burn
under certain circumstances. Certain operating conditions, such
as the continuous display of a static image over a prolonged
period of time, can result in phosphor burn if proper precautions
are not taken. To protect your investment in this plasma monitor,
please adhere to the following guidelines and recommendations
for minimizing the occurrence of image burn:

* Always enable and use your computer’s screen saver function
during use with a computer input source.

* Change the position of the menu display from time to time.

* Always power down the monitor when you are nished using
it.
If the plasma monitor is in long term use or continuous operation
take the following measures to reduce the likelihood of phosphor
burn:

* Lower the Brightness and Contrast levels as much as possible
without impairing image readability.

* Display an image with many colors and color gradations (i.e.
photographic or photo-realistic images).

* Create image content with minimal contrast between light and
dark areas, for example white characters on black backgrounds.
Use complementary or pastel color whenever possible.

* Avoid displaying images with few colors and distinct, sharply
dened borders between colors.

NOTE: BURN-INS ARE NOT COVERED BY THE
WARRANTY

Contact your dealer for other recommended procedures that will
best suit your particular application needs.

* Display a moving image whenever possible.

7

LIMITED WARRANTY

Congratulations on your purchase of a Vidikron video product and
welcome to the Vidikron family! With proper installation, setup
and care, you should enjoy many years of unparalleled video
performance. This is a LIMITED WARRANTY as defined in the
Magnuson-Moss Warranty Act. Please read it carefully and retain it
with your other important documents.

WHAT IS COVERED UNDER THE TERMS OF THIS
LIMITED WARRANTY:

SERVICE LABOR: Vidikron will pay for service labor by a Vidikron
Authorized Service Center when needed as a result of manufacturing
defect for a period of one (1) year from the effective date of delivery
to the end user.
PARTS: Vidikron will provide new or rebuilt replacement parts for
the parts that fail due to defects in materials or workmanship for a
period of one (1) year from the effective date of delivery to the end
user. Such replacement parts are then subsequently warranted for the
remaining portion (if any) of the original warranty period.

WHAT IS NOT COVERED UNDER THE TERMS OF THIS
LIMITED WARRANTY:

Image burn-in on plasma display panels are specifically excluded
from coverage under this Limited Warranty. Image burn-in is the
result of misuse of the product and therefore cannot be repaired
under the terms of this Limited Warranty.
TO AVOID IMAGE BURN-IN:
Please ensure that still images are left on your plasma display panel
for no more than a few minutes. Also ensure that images displayed

8

in the 4:3 aspect ratio mode (black or gray stripes, but no picture
information is present on the left and right edges of the screen) are
used as infrequently as possible. This will prevent permanent image
burns on your plasma display panel, which can be seen permanently
under certain conditions once burn-in has occurred.

The types of images to avoid include video games, still images and
computer screens with stationary tool bars and icons. (This is why
computers are equipped with screen savers – to prevent still images
from burning into the monitor’s phosphors after being displayed
continuously for an extended period of time).

Normal viewing material such as television/satellite broadcasts,
videotape or DVDs (not put into pause for extended periods of time)
will not cause damage to your display under normal conditions.
Many DVD players are also equipped with screen savers for this
reason.

This Limited Warranty only covers failure due to defects in materials
and workmanship that occur during normal use and does not cover
normal maintenance. This Limited Warranty does not cover cabinets
or any appearance items; failure resulting from accident, misuse,
abuse, neglect, mishandling, misapplication, faulty or improper
installation or setup adjustments; improper maintenance, alteration,
improper use of any input signal; damage due to lightning or power
line surges, spikes and brownouts; damage that occurs during
shipping or transit; or damage that is attributed to acts of God. In the
case of remote control units, damage resulting from leaking, old,

Limited Warranty

damaged or improper batteries is also excluded from coverage under
this Limited Warranty.

CAUTION: THIS LIMITED WARRANTY ONLY COVERS
VIDIKRON PRODUCTS PURCHASED FROM VIDIKRON
AUTHORIZED DEALERS. ALL OTHER PRODUCTS ARE
SPECIFICALLY EXCLUDED FROM COVERAGE UNDER
THIS LIMITED WARRANTY. MOREOVER, DAMAGE
RESULTING DIRECTLY OR INDIRECTLY FROM IMPROPER
INSTALLATION OR SETUP IS SPECIFICALLY EXCLUDED
FROM COVERAGE UNDER THIS LIMITED WARRANTY.

RIGHTS, LIMITS AND EXCLUSIONS:

Vidikron limits its obligations under any implied warranties under
state laws to a period not to exceed the warranty period. There are no
express warranties. Vidikron also excludes any obligation on its part
for incidental or consequential damages related to the failure of this
product to function properly. Some states do not allow limitations
on how long an implied warranty lasts, and some states do not allow
the exclusion or limitation of incidental or consequential damages.
So the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other
rights that vary from state to state.

EFFECTIVE WARRANTY DATE:

This warranty begins on the effective date of delivery to the end
user. For your convenience, keep the original bill of sale as evidence
of the purchase date.

IMPORTANT: WARRANTY REGISTRATION:

Please fill out and mail your warranty registration card. It is
imperative that Vidikron knows how to reach you promptly if we
should discover a safety problem or product update for which you
must be notified.

CONTACT A VIDIKRON AUTHORIZED SERVICE CENTER
TO OBTAIN SERVICE:

Repairs made under the terms of this Limited Warranty covering
your Vidikron video product will be performed at the location of the
product, during usual working hours, providing location of product
is within normal operating distance from a Vidikron Authorized
Service Center. In some instances it may be necessary for the
product to be returned to the Vidikron factory for repairs. If, solely
in Vidikron’s judgment, location of product to be repaired is beyond
normal operating distance of the closest Vidikron Authorized Service
Center, or the repair requires the unit be returned to the Vidikron
factory, it is the owner’s responsibility to arrange for shipment of
the product for repair. These arrangements must be made through
the selling Vidikron dealer. If this is not possible, contact Vidikron
directly to locate an authorized Vidikron representative who will
assist you in getting a return authorization. Vidikron will return
product transportation prepaid in the United States, unless no
product defect is discovered. In that instance, shipping costs will be
the responsibility of the owner.

9

Limited Warranty

ADDITIONAL INFORMATION:

To locate the name and address of the nearest VIDIKRON authorized service location, or for additional information about this Limited
Warranty, please call or write:

VIDIKRON

Attn: Customer Service Department

2900 Faber Street

Union City, CA 94587

Ph [phone]

Fax [phone]

Toll Free 1-888-4-VIDIKRON

10

50mm (2")

50

mm

(2") 50

mm

(2")

Wall

Wall

50mm (2")

50mm (2")

HOW TO ATTACH OPTIONS TO THE PLASMA MONITOR

You can attach your optional mounts or stand to the
plasma monitor in one of the following two ways:

1) While it is upright. (See drawing A)

2) As it is laid down with the screen face down (See
drawing B). Lay the protective sheet, which was
wrapped around the plasma monitor when it was
packaged, beneath the screen surface so it does not
scratch the screen face.

* DO NOT touch or hold the screen face when
carrying the unit.

• This device cannot be installed on its own. Be sure
to use a stand or original mounting unit. (wallmount
unit, stand, etc.)

• For correct installation and mounting, it is required
to use a trained, Vidikron Authorized Dealer. Failure
to follow correct mounting procedures could result
in damage to the equipment or injury to the installer.
Product warranty does not cover damage caused by
improper installation.

B

A

Use only the mounting kit or stand provided
by Vidikron. Refer to mounting kit for detailed
instructions.

Ventilation Requirements for enclosure mounting

To allow heat to disperse, leave space between surrounding
objects as shown on the diagram to the right when installing.

11

PART NAMES AND FUNCTIONS

MENU / ENTER

INPUT SELECT

DOWN UP LEFT/- RIGHT/+ /EXIT

VOLUME

4

5

6

7

1

Located on bottom
of Plasma

Located on bottom
of Plasma

3

2

» Front View

1 POWER

Turns the plasma monitor’s power on and off.

2 REMOTE SENSOR WINDOW

Receives the signals from the remote control.

3 POWER

When the power is on it will light GREEN. When the power is on
the standby mode, it will light RED.

4 INPUT SELECT / EXIT

Switches the input, in the following order. The available inputs
depend on the setting of “BNC INPUT”.

RGB: VIDEO1 VIDEO2 VIDEO3 HD/COMP/DTV

RGB/PC3 RGB/PC2 RGB/PC1

COMP: VIDEO1 VIDEO2 VIDEO3 HD1/COMP1/DTV1
RGB/PC2 RGB/PC1 HD2/COMP2/DTV2

5 LEFT/- and RIGHT/+

Enlarges or reduces the image. Functions as the CURSOR ( / )
buttons in the On-Screen Display (OSD) mode.

6 VOLUME DOWN and UP

Adjusts the volume. Functions as the CURSOR ( / ) buttons in
the On-Screen Menu mode.

12

7 MENU

Sets the On-Screen Menu mode and displays the main
menu.

» Rear View / Terminal Board

A AC IN

Connect the included power cord here.

B Connect speakers (not available from Vidikron) here.
Maintain the correct polarity.

C VIDEO 1,2,3 (BNC, RCA, S-Video)

Connect VCR’s, DVD’s or Video Cameras, etc here.
VIDEO1 can be used for INPUT or OUTPUT.

D AUDIO1, AUDIO2, AUDIO3
These are audio input terminals. The input is selectable.

Set which video image to distribute them from the audio
menu screen.

E DVD1 / HD1

Connect DVD’s, High Denition or Laser Disks, etc here.

F RGB2 / DVD2 / HD2

RGB2: Connect an analog RGB signal and the
synchronization signal.
DVD2 / HD2: Connect DVD’s, High Definition sources,
Laser Discs, etc. here. This input can be set for use with an
RGB or Component source.

Part Names and Functions

G RGB1 (mini D-Sub 15pin)

Connect an analog RGB signal from a computer, etc. here.
This input can be used for Input or Output.

H RGB3 (DVI 24pin)

Connect a digital signal (TMDS) from a source with a DVI
output.

I EXTERNAL CONTROL

This terminal is used when operating and controlling the
monitor externally by RS-232.

13

Part Names and Functions

SPEAKERS MUST
HAVE MORE THAN
7WATT RATING
IMPEDANCE 6 OH

M

RIGHT

LEFT

AC IN

SPEAKERS MUST
HAVE MORE THA

N

7WATT RATING

IMPEDANCE 6 OH

M

RIGHT

LEFT

AC IN

A B

VIDEO

(
IN/OUT

)

VIDEO

1

VIDEO

2

VIDEO

3

AUDIO

1

DVD

1

/
HD

1

R

(

MONO

)

L

Y Cb/Pb

Cr/Pr

RGB

2

/
DVD

2

/
HD

2

RGB

1

R/

VD

G/ B/

HD

(
IN/ OUT

)

DVI

(
Digital RGB

)

AUDIO

2

R

(

MONO

)

L

AUDIO

3

R

(

MONO

)

L

Cr/Pr Y Cb/Pb

RGB

3

External Control

IN OUT

REMOTE

D

C

E

F

G

H

I

J

K

Rear View / Terminal Board

14

» Remote Control

1 ON/OFF

Switches Power ON/OFF. (This does not operate when
POWER/STANDBY indicator of the main unit is off.

2 CURSOR ( / / / )

Use these buttons to select items or settings and to adjust
settings or switch the display patterns.

3 EXIT

Press this button to exit the OSD controls in the main menu.
Press this button during the display of the sub menu
to return to the previous menu.

Part Names and Functions

7 RGB 1-2-3

Press this button to select RGB/PC as the source. The
available sources depend on the setting of “BNC INPUT”.
RGB: RGB1 RGB2 RGB3

COMP: RGB1 RGB3

RGB can also be selected using the INPUT SELECT
button on the monitor.

8 ASPECT

Press this button to select between aspect ratios.

4 MENU

Press this button to access the OSD controls. Press this
button during the display of the main menu to go to the sub
menu.

5 VID 1-2-3

Press this button to select VIDEO as the source.
VID1 VID2 VID3
VIDEO can also be selected using the INPUT SELECT
button on the monitor.

6 COMP 1-2

Press this button to select between Component 1 and
Component 2 inputs.

9 MUTE

Mutes the sound.

10 VOLUME (+/-)

Adjusts the audio volume.

11 AUTO OFF

Use to select AUTO OFF TIMER settings.

15

Part Names and Functions

Remote Control (continued)

12 DISPLAY

Displays the source settings on the screen.

13 LIGHT*

Press this to illuminate the buttons.
* Not available on all models.

11

12

1

2

3

5

8

4

6

7
9

10

13

16

» Battery Installation and Replacement

Insert the 2 “AAA” batteries, making sure to
set them in with the proper polarity.

1. Press and open the cover.

2. Align the batteries according to the (+) and
(–) indication inside the case.

3. Replace the cover.

Part Names and Functions

17

Part Names and Functions

Approx.

23 ft (7m)

» Handling the remote control

• Do not drop or mishandle the remote control.

• Do not get the remote control wet. If the remote control gets wet,
wipe it dry immediately.

• Avoid heat and humidity.

• When not using the remote control for a long period, remove the
batteries.

• Do not use new and old batteries together, or use different types
together.

• Do not take apart the batteries, heat them, or throw them into a
re.

» Operating Range

* Use the remote control within a distance of about 23 ft. (7m)
from the front of the monitor’s remote control sensor and at
horizontal an vertical angles of up to approximately 30°

.

* The remote control operation may not function if the monitor’s
remote control sensor is exposed to direct sunlight or strong
articial light, or if there is an obstacle between the sensor and
the remote control.

18

INSTALLATION

VIDEO

(
IN/OUT

)

VIDEO

1

VIDEO

2

VIDEO

3

AUDIO

1

DVD

1

/ HD

1

R

(

MONO

)

L

Y Cb /Pb Cr/P

r

RGB

2

/ DVD

2

/ HD

2

RGB

1

R/

VD

G/ B /

HD

(
IN

/OUT

)

DVI

(
Digital RGB

)

AUDIO

2

R

(

MONO

)

L

AUDIO

3

R

(

MONO

)

L

Cr/Pr Y Cb/Pb

RGB

3

External Control

IN OUT

REMOTE

VCR or Laser Disc Player

VIDEO 1-3

DVD Player

IBM VGA or

Compatibles

To Mini D-Sub 15 pin connector on the plasma monitor

To video inputs on
the plasma monitor

Monitor adapter for
Macintosh

Macintosh or Compatibles

(Desktop type)

HD Set Top Box with DVI
HDCP Output, Computer,
other devices

19

Installation

» Connecting Your PC or Macintosh Computer

Connecting your PC or Macintosh computer to your plasma
monitor will enable you to display your computer’s screen image
for an impressive presentation. The plasma monitor supports the
signals described on page 106.

To connect a PC, Macintosh or compatible graphics adapter,
simply:

1. Turn off the power to your plasma monitor and computer.

2. If your PC does not support SXGA/XGA/SVGA/VGA you
will need to install an SXGA/XGA/SVGA/VGA graphics
board. Consult your computer’s owner’s manual for your SXGA/
XGA/SVGA/VGA conguration. If you need to install a new
board, see the manual that comes with your new graphics board
for installation instructions.

3. This plasma monitor provides signal compatibility up to VESA
1600 x 1200 (UXGA). However, it is not recommended to use
this resolution due to image readability on the monitor’s native
pixel resolution panel.

4. Use the signal cable to connect your PC or Macintosh computer
to the plasma monitor. For Macintosh, use the monitor adapter to
connect to your computer’s video port, if necessary.

5. Turn on the plasma monitor and the computer.

6. If the plasma monitor goes blank after a period of inactivity, it
may be caused by a screen saver installed on the computer you’ve
connected to the plasma monitor.

When using a Macintosh with the plasma monitor, the
following four display standards are supported using the
Macintosh adapter:
13” fixed mode
16” fixed mode
19” fixed mode
21” fixed mode
The 13” fixed mode is recommended for your 42” Wide VGA.

20

Installation

» Connecting Your VCR or Laser Disc Player:

Use common RCA cables (not provided) to connect your VCR
or laser disc player to your plasma monitor. To make these
connections, simply:

1. Turn off the power to your plasma monitor and VCR or laser
disc player.

2. Connect one end of your RCA cable to the video output
connector on the back of your VCR or laser disc player, connect
the other end to the Video input on your plasma monitor. Use
standard RCA audio patch cords to connect the audio from your
VCR or laser disc player to your plasma monitor (if your VCR or
laser disc player has this capability). Be careful to keep your right
and left channel connections correct for stereo sound.

3. Turn on the plasma monitor and the VCR or laser disc player.

Note: Refer to your VCR or laser disc player owner’s
manual for more information about your equipment’s
video output requirements.

» Connecting Your DVD Player:

You can connect your plasma monitor to a DVD player. To do
so, simply:

1. Turn off the power to your plasma monitor and DVD player.

2. Use a component video cable to connect your DVD player
to the Y, Cb, and Cr inputs on your plasma monitor. Or use
the DVD-player’s S-Video output. Use a standard S-Video
cable to connect to the S-Video input on the plasma monitor.

3. Turn on the plasma monitor and the DVD player.

21

Installation

5 4 3 2 1

15 14 13 12 11

10 9 8 7 6

1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 1

6

20191817 21 22 23 24

RGB 3

» Pin Assignment and Signal Levels for 15 pin RGB (analog) » Pin Conguration and Signal of the RGB 3 Connector (DVI

Connector)

The unit is equipped with a type of connector commonly used for
digital. (This cannot be used for an analog input.)

Pin No. Signal (Analog)

1 Red
2 Green or sync-on-green
3 Blue
4 No connection
5 Ground
6 Red ground
7 Green ground
8 Blue ground

9 No connection
10 Sync signal ground
11 No connection
12 Bi-directional DATA (SDA)
13 Horizontal sync or Composite sync
14 Vertical sync
15 Data clock

Pin No. Signal (Digital)

1 T.M.D.S Data 2 ­2 T.M.D.S Data 2 +
3 T.M.D.S Data 2 Shield
4 No connection
5 No connection
6 DDC Clock
7 DDC Data
8 No connection

9 T.M.D.S Data 1 ­10 T.M.D.S Data 1 +
11 T.M.D.S Data 1 Shield
12 No connection

Pin No. Signal (Digital)

13 No connection
14 +5V Power
15 Ground
16 Hot Plug Detect
17 T.M.D.S Data 0 ­18 T.M.D.S Data 0 +
19 T.M.D.S Data Shield
20 No connection
21 No connection
22 T.M.D.S Clock Shield
23 T.M.D.S Clock +
24 T.M.D.S Clock -

22

» POWER

To turn the unit ON and OFF:

1. Plug the power cord into an active AC power outlet.

2. Press the POWER ON button (on the remote control or control
panel) to turn on the unit.
The monitor’s POWER/STANDBY indicator will light up (green)
when the unit is on.

3. Press the POWER OFF button (on the remote control or control
panel) to turn off the unit.
The monitor’s POWER/STANDBY indicator turns red and the
standby mode is set (only when turning off the unit with the
remote control).

» VOLUME

To adjust the sound volume:

1. Press and hold the VOLUME (+) button (on the remote control
or the unit) to increase to the desired level.

2. Press and hold the VOLUME (-) button (on the remote control
or the unit) to decrease to the desired level.

» MUTE

To cancel the sound:

Press the MUTE button on the remote control to cancel the sound;
press again to restore.

BASIC OPERATIONS

» DISPLAY

To check the settings:

1. The screen changes each time the DISPLAY button is pressed.

2. If the button is not pressed for approximately three seconds, the
menu turns off.

23

Basic Operations

» TIMER OFF

To set the timer off:

The timer off can be set to turn the power off after 30, 60, 90 or
120 minutes

1. Press the AUTO OFF button to start the timer at 30 minutes.

2. Press the AUTO OFF button to the desired time.

3. The timer starts when the menu turns off.
30 60 90 120 0 ┐

To check the remaining time:

1. Once the off timer has been set, press the AUTO OFF button
once.

2. The remaining time is displayed, then turns off after a few
seconds.

3. When ve minutes remain the remaining time appears until it
reaches zero.

└─────────────────

TIMER OFF 30

TIMER OFF 30

To cancel the off timer:

1. Press the AUTO OFF button twice in a row.

2. The off timer is canceled.

TIMER OFF 30

NOTE:

After the power is turned off with the timer off...
A slight current is still supplied to the monitor. When you are
leaving the room or do not plan to use the system for a long period
of time, turn off the power of the monitor.

24

» Aspect Ratio Operations (Manual)

Active


Area

Active Image Area

Active Image Area

There are four aspect ratios available that can be selected for
video signal inputs.

When viewing videos or DVDs:

1. Press the ASPECT button on the remote control.

2. Within 3 seconds...
Press the ASPECT button again.
The screen size switches as follows:

LTR BOX STD (4:3) ANAMPHC INTELLIWIDE

LTR BOX mode

The image in the Letterbox mode will be zoomed in, and the top
and bottom portion ‘blanked off.’ This ratio is best suited for
LaserDisc movies or non-anamorphic DVD’s.

ASPECT RATIO CONTROLS

STD 4:3 mode

The input signal will be scaled to t in the center of the 16:9
screen.

ANAMPHC mode

The image is compressed vertically, but anamorphic software
will appear properly proportioned.
This is best suited for use with 16:9 DVD’s.

25

Aspect Ratio Controls

Active


Area

INTELLIWIDE mode

This aspect ratio is designed to ll the 16:9 screen with a 4:3
image. The center of the picture is not stretched, and it gradually
stretches on the sides reaching the most extreme stretch at the far
edges of the picture. (non-linear scaling)
In addition, we apply a very slight vertical stretch uniformly (no
graduation) which results in a very small amount of cropping of
the top and bottom of the image area.
Thus a 4:3 image is transformed into a 16:9 image with minimal
distortion.

26

» Aspect Ratio Operation with Computer Signals

Active


Area

Active Image Area

Active Image Area

Aspect Ratio Controls

Switch to the wide screen mode to expand the 4:3 image to ll the
entire screen.

1. Press the ASPECT button on the remote control.

2. Within 3 seconds...
Press the ASPECT button again.
The screen size switches as follows:

STD (4:3) ANAMPHC LTR BOX

STD 4:3 mode (4:3 or SXGA 5:4)

The picture has the same size as the normal computer image.

ANAMPHC mode

The image is expanded in the horizontal direction.

LTR BOX mode

When wide signals are input.

Information

■ Supported resolution
See page 106 for details on the display output of the
various VESA signal standards supported by the monitor.

■ When 853 (848) dot x 480 line wide VGA *signals
with a vertical frequency of 60 Hz and horizontal
frequency of 31.7 (31.0) kHz are input.

Select an appropriate setting for RGB SELECT mode
referring to the “Table of Signals Supported” on page

106.
* “IBM PC/AT” and “VGA” are registered trademarks of
IBM, Inc. of the United States.

NOTE:

Do not leave the displayed in 4:3 mode for an extended period.
This can cause a phosphor burn-in.

27

OSD (On Screen Display) Controls

PICTURE ADJUST

AUDIO SETUP

IMAGE OPTIONS

SETTING 1

SETTING 2

SETTING 3

NEXT PAGE

PLASMAVIEW 1/2

SEL. OK EXIT

MENU/ENTER

EXIT

PICTURE ADJUST

AUDIO SETUP

IMAGE OPTIONS

SETTING 1

SETTING 2

SETTING 3

NEXT PAGE

PLASMAVIEW 1/2

SEL. OK EXIT

MENU/ENTER

EXIT

LANGUAGE

VIDEO STANDARD

SIGNAL INFO.

PLASMAVIEW 2/2

PREVIOUS PG.

SEL. OK EXIT

MENU/ENTER

EXIT

CONTRAST 0

BRIGHTNESS 0

SHARPNESS 0

COLOR 0

TINT 0

IMAGE MEM. : FACTORY

VIDEO NR : OFF

NEXT PAGE

PICTURE ADJUST 1 / 2

» Menu Operations

The OSD window is displayed with respect to the screen as shown
on the diagram.

* Depending on the screen’s mode, the OSD may be displayed
differently. In the explanation, the OSD section is shown close
up.

3. Press the cursor buttons on the
remote control to highlight the menu
you wish to enter.

The following describes how to use the menus and the selected
items.

1. Press the MENU button on
the remote control to display
the MAIN MENU.

2. Press the MENU button on the remote control to select a
submenu or item.

28

4. Adjust the level or change the setting of the selected item by
using the cursor buttons ◄► on the remote control.

5. Change the adjustments or the settings that are stored in
memory. The change is stored until you change it again.

6. Repeat steps 2-5 to adjust an additional item, or press the EXIT
button on the remote control to return to the main menu.

NOTE:

The main menu disappears by pressing the EXIT button.

OSD (On Screen Display) Controls

Main Menu Sub Menu Functions Default Reset

ADJUST

CONTRAST Adjusts the contrast. Center Yes

BRIGHTNESS Adjusts the brightness. Center Yes

SHARPNESS Adjusts the sharpness Center Yes

COLOR Adjusts the color. Center Yes

TINT Adjusts the tint. Center Yes

IMAGE MEM. Sets the image memory according to the VIDEO environment and image S/W.

CONTRAST

Yes

VIDEO NR Reduces noise visible in image. OFF Yes

WHITE BAL. Adjusts the color temperature and white balance. 8500K Yes

WHITE
BALANCE
ADJUST

GAIN RED

GAIN GREEN

GAIN BLUE

RED OFFSET

GREEN OFFSET

BLUE OFFSET

RESET

Adjusts the red content (signal level). Center Yes

Adjusts the green content (signal level). Center Yes

Adjusts the blue content (signal level). Center Yes

Adjusts the red content (black level). Center Yes

Adjusts the green content (black level). Center Yes

Adjusts the blue content (black level). Center Yes

Resets the WHITE BALANCE ADJUST settings to the factory default values. OFF Yes

GAMMA CURVE Adjusts the brightness of midtone areas. 2.2 Yes

DITHER Enables high-quality dark area reproduction. AUTO Yes

COLOR CHART RED Adjusts hue and color density of red. Center Yes

GREEN Adjusts hue and color density of green. Center Yes

BLUE Adjusts hue and color density of blue. Center Yes

YELLOW Adjusts hue and color density of yellow. Center Yes

MAGENTA Adjusts hue and color density of magenta. Center Yes

CYAN Adjusts hue and color density of cyan. Center Yes

RESET Resets COLOR CHART settings to the factory default values. OFF Yes

29

OSD (On Screen Display) Controls

Main Menu Sub Menu Functions Default Reset

AUDIO SETUP BASS Sets the bass. Center Yes

TREBLE Sets the treble. Center Yes

BALANCE Sets the left/right balance. Center Yes

AUDIO INPUT 1-3 Sets the allocation of the audio connectors. *1 Yes

Main Menu Sub Menu Functions Default Reset

OPTIONS

Main Menu Sub Menu Functions Defaults Reset

SETTING 1 OSD

ASPECT RATIO Selects between the different aspect ratio modes. -- --

V SHIFT Adjusts the vertical position. Center Yes

H SHIFT Adjusts the horizontal position. Center Yes

V-SIZE Adjusts the vertical size. Min Yes

H-SIZE Adjusts the horizontal size. Min Yes

COMPUTER Turn this on to have the monitor automatically adjust “FINE PICTURE” and

“PICTURE ADJ”

FINE PICTURE Adjusts for ickering on the computer image. Min *2 Yes

PICTURE ADJUST Adjusts for striped patterns on the computer image. Center *2 Yes

DISPLAY OSD

OSD ADJ. Sets the position of the menu. 1 Yes

OSD POSITION Sets the display format as a horizontal or vertical screen. H Yes

OSD ORBITER

BNC INPUT Sets the BNC connectors. RGB Yes

D-SUB TYPE Checks the signal being transmitted to RGB1 terminal. RGB --

RGB TYPE Sets the appropriate mode for the computer image. AUTO Yes

When set to OFF, the on-screen menu is not displayed. ON Yes

Sets the OSD not to be displayed at the same position. OFF Yes

OFF * No

30

OSD (On Screen Display) Controls

Main Menu Sub Menu Functions Default Reset

RGB (VGA signals), VIDEO (Moving picture), WIDE (Wide VGA), DTV.

HD TYPE Sets the digital broadcasting (1080A, 1080B, 1080C) or the High Vision (1035I). 1080B No

INPUT SKIP Skips over signals which are not present. OFF Yes

FACTORY Resets all the settings (PICTURE ADJUST, AUDIO, IMAGE OPTIONS,

SETTING 1-3, etc.) to the factory default values.

Main Menu Sub Menu Functions Default Reset

SETTING 2 AUTO OFF Sets the monitor for use as an energy-saving display when used with a computer. OFF Yes

CINEMA MODE Sets the picture to suit the movie. ON Yes

PIXL PROTECT LUM. SETTING Limits screen brightness to reduce burn-in on the display. AUTO Yes

ORBITER Moves the picture intermittently. OFF Yes

INVERSE Displays a negative/positive inverse image or an all-white screen. OFF Yes

IMAGE SWEEP Sweeps the screen with a white vertical bar. OFF Yes

SOFTEN Softens the detail in 4 steps (1-4) OFF Yes

SIDEBAR LEV. In case of 4:3, sets the luminance of both sides. 3 Yes

S1/S2 Resizes the S-video image to best t the display. OFF Yes

Main Menu Sub Menu Functions Defaults Reset

SETTING 3 TIMER

INPUT SELECT Sets the input mode at the time the power is switched on. LAST Yes

CONTROL LOCK Disables the function of the front panel buttons. OFF Yes

IR ENABLE Disables the transmission of the remote control. ON Yes

LOOP OUT When set to ON, the received signal will be looped out. OFF Yes

PRESENT TIME

PROGRAM Sets the ON/OFF time for switching on the power and the input mode. OFF Yes

Sets the day of the week and the time. -- No

-- --

31

OSD (On Screen Display) Controls

Main Menu Sub Menu Functions Default Reset

ID NUMBER Sets ID number for the display. ALL Yes

VIDEO WALL DIVIDER Creates a 2x2 or 3x3 video wall. OFF Yes

POSITION Sets the position. -- --

DISP. MODE Selects the screen mode from between Splitting and Blanking. SPLIT Yes

AUTO ID Automatically sets the ID number of multiple displays. OFF Yes

ADJUST

P. ON DELAY When set to ON, each display turns on after a delay time. OFF Yes

LUM SET
LINK

REPTR
TIMER

Main Menu Sub Menu Functions Default Reset

LANGUAGE Sets the language of the menus (English, German, French, Italian, Spanish). English No

VIDEO
STANDARD

SIGNAL INFO. Used to check the frequency and synchronizing polarities of the active signal

*1 AUDIO INPUT 1: VIDEO 1 AUDIO INPUT 2: HD/DVD1 AUDIO INPUT 3: RGB1
*2 RGB/PC only

Adjusts the position of the image, etc. -- --

Sets a uniform brightness for each display. OFF Yes

Sets two programmable timers. OFF Yes

Sets the VIDEO format (AUTO, PAL, PAL-M, PAL-N, PAL60, SECAM, 4.43
NTSC or 3.59 NTSC).

being input.

AUTO No

-- --

32

» Picture Adjust Menu

CONTRAST 0

BRIGHTNESS 0

SHARPNESS 0

COLOR 0

TINT 0

IMAGE MEM. : FACTORY

VIDEO NR : OFF

NEXT PAGE

PICTURE ADJUST 1 / 2

CONTRAST 0

Adjusting the picture

The contrast, brightness, sharpness, color and tint can be adjusted
as desired.

Example: Adjusting the contrast

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the and buttons to select “CONTRAST”.

3. Use the and buttons to adjust the contrast.

OSD (On Screen Display) Controls

* If neither or buttons is pressed within 5 seconds, the current
setting is set and the previous screen reappears.

4. Once the adjustment is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

NOTE:

If “CAN NOT ADJUST” appears...
When trying to enter the PICTURE submenu, make sure IMAGE
MEM. is not set to FACTORY.

Information

■ Picture adjustment screen

CONTRAST ......... Changes the picture’s white level.

BRIGHTNESS ..... Changes the picture’s black level.

SHARPNESS ....... Changes the picture’s sharpness.

Adjusts picture detail of VIDEO
display.

COLOR ................ Changes the color density.

TINT .................... Changes the picture’s tint. Adjust for

natural colored skin, background, etc.

■ Adjusting the computer image

Only the contrast and brightness can be adjusted when a
computer signal is connected.

■ Restoring the factory default settings

Select “FACTORY” under the “IMAGE MEM.” settings.

33

OSD (On Screen Display) Controls

CONTRAST 0

BRIGHTNESS 0

SHARPNESS 0

COLOR 0

TINT 0

IMAGE MEM. : FACTORY

VIDEO NR : OFF

NEXT PAGE

PICTURE ADJUST 1 / 2

IMAGE MEM. : FACTORY

Setting the picture mode according to the brightness of the
room

There are four picture modes that can be used effectively according
to the environment in which you are viewing the display.

Example: Setting the “FACTORY” mode

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the and buttons to select “IMAGE MEM.”

34

3. To set to “FACTORY” ...
Use the and buttons to select “FACTORY”. The mode
switches as follows when the and buttons are pressed:

CONTRAST LW BLK1 LW BLK2 FACTORY BOOST

If neither the or button is pressed within 5 seconds, the
current selection is set and the previous screen reappears.

4. Once the adjustment is completed...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Information

■ Types of picture modes

LW BLK1, 2
Set this mode when watching video in a dark room. This mode
provides darker, ner pictures, like the screen in movie theaters. For a
darker image, select LW BLK2.

CONTRAST
Set this mode when watching video in a bright room. This mode
provides dynamic pictures with distinct differences between light and
dark sections.

BOOST
Use this setting to boost brightness.

FACTORY
Use this to reset the picture to the factory default settings.

Reducing noise in the picture

  

  

  

   

   

 

 

��������

���������

VID NR : VID NR3

Use these settings if the picture has noise due to poor reception
or when playing video tapes on which the picture quality is poor.

Example: Setting “VID NR-3”

Press the MENU button on the remote control to display the

MAIN MENU on the screen, then...

1. Use the and buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the and buttons to select “VIDEO NR”.

OSD (On Screen Display) Controls

3. Use the and buttons to select “VID NR3”.
The mode switches as follows when the and buttons are
pressed:

OFF VID NR-1 VID NR-2 VID NR-3

* If neither the or button is pressed within 5 seconds,
the current selection is set and the previous screen reappears.

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information:

■ VIDEO NR

* “NR” stands for Noise Reduction.
* This function reduces noise in the picture.

■ Types of noise reduction

There are three types of noise reduction. Each has a different
level of noise reduction. The effect becomes stronger as the
number increases (in the order VID NR1 VID NR2
VID NR3).

OFF ....... Turns the noise reduction function off.

35

WHITE BAL : 6500K

GAMMA CURVE : 2.2

DITHER : AUTO

COLOR CHART

PICTURE ADJUST 2 / 2

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

OSD (On Screen Display) Controls

Setting the White Balance

Use this procedure to set color tone produced by the plasma dis­play.
Example: Setting “6500K”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the and buttons to select “WHITE BAL”.

* If neither the or button is pressed within 5 seconds, the
current selection is set and the previous screen reappears.

4. Once the setting is completed...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Information

■ Setting the color temperature

5400K .................... Redder

6500K .................... Slightly redder

8500K .................... Standard (slightly bluer)

9300K .................... Bluer

3. Use the and buttons to select “6500K”.
The mode switches as follows when the and buttons are
pressed:

5400K 6500K 8500K 9300K

* See below to set “WHITE BALANCE ADJUST”.

36

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that
this also restores other settings to the factory defaults.

Adjusting the color to the desired level

Use this procedure to adjust the white balance for each color
temperature to achieve the desired color quality.

Example: Adjusting the “GAIN RED” of “9300K” color
temperature.

Perform the following operations.

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

Perform Steps 1-3 of WHITE BAL., then...

OSD (On Screen Display) Controls

GAIN RED 0

GAIN GREEN 0

GAIN BLUE 0

RED OFFSET 0

GREEN OFFSET 0

BLUE OFFSET 0

RESET : OFF

WHITE BALANCE ADJUST

WHITE BAL. 6500K

SEL. ADJ. EXIT

EXIT

GAIN RED 0

4. Press the MENU button. The “WHITE BAL.” screen appears.

5. Use the and buttons to select “GAIN RED”.

6. Adjust the white balance using the and buttons.

* If neither the and buttons is pressed within 5 seconds, the
current setting is set and the previous screen reappears.

7. Once the adjustment is completed...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Information

■ Adjusting the white balance

R/G/B GAIN ......... White balance adjustment for signal level

R/G/B OFFSET ......White balance adjustment for black level

RESET .................... Resets settings to the factory default

values. Use and buttons to select

“ON”, then press the MENU button.

■ Restoring the factory default settings

Select “RESET” under the WHITE BAL. menu.

Changing the Gamma Curve

This feature adjusts the brightness of the midtone areas while
keeping shadows and highlights unchanged.
Example: Setting “2.8”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the ▲ and ▼ buttons to select “GAMMA CURVE”.

3. Use the and buttons to select “2.8”. The mode switches as
follows each time the or button is pressed:

1.8 2.2 2.5 2.8

37

OSD (On Screen Display) Controls

WHITE BAL : 6500K

GAMMA CURVE : 2.8

DITHER : AUTO

COLOR CHART

PICTURE ADJUST 2 / 2

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

WHITE BAL. : 6500K

GAMMA CURVE : 2.8

DITHER : AUTO

COLOR CHART

PICTURE ADJUST 2 / 2

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the and buttons to select “DITHER”.

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information

■ GAMMA CURVE settings

The picture becomes darker as the number increases (in the
sequence of 1.8, 2.2, 2.5, 2.8).

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that
this also restores other settings to the factory defaults.

Making the Dither adjustments

This feature allows more detailed tone to be reproduced especially
in the dark area.

Example: Setting “2.2”

38

3. Use the and buttons to select “AUTO”. The mode switches
as follows each time the or button is pressed:

AUTO STILL MOTION DIFFUSED

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

OSD (On Screen Display) Controls

RED Y M 0

GREEN C Y 0

BLUE M C 0

YELLOW G R 0

MAGENTA R B 0

CYAN B G 0

RESET : OFF

COLOR CHART

SEL. ADJ. EXIT

EXIT

Information

■ DITHER settings

AUTO ....................Will automatically appraise the picture

and make adjustments.

STILL ....................Will apply the dither method suitable

for still pictures.

MOTION................Will apply the dither method suitable

for motion pictures.

DIFFUSE...............Will apply the error diffusion method.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that
this also restores other settings to the factory defaults.

Adjusting the colors

Use this procedure to adjust hue and color density for red, green,
blue, yellow, magenta and cyan. Such adjustments will not affect
the other colors. You can accentuate the green color of trees, the
blue of the sky, etc.

Example: Adjusting the color tune for blue

Perform the following operations.

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the ▲ and ▼ buttons to select “PICTURE ADJUST”,
then press the MENU button. The “PICTURE ADJUST” screen
appears.

2. Use the ▲ and ▼ buttons to select “COLOR CHART”, then
press the MENU button. The “COLOR CHART” screen appears.

3. Use the ▲ and ▼ buttons to select “BLUE”.

4. Adjust using the ◄ and ► buttons.

* If neither the ◄ or ► button is pressed within 5 seconds, the
current selection is set and the previous screen reappears.

To continue making other adjustments...

Repeat from step 3.

5. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

39

OSD (On Screen Display) Controls

BASS 0

TREBLE 0

BALANCE 0

AUDIO INPUT1 : VIDEO 2

AUDIO INPUT2 : HD 1

AUDIO INPUT3 : RGB 1

AUDIO SETUP

SEL. ADJ. EXIT

EXIT

Information

■ COLOR CHART settings

RED ....................... Makes red’s adjustment

GREEN ................. Makes green’s adjustment

BLUE .................... Makes blue’s adjustment

YELLOW .............. Makes yellow’s adjustment

MAGENTA ........... Makes magenta’s adjustment

CYAN .................... Makes cyan’s adjustment

RESET ................... Resets settings to the factory default values. Use

and buttons to select “ON”, then press the MENU button.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that this also
restores other settings to the factory defaults.

» Audio Setup Menu

Adjusting the treble, bass and left/right balance and audio
input select

The treble, bass and left/right balance can be adjusted to suit your
tastes.

Example: Adjusting the bass

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

40

1. Use the and buttons to select “AUDIO SETUP”, then press
the MENU button. The “AUDIO SETUP” screen appears.

2. To adjust the bass... Use the and buttons to select
“BASS”.

3. Adjust the bass using the and buttons.

To continue adjusting the audio ...

Repeat from step 2.

Information

■ Audio setup menu

BASS .................... Controls the level of low frequency sound.

TREBLE ............... Controls the level of high frequency sound.

BALANCE ........... Controls the balance of the left and right

channels.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

OSD (On Screen Display) Controls

BASS 0

TREBLE 0

BALANCE 0

AUDIO INPUT1 : VIDEO 2

AUDIO INPUT2 : HD 1

AUDIO INPUT3 : RGB 1

AUDIO SETUP

SEL. ADJ. EXIT

EXIT

Note:

If “CAN NOT ADJUST” appears...
Set “AUDIO INPUT” on the AUDIO SETUP menu correctly.

4. Once the adjustment is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once again.

Setting the allocation of the audio connectors

Setting the AUDIO 1, 2, and 3 connectors to the desired input.
Example: Setting “AUDIO INPUT1” to “VIDEO 2”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “AUDIO SETUP”, then press
the MENU button. The “AUDIO SETUP” screen appears.

2. Use the and buttons to select “AUDIO INPUT1”.

3. To set the AUDIO INPUT1 to “VIDEO2”...

Use the and buttons to select “VIDEO2”.
The mode switches as follows each time the and buttons is

pressed:
The available sources depend on the setting of “BNC INPUT”.
RGB: → VIDEO1↔ VIDEO2 ↔ VIDEO3 ↔ HD1 ←

→ RGB3 ↔ RGB2 ↔ RGB1 ←

COMP: → VIDEO1↔ VIDEO2 ↔ VIDEO3 ↔ HD/DVD1 ←
→ RGB3 ↔ RGB1 ↔ HD/DVD2 ←

4. Once the adjustment is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information

■ AUDIO INPUT

A single audio input cannot be selected as the audio
channel for more than one input terminal.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the
factory defaults.

41

OSD (On Screen Display) Controls

ASPECT RATIO : I-WIDE

V SHIFT 0

H SHIFT 0

V - SIZE 0

H - SIZE 0

IMAGE OPTIONS

SEL. ADJ. EXIT

EXIT

V SHIFT 0

ASPECT RATIO : I-WIDE

V SHIFT 0

H SHIFT 0

V - SIZE 0

H - SIZE 0

COMPUTER : OFF

FINE PICTURE 0

PICTURE ADJ. 0

IMAGE OPTIONS

SEL. ADJ. EXIT

EXIT

» Image Options Settings Menu

The position of the image can be adjusted and ickering of the
image can be corrected.

Example: Adjusting the vertical position in the normal mode

Press the MENU button on the remote control to display the

MAIN MENU on the screen, then...

1. Use the and buttons to select “IMAGE OPTIONS”,
then press the MENU button. The “IMAGE OPTIONS” screen
appears.
Default settings (when RGB/PC is selected).

* The settings on the IMAGE ADJUST menu are not preset at the
factory.

42

To select a mode ...

Use the and buttons to select a mode. The mode switches as
follows when the and buttons are pressed:

STD 4:3 ↔ ANAMPHC ↔ I-WIDE ↔ LTR BOX

* The mode can also be switched by pressing the “ASPECT”
button on the remote control.

2. To adjust the vertical position ...
Use the and buttons to select “V SHIFT”.

3. Adjust using the and buttons.

* If neither the or button is pressed within 5 seconds, the
current setting is set and the previous screen reappears.

To continue making other computer image adjustments...

Repeat from step 2.

4. Once all adjustments are completed...

ASPECT RATIO : I-WIDE

V SHIFT 0

H SHIFT 0

V - SIZE 0

H - SIZE 0

COMPUTER : OFF

FINE PICTURE 0

PICTURE ADJ. 0

IMAGE OPTIONS

SEL. ADJ. EXIT

EXIT

Press the EXIT button to return to the main menu, To delete the
main menu, press the EXIT button once more.

Information

■ When “COMPUTER” is off

OSD (On Screen Display) Controls

* If FINE PICTURE will not adjust, set “Computer” to OFF and adjust
manually.

■ Adjusting the position of the image

V SHIFT....................Adjusts the vertical position of the image.

H SHIFT....................Adjusts the horizontal position of the image.

V-SIZE ......................Adjusts the vertical size of the image.

(Except for I-WIDE mode)

H-SIZE.......................Adjusts the horizontal size of the image.

(Except for I-WIDE mode)

FINE PICTURE* .... Adjusts for ickering.

PICTURE ADJ.* ..... Adjusts for striped patterns on the image.

When Auto Picture is off, the Fine Picture and the Picture ADJ. items
area displayed so that you can adjust them.

■ Adjusting the COMPUTER

ON .............. The picture ADJ., Fine Picture and Position adjustments

are made automatically. Not available for digital ZOOM.

OFF ............ The Picture ADJ., Fine Picture and Position adjustments

are made manually.

*The Picture ADJ. and Fine Picture features are available only when
the “Computer” is off.

* The COMPUTER, FINE PICTURE and PICTURE ADJ. are
available only for RGB signals. But, these features are not available
for moving pictures on VIDEO, COMP or RGB.

■ Restoring the factory defaults settings

Select “FACTORY” under the SETTING 1 menu. Note that this also
restores other settings to the factory defaults for Auto Picture.

43

OSD (On Screen Display) Controls

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. OK EXIT

MENU/ENTER

EXIT

DISPLAY OSD : OFF

OSD ADJ. : 1

OSD ANGLE : H

OSD ORBITER : OFF

OSD

SEL. ADJ. EXIT

EXIT

» SETTING 1 Settings Menu

Setting the on-screen menu

This sets the position of the menu, the display format (horizontal
or vertical) etc.

Example: Turning the DISPLAY OSD off

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 1”, then press the
MENU button. The “SETTING 1” menu appears.

2. Use the and buttons to select “OSD”, then press the MENU
button. The “OSD” menu appears.

3. Use the and buttons to select “DISPLAY OSD”.

4. To set the DISPLAY OSD to “OFF”...
Use the and buttons to select “OFF”. The mode switches as
follows each time the or button is pressed:
ON ↔ OFF

44

5. Once the setting is completed...
Press the EXIT button to return to the SETTING 1 menu.
To return to the main menu, press the EXIT button once more.

Information

■ DISPLAY OSD settings

ON.......... The on-screen menu appears.

OFF ........ The on-screen menu does not appear.

If you press the DISPLAY button on the remote control for more than
3 seconds the main menu will appear and can be set (although it is
not ON).

■ OSD ADJUST settings

Adjusts the position of the menu when it appears on the screen.
The position can be set between 1 to 6.

1 2 3
4 5 6

■ OSD ANGLE settings

Sets the display format (landscape “H” or portrait “V”).

■ OSD ORBITER settings

AUTO OFF : OFFf

CINEMA MODE : ON

PIXL PROTECT : OFF

GRAY LEVEL : 3

S1 / S2 : OFF

DVI TYPE

SETTING 2 2 / 3

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

NEXT PAGE

ON.......... The position of the menu will be shifted

by eight dots each time OSD is displayed.

OFF ........ OSD will be displayed at the same position.

■ Restoring the factory defaults settings

Select “FACTORY” under the SETTING 1 menu. Note that this
also restores other settings to the factory defaults for Auto Picture.

Setting the BNC connectors

Select whether to set the input of the 5 BNC connectors to RGB
and Component.
Example: Set the BNC INPUT mode to “COMP”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 1”, then press the
MENU button. The “SETTING 1” menu appears.

2. Use the and buttons to select “BNC INPUT”.

3. To set the BNC INPUT mode to “COMP”...
Use the and buttons to select “COMP”. The mode switches as
follows each time the or button is pressed:
RGB ↔ COMP

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

OSD (On Screen Display) Controls

Information

■ BNC INPUT settings

RGB ......... Use the 5BNC terminals for RGB input.

COMP ...... Use the 3BNC terminals for Component input.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

45

OSD (On Screen Display) Controls

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

Checking the signal being transmitted to RGB1 terminal

Use this to conrm the signal being transmitted to the RGB1
terminal.
It is set to RGB and can not be adjusted.

Setting a computer image to the correct RGB select screen

With the computer image, select the RGB Select mode for a
moving image such as (video) mode, wide mode or digital
broadcast.

Example: Setting the “RGB TYPE” mode to “AUTO”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 1”, then press the
MENU button. The “SETTING 1” menu appears.

2. Use the and buttons to select “RGB TYPE”.

46

3. To set the RGB select mode to “AUTO”...
Use the and buttons to select “AUTO”. The mode switches as
follows each time the or button is pressed:

AUTO STILL MOTION RESIZE1 RESIZE2 DTV

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information

■ RGB TYPE modes

One of these 6 modes must be selected in order to display the
following signals correctly.

AUTO: Select the suitable mode for the specications of input
signals as listed in the table “Computer input signals
supported by this system” on page 106.
STILL: To display VESA standard signals. (Use this mode for
a still image from a computer.)

continued on next page ...

OSD (On Screen Display) Controls

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

MOTION: The video signal (from a scan converter) will be
converted to RGB signals to make the picture
more easily viewable. (Use this mode for a motion
image from a computer.)

RESIZE1: When an 852 dot 480 line signal with a horizontal
frequency of 31.7kHz is input, the image may be
compressed horizontally. To prevent this, set RGB
TYPE to RESIZE1.

RESIZE2: When an 848 dot 480 line signal with a horizontal
frequency of 31.0 kHz is input, the image may be
compressed horizontally. To prevent this, set RGB
TYPE to RESIZE2.

DTV: Set this mode when watching digital broadcasting
(480P).

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

Setting high denition images to the suitable screen size

Use this procedure to set whether the number of vertical lines of
the input high denition image is 1035 or 1080.

Example Setting the “1080B” mode to “1035I”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 1”, then press the
MENU button. The “SETTING 1” menu appears.

2. Use the and buttons to select “HD TYPE”.

3. To set the HD TYPE mode to “1080B”...
Use the and buttons to select “1080B”. The mode switches as
follows each time the or button is pressed:
1080B 1035I 1080A

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

47

OSD (On Screen Display) Controls

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

Information

■ HD TYPE modes

These 3 modes are not displayed with correct image signals
automatically.

1080B ......... Standard digital broadcasts

1035I ........... Japanese “High Vision” signal format

1080A ......... Special Digital broadcasts (for example: DTC100)

Setting the Input Skip

When this is ON, signals which are not present will be skipped
over and only pictures whose signals are being transmitted will
be displayed. This setting is valid only for the INPUT SELECT
button on the unit.

Example: Set to “OFF”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 1”, then press the
MENU button. The “SETTING 1” menu appears.

2. Use the and buttons to select “INPUT SKIP”.

3. To set the INPUT SKIP mode to “OFF”...
Use the and buttons to select “OFF”. The mode switches as
follows each time the or button is pressed:

48

OFF ON

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information

■ INPUT SKIP settings

OFF ........... Regardless of the presence of the signal, scan and

display all signals.

ON.............. If no input signal is present, skip that signal.

* “SETTING NOW” will appear during the input search.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

Resetting to the default values

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

OSD

BNC INPUT : COMP

D-SUB TYPE : RGB

RGB TYPE : AUTO

HD TYPE : 1080B

INPUT SKIP : OFF

FACTORY : OFF

NEXT PAGE

SETTING 1

SEL. ADJ. EXIT

EXIT

SETTING NOW

FACTORY

Use these operations to restore all the settings (PICTURE
ADJUST, AUDIO, IMAGE OPTIONS, SETTING 1~3, etc) to
the factory default values.

1. On the MAIN MENU, select “SETTING 1”, then press the
MENU button.
The “SETTING 1” menu appears.

2. Use the and buttons to select “FACTORY”, then press the

3. Use the and buttons to select “ON”, then press the MENU
button.

OSD (On Screen Display) Controls

When the “SETTING NOW” screen disappears, then all the
settings are restored to the default values.

4. Once the setting is completed ...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

49

OSD (On Screen Display) Controls

AUTO OFF : OFFf

CINEMA MODE : ON

PIXL PROTECT : OFF

GRAY LEVEL : 3

S1 / S2 : OFF

DVI TYPE

SETTING 2 2 / 3

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

NEXT PAGE

» SETTING 2 Menu

Setting the Auto Off for computer images

This energy-saving (Auto Off) function automatically reduces the
monitor’s power consumption if no operation is performed for a
certain amount of time.

Example: Turning the Auto Off function on

Perform the following operations.
Press the MENU button on the remote control to
display the MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 2”, then press the
MENU button. The “SETTING 2” menu appears.

2. Use the and buttons to select “AUTO OFF”.

3. To turn the Auto Off function on ...
Use the and buttons to select “ON”. The mode switches as
follows each time the or button is pressed:

ON OFF

50

4. Once the setting is completed...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once more.

Information

■ AUTO OFF function

* The auto off function automatically reduces the monitor’s power
consumption if the computer’s keyboard or mouse is not operated for
a certain amount of time. This function can be used when using the
monitor with a computer.
* If the computer’s power is not turned on or if the computer and
selector tuner are not properly connected, the system is set to the off
state.
* For instructions on using the computer’s Auto Off function, refer to
the computer’s operating instructions.

■ AUTO OFF settings

ON ........ In this mode the Auto Off function is turned on. OFF ....... In

this mode the Auto Off function is turned off.

■ AUTO OFF function and POWER / STANDBY indicator

The POWER/STANDBY indicator indicates the status of the Auto Off
function. See page 51 for indicator status and description.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

OSD (On Screen Display) Controls

AUTO OFF : OFF

CINEMA MODE : OFF

PIXL PROTECT : OFF

GRAY LEVEL : 3

S1 / S2 : OFF

DVI TYPE

SETTING 2 2 / 3

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

NEXT PAGE

POWER / STANDBY indicator

AUTO
OFF
mode

On Green Not

Off Red Activated. Horizontal and/or

POWER /
STANDBY
indicator

AUTO OFF
operating
status

activated.

Description Turning the picture

Horizontal and
vertical synchronizing
signals are present
from the computer.

vertical synchronizing
signals are not sent
from the computer.

back on

Picture already on.

Operate the keyboard
or mouse. The
picture reappears.

Setting the picture to suit the movie

The lm image is automatically discriminated and projected in
an image mode suited to the picture. [NTSC, PAL, PAL60, 480I
(60Hz), 525I (60Hz), 576I (50Hz), 625I (50Hz), 1035I (60Hz),
1080I (60Hz) only]

Example: Setting the “CINEMA MODE” to “OFF”

Perform the following operations.

Press the MENU button on the remote control to
display the MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 2”, then press the
MENU button. The “SETTING 2” menu appears.

2. Use the and buttons to select “CINEMA MODE”.

3. To set the CINEMA MODE to “OFF”...
Use the and buttons to select “OFF”. The mode switches as
follows each time the or button is pressed:
ON OFF

Information

■ CINEMA MODE

ON ......... Automatic discrimination of the image and projection

in cinema mode.

OFF ....... Cinema mode does not function.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

4. Once the setting is completed ...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

51

OSD (On Screen Display) Controls

LUM. SETTING : AUTO

ORBITER : OFF

INVERSE : OFF

IMAGE SWEEP : OFF

SOFTEN : OFF

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

Dynamic Pixel Protection (PIXL PROTECT)

Reducing burn-in of the screen

The brightness of the screen, the position of the picture, positive/
negative mode and image sweep are adjusted to reduce burn-in of
the screen.

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 2”, then press the
MENU button. The “SETTING 2” menu appears.

2. Use the and buttons to select “PIXL PROTECT”, then
press the MENU button. The “PIXL PROTECT” screen appears.

52

3. Set the PIXL PROTECT mode using and buttons.
See page 52 to set LUM. SETTING
See page 53 to set ORBITER.
See page 54 to set INVERSE.
See page 56 to set IMAGE SWEEP.

Information

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

4. Once the setting is completed...
Press the EXIT button to return to the SETTING 2 screen.
To return to the main menu, press the EXIT button once more.

LUM. SETTING (Luminance Setting)

Use this to activate the brightness limiter.
Example: Setting “LUM. SETTING” to “SET. 1”

Perform Steps 1-2 of PIXL PROTECT, then...

3. Use the and buttons to select “LUM SETTING” (relates
to above)

4. Use the and buttons to select “SET. 1”. The mode switches
as follows each time the or button is pressed:
AUTO SET. 1 SET. 2 SET. 3

Information

LUM. SETTING : SET. 1

ORBITER : OFF

INVERSE : OFF

IMAGE SWEEP : OFF

SOFTEN : OFF

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

LUM. SETTING : AUTO

ORBITER : AUTO1

INVERSE : OFF

IMAGE SWEEP : OFF

SOFTEN : OFF

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

■ LUM. SETTING

AUTO .................... The brightness of the screen is adjusted

automatically to suit the picture quality.

SET. 1, 2, 3 .... Sets maximum brightness. The brightness

level decreases in the order of SET. 1, 2, 3.
SET. 3 provides minimum brightness.

OSD (On Screen Display) Controls

4. Use the and buttons to select “AUTO1”. The mode switches
as follows each time the or button is pressed:
OFF AUTO1 AUTO2 MANUAL

Information

■ ORBITER settings

OFF ................ Orbiter mode does not function.

ORBITER

Use this to set the picture shift.
Example: Setting ”ORBITER” to “AUTO1”

Perform Steps 1-2 of PIXL PROTECT, then...

3. Use the and buttons to select “ORBITER”
(relates to above).

AUTO1............ The picture moves around the screen

intermittently, making the picture smaller.

AUTO2 ........... The picture moves around the screen

intermittently, making the picture bigger.

MANUAL ....... Use can adjust the orbiter function

(H-Dot, V-Line and Time) manually.
See the following explanation.

53

OSD (On Screen Display) Controls

H-DOT : 2 DOT

V-

LINE : 4 LINE

TIME : 3 M

ORBITER

SEL. ADJ. EXIT

EXIT

LUM. SETTING : AUTO

ORBITER : OFF

INVERSE : WHITE

IMAGE SWEEP : OFF

SOFTEN : OFF

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

Adjust the ORBITER function manually.

Set the amount of shift and the time between movement.

Example: Setting so that the picture moves 2 dots horizontally
and 3 lines vertically every 3 minutes.

Perform Steps 1-3 of ORBITER, then...

4. Use the and buttons to select “MANUAL”, then press
the MENU button. The “ORBITER” screen appears.

5. Adjust the items using the and buttons. The mode
switches as follows each time the or button is pressed:

• H-DOT

1 DOT 2 DOT ..... 19 DOT 20 DOT

• V-LINE

1 LINE 2 LINE ..... 19 LINE 20 LINE

• TIME

1 M 2 M 3 M 4 M 5 M

54

Information

■ ORBITER FUNCTION settings

H-DOT .......... Moves from 1 to 20 dots in the

horizontal direction.

V-LINE.......... Moves from 1 to 20 dots in the

vertical direction.

TIME ............. Interval of 1~5 minutes.

INVERSE

Use this to set the inverse mode or to display a white screen.
Example: Setting “INVERSE” to “WHITE”

Perform Steps 1-2 of PIXL PROTECT, then...

3. Use the and buttons to select “INVERSE”.

4. Use the and buttons to select “WHITE”. The mode
switches as follows each time the or button is pressed:

OFF ON WHITE

OSD (On Screen Display) Controls

ACTIVE : 01H30M

STANDBY : 02H00M

INVERSE/WHITE

SEL. ADJ. EXIT

EXIT

Setting the time for INVERSE/WHITE

Set a time duration.
Example: Setting to that the INVERSE mode starts in 2 hours
and proceeds for one hour and a half.

Perform Steps 1-3 of INVERSE, then...

4. Use the and buttons to select “ON”, then press the MENU
button. The “INVERSE/WHITE” screen appears.

5. Adjust the time using the and buttons. The mode
switches as follows each time the or button is pressed:

• ACTIVE

ON 00H03M 00H06M ...... 12H42M 12H45M

• STANDBY

00H03M 00H06M 00H09M .... 12H42M 12H45M

6. Once the setting is completed...
Press the EXIT button to return to the PIXL PROTECT screen.

Information

■ Setting the time

ACTIVE ............. Set the time duration for “INVERSE/

WHITE”. When the ACTIVE is set to “ON”
the mode will stay on.

STANDBY ......... Set the standby time until the “INVERSE/

WHITE” mode starts.

* The “STANDBY” can not be set when the “ACTIVE” is ON.
* The “ACTIVE” and “STANDBY” can be set for up to 12
hours and 45 minutes in units of 3 minutes.
* When ending an ACTIVE function, the monitor will be in
STAND BY.

[Example]
ACTIVE: 01H30M
STANDBY: 02H00M
|<---------- 2 H ---------->|<----- 1.5 H ----->|<---------­ INVERSE/WHITE Start STAND BY

■ To select “ON” for the “ACTIVE”...

Set the hours of the active time to 0H and the minutes to 0M.
“ON” will be displayed.

55

OSD (On Screen Display) Controls

LUM. SETTING : AUTO

ORBITER : OFF

INVERSE : OFF

IMAGE SWEEP : ON

SOFTEN : OFF

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

ACTIVE : 01H30M

STANDBY : 02H00M

SPEED : 3

IMAGE SWEEP

SEL. ADJ. EXIT

EXIT

IMAGE SWEEP

When this is set to ON, a white vertical bar moves repeatedly from
the left and of the screen to the right end at a constant speed.

Example: Setting “IMAGE SWEEP” to “ON”

Perform Steps 1-2 of PIXL PROTECT, then...

3. Use the and buttons to select “IMAGE SWEEP”.

4. Use the and buttons to select “ON”. The mode switches
as follows each time the or button is pressed:
OFF ON

Information

■ IMAGE SWEEP

ON ........ The white vertical bar appears. You can set the time by

pressing the MENU button while “ON” is set.

OFF........ Image sweep mode does not funtion.

56

Setting the time for IMAGE SWEEP

Set a time duration and the speed.
Example: Setting to that the IMAGE SWEEP mode starts
in 30 minutes and proceeds for one hour and a half.

Perform Steps 1-3 of IMAGE SWEEP, then...

4. Use the and buttons to select “ON”, then press the
MENU button. The “IMAGE SWEEP” screen appears.

5. Adjust the time using the and buttons. The mode
switches as follows each time the or button is pressed:

• ACTIVE

ON 00H03M 00H06M ...... 12H42M 12H45M

• STANDBY

00H03M 00H06M 00H09M ...... 12H42M 12H45M

• SPEED

1 2 3 4 5

Information

LUM. SETTING : AUTO

ORBITER : OFF

INVERSE : OFF

IMAGE SWEEP : ON

SOFTEN : 2

PIXL PROTECT

SEL. ADJ. EXIT

EXIT

■ Setting the time

ACTIVE ........ Set the time duration for “IMAGE SWEEP”.

When the ACTIVE is set to “ON” the mode will
stay on.

STANDBY .... Set the standby time until the “IMAGE SWEEP”

mode starts.

SPEED ......... Set the moving speed for the “IMAGE SWEEP”.

The speed decreases as the number increases.

* The “STANDBY” can not be set when the “ACTIVE” is ON.
* The “ACTIVE” and “STANDBY” can be set for up to 12
hours and 45 minutes in units of 3 minutes.

6. Once the setting is completed...
Press the EXIT button to return to the IMAGE SWEEP screen.

SOFTEN

Reduces edges and softens the image.
Example: Setting “SOFTEN” to “2”

OSD (On Screen Display) Controls

Information

■ SOFTEN settings

OFF ........ Turns the SOFTEN function off.

1,2,3,4 .....Activates the SOFTEN setting. The higher numbers

create a softer image.
“SHARPNESS” can not be adjusted on the “PICTURE
ADJUST” menu.

Setting the Sidebar Lev. for the sides of the screen

Use this procedure to set the Sidebar Lev. for the parts on the
screen on which nothing is displayed when the screen is set to
4:3 size.

3. Use the and buttons to select “SOFTEN”.

4. Use the and button to select “2”. The mode switches as
follows each time the or button is pressed:

1 2 3 4 5

Example: Adjusting the “SIDEBAR LEV.”
Perform the following operations.

1. On the MAIN MENU, select “SETTING 2”, then press the
MENU button. The “SETTING 2” menu appears.

57

OSD (On Screen Display) Controls

AUTO OFF : OFF

CINEMA MODE : ON

PIXL PROTECT : OFF

SIDEBAR LEV. : 5

S1 / S2 : OFF

DVI TYPE

SETTING 2 2 / 3

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

NEXT PAGE

PWR. MGT. : OFF

CINEMA MODE : ON

PIXL PROTECT : OFF

SIDE BARS : 5

S1 / S2 : AUTO

AUTO SIZE : ON

DVI TYPE

SETTING 2 2 / 3

SEL. ADJ. EXIT

EXIT

PREVIOUS PG.

NEXT PAGE

2. Use the and buttons to select “SIDEBAR LEV.”.

3. To adjust the “SIDEBAR LEV.” ...
Use the and buttons to adjust the SIDEBAR LEV..

Information

■ SIDEBAR LEV. settings

This adjusts the brightness of the black (the Sidebar Lev.) for the
sides of the screen. The standard is 0 (black). The level can be
adjusted from 0 to 15. The factory setting is 3 (dark gray).

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

58

Setting the screen size for S1/S2 video input

If the S-Video signal contains screen size information, the image
will be automatically adjusted to fit the screen when this S1/S2 is
set to AUTO.
This feature is available only when an S-Video signal is input via
the VIDEO3 terminal.
Example: Setting the “S1/S2” to “AUTO”

Perform the following operations.

1. On the MAIN MENU, select “SETTING 2”, then press MENU
button. The “SETTING 2” screen appears.

2. Use the and buttons to select “S1/S2”.

3. Use the and buttons to select “AUTO”. The mode
switches as follows each time the and buttons is pressed:
OFF AUTO

OSD (On Screen Display) Controls

PLUG/PLAY : STB/DVD

BLACK LEVEL : HIGH

DVI TYPE

SEL. ADJ. EXIT

EXIT

Information

■ S1/S2 Settings

AUTO........ Adjusts the screen size automatically according to

the S1/S2 video signal.

OFF............ Turns the S1/S2 funtion off.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that this
also restores other settings to the factory defaults.

4. Once the setting is completed...
Press the EXIT button to return to the SETTING 3 screen.
To return to the main menu, press the EXIT button once more.

Setting the signal and black level for DVI signal

Example: Setting the “PLUG/PLAY” mode on “STB/DVD”

Perform the following operations.

1. On the MAIN MENU, select “SETTING 2” , then press the
MENU button. The “SETTING 2” screen appears.

2. Use the and buttons to select “DVI TYPE”, then press the
MENU button. The “DVI TYPE” screen apprears.

3.To set PLUG/PLAY mode to “STB/DVD” ...
Use the and buttons to select “STB/DVD”.
The mode switches as follows each time the and buttons is
pressed:
PLUG/PLAY: PC STB/DVD

BLACK LEVEL: LOW HIGH

Information

■ PLUG/PLAY Settings

PC............... When connected to the PC signal.

BLACK LEVEL is set to “HIGH” automatically.

STB/DVD.... When connected to a satellite receiver, DVD, etc.

BLACK LEVEL is set to “HIGH” automatically.

■ BLACK LEVEL settings

LOW ........ When connected to the PC signal.

HIGH ....... When connected to the satellite receiver, DVD, etc.

Change “HIGH” into “OFF” if the black level
apprears gray.

59

OSD (On Screen Display) Controls

PRESENT TIME

PROGRAM : OFF

TIMER

SEL. OK EXIT

MENU/ENTER

EXIT

PRESENT TIME

SEL. ADJ. EXIT

EXIT

RETURN

DAYLIGHT

SAVING TIME : OFF

WEDNESDAY
13 : 00 : 00

» SETTING 3 Menu

Using the timer

This function sets the monitor to turn ON/OFF automatically at
a set time.

Perform the following operations.

1. On the MAIN MENU, select “SETTING 3”, then press MENU
button. The “SETTING 2” screen appears.

2. Use the and buttons to select “TIMER”, then press the
MENU button.
The “TIMER” screen apprears.

3. Set the TIMER using the and buttons.

60

See page 60 to set PRESENT TIME.
See page 62 to set PROGRAM.

Information

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

PRESET TIME

This sets the day of the week and present time.

Example: Setting “WEDNESDAY”, “22:05”

Perform Steps 1-2 of TIMER, then...

3. Use the and buttons to select “PRESET TIME”, then
press the MENU button. The “PRESET TIME” screen appears.

4. Use the and buttons to select the item, then adjust using
the and buttons.

OSD (On Screen Display) Controls

PRESENT TIME

SEL. ADJ. EXIT

EXIT

RETURN

DAYLIGHT

SAVING TIME : OFF

WEDNESDAY

22 : 05 : 00

PRESENT TIME

RETURN

DAYLIGHT

SAVING TIME : OFF

WEDNESDAY
22 : 05 : 00

SET

SEL. OK EXIT

MENU/ENTER

EXIT

The mode switches as follows each time the or buttons is
pressed:

• DAYLIGHT SAVING TIME

ON OFF

• DAY

SUNDAY MONDAY ...... FRIDAY SATURDAY

• HOUR/MINUTES

00:00 00:01 00:02 ..... 23:58 23:59

5. Once the setting is completed...
Use the and buttons to select “SET”, then press the MENU
button. The adjustments are stored and return to the TIMER
menu.

Information

■ PRESET TIME settings

DAYLIGHT SAVING TIME ....

Use to set DAYLIGHT SAVING TIME.
ON: The present time + 1 hour.
OFF: Cancelled

DAY ................ Set the day of the week (e.g. Sunday).

HOUR .............. Set the hour in the 24-hour format (range 00 to 23).

MINUTES ........ Set the minutes (range 00 to 59)

* If you press the EXIT button instead of the MENU button in step
5, the settings can not be mode.

61

OSD (On Screen Display) Controls

PRESENT TIME

PROGRAM : OFF

TIMER

SEL. ADJ. EXIT

EXIT

ZOOM

PROGRAM TIMER

SEL. ADJ. EXIT

EXIT

DATE ON OFF INPUT FUNCTION

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

MON 08:30 10:30 RGB2 INVERSE

PROGRAM TIMER

This sets the day and time at which the power will be switched
ON/OFF as well as the input mode.

Example: Setting so that the power will be switched on at 8:30
A.M., Monday, displaying RGB2 source, and switched off at
10:30 A.M.

Perform Steps 1-2 of TIMER, then...

3. Use the and buttons to select “PROGRAM”.

4. Use the and buttons to select “ON”, then press the MENU
button. The “PROGRAM TIMER” screen appears.

5. Adjust using the and buttons and ZOOM +/- button.

62

The mode switches as follows each time the ZOOM +/- button is
pressed:

• DATE

-- SUN MON .... SAT * SUN *MON .... *SAT

• ON/OFF Hour

00 01 02 .... 21 22 23

• MINUTE

00 01 02 .... 57 58 59

• INPUT

-- LAST VIDEO1 VIDEO2 VIDEO3 HD/DVD1
RGB3 RGB2 RGB1 HD/DVD2

• FUNCTION

-- ORBITER INVERSE WHITE IMAGE SWEEP

6. Once the setting is completed...
Press the EXIT button. The programs are stored, and return to the
TIMER screen.

OSD (On Screen Display) Controls

ZOOM

PROGRAM TIMER

SEL. ADJ. EXIT

EXIT

DATE ON OFF INPUT FUNCTION

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

--- - -:- - - -:- - --- -----

MON 08:30 10:30 RGB2 INVERSE

Information

■ PROGRAM TIMER settings

DATE ......................... Set the day of the week (e.g. Sunday).

ON (hour, minutes) .... Set the time at which the power will be turned

on in the 24-hour format.

OFF (hour, minutes)... Set the time at which the power will be turned
off in the 24-hour format.

INPUT ....................... Set the input mode that will be displayed

when the timer is on.

FUNCTION ........ Set the PIXL PROTECT function.

■ To reset the program

Align the cursor with the DATE eld that you wish to reset, then press
the CLEAR button.

■ To reset the data

Align the cursor with the eld (ON/OFF/INPUT/FUNCTION) that
you wish to reset, then press the CLEAR button.

■ Special characters in the PROGRAM TIMER screen

• An asterisk “*” in the DATE eld

An asterisk “*” means “every”. For example, “*FRI” means every
Friday and “*” means everyday.

• A hyphen “-” in the ON eld or OFF eld

If any hyphen remains in the ON eld of OFF eld, the FUNCTION
can not be set.

• A hyphen “-” in the FUNCTION eld

A hyphen “-” means last mode (the mode that was last selected at the
time the power was switched off).

Setting the DEFAULT INPUT

This function sets the input mode at the time the power is
switched on.

Example: Setting “VIDEO2”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then ...

1. Use the and buttons to select “SETTING 3”, then press
the MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “DEFAULT INPUT”.

3. To set the DEFAULT INPUT to “VIDEO2”...

Use the and buttons to select “VIDEO2”.

63

OSD (On Screen Display) Controls

TIMER

INPUT SELECT : VIDEO2

CONTROL LOCK : OFF

IR ENABLE : ON

LOOP OUT : OFF

ID NUMBER : ALL

VIDEO WALL

SETTING 3 3 / 3

PREVIOUS PG.

SEL. ADJ. EXIT

EXIT

The mode switches as follows each time the or buttons is
pressed:

The available sources depend on the setting of “BNC INPUT”.
RGB: → LAST ↔ VIDEO1 ↔ VIDEO2 ↔ VIDEO3 ←

→ RGB3 ↔ RGB2 ↔ RGB1 ↔ HD1 ←

COMP: → LAST↔ VIDEO1 ↔ VIDEO2 ↔ VIDEO3 ←
→ RGB3 ↔ RGB1 ↔ HD2 ↔ HD1 ←

4. Once the setting is completed ...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

64

Information

■ INPUT SELECT settings

LAST ................... Last mode (the mode that was last selected at

the time the power was switched off).

VIDEO 1, 2, 3 ...... VIDEO input mode.

RGB 1, 2, 3 .......... RGB input mode.

HD 1, 2 ................. HD/DVD input mode.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

Enabling/disabling the front panel controls

This function enables/disables the front panel controls.

Example: Setting “ON”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 3”, then press
the MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “CONTROL LOCK”.

OSD (On Screen Display) Controls

TIMER

INPUT SELECT : LAST

CONTROL LOCK : ON

IR ENABLE : ON

LOOP OUT : OFF

ID NUMBER : ALL

VIDEO WALL

SETTING 3 3 / 3

PREVIOUS PG.

SEL. ADJ. EXIT

EXIT

TIMER

INPUT SELECT : LAST

CONTROL LOCK : ON

IR ENABLE : OFF

LOOP OUT : OFF

ID NUMBER : ALL

VIDEO WALL

SETTING 3 3 / 3

PREVIOUS PG.

SEL. ADJ. EXIT

EXIT

3. To set the CONTROL LOCK to “ON”...
Use the and buttons to select “ON”, then press the MENU
button.
The mode switches as follows each time the or button is
pressed: OFF ON

4. Once the setting is completed ...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Information

■ CONTROL LOCK settings

ON ................... Disables the buttons on the front panel.

OFF .................. Enables the buttons on the front panel.

* Even when the CONTROL LOCK is set, the POWER switch will
not be locked.
* This becomes effective when the on-screen menu goes out.

Enabling/disabling remote control wireless transmission

This function enables/disables remote control wireless
transmission.

Example: Setting “OFF”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 3”, then press
the MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “IR ENABLE”.

3. To set the IR ENABLE to “OFF”...
Use the and buttons to select “OFF”, then press the MENU
button.
The mode switches as follows each time the or button is
pressed: OFF ON

65

OSD (On Screen Display) Controls

TIMER

INPUT SELECT : LAST

CONTROL LOCK : ON

IR ENABLE : OFF

LOOP OUT : ON

ID NUMBER : ALL

VIDEO WALL

SETTING 3 3 / 3

PREVIOUS PG.

SEL. ADJ. EXIT

EXIT

4. Once the setting is completed ...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Information

■ IR ENABLE settings

ON ........ Enables remote control wireless transmission.

OFF ....... Disables remote control wireless transmission. Set “OFF”

to avoid unwanted control from other remote controls.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

Loop Out Setting

When this feature is set to ON, the received signal will be
looped out.
Example: Setting “ON”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 3”, then press
the MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “LOOP OUT”.

3. To set the LOOP OUT to “ON”...
Use the and buttons to select “ON”.

66

The mode switches as follows each time the or button is
pressed: OFF ON

Information

■ LOOP OUT settings

ON ........ The received signal will be looped out via

PC1 terminal or VIDEO1 terminal.

OFF ....... The received signal will not loop out.

* Even if LOOP OUT is ON, signals would
not be sent out if POWER is being turned off.

■ To connect to another display...

See page 68.

■ If the RGB/PC1 signal is present at the time
the power is switched on...

The RGB/PC1 input will be displayed regardless
of the setting of LOOP OUT.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu. Note that
this also restores other settings to the factory defaults.

OSD (On Screen Display) Controls

TIMER

INPUT SELECT : LAST

CONTROL LOCK : ON

IR ENABLE : OFF

LOOP OUT : OFF

ID NUMBER : 2

VIDEO WALL

SETTING 3 3 / 3

PREVIOUS PG.

SEL. ADJ. EXIT

EXIT

ID Number Setting

When using more than one of these displays, this function sets ID
numbers so that operation of the remote control does not cause
multiple monitors to operate at the same time.

Example: Setting “2”

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 3”, then press
the MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “ID NUMBER”.

3. To set the ID NUMBER to “O2”...
Use the and buttons to select “2”.
The mode switches as follows each time the and button is
pressed:

ALL 1 2 .... 255 256

* To reset back to ALL
Press the CLEAR button.

Information

■ ID NUMBER settings

ALL ............. ID NUMBER will not be set.

1 to 256 ........ ID NUMBER will be set.

■ When the ID NUMBER has been set

You can also set ID NUMBER for each remote control to operate the
plasma display individually. To do so, requires special remote control
available only from Vidikron factory Service Department.

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

To set the ID number for the remote control (requires special

remote control available only from Vidikron factory Service
Department)

Example: Setting “2”

1. Use the and buttons to select “ID NUMBER”.

2. To set the ID NUMBER to “2” ...
Use the and buttons to select “2”. The mode switches as
follows each time the and button is pressed:

ALL 1 2 .... 255 256

67

OSD (On Screen Display) Controls

DIVIDER : 1

POSITON

DISP. MODE : SPLIT

AUTO ID : OFF

IMAGE ADJUST

P.

ON DELAY : OFF

LUM SET LINK : OFF

REPTR TIME : OFF

VIDEO WALL

SEL. ADJ. EXIT

EXIT

POSITION 1: 1

ID NUMBER : OFF

SELECT ID

ADJ. EXIT

EXIT

* To reset back to ALL
Press the CLEAR button.

4. Once the setting is completed...
Press the EXIT button to delete the SELECT ID screen.

Video Wall Setting

Use this feature to congure a 2×2 or 3×3 video wall.

Perform the following operations.
Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

1. Use the and buttons to select “SETTING 3”, then press the
MENU button. The “SETTING 3” screen appears.

2. Use the and buttons to select “VIDEO WALL”, then press
the MENU button. The “VIDEO WALL” screen appears.

68

3. Set the VIDEO WALL using and buttons.
See page 69 to set DIVIDER.
See page 69 to set POSITION.
See page 70 to set DISP. MODE.
See page 70 to set AUTO ID.
See page 71 to set IMAGE ADJUST.
See page 72 to set P. ON DELAY.
See page 73 to set LUM SET LINK.
See page 74 to set REPTR TIME.

4. Once the setting is completed...
Press the EXIT button to return to the SETTING 3 menu.

5. Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

NOTE:

A contingency method of shutting off the electric power should be
used in cases of emergency during video wall setup.

OSD (On Screen Display) Controls

DIVIDER : 4

POSITON

DISP. MODE : SPLIT

AUTO ID : OFF

IMAGE ADJUST

P.

ON DELAY : OFF

LUM SET LINK : OFF

REPTR TIME : OFF

VIDEO WALL

SEL. ADJ. EXIT

EXIT

Information

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

DIVIDER

Set the 2x2 or 3x3 video wall.
Example: Setting “4”

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “DIVIDER”.

4. Use the and buttons to select “4”.
The mode switches as follows each time the or button is
pressed:

OFF 1 4 9

Information

■ DIVIDER settings

OFF, 1 ......... 1 Screen (Matrix display function does not work)

4 .................. 4 Screens (2x2 video wall)

9 .................. 9 Screens (3x3 video wall)

* When you select “4” or “9”, set the VIDEO WALL POSITION.

VIDEO WALL POSITION

Set the position of each display.
Example: Setting “4”

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “POSITION”, then press the
MENU button. The “VIDEO WALL POSITION” screen appears.

4. Use the and buttons to select “NO. 4”.
The mode switches as follows each time the or button is
pressed:

• 4 Screens

NO. 1 NO. 2 NO. 3 NO. 4

• 9 Screens

NO. 7 NO. 8 ....... NO. 14 NO. 15

69

OSD (On Screen Display) Controls

POSITION NO. 4

VIDEO WALL POSITION

SEL. ADJ. EXIT

EXIT

DIVIDER : 1

POSITON

DISP. MODE : BLANK

AUTO ID : OFF

IMAGE ADJUST

P.

ON DELAY : OFF

LUM SET LINK : OFF

REPTR TIME : OFF

VIDEO WALL

SEL. ADJ. EXIT

EXIT

5. Press the EXIT button to return to the VIDEO WALL screen.

Information

■ VIDEO WALL POSITION settings

1 Screen ..... There is no need to set POSITION.

4 Screens

NO. 1 NO. 2

NO. 4 NO. 3

9 Screens

DISP. MODE

Select the screen mode from between two options
(Splitting, Blanking).
Example: Setting “BLANK”

70

NO. 7 NO. 8 NO. 9

NO. 10 NO. 11 NO. 12

NO. 13 NO. 14 NO. 15

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “DISP. MODE”.

4. Use the and buttons to select “BLANK”.
The mode switches as follows each time the or button is
pressed: SPLIT BLANK

Information

■ DISP. MODE SETTINGS

SPLIT .......... Combines enlarged screens and creates multiple

screens.

BLANK ....... Corrects misalignment of combined screen

portions and creates multiple screens.

AUTO ID

This feature automatically sets the ID numbers of multiple
displays connected to each other.
Example: Setting “ON”

OSD (On Screen Display) Controls

AUTO ID

ADJ. EXIT

EXIT

CONNECTION TURN

WIRED CABLE

AUTO ID : ON

1

2

3

4

3

8

1

2

9

4

7

6

5

Set the ID number for the No. 1 display on ID NUMBER menu.

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “AUTO ID”.

4. Use the and buttons to select “ON”, then press the MENU
button.
The mode switches as follows each time the or button is
pressed: OFF ON

Information

■ AUTO ID settings

ON ...... Enables Audo ID function. In the case shown below, display 1

will be set as ID 1, display 2 as ID 2, etc.

REMOTE

REMOTE

REMOTE

OUT

No. 1 No. 2

IN

No. 4 No. 3

Display 1 Display 2

No. 1 No. 2

No. 4 No. 3

Display 4 Display 3

OUT

REMOTE

REMOTE

REMOTE
IN

IN

OUT

No. 1 No. 2

No. 4 No. 3

No. 1 No. 2

No. 4 No. 3

REMOTE
OUT

REMOTE
IN

OFF ..... Disables Auto ID function.

IMAGE ADJUST

The position of the image can be adjusted and ickering of the image can
be corrected.
Example: Adjusting the vertical position.

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “IMAGE ADJUST”, then

press the MENU button. The “IMAGE ADJUST” screen ap­pears.

71

DIVIDER : 1

POSITON

DISP. MODE : BLANK

AUTO ID : OFF

IMAGE ADJUST

P. ON DELAY : ON

LUM SET LINK : OFF

REPTR TIME : OFF

VIDEO WALL

SEL. ADJ. EXIT

EXIT

OSD (On Screen Display) Controls

V SHIFT 0

ASPECT RATIO : I-WIDE

V SHIFT 0

H SHIFT 0

V - SIZE 0

H - SIZE 0

COMPUTER : OFF

FINE PICTURE 0

PICTURE ADJ. 0

IMAGE OPTIONS

SEL. ADJ. EXIT

EXIT

4. Use the and buttons to select “V SHIFT”.

5. Adjust using the and buttons.

* If neither the and button is pressed within 5 seconds, the
current setting is set and the previous screen reappears.

6. Once the setting is completed...
Press the EXIT button to return to the VIDEO WALL screen.

72

Information

■ IMAGE ADJUST settings

These are the same functions as the
IMAGE ADJUST menu on page xx.

P. ON DELAY (Power on delay)

Use this funciton to activate power-on delay.
Turn on the AUTO ID before the following operations.
Example: Setting “ON”
Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “P. ON DELAY”.

4. Use the and buttons to select “ON”.
The mode switches as follows each time the or button is
pressed: OFF ON

OSD (On Screen Display) Controls

DIVIDER : 1

POSITON

DISP. MODE : BLANK

AUTO ID : OFF

IMAGE ADJUST

P.

ON DELAY : ON

LUM SET LINK : ON

REPTR TIME : OFF

VIDEO WALL

SEL. ADJ. EXIT

EXIT

Information

■ P. ON DELAY settings

ON ....... Turns on the main power of each display after a delay time.

OFF ..... Turns on the main power of all displays at the same time.

* Once this function has been set to “ON”, POWER ON/OFF button
on the remote control does not function except for the No. 1 monitor.
By pressing the POWER ON button on the remote control the No.
1 monitor will turn on and the others will be turned on one by one
automatically.

* From the second monitor onward, neither the POWER button on the
unit nor the POWER ON button on the remote control does function.
However, by pressing and holding the POWER ON button for more
than 3 seconds, the monitor will be turned on.

LUM SET LINK

Use this function to set a uniform brightness for each display.
Turn on the AUTO ID before the following operations.
Example: Setting “ON”

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “LUM SET LINK”.

4. Use the and buttons to select “ON”, then press the MENU
button.

The mode switches as follows each time the or button is
pressed: OFF ON

73

OSD (On Screen Display) Controls

DIVIDER : 1

POSITON

DISP. MODE : BLANK

AUTO ID : OFF

IMAGE ADJUST

P.

ON DELAY : OFF

LUM SET LINK : OFF

REPTR TIME : ON

VIDEO WALL

SEL. ADJ. EXIT

EXIT

Information

■ LUM SET LINK settings

ON ...... Sets a uniform brightness for each screen in a 2x2 video

wall.

OFF .... Sets the individual screen brightness for each screen in a 2x2

video wall.

* Set “OFF” in a 3x3 video wall.
* When this function is set “ON”, connect your plasma displays with
the remote cable (optional) in the order of the position numbers for
the 2x2 video wall. See the drawing below.
* If there are changes in the DIVIDER or POSITION, the LUM SET
LINK will automatically turn OFF.

REMOTE
OUT

REMOTE

REMOTE

REMOTE
IN

IN

OUT

No. 1 No. 2

No. 4 No. 3

No. 1 No. 2

No. 4 No. 3

OUT

No. 1 No. 2

IN

No. 4 No. 3

Display 1 Display 2

No. 1 No. 2

No. 4 No. 3

Display 4 Display 3

REMOTE

REMOTE

NOTE:

The remote control can not be operated unless the IR ENABLE is set
to “OFF”.

74

REMOTE
OUT

REMOTE
IN

REPEAT TIMER (REPTR)

Use this to set two timers. Each timer can use the
DIVIDER, SOURCE and ACTIVE functions.
Turn on the AUTO ID before the following operations.

Example:
TIMER1... VIDEO1 will be displayed for 3 minutes.
TIMER2... RGB1 will be displayed for 6 minutes in a
2×2 video wall.

Perform Steps 1-2 of VIDEO WALL, then...

3. Use the and buttons to select “REPTR TIME”.

4. Use the and buttons to select “ON”, then press the
MENU button. The “REPTR TIME” screen appears.

OSD (On Screen Display) Controls

1 DIVIDER : 1

SOURCE : VIDEO1

ACTIVE : 00H03M

2 DIVIDER : 4

SOURCE : RGB1

ACTIVE : 00H06M

REPTR TIME

SEL. ADJ. EXIT

EXIT

5. Adjust using the and buttons.
The mode switches as follows each time the or button is
pressed:

• DIVIDER

1 4 9

• SOURCE
The available sources depend on the setting of “BNC INPUT”.
RGB: → VIDEO1 ↔ VIDEO2 ↔ VIDEO3 ↔ HD/DVD1 ←

→ RGB3 ↔ RGB2 ↔ RGB1 ↔ HD/DVD2 ←

• ACTIVE

00H01M 00H02M 00H03M .... 04H14M 04H15M

6. Once the setting is completed...
Press the EXIT button to return to the VIDEO WALL screen.

Information

■ REPTR TIME settings

If you set both timers, Timer 1 and Timer 2 run consecutively.
In the case of the Video Wall, timer No. 1 can be used to control all the
displays simultaneously.

* This becomes effective when the on-screen menu goes out.

75

OSD (On Screen Display) Controls

LANGUAGE

ADJ. OK EXIT

MENU/ENTER

EXIT

LANGUAGE

: DEUTSCH

■ Restoring the factory default settings

Select “FACTORY” under the SETTING 1 menu.
Note that this also restores other settings to the factory defaults.

» Language Settings Menu

Setting the language for the menus

The menu display can be set to one of seven languages: English,
German, French, Italian, or Spanish.

Example: Setting the menu display to “DEUTSCH”

Press the MENU button on the remote control to display the
MAIN MENU on the screen, then...

3. Once the setting is completed...
Press the MENU button to store the setting and return to the main
menu. To delete the main menu, press the EXIT button.

Information

1. Use the and buttons to select “LANGUAGE”, then press
the MENU button. The “LANGUAGE” screen appears.

2. To select “DEUTSCH”...
Use the and buttons to select “DEUTSCH”.
The mode switches as follows each time the and buttons
are pressed:

→ ENGLISH ↔ DEUTSCH ↔ FRANÇAIS ←
→ ITALIANO ↔ ESPAÑOL ←

76

■ Language settings

English
German
French
Spanish
Italian

OSD (On Screen Display) Controls

VIDEO STANDARD

ADJ. EXIT

EXIT

VIDEO STANDARD

: 3.58NTSC

» Video Standard Menu

Setting the video signal format

Use these operations to set the video standards of composite video
signals or Y/C input signals.

Example: Setting the video standard to “3.58 NTSC”

Press the MENU button on the remote control to display the

MAIN MENU on the screen, then...

1. Use the and buttons to select “VIDEO STANDARD”,
then press the MENU button. The “VIDEO STANDARD” screen
appears.

2. To select “3.58NTSC”...
Use the and buttons to select “3.58NTSC”.
The mode switches as follows when the and buttons are
pressed:

→ AUTO ↔ 3.58NTSC ↔ 4.43NTSC ←
→ SECAM ↔ PAL-M ↔ PAL-N ↔ PAL-60 ↔ PAL ←

3. Once the setting is completed...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button.

77

OSD (On Screen Display) Controls

H. FREQ : 48.4 KHz

V.

FREQ : 60.0 KHz

H. POLARITY : NEG.

V.

POLARITY : NEG.

MEMORY : 24

RESOLUTION : 1366x768

SIGNAL INFO.

SEL. ADJ. EXIT

EXIT

Information

■ Video standard formats

Different countries use different formats for video signals. Set to the
video standard used in your current country.

AUTO ........... The video standards are automatically identied and

the format is set accordingly.

PAL ............... This is the standard format used mainly in the United

Kingdom and Germany.

SECAM ........ This is the standard format used mainly in France and

Russia.

4.43 NTSC,

PAL60 ........... This format is used for videos in countries using PAL

and SECAM video signals.

3.58 NTSC .... This is the standard format used mainly in the United

States and Japan.

PAL-M .......... This is the standard format used mainly in Brazil.

PAL-N ........... This is the standard format used mainly in Argentina.

78

» Signal Info. Menu

Checking the frequencies, polarities of input signals, and
resolution

Use this function to check the frequencies and polarities of the
signals currently being input from a computer, etc.

Press the MENU button on the remote control to display the

MAIN MENU on the screen, then...

1. Use the and buttons to select “SIGNAL INFO.”, then press
the MENU button.

2. The “SIGNAL INFO” is displayed.

3. Once you have checked the frequency ...
Press the EXIT button to return to the main menu. To delete the
main menu, press the EXIT button once more.

Application

1

5

9

6

2

3 4

7

8

These specications cover the communications control of the
plasma monitor by external equipment.

Connections

Connections are made as described below.

Plasma Monitor External Equipment
e.g. Personal Computer

1) Connector on the plasma monitor side: EXTERNAL
CONTROL connector.

EXTERNAL CONTROLS

2) Connector on the external equipment side: Serial port
(RS-232C) connector.
See the specifications of the equipment that is to be connected
for the type of connector and the pin assignment.

3) Wiring

Use a crossed (reverse cable).

Wire the cable so that each pair of data lines cross between the
two devices. These data line pairs are RXD (Receive data) and
TXD (Transmit data), DTR (DTE side ready) and DSR (DCE side
ready), and RTS (Ready to send) and CTS (Clear to send).

If DTR (4) and DSR (6) are not available, these 2 pins can be
ignored. If RTS (7) and CTS (8) are not available, these 2 pins can
be tied together.

Type of connector: D-Sub 9-pin male

No. Pin Name No. Pin Name

1 No Connection 8 CTS (Clear to send)

2 RXD (Receive data) 9 No Connection

3 TXD (Transmit data)

4 DTR (DTE side ready)

5 GND

6 DSR (DCE side ready)

7 RTS (Ready to send)

Communication Parameters

(1) Communication system Asynchronous
(2) Interface RS-232C
(3) Baud rate 9600 bps
(4) Data length 8 bits
(5) Parity Odd
(6) Stop bit 1 bit
(7) Communication code Hex

79

External Controls

Communication Format

8 bit 8 bit 8 bit 8 bit 8 bit 8 bit • • 8 bit 8 bit

Command 1
Unit ID 1
Unit ID 2
Command 2
Data length
Data
Check sum

Command 1

Command 1, along with command 2, is a number used to
distinguish each command. In the case of ACK, when the lower
order 4 bits is FH (as in 3FH and 7FH), this indicates that the
commands and data of the supported equipment have been
received. When the lower order 4 bits is BH (as in 3BH and 7BH),
this indicates that unsupported commands and data have been
received.

Unit ID 1 and Unit ID 2

Unit ID 1 and unit ID 2 are numbers used to identify the
equipment that is to be connected. 60H is used for the plasma
monitor and 80H is used for external control equipment such as a
personal computer.

1) Unit ID 1: Indicates the equipment sending the signal

2) Unit ID 2: Indicates the equipment receiving the signal

80

Command 2

Command 2, along with command 1, is a number used to
distinguish each command.

Check Sum (CKS), Error Processing, and ACK

1) The check sum described below and RS-232C odd parity
are used together for a check of the received data. The check
sum is the lower order 8 bits of one frame of sent or received
data comprising the sum total of Command 1, Unit ID 1 and
2, Command 2, Data Length, and Data.

Check Sum Example

DFH 80H 60H 47H 01H 01H 08H

Com-

mand 1

Unit
ID 1

Unit
ID 2

Com-

mand 2

Data

Length

Data Check

Sum

Total 208H

2) Error Processing
* When the communication interval is vacant for more than 4
ms, thereafter a received Command 1 will be recognized. If, at
this time, meaningful data cannot be recognized, that data will
not be recognized (as valid data).
* An ACK will not be returned unless the receive data error, the
check sum error, and the receive data are all taken in.

Command Reference List

01

Power ON 9FH 4EH 00H

02

Power OFF 9FH 4FH 00H

03

Input Switch Change DFH 47H 01H

04

VOLUME Gain Data DFH 7FH 03H

05

AUDIO Mute On 9FH 3EH 00H

06

AUDIO Mute Off 9FH 3FH 00H

07

CONTRAST Gain Data DFH 7FH 03H

08

BRIGHT Gain Data DFH 7FH 03H

09

SHARPNESS Gain Data DFH 7FH 03H

10

COLOR Gain Data DFH 7FH 03H

11

TINT Gain Data DFH 7FH 03H

12

IMAGE MEM. Select DFH 0AH 01H

13

WHITE BAL. Select DFH 00H 01H

14

RED Gain Data DFH 7FH 04H

15

GREEN Gain Data DFH 7FH 04H

16

BLUE Gain Data DFH 7FH 04H

17

VID NR Mode Set DFH C0H 01H

18

BASS Gain Data DFH 7FH 03H

19

TREBLE Gain Data DFH 7FH 03H

20

BALANCE Gain Data DFH 7FH 03H

21

ASPECT RATIO Select DFH 51H 01H

22

V SHIFT Gain Data DFH 7FH 03H

23

H SHIFT Gain Data DFH 7FH 03H

24

V-SIZE Gain Data DFH 7FH 03H

CMD1 CMD2 LEN

25

H-SIZE Gain Data DFH 7FH 03H

26

PHASE Gain Data DFH 7FH 03H

27

CLOCK Gain Data DFH 7FH 03H

28

OSD Select DFH 58H 01H

29

OSD ADJ. Gain Data DFH 1AH 02H

30

AUTO OFF Select DFH 1AH 02H

31

SIDEBAR LEV. Set DFH C6H 01H

32

CINEMA MODE Set DFH C1H 01H

33

RGB3 ADJ. Select DFH 1AH 02H

34

PIXL PROTECT Set DFH 6BH 03H

35

INVERSE Set DFH C7H 03H

36

IMAGE SWEEP Set DFH C8H 04H

37

FACTORY 1FH 54H 00H

38

AUDIO Set DFH 70H 02H

39

BNC Select DFH 8CH 01H

40

RGB Select DFH 8BH 01H

41

HD Select DFH 8AH 01H

42

LANGUAGE Select DFH 5BH 01H

43

VIDEO STANDARD Select DFH 5CH 01H

44

FREQUENCY Request 1FH 26H 00H

45

INPUT MODE Request 1FH 41H 00H

46

VIDEO ADJ Request 1FH 45H 00H

47

AUDIO Request 1FH 6FH 00H

48

FAILURE MODE Request 1FH 3FH 00H

49

MODEL NAME Request 1FH 17H 00H

External Controls

81

External Controls

01 POWER ON

Function

The external control equipment switches on the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4EH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is
switched on.

3FH 60H 80H 4EH 00H CKS

NOTE: Do not set the Power ON or Power OFF command
continuously.

02 POWER OFF

Function

The external control equipment switches off the power of the plasma monitor.

Transmission Data

9FH 80H 60H 4FH 00H CKS

ACK

The plasma monitor returns the following ACK when the power is
switched on.

3FH 60H 80H 4FH 00H CKS

03 INPUT SWITCH CHANGE

Function

The external control equipment switches the input of the plasma monitor.

Transmission Data

DFH 80H 60H 47H 01H DATA00 CKS

DATA00: Input Select 01H: Video1

ACK

The plasma monitor returns the following ACK when the input is
switched.

3FH 60H 80H 47H 00H CKS

02H: Video2
03H: Video3
05H: HD (HD1 or DTV or DTV1)
06H: HD2 (DTV2)
07H: RGB1/PC1
08H: RGB2/PC2
0CH: RGB3/PC3

NOTE: Do not set the Power ON or Power OFF command
continuously.

82

External Controls

04 VOLUME GAIN DATA

Function

The external control equipment changes the VOLUME gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER SOUND Gain Flag 05H
DATA01: VOLUME Gain Flag 01H
DATA02: VOLUME Gain 00H: Step 0

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER SOUND Gain Flag 05H
DATA01: VOLUME Gain Flag 01H

|
0AH: Step 10 (Default)
|
2AH: Step 42

05 AUDIO MUTE ON

Function

The external control equipment switches on AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3EH 00H CKS

ACK

3FH 60H 80H 3EH 00H CKS

06 AUDIO MUTE OFF

Function

The external control equipment switches off AUDIO Mute of the plasma monitor.

Transmission Data

9FH 80H 60H 3FH 00H CKS

ACK

3FH 60H 80H 3FH 00H CKS

07 CONTRAST GAIN DATA

Function

The external control equipment changes the CONTRAST gain data of the plasma
monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 051H
DATA01: CONTRAST Gain Flag 07H
DATA02: CONTRAST Gain CCH: -52

|
FFH: -01
00H: 0
01H: +01
|
14H: +20

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: CONTRAST Gain Flag 07H

83

External Controls

08 BRIGHT GAIN DATA

Function

The external control equipment changes the BRIGHT gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: BRIGHT Gain Flag 08H
DATA02: BRIGHT Gain E0H: -32

|
FFH: -01
00H: 0
01H: +01
|
20H: +32

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: BRIGHT Gain Flag 08H

09 SHARPNESS GAIN DATA

Function

The external control equipment changes the SHARPNESS gain data of the plasma
monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: SHARPNESS Gain Flag 06H
DATA02: SHARPNESS Gain F0H: -16

|
FFH: -01
00H: 0
01H: +01
|

10H: +16
Only when a RGB signal is connected
DATA02 SHARPNESS Gain 01H: 1

02H: 2

03H: 3

04H: 4

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: SHARPNESS Gain Flag 06H

84

External Controls

10 COLOR GAIN DATA

Function

The external control equipment changes the COLOR gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: COLOR Gain Flag 04H
DATA02: COLOR Gain E0H: -32
* COLOR Gain is from -22 (EAH) to
+22 (16H) only during video

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: COLOR Gain Flag 04H

|
FFH: -01
00H: 0
01H: +01
|
20H: +32

11 TINT GAIN DATA

Function

The external control equipment changes the TINT gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: TINT Gain Flag 05H
DATA02: TINT Gain E0H: -32

|

FFH: -01

00H: 0

01H: +01

|

20H: +32

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: TINT Gain Flag 05H

85

External Controls

12 IMAGE MEM. SELECT

Function

The external control equipment sets the picture mode of the plasma monitor.

Transmission Data

DFH 80H 60H 0AH 01H DATA00 CKS

DATA00: 01H: MEMORY

02H: LW BLK1
03H: CONTRAST
04H: FACTORY

ACK

7FH 60H 80H 0AH 01H DATA00 CKS

DATA00: 01H: MEMORY

02H: LW BLK1
03H: NORMAL
04H: FACTORY

13 WHITE BAL. SELECT

Function

The external control equipment changes the WHITE BAL. of the plasma monitor.

Transmission Data

DFH 80H 60H 00H 01H DATA00 CKS

DATA00: 00H: 5400K
DATA01: 01H: 6500K
DATA02: 03H: 9300K

ACK

7FH 60H 80H 00H 01H DATA00 CKS

DATA00: 00H: 5400K

01H: 6500K
02H: 8500K
03H: 9300K

NOTE: Set so that at the selection of 5400K, 6500K, 8500K
of WHITE BAL. change of the following R/G/B GAIN data
cannot be accepted.

86

External Controls

14 RED GAIN DATA

Function

The external control equipment changes the RED gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: RED Gain Flag 01H
DATA02: RED Gain 1 (Offset) D8H: -40

|
FFH: -1
00H: 0
|
IEH: +30

DATA03 RED Gain 2 (Drive) D8H: -40

|
FFH: -1
00H: 0
|
IEH: +30

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: RED Gain Flag 01H

15 GREEN GAIN DATA

Function

The external control equipment changes the GREEN gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: GREEN Gain Flag 02H
DATA02: GREEN Gain 1 (Offset) D8H: -40

|

FFH: -1

00H: 0

|

IEH: +30
DATA03 GREEN Gain 2 (Drive) D8H: -40

|

FFH: -1

00H: 0

|

IEH: +30

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: GREEN Gain Flag 02H

87

External Controls

16 BLUE GAIN DATA

Function

The external control equipment changes the BLUE gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 04H DATA00 to DATA03 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: BLUE Gain Flag 03H
DATA02: BLUE Gain 1 (Offset) D8H: -40

|
FFH: -1
00H: 0
|
IEH: +30

DATA03 BLUE Gain 2 (Drive) D8H: -40

|
FFH: -1
00H: 0
|
IEH: +30

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 01H
DATA01: BLUE Gain Flag 03H

17 VID NR MODE SET

Function

The external control equipment sets the VID NR (Noise Reduction) mode of the plasma
monitor.

Transmission Data

DFH 80H 60H C0H 01H DATA00 CKS

DATA00: 01H: VID NR OFF

02H: VID NR-1
03H: VID NR-2
04H: VID NR-3

ACK

7FH 60H 80H C0H 01H DATA00 CKS

DATA00: 01H: VID NR OFF

02H: VID NR-1
03H: VID NR-2
04H: VID NR-3

88

External Controls

18 BASS GAIN DATA

Function

The external control equipment changes the BASS gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: BASS Gain Flag 03H
DATA02: BASS Gain F3H: -13

|
FFH: -01
00H: 0
01H: +01
|
ODH: +13

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: BASS Gain Flag 03H

19 TREBLE GAIN DATA

Function

The external control equipment changes the TREBLE gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: TREBLE Gain Flag 04H
DATA02: TREBLE Gain F3H: -13

|

FFH: -01

00H: 0

01H: +01

|

0DH: +13

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: TREBLE Gain Flag 04H

89

External Controls

20 BALANCE Gain Data

Function

The external control equipment changes the BALANCE gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: BALANCE Gain Flag 02H
DATA02: BALANCE Gain EAH: -22

|
FFH: -01
00H: 0
01H: +01
|
16H: +22

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 05H
DATA01: BALANCE Gain Flag 02H

21 ASPECT RATIO SELECT

Function

The external control equipment switches the screen mode of the plasma monitor.

Transmission Data

DFH 80H 60H 51H 01H DATA00 CKS

DATA00: 02H: I-WIDE

03H: LTR BOX
04H: STD 4:3
05H: ANAMPHC

ACK

7FH 60H 80H 51H 01H DATA00 CKS

DATA00: 02H: I-WIDE

03H: LTR BOX
04H: STD 4:3
05H: ANAMPHC

90

External Controls

22 V SHIFT GAIN DATA

Function

The external control equipment changes the V SHIFT gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: V SHIFT Gain Flag 01H
DATA02: V SHIFT Gain C0H: -64

|
FFH: -01
00H: 0
01H: +01
|
40H: +64

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: V SHIFT Gain Flag 01H

23 H SHIFT GAIN DATA

Function

The external control equipment changes the H SHIFT gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: H SHIFT Gain Flag 02H

DATA02: H SHIFT Gain 80H: -128

|

FFH: -01

00H: 0

01H: +01

|

7FH: +127

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: H SHIFT Gain Flag 02H

91

External Controls

24 V-SIZE GAIN DATA

Function

The external control equipment changes the V-SIZE gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: V-SIZE Gain Flag 07H
DATA02: V-SIZE Gain 00H: 0

|
40H: +64

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: V-SIZE Gain Flag 07H

25 H-SIZE GAIN DATA

Function

The external control equipment changes the H-SIZE gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: H-SIZE Gain Flag 08H
DATA02: H-SIZE Gain 00H: 0

|

40H: +64

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: H-SIZE Gain Flag 08H

92

External Controls

26 PHASE GAIN DATA

Function

The external control equipment changes the PHASE gain data (Phase) of the plasma
monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: PHASE Gain Flag 03H
DATA02: PHASE Gain 00H: 0

|
2CH: +44

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: PHASE Gain Flag 03H

27 CLOCK GAIN DATA

Function

The external control equipment changes the CLOCK gain data of the plasma monitor.

Transmission Data

DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: CLOCK Gain Flag 04H
DATA02: CLOCK Gain C0H: -64

|

FFH: -01

00H: 0

01H: +01

|

40H: +64

ACK

7FH 60H 80H 7FH 02H DATA00 DATA01 CKS

DATA00: USER PICTURE Gain Flag 03H
DATA01: CLOCK Gain Flag 04H

93

External Controls

28 OSD SELECT

Function

The external control equipment switches on or off the on-screen display (OSD) of the
plasma monitor.

Transmission Data

DFH 80H 60H 58H 01H DATA00 CKS

DATA00: 01H: On-Screen display On

ACK

7FH 60H 80H 58H 01H DATA00 CKS

DATA00: 01H: On-Screen diaplay On
02H: On-Screen display Off

On-Screen display On/Off is equivalent to the OSD menu item under the
FUNCTION menu.

*Operation is as described in the table below.

Remote control
operation

Personal computer
control operation

02H: On-Screen display Off

Operation

On-Screen Display (OSD)

Display of items and
adjustments on the menu

When screen
display is ON

Yes Yes Yes No

No No Yes No

When screen
display is
OFF

Volume display, input display,
and screen display

When screen
display is
ON

When screen
display is
OFF

29 OSD ADJ. GAIN DATA

Function

The external control equipment sets the position of the OSD menu of the plasma monitor.

Transmission Data

DFH 80H 60H 1AH 02H DATA00 DATA01 CKS

DATA00: OSD ADJ. Gain Flag 02H
DATA01: 01H: 1

ACK

7FH 60H 80H 1AH 01H DATA00 CKS

DATA00: OSD ADJ. Gain Flag 02H

│
06H: 6

94

External Controls

30 AUTO OFF SELECT

Function

The external control equipment switches on or off the AUTO OFF of the plasma monitor.

Transmission Data

DFH 80H 60H 1AH 02H DATA00 DATA01 CKS

DATA00: AUTO OFF Select 03H
DATA01: 01H: ON

02H: OFF

ACK

7FH 60H 80H 1AH 02H DATA00 DATA01 CKS

DATA00: AUTO OFF Select 03H
DATA01: 01H: ON
02H: OFF

31 SIDEBAR LEV. SET

Function

The external control equipment sets the SIDEBAR LEV. of the plasma monitor.

Transmission Data

DFH 80H 60H C6H 01H DATA00 CKS

DATA00: SIDEBAR LEV. 00H: 0

ACK

7FH 60H 80H C6H 01H DATA00 CKS

DATA00: SIDEBAR LEV. 00H: 0

│
0FH: 15

│
0FH: 15

32 CINEMA MODE SET

Function

The external control equipment switches on or off the CINEMA MODE of the plasma
monitor.

Transmission Data

DFH 80H 60H C1H 01H DATA00 CKS

DATA00: CINEMA MODE Set 01H: ON

02H: OFF

ACK

7FH 60H 80H C1H 01H DATA00 CKS

DATA00: CINEMA MODE Set 01H: ON

02H: OFF

95

External Controls

33 RGB3 ADJ. SELECT

Function

The external control equipment sets the RGB3 ADJUST of the plasma monitor.

Transmission Data

DFH 80H 60H 1AH 02H DATA00 DATA01 CKS

DATA00: RGB3 ADJ. Select 06H
DATA01: 01H: 1

02H: 2
03H: 3

ACK

7FH 60H 80H 1AH 02H DATA00 DATA01 CKS

DATA00: RGB3 ADJ. Select 06H
DATA01: 01H: 1
02H: 2
03H: 3

34 PIXL PROTECT SET

Function

The external control equipment sets the LUM. SETTING, ORBITER, and INVERSE
(inverse of image brightness) of the plasma monitor.

Transmission Data

DFH 80H 60H 6BH 03H DATA00 DATA01 DATA02 CKS

DATA00: LUM SETTING 01H: AUTO

02H: SET.
DATA01: INVERSE 01H: ON

02H: OFF

03H: WHITE
DATA02: ORBITER (PICTURE SHIFT) 01H: ON

02H: OFF

ACK

The plasma monitor returns the following ACK when setting the LUM. SETTING,
ORBITER, and INVERSE (inverse of image brightness):

3FH 60H 80H 6BH 00H CKS

96

External Controls

35 INVERSE SET

Function

The external control equipment sets the INVERSE (inverse of image brightness) and the
WHITE of the plasma monitor.

Transmission Data

DFH 80H 60H C7H 03H DATA00 DATA01 DATA02 CKS

DATA00: INVERSE/WHITE 00H: No operation

01H: ON (INVERSE)
02H: OFF
03H: WHITE

DATA01: ACTIVE 00H: ON

01H: 03M (minutes)
02H: 06M (minutes)
|
FFH: 12H (hours) and 45M
(minutes)

DATA02: STANDBY 01H: 03M (minutes)

02H: 06M (minutes)
|
FFH: 12H (hours) and 45M
(minutes)

ACK

3FH 60H 80H C7H 00H CKS

Note: The ACTIVE and the STANDBY can be set in units of 3 minutes.
Example: 03H=9 minutes
1EH=1 hour and 30 minutes

36 IMAGE SWEEP SET

Function

The external control equipment sets the IMAGE SWEEP of the plasma monitor.

Transmission Data

DFH 80H 60H C8H 04H DATA00 to DATA03 CKS

DATA00: IMAGE SWEEP 00H: No operation

01H: ON

02H: OFF
DATA01: ACTIVE 00H: ON

01H: 03M (minutes)

02H: 06M (minutes)

|

FFH: 12H (hours) and 45M

(minutes)
DATA02: STANDBY 01H: 03M (minutes)

02H: 06M (minutes)

|

FFH: 12H (hours) and 45M

(minutes)
DATA03: SPEED 01H: 1

|

05H: 5

ACK

3FH 60H 80H C8H 00H CKS

Note: The ACTIVE and the STANDBY can be set in units of 3 minutes.
Example: 03H=9 minutes
1EH=1 hour and 30 minutes

97

External Controls

37 FACTORY

Function

The external control equipment resets the user adjustment of the plasma monitor.

Transmission Data

1FH 80H 60H 54H 00H CKS

ACK

3FH 60H 80H 54H 00H CKS

38 AUDIO SELECT SET

Function

The external control equipment sets combinations of audio and video inputs for the
plasma monitor.

Transmission Data

DFH 80H 60H 70H 02H DATA00 DATA01 CKS

DATA00: AUDIO 01H: AUDIO 1

02H: AUDIO 2

03H: AUDIO 3
DATA01: VISUAL INPUT 01H: Video 1

02H: Video 2

03H: Video 3

05H: HD (HD1 or DVD or DVD1)

06H: HD2 (DTV2)

07H: RGB 1/PC1

08H: RGB 2/PC2

0CH: RGB 3/PC3

ACK

The plasma monitor returns the following ACK when the input is switched.

3FH 60H 80H 70H 00H CKS

* The plasma monitor returns “Not Available” when selecting the video input same as the
one set at one of the AUDIO 1 to 3.

Example:

The plasma monitor returns “Not Available” when selecting the VIDEO1 for AUDIO2 or
VIDEO3 after VIDEO1 has been set to AUDIO1.

98

External Controls

39 BNC SELECT

Function

The external control equipment sets the BNC SELECT of the plasma monitor.

Transmission Data

DFH 80H 60H 8CH 01H DATA00 CKS

DATA00: BNC SELECT 01H: RGB

02H: Component
03H: Video

ACK

The plasma monitor returns the following ACK when setting the BNC SELECT:

7FH 60H 80H 8CH 01H DATA00 CKS

DATA00: BNC SELECT 01H: RGB

02H: Component
03H: Video

41 RGB SELECT

Function

The external control equipment sets the RGB SELECT of the plasma monitor.

Transmission Data

DFH 80H 60H 8BH 01H DATA00 CKS

DATA00: 01H: AUTO

02H: STILL
03H: MOTION
04H: RESIZE1
05H: RESIZE2
06H: DTV

ACK

7FH 60H 80H 8BH 01H DATA00 CKS

DATA00: 01H: AUTO

02H: STILL
03H: MOTION
04H: RESIZE1
05H: RESIZE2
06H: DTV

99
