ARGUS BASIC

Programmer’s Reference Manual

VIDICODE Datacommunicatie BV

Zoetermeer 1990 - 1997

ARGUS BASIC Programmer’s Reference Manual

Zoetermeer

Designed, edited and typeset in The Netherlands.

No part of this publication may be used or reproduced, stored in a

database or retrieval system, transmitted in any form or by any means,

electronic, mechanical, photocopying, recording, or otherwise, without

the prior written permission of the publisher, except in the cases

of brief quotations embodied in critical articles and reviews.

Making copies of any part of this book for any purpose other than

your own personal use is a violation of copyright laws.

Further copies of this manual and information on the Argus range of products and services may be obtained from the publishers.

Please address all inquiries to:

EUROPE:

Vidicode Datacommunicatie BV Blauwroodlaan 140 2718 SK Zoetermeer Netherlands

Voice: (+31) 79 3617181 Fax: (+31) 79 3618092 Email: VIDICODE@VIDICODE.NL Website: WWW.VIDICODE.NL

USA:

Vidicode Datacommunication Inc. 1616 Shipyard Blvd. Suite 259 Wilmington, NC 28412

Voice: (+1) 910-452-5600 Fax: (+1) 910-254-3525 Email: SALES@VIDICODE.COM Website: WWW.VIDICODE.COM

Table of Contents

PROGRAMMING THE MODEM 7

1.1 Program structure 7

Program lines & commands 7 Variables & constants 7 Variable names 8 Integers & integer arrays 8 Strings & string arrays 8 Labels 9 Calculations & expressions 10 Hexadecimal numbers 10 Logical operations 10 Events 11

1.2 Writing programs 12

Direct programming 12 Indirect programming 13

1.3 Running programs 14

Running files from the filing system 15

1.4 Program and variable storage 15

1.5 I/O ports 16

Port syntax 17

1.6 The Argus filing system 18

Text files 19 Binary files 20 BASIC programs 20

1.7 Program backup 20

Backing up Program memory 21 Backing up the RAM-, FLASH- or Hard-disk 21

ARGUS BASIC - COMMAND REFERENCE 22

Syntax 22 ABS absolute value 24 ACTIVE set modem active 25 ADC read analogue to digital conversion 27 AND logical AND 28 ANSWER answer a call 29 ASC ASCII value 30 AT AT scan 31

AT (#[port]) (SLASH) ON/OFF 32

AT INPUT (#[port]) 32

AT REPEAT 32

AT [string] 32 AUTO automatic line numbering 34

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BAUD set baud rate 35 BOOT ON/OFF enable/disable BOOT file 37 BRK transmit a break 38 BUFFER reserve buffer space 39 BUTTON read the S/A button position 42 CALL jump to machine code subroutine 43 CHR$ character string 44 CLEAR clear variables/memory 45

1. CLEAR 45

2. CLEAR ALL 45

3. CLEAR (#[port]) 45

4. CLEAR INPUT (#[port]) 45

5. CLEAR OUTPUT (#[port]) 45

6. CLEAR BUFFER 45

7. CLEAR PRINTER 45

8. CLEAR! or CLEAR FILE 45

9. CLEAR ROM 45 CLOCK$ read internal clock 47 CONNECT connect to remote modem 48 COPY copy files 49 CTS Clear To Send 50 DATA define constant data 51 DATE$ read system date 52 DAY read/set day of week 53 DCD Data Carrier Detect 54 DDAY read/set day in month 55 DELETE or DEL delete program lines/files 56 DIAL dial number 58 DIM reserve space for arrays 59 DIR list file directory 60 DIR ROM list ROM directory 62 DIV integer divide 63 DSR Data Set Ready 64 DTMF ON/OFF dial tone multiple frequency 65 [var] = DTMF read DTMF receiver 66 DTR Data Terminal Ready 67 DUTCH select language and screen mode 68 ECHO enable/disable character echo 69 END end of program 70 ENGLISH select language and screen mode 71 EOR logical Exclusive OR 72 ERL error line system variable 73 ERN error number system variable 74 ESCAPE set Escape character 75 FALSE Boolean system variable 76 FAX MODEM ON/OFF enable/disable fax selector 77 FAX ON/OFF turn FAX on or off 78 FAX RECEIVE receive fax file 79 FAX SEND ...TO... send fax file 80 FOR ... (TO) ... (NEXT) ... (STEP) loop structure 85 FREQ read frequency measurement 87 GET get byte (with wait) 88 GET$ get character (with wait) 89 GOSUB ... RETURN jump to subroutine 90 GOTO unconditional jump 92 HANDSHAKE select/enable handshaking 93

RTS/CTS selected: 93 XON/XOFF selected: 93

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Handshaking via LINKed ports 93 HANGUP disconnect a call 95 HOOK hook control 96 HOUR read/set hour of day 97 IF ... THEN ... ELSE condition test 98 ILINE read input line 99 INPUT read string/number 100 IPORT default input port 102 KEY get byte (without wait) 103 KEY$ get character (without wait) 104 LCASE convert ASCII to lowercase 105 LCASE$ convert string to lowercase 106 LED control LEDs 107 LEFT$ extract left part of a string 108 LEN get length of string 109 LENGTH set or read serial port word length 110 LINEFEED enable/disable Line Feeds 111 LINK connect logical data streams 112 LIST list BASIC program 115 LIST AUTO list program for editing 116 LOAD load BASIC program or data 117 LOAD ROM load BASIC programs from socket 2 118 LTRIM$ remove leading spaces 119 MATCH find matching files/data 120 MATCH ROM find matching files in socket 2 122 MID$ extract middle portion of string 123 MIN set/read minute value 124 MNP (4/5) ON/OFF turn error correction on/off 125 MOD integer remainder operator 126 MODEM select standard modem mode 127 MONTH set/read month of year 128 NETWORK Argus LAN network command 125 NEW new program 132 OLD restore program 133 OLINE set/read digital output line 134 ON AT AT scan event handler 136 ON BRK BRK event handler 137 ON BUTTON USER button event handler 138 ON CONNECT connection detect event handler 139 ON DTD DTR loss event handler 140 ON DTR DTR event handler 141 ON ERROR error handler 142 ON ESCAPE Escape event handler 143 ON ... GOSUB/GOTO jump on value 144 ON HANGUP loss of connection event handler 145 ON OFF disable all events 146 ON RESET reset event handler 147

(a) A !BOOT program is found on the disk 147

(b) No program running at moment of reset 147

ON RESET RUN [filename] 148

ON RESET RUN 148

ON RESET ... 148 ON RING RING event handler 150 ON SEQUENCE Esc. sequence event handler 151 ON SLASH AT scan event handler 152 ON TIMEOUT timeout event handler 153 OPORT default output port 155

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ORI output ring indicator 157 OUTPUT send data to port 158 PARITY read or set parity 159 PBOT program bottom 160 PEEK read byte from memory 162 PEEK$ read string from memory 163 PLAY [filename] playback a recorded file 164 PLAY ON/OFF turn play on/off 166 PLAY VOLUME [num] playback attenuation 167 POKE put byte into memory 168 POKE$ put string into memory 169 PORT last event port system variable 170 PRINT send data to port 171

PRINT positioning & formatting 171 PRINTER enable/disable printer port 173

PRINTER and PRINTER ON 173

PRINTER OFF 173

PRINTER LINEFEED ON/OFF 173

PRINTER INPUT/OUTPUT 173 PROTOCOL set file transfer protocol 174 PTOP program top system variable 178 PULSE set/do pulse dialing 179 PUT write byte value to port 180 PUT$ write character to port 181 READ read data items 182 RECEIVE receive file or data 183 RECEIVE #[port], [address] receive data 184 RECEIVE [filename], [type] receive file 185 RECEIVE ALL receive disk backup 189 RECEIVE TIMEOUT = [int] set Sreg66 timeout 190 RECORD [filename] record a voice file 191 RECORD ON/OFF turn record mode on/off 193 RECORD TIMEOUT [num] set record timeout 194 REM remark 195 RENAME rename files 196 RENUM renumber program 197 REPEAT ... UNTIL loop structure 198 REPORT report result or error 199

REPORT ERN 199

REPORT or REPORT RESULT 199 RESET generate hardware reset 200 RESET ALL SREG reset all S-registers to factory settings 201 RESET MODEM 2 reset modem-chip only 202 RESTORE restore pointer to data command/buffer/RAM-disk 203 RESULT last status of modem action 204 RETURN return from procedure/ set return character 206

1. Return from procedure 206

2. Set value of RETURN character. 206 RIGHT$ extract right portion of string 207 RING ring counter 208 ROM access RAM/ROM-disk in socket 2 209 RPT$ repeat string 211 RTRIM$ remove trailing spaces 212 RTS ready to send 213 RUN run a program 214 RUN ROM run a program from ROM/RAM-disk in socket 2 215 SAVE save program or data to memory/disk 216 SAVE ROM save files in RAM-disk in socket 2 217

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

SCAN set answering speed/scan 218 SEC read/set seconds value 219 SEND send file or data 220 SEND #[port], [address], [address] send data 221 SEND [filename], [type], [option] send file 222 SEND ALL make a backup of disk 227 SEQUENCE select escape sequence character 228 SGN get sign of number 229 SOUND (MODEM) make a sound on speaker or phoneline 230 SPC$ repeat spaces 231 SPEAKER ON/OFF speaker control 232 SPEED set line modem-speed 233 SPEED BUFFER ON/OFF speed buffer on/off 234 SREG set/read S-registers 235 STOP stop program execution 236 TIME$ read or set time 237 TRACE trace program-lines execution 238 TRIM$ remove spaces 239 UCASE convert ASCII to uppercase 240 UCASE$ convert string to uppercase 241 VAL convert string to number 242 VAL$ convert number to string 243 VOICE set modem to voice-mode 244 VOLUME set speaker volume 246 WAIT ... (SEC/MIN) wait some time 247 WHILE ... DO ... WEND loop structure 248 XOFF define XOFF character 249 XON define XON character 250 YEAR read/set year value 251 BASIC Error Messages 252 BASIC Keywords and associated short forms 256 Keyboard & LCD codes 266

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

This page intentionally left blank

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Programming the modem

1.1 Program structure

Argus BASIC is part of the Argus Programmable Modem, the Argus Call Recorder and of the Telecommunications Centre Lite (T.C.Lite). A keyboard and LCD display are optional for the Argus Programmable Modem and always available on the Argus Call recorder and the T.C.Lite. A filing system is optional for the Argus Programmable Modem and can be a RAMdisk, a FLASH-disk, a Hard-disk or an Argus LAN (Local Area Network). The T.C.Lite only supports the FLASH-disk.

Argus BASIC is much like any other version of BASIC in terms of both syntax and structure, but there are also many significant differences. This chapter provides an overall description of the modem programming environment and goes on to describe each of the Argus BASIC commands in detail.

Program lines & commands

A BASIC program consists of a series of lines which must start with a 'line number' and may contain up to 255 characters. A line that is entered without a line number will not be treated as part of a program but will be executed immediately. For example, the following command :

PRINT "Of Mice and Men - by John Steinbeck"

will display the quoted message on your screen as soon as you press [Return]. Alternatively, when you type the line:

10 PRINT "Of Mice and Men - by John Steinbeck"

it will be treated as line 10 of the current program and stored in the modem's memory until the program is executed. Program lines may be entered in any order but the modem will always list and execute them sequentially from lower line numbers to higher ones (unless control of flow is changed by a branch command such as GOTO).

A single program line may contain more than one command with individual commands being separated by a colon. The following line contains three commands:

10 X=9 : PRINT "The square of ";X;" is "; : PRINT X^2

The first command defines a 'variable' called X and gives it the value 9. The second command outputs a message, including the value of X, to the currently selected output port, and finally, another PRINT command outputs the value of X^2. The overall effect of the line is to output the following:

The square of 9 is 81

As many commands may be placed on a single line as will fit in the maximum line length of 255 characters.

BASIC keywords such as PRINT may be entered in upper or lower case but the modem will convert them all to capitals. Also, it is not necessary to leave spaces between commands, as the modem will insert them automatically.

During program entry it is advisable to leave (numerical) gaps in the line numbering, so that additional lines may be inserted later. The convention is to number lines 10, 20, 30 etc., although there is a command for re-numbering programs (RENUM).

Variables & constants

Data stored or used in a BASIC program may exist as a 'constant' or as a 'variable'. The following examples are constants:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

"The quality of mercy is not strained.."

Constants are so-called because they have a fixed value that does not change during program execution.

The term variable is used to describe a named piece of data whose value can change during program execution. For example:

X=25

Quote$="The quality of mercy is not strained.."

Here, X and Quote$ are variables which can be given different values at different times. After the command:

X=43

the value of X will be 43, not 25 as previously.

There are only two types of constants and variables in modem BASIC which are known as 'integers' and 'strings'. Floating point (fractional) numbers are not allowed.

Variable names

Variable names must start with a letter, may contain letters, numbers and the underline character and may be up to 127 characters long. They may be typed in upper or lower case but the modem will convert them during listing so that only the first character is capitalized. The underline character is generally used to split a variable name into two or more parts to make it more readable, in which case the first letter after each underline will also be capitalized.

The following are examples of valid variable names:

A X395

Home_Num$ Start_Pointer

Inp_Line$ S$

Name$ Start_Date$

Telephone Temperature

String variable names are suffixed by '$' as in most versions of BASIC, but, whereas it is normal to use the '%' or '#' symbols to distinguish between integer and floating point variables, this is not necessary on the modem so that any variable not suffixed by '$' will be treated as an integer.

Integers & integer arrays

Argus BASIC will handle integer numbers and variables in the range -32768 to 32767 ($0000 - $FFFF). Arrays (tables) can only have one dimension and the number of elements is limited to 32767. Space for arrays is allocated using the standard form of the DIM command. For example:

DIM A(100)

reserves space for 100 integers in array A. Only 1 dimensional arrays are allowed. Multiple arrays can be defined in a single DIM command:

DIM Table1(300), Table2(500)

To assign the contents of the tenth element in the array Table1 above, to the integer variable R, you would use the notation:

R=Table1(9)

Element 0 is the first element.

Integers occupy two bytes of memory.

Strings & string arrays

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Strings are sequences of up to 32767 characters enclosed in double quotes. String variables are assigned values using the equal '=' sign:

Postcode$="GL53 7PJ"

Title$="Introduction to Basic"

Arrays of strings can also be defined:

DIM Options$(8)

DIM Lines1$(200), Line2$(50)

Strings can be added using the '+' sign, or by just writing the one after the other; thus A$B$ is the same as A$+B$.

When A$="ABC" and B$="DEF" and these two strings are added, the result will be "ABCDEF" as one string. The minus sign can also be used with strings, but its operation is very different. It will search for the numerical location where a given string is found within another string. Thus:

x="HELLO" - "LL"

will result in x=3.

If the result is 0, the string was not found. E.g.:

IF A$ - "Post" GOSUB Zip

will execute the procedure Zip only if "Post" is found in A$.

Normally when you input a string a carriage return will terminate the input. To insert a carriage return between B$ and C$ use A$=B$'C$; or to add a carriage return use A$=A$'.

Labels

In addition to line numbers, Argus BASIC allows the use of 'labels' to uniquely identify particular program lines; e.g. the first line of a subroutine.

Label names must be preceded by a '%' symbol and must appear at the start of a line immediately following the line number. In all other respects labels obey the same rules as variable names and, as with variables it is advisable to choose meaningful names that indicate the function of the label.

300%Count_pulses

550%Check_password

Labels can be used interchangeably with line numbers in commands such as GOSUB and GOTO:

GOTO Try_again

GOSUB Mail

IF A=1 GOTO Yes ELSE GOTO No

The commands LIST and DELETE can also be used with labels:

LIST phone

LIST p1,p2

DELETE part3,part16

To retain compatibility with earlier versions of Argus BASIC, it is permissible to precede the label with '%'. Thus:

GOSUB %Mail

is equivalent to:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

GOSUB Mail

If you want to use a label with the same name as an existing command, you must always place a % sign in front of the label, e.g.:

GOTO %Connect

GOSUB %Delete

Calculations & expressions

Like any version of BASIC, Argus BASIC can be used for calculations; but as a result of the fact that only integer numbers are allowed, all mathematical operations give integer results.

The following mathematical operators are available:

+ : addition

- : subtraction

* : multiplication

/ : integer division

DIV : same as /

MOD : remainder from integer division

ABS : absolute value

SGN : sign

The following are examples of expressions using integer variables:

X=10 * Y

Scs =(HOUR * 60 * 60) + (MIN * 60)

Res=X/3+Y

Hexadecimal numbers

Numbers can be entered and displayed in decimal or hexadecimal format. Hex numbers must be preceded by the ampersand (&) character:

Hex=&3AC0

Address=PTOP+&1000

Print &A84B

Converting hexadecimal numbers into decimal format is achieved by preceding the hex value by the tilde (~) character. For instance, to print the decimal equivalent of a hex value or variable:

PRINT ~1200 displays 4608

PRINT ~PTOP displays the value of PTOP in

decimal

PRINT ~1000+50 displays 4146 (i.e. 4096 + 50)

By adding the command VAL$, the decimal value can be stored in a text string:

G$=VAL$~120

assigns the value "78" to the string variable G$.

Logical operations

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Argus BASIC also supports a full range of logical operators which are used to make comparisons between expressions, usually within conditional commands such as IF...THEN...ELSE, REPEAT...UNTIL etc.

The logical operators are:

AND

EOR

FALSE

NOT

TRUE

: bitwise AND

: bitwise Exclusive OR

: logical 0

: bitwise negation

: bitwise OR

: logical 1

: equal to

: greater than

: less than

: less than or equal to

: greater than or equal to

: not equal to

Logical operations by the modem are carried out in a 'bitwise' fashion. For example, the command:

X=6AND8

would set X to 0 as follows:

00000110 AND 00001000 = 00000000

Similarly:

X=6OR8

would set X to 12:

00000110 OR 00001000 = 00001110

Strings can be compared using logical operators:

IF A$="Z" THEN ...

IF A$>B$ THEN ...

X=A$<=B$

Events

Argus BASIC recognizes many events, partly on the hardware side, that makes programming a lot easier. You can cause any part of your program to be triggered into action when these events occur While the modem is in BASIC mode, the events enabled will always be operative, even if the program is not running. The events are:

ON AT

ON BRK

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ON BUTTON(1/2/3)

ON CONNECT

ON DTD

ON DTR

ON ERROR

ON ESCAPE

ON HANGUP

ON RESET

ON RING

ON SEQUENCE

ON SLASH

ON TIMEOUT

So, if you would like your modem to welcome you with a start-up message whenever you start your terminal program, you might include in your program:

10 ON DTR GOSUB Welcome

1100%Welcome

1110 Print "Hello there, this is your modem."

1120 RETURN

1.2 Writing programs

There are two distinct methods of programming the modem.

The first, which you have used so far, is referred to as direct programming; i.e. programs are typed straight into the modem from your computer, using the terminal mode of your communications software. This method is suitable for entering small programs and for testing individual functions; but due to the lack of editing facilities provided by the modem, it is impractical for large programs.

Large programs are best created using a word processor on your computer and then 'downloading' them into the modem when they are ready for testing. This is referred to as indirect programming.

Direct programming

Assuming that the modem is now in command mode with the >1 prompt displayed on screen, you can enter BASIC commands or program lines. The modem is now functioning as a computer and is simply using your PC's keyboard and screen for input and output respectively.

Before starting to enter any new program you should use the following commands to ensure that no other programs are loaded and that the new program is stored in the correct place:

BUFFER OFF

NEW

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

For reasons of speed, direct programming is best carried out at 19200 baud or 38400 baud. If your terminal does not support 38400 baud, use the next highest speed that is available. If your terminal is currently running at a slower speed, you may reconfigure the modem as follows:

• Enter the command WAIT FOR AT, or press the STOP button on the front panel. This will put the modem into 'AT' scan mode.

• Change the baud rate in your terminal software to the required speed.

• Go back on-line. If you pressed the STOP button, type:

AT*B [Return]

if you entered the command WAIT FOR AT, type:

• The baud rate serial and data format for port 1 will now be set to match that of your terminal, and the command mode prompt will be shown.

There is only one editing tool available if you are editing on-line. CTRL-R will display the last line entered. The cursor will be at the end of the line and you can delete the characters backwards and/or add new characters.

Despite the limited editing facilities that are available when entering programs directly, it is still an ideal way to explore the modem and learn about the various functions that are provided. Most commands or commands when entered without line numbers will be executed immediately, and you will see the results.

Indirect programming

It is simpler and more efficient to use the word processing or text editing facilities on your computer to write larger programs. In this case you will first create an ASCII text file of the program and save it on disk. This file may then be transferred (downloaded) into the modem, using the ASCII file transfer option in your communications software. The sequence of events for creating and loading a program in this way is as follows:

• Use a word processor or text editor to create the ASCII version of the program.

• Save the program in a file on disk.

• Load your communications software and get the command mode prompt from the modem.

• Use the ASCII file transfer option in your communications software (NOT X/Y-MODEM or any other error correcting

protocol), to send the program file to the modem.

Note: If you encounter problems with 'echo' during the transfer procedure, you should reset the modem before disabling echo (using the ECHO OFF command), and try again.

When programming indirectly, the first few lines of your program file must contain certain commands which prepare the modem to receive the remainder of the program. Specifically the following must be included:

• CLEAR or BUFFER OFF - to clear that part of the modem's memory which is used for variable storage.

• PBOT=&3000 - sets the address in the modem's memory at which the program will be stored. PBOT is a

system variable that stands for Program BOTtom.

• NEW - clears program memory and prepares the modem BASIC interpreter to accept a new program.

If you include line numbers in your word-processed file you must keep track of them yourself. For obvious reasons you will not be able to use the modem's RENUM command until you have uploaded the program.

If you do not include line numbers in your program text file, you must include the AUTO command at the beginning of the file so that line numbers will be generated for you during uploading. One disadvantage of using a word processor to create program files without line numbers is the difficulty of implementing GOTOs or GOSUBs to line numbers. As an alternative to line numbers in programs where a limited number of subroutine calls or GOTO commands are used, you should use labels. Because labels are easier to remember, we recommend that you only use labels.

The first few lines of your program should be:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

With line numbers: Without line numbers:

PBOT=&3000 PBOT=&3000

BUFFER OFF BUFFER OFF

NEW NEW

10 REM Program start AUTO

. REM Program start

Prior to downloading you should ensure that you have hardware handshaking (RTS/CTS), enabled within your terminal software to avoid losing characters during the transfer.

Note: the modem uses hardware handshake by default, but software handshaking can also be selected using the HANDSHAKE command.

You should also ensure that ESCAPE is enabled in order that it can be used to cancel auto line-numbering when downloading is complete. (See ESCAPE.)

Remarks in a text file can be best implemented by using the '\' sign instead of the REM command. The BASIC interpreter discards the rest of the line behind \ when it is in auto mode. Example:

X=12 \ Start for X

1.3 Running programs

The modem has two (2) different operating modes: it can be used either as a Hayes compatible modem or as a Programmable (or BASIC) modem. It is important that you know exactly how to change from one mode to the other.

To go from modem-mode to BASIC-mode:

• enter AT*B [Return]

To go from BASIC to modem-mode:

• enter MODEM [Return], or have MODEM as a command in a program line.

• In case of an Argus with 5 buttons: first set the S/A button in the in-position and push the STOP button, then set the S/A button in the out-position again.

• In case of an Argus with keyboard: press > + >> + >>> at the same time. This will jump directly to modem-mode.

The effect of entering modem-mode from BASIC is to:

• disable all events but ON RESET. You must be careful here, since once ON RESET is effective, the modem will execute the command associated with ON RESET after every reset or power shutdown.

• leave all variables and buffers as they are.

While still under development, a program will normally be executed using the RUN command. Once development is complete, it is recommended that the program be started with the command ON RESET, or ON RESET GOTO <line number>. This will make your program start whenever you press the RESET button, or after a power failure in the same way. No variables or buffers will be cleared when this happens. If you want the variables and buffers to be cleared, make

CLEAR one of your first program commands.

10 ON RESET PRINT "You are in BASIC once again"

20 PRINT "*";

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

30 WAIT 300

40 GOTO 20

If the RESET button is pressed immediately after this program has been entered (but before it has been run), nothing will happen. After the program has been run once, the modem will return to BASIC mode after you press the RESET button, print "You are in BASIC once again", and send asterisks to your screen.

Pressing the RESET button will restart the program again from the first line. If an [Esc]ape sequence ([Ctrl-C]) is now entered , the program will stop; but ON RESET will still be enabled. Pressing the START button prints 'You are in BASIC once again' and the program will show the asterisks again. If you now press the STOP button again, you will return to modem mode once more.

As soon as you press the RESET button again after that you will return to BASIC once more and the program will run once more, etc.

Running files from the filing system

If you have a filing system (RAM-, FLASH- or Hard-disk or LAN), you can load and save BASIC programs. The command RUN "Name" will first load the program ‘Name’ in system memory on address PBOT (default &3000) and then run it. Once ON RESET RUN "Name" has been entered, you will always start the program 'Name', when you push the RESET button. For standard applications, we have also included a special program named 'BOOT'. This means that if there is a program in memory/disk with the name BOOT, it will always run when you press RESET or after a power shutdown, even if ON RESET is active or inactive. The only way to disable BOOT is with the command BOOT OFF.

1.4 Program and variable storage

The area of memory between &3000 and &7FFF is known as Program memory. BASIC programs are normally stored starting at location &3000 and working upwards, while the variables used by a program are stored in the area just below &7FFF.

A system variable PBOT is used to hold the current program start address, and can be changed to allow two or more programs to be stored at the same time in Program memory.

The highest location used by a program is held in another system variable called PTOP. The size of a program can therefore be calculated by subtracting PBOT from PTOP, and the amount of space remaining for variable storage may be calculated by subtracting PTOP from &7FFF.

Two other commands will reduce the amount of space available for variables:

BUFFER ... if the BUFFER command has been used to define a 'user buffer', the specified amount of space

will be reserved starting from &7FFF and working downwards. This means that variables will be stored at a lower location than usual.

BUFFER OFF may be used to release previously allocated space.

Note: the use of BUFFER will always clear all variables and is therfore recommended to be one of the first commands in any program.

If a program runs out of memory, it is also possible to split up a big program into smaller programs. Depending on the application, a program can be called from within another program with RUN “Name2”, without loosing all variables!

Variables are stored in alphabetical order in memory so that, for example, if an integer A is the first used variable, its value will be stored in locations &7FFE and &7FFF.

The first letter of a variable name is therefore very important as two 26-entry tables are maintained (one for integers and the other for strings), which contain the start address for variables starting with a specific letter. Once an entry has been created in the table, all variables with the same first character are stored in the same memory area. As only the first defined variable

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

with a specific start character is directly accessible, a sequential search of memory must be made to find other variables starting with the same letter. For this reason you should try to use as many different start characters as possible when speed of operation is important.

This method of storage results in the creation of up to 52 separate storage areas. If no variables starting with the letter 'T' are used then no space will be reserved for them. The CLEAR command which is used to destroy all program variables simply clears the look-up table and sets the variable pointer to &7FFF.

Assuming that no buffer memory is allocated, the memory map will be as follows:

Address Letter/variable type

&7FFF

integer variables starting with Z

integer variables starting with A

string variables starting with Z

string variables starting with A

PTOP

PBOT

end of program

start of program

The way in which variables are allocated can be demonstrated by entering the following program:

PBOT=&3000

NEW

DIM A(6000)

After execution of this program, a single variable with 12K allocated has been created in memory. When variable B is defined with the command:

B=0

you might notice that it takes a little while before the prompt returns. This is because the entire area of memory allocated for the integer array A must be shifted in order to create space for the integer variable B. Once this has been done, further access of B will take no noticeable time, a fact that you may prove by now entering the command:

B=1

1.5 I/O ports

Each I/O port on the modem is identified by a unique port number:

Port Device

1 Serial port 1 (25 pin D type)

2 Serial port 2 (9 pin D type)

3 Telephone line (modem chip)

4 reserved

5 reserved

6 Keyboard input & LCD display output

7 Parallel Printer port

8 Memory buffer

Port 1 is serial communications port 1 with asynchronous speeds up to 115200 baud. Synchronous operation is also possible.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Port 2 is serial communications port 2 with asynchronous speeds up to 38400 baud.

Port 3 is the telephone line and is only used if a modem connection is active.

All data streams associated with these ports (receive and send for each), are managed by the modem's operating system, using interrupt driven buffers. All BASIC commands related to the receipt of data (INPUT, GET, etc.) automatically use the input buffers. Commands which serve to transmit characters, such as PRINT and PUT, use the output buffers. Buffer management is therefore transparent to the user, whose only concern should be the type of handshaking used (see below).

I/O buffers are 256 bytes in length and are filled and emptied automatically as data is transferred. However, overflow of input buffers will occur at any speed if data is removed from the input buffers more slowly than new data is received AND no handshaking protocol is in use. Loss of data due to overflow can be avoided by enabling either software (XON/XOFF), or hardware (RTS/CTS) handshaking as appropriate.

Under normal conditions, a program attempting to place data into a full output buffer will be suspended until space becomes available. However when a LINK has been established between two ports handshaking must again be used to prevent overflow. Full descriptions of the HANDSHAKE and LINK commands are given under the appropriate headings in the BASIC reference section.

Port 6 is used for the keyboard as an input and the LCD display as an output (if available). At the back of this manual there are tables for both keyboard and LCD codes..

Port 7 is the parallel printer port. The connector is situated inside the case but a slot in the rear panel is provided for a parallel cable. The parallel port can be defined as an input only or output only.

Port 8 is unusual in that it is not a hardware port, but refers to an area of memory that may be used as a data buffer by BASIC programs. The buffer must be created explicitly using the BUFFER command before it can be used, but thereafter it may be treated in the same way as any other port, using commands such as PUT, GET, PRINT and INPUT. It can be used for input and output in the way a FIFO stack works.

Port syntax

Port numbers in BASIC commands must always be preceded by the hash or pound (#) character. For example, to print a message to port 2 you could use the following:

PRINT#2, "Message from port 2"

In all cases the word "PORT" can also be used e.g.:

PRINT PORT1, "Message from port 1"

Similarly, to read a string from port 2:

INPUT#2, A$

Your program may be easier to understand if you give names to the ports that you use by assigning them to variables:

P=3

PRINT#P, "text"

INPUT#P, A$

For those commands used to set port attributes such as the baud rate, and those used to output data, you may specify more than one port. The following command will print the message "Commencing file transfer..." to both ports 1 and 2 simultaneously:

PRINT#1,#2, "Commencing file transfer..."

Commas between the port numbers are optional (PRINT#1#2).

Listed below are those commands which may include one or more port numbers as parameters:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

AT ESCAPE LENGTH PARITY SBITS

BAUD GET LINEFEED PRINT SEND

CLEAR GET$ LINK PUT XOFF

CTS HANDSHAKE LIST PUT$ XON

DCD INPUT MATCH RECEIVE

DSR KEY ORI RTS

DTR KEY$ OUTPUT

For obvious reasons commands used to input data may only specify a single port.

When repeated access is required to one or more ports you may define default values for input and output using the IPORT and OPORT system variables which are described fully under the relevant BASIC reference headings.

1.6 The Argus filing system

The primary aim of any communications system is the successful transfer of information. However temporary storage of information is very often required to synchronize communications between two different systems. Very different from any other modem, this modem can store data to be sent, or data that has been received temporarily, to allow transfer to a remote or to the local system later. The data may consist of computer programs, text files or other forms of data. Various standards have been adopted over the years to suit different applications, including MNP or V42 error correction and Xmodem or Ymodem file transfer. The mechanism to support some of the common standards have been built into the modem, and have, as far as possible, been made transparent to the programmer. As a result, the task of receiving, storing and sending files and messages is handled almost entirely by the modem.

In order to manage the various types of information that may exist, the modem can have its own filing system. There are 4 types:

1. RAM-disk (up to 1 Mb)

2. FLASH-disk (up to 2 Mb)

3. Hard-disk (up to 3.6 Gb)

4. Argus LAN (network server + station’s)

The RAM/FLASH-disk is 'bank-switched' into the memory map from &A000 to &C000. Bank-switching is fully automatic and requires no special action by the programmer. In the case of an Argus Programmable Modem, there are two 32-pin sockets provided inside the modem, each of which will accept a 128Kb, 256Kb or 512Kb RAM module. The second socket will accept a 128Kb or 512Kb FLASH module, only if the first socket contains a 128Kb RAM module. In the case of a T.C.Lite (with keyboard and LCD display) there is only one socket which will accept a 128Kb, 512Kb or 2Mb FLASH module.

The Hard-disk and LAN are only available for the Argus Programmable Modem. The network server is an Argus with Harddisk and a station is an Argus with build-in network facilities.

The filing system is not a standard feature of the modem, but an option that you can order with your modem, or add later, as and when required.

The filing system of the modem recognizes three distinct types of files:

• Text messages

• Binary files (voice also)

• Argus BASIC programs

File storage is handled entirely by the modem's operating system. Files are stored sequentially in RAM/FLASH-disk, the oldest first.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

On a Hard-disk, the files are stored in ‘directories’ which are created and removed automatically by the operating system; the first character of a filename is the directory entry. Only the characters 0-9, @, and A-Z are possible as the first character in a filename!

The following commands can be used to manipulate files:

CLEAR PLAY/RECORD

COPY RECEIVE

DELETE RENAME

DIR RESTORE

FAX RUN

LOAD SAVE

MATCH SEND

The syntax for manipulating files in general is:

COMMAND ![filename]

COMMAND FILE [filename]

However in most cases the exclamation mark (!) or the word "FILE" can be left out. Only with MATCH, CLEAR and RESTORE they must be used.

Filenames may be up to 16 characters long and may only contain ASCII characters from 33 to 127 (so they cannot include spaces). Two other characters with special meanings that can be used in filenames are:

* : the asterisk (star), which is used as a multiple character 'wildcard'.

? : the question mark, which is used as a single character ‘wildcard’.

. : the full point (dot), which is used to split filenames into a maximum of three sections called extensions. This

allows groups of related files to be given the same extension.

In order for files of a similar type to be grouped together within a directory listing, it is logical to use filename extensions. For example, all BASIC program files could be given the extension '.BAS'; text files could be '.TXT'; etc. To display a list of BASIC programs you would then use:

DIR "*.BAS"

Text files

Straightforward text files are stored in the disk 'as is', i.e. one byte is used for each ASCII character. However, when it comes to transferring text files the modem supports a number of the conventions used by telex-based systems. For instance, the command:

RECEIVE#1, "TEST", T

prepares the modem to receive a text file via serial port 1 (the T is short for Text or Teletype). First, the modem transmits the message:

Please enter your message:

to port 1. It then reads any characters received from port 1 and places them in the disk in a file called "TEST". The file is only closed when either:

or:

a) a single line containing the characters "NNNN" is encountered in the input stream

b) an ESCAPE is received.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

The second method can be disabled if necessary by using the ESCAPE OFF command.

When a transfer is complete, the DIR command may be used to verify that a new file has been created. DIR will also show the type of the file, how many 256-byte blocks it occupies and how many free blocks (or clusters on hard disk) remain.

A text file can be 'read' by sending it to the port to which you are connected. Thus to display the file "TEST" from the previous example you would use:

SEND "TEST",T

Text files can be removed from the disk using the DELETE command, but they must be read at least once before this can be done.

Binary files

Binary files may contain any type of data and are transferred using the Xmodem or Ymodem file transfer protocol. For example, to download a binary file into the modem using Xmodem, you could use the command:

RECEIVE "DATA1",X

Once this has been entered the modem will initiate an Xmodem receive sequence. The required file can now be downloaded by selecting the Xmodem file transmit option in your terminal software. When the transfer is complete the file will be stored in the disk using the name given in the RECEIVE command.

To re-transmit the file use:

SEND "NAME",X

This will only work if the receiving system supports Xmodem file transfer. Multiple files can be merged by using the wildcard character in the filename specification:

SEND "*.DATA",X

However in most cases it is better to use the Ymodem file transfer, because file length is preserved (see PROTOCOL command).

BASIC programs

BASIC programs can be stored to and retrieved from disk using the SAVE and LOAD commands. Disk programs are accessed by their filename:

SAVE "TESTPROG1.PRG"

LOAD "TESTPROG2.PRG"

The file type as shown in a directory listing will be 'B' for BASIC program.

Programs may also be loaded into Program memory and executed with a single RUN command:

RUN "HOSTSYS.PRG"

1.7 Program backup

The importance of making regular backup copies of both programs and data from your computer cannot be stressed too often, and the same golden rule applies when writing programs for the modem.

If you use a word processor to create and edit programs, your normal computer backup procedures can be applied. Backups should be made every time you modify a program.

A different procedure will be required to maintain backups of programs entered directly into the modem. Although the modem memory is battery-backed and does not lose its contents when power is shut off, it is possible that low usage over a

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

period of time will cause the battery to run down and memory to be corrupted. For this reason you should make copies of programs from the modem into your computer or to diskette, to use as permanent backups.

Backing up Program memory

Currently active programs, i.e. those in Program memory, are stored in a compact, encoded (tokenized) form, and cannot therefore be read without the aid of the LIST command. When you use LIST, the stored program is decoded and displayed as ASCII text in the form in which it was originally entered. You may take advantage of this fact to obtain backups in ASCII format of programs that have been entered directly, by using the following procedure:

• Load your terminal software and put the modem into Command mode.

• Use your terminal software to open a file for the reception of ASCII text.

• Go back on-line to the modem and use the LIST command to list the program.

• When listing is complete, close the file and save it on disk.

This file can now be stored permanently as a backup, or it can be edited and downloaded back into the modem when editing is complete. To avoid loss of data while using LIST in this way, make sure that either software or hardware handshaking is selected as appropriate.

Backing up the RAM-, FLASH- or Hard-disk

Even when you have a filing system installed, the need to make a back-up of all your programs and data, is still there. Normally you will save programs, text and binary files in the disk. It is extremely difficult to erase the disk by accident, and the battery backup (in case of RAM-disk) is quite reliable because of the watchdog facility. Nevertheless, we think that it is a wise precaution to backup valuable data now and then onto floppy or the hard disk of your computer.

The easiest way to create a backup is to connect to the modem locally or from a remote terminal and go into BASIC. Then tell the modem:

SEND ALL or SEND "*.*.*.*",C

and use your communications program to download the complete contents of the disk with Xmodem-CRC file transfer.

To restore the complete contents of the disk from your PC, tell your modem to:

RECEIVE ALL or RECEIVE "C",C

and use your communications program to return the same data you have received earlier (also with Xmodem-CRC file transfer).

Of course you can also back up separate files from the disk by using the ,C option. In this way you get a backup-part:

SEND "*.PRG",C

SEND "MESS*.SYS",C

Seperate received backup-parts can be added together in the PC as one big file, which can be used later to restore a disk.

The ,C option tells the modem that it is a file Copy, meaning that all information such as name, length and date, is included in the transfer.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Argus BASIC - Command Reference

Argus BASIC is a custom communications' variant of the popular BASIC language found on many micro-computers. It is a relatively fast implementation which owes much of its speed to the use of a 68HC11 microprocessor running at 3.68 MHz, and integer-only operation. However, multiple high-speed communication streams can still present problems, and some care may be required when developing more adventurous applications in order to avoid potential timing problems; especially if you are using error correction and/or data compression at the same time, at high baud rates such as 9600 baud. Remember also that the execution speed of a program can depend greatly upon how it is written. In this respect you should take note of the following if speed is critical in your application:

• Avoid using port numbers in commands - use default values by assigning IPORT and OPORT appropriately where this is possible.

• Minimize the use of brackets in expressions and function calls - CHR$7 is the same as CHR$(7).

•

Use short variable names.

• Distribute the first characters of variable names across the whole alphabet.

• Combine multiple commands into single program lines.

• Omit variable names with the NEXT clause of FOR ... NEXT loops.

• Minimize the use of string variables.

• Split long calculations into separate, short sections.

• Avoid using the READ and DATA commands - they are relatively slow.

• Using line numbers for GOTOs is faster than using labels.

• If you do use labels keep them short (e.g. %OL, %2).

You should realize that the application of these guidelines may result in poorly structured programs that are difficult to read. Some compromise may be required, particularly during the development stage.

Syntax

Each of the command descriptions in this section is followed by a series of examples, a syntax description, and a list of associated commands to be used as a cross-reference.

The following notation is used in the syntax descriptions:

[-] items in square brackets indicate one of the program 'elements' listed below.

[num-var] : numeric variable

[num] : a numeric variable or constant

[string-var] : string variable; e.g. Name$

[string] : string variable or constant

[integer] : an integer value from -32767 to 32768

[integer n1 ... n2] : an integer value in the range n1 to n2

[port] : a port number (1,2,3,7 or 8)

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

[option] : a single character option code

[type] : a single character type code

x|y : either x or y

( [...] ) : the enclosed item is optional

( , ... ) : optional repetition of the previous item

Other items that appear in the syntax of a command, e.g. #, are shown 'as is'.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ABS absolute value

ABS is used to obtain the absolute value of an integer; i.e. its magnitude.

ABS(-10)

will return the value 10.

It is commonly used to find the difference between two numbers:

diff=ABS(X-Y)

Examples:

A=ABS(B)

PRINT ABS(Temp-38)

Syntax:

[num-var] = ABS [num]

See also:

SGN

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ACTIVE set modem active

This command will simulate any modem connection, after the two modems are connected. It can therefore best be used after the ON CONNECT event. When entering the command, it will set the link between the terminal port and the line port (3). The terminal port must first be set with the system variables IPORT and OPORT. A multiplexed or half duplex connection is also simulated if selected. Exiting the command must be done by ON-events, which are set before the

ACTIVE command was given. The following events are possible during ACTIVE.

ON HANGUP

ON TIMEOUT

ON SEQUENCE

ON DTD: : DTR on the port has dropped

ON ESCAPE

Example:

10 ON CONNECT GOTO %Conn

20 DIAL "123456"

30 REPORT:END

40%Conn

: Connection is lost

: An inactivity timeout has passed

: The escape-sequence is detected (+++)

: An escape is detected

50 ON HANGUP GOTO %Loss

60 ON TIMEOUT 10 TIMEOUT OFF: GOTO %Hang

70 ON SEQUENCE GOTO %Hang

80 ON DTD GOTO %Hang

90 IPORT = 1: OPORT = 1

100 REPORT

110 ESCAPE OFF

120 ACTIVE

130%Hang

140 HANGUP

150%Loss

160 REPORT

170 ON OFF

Syntax:

180 END

ACTIVE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

See also:

ON CONNECT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ADC analogue to digital conversion

The modem is capable of performing an analogue measurement of the signal voltage level on the line. A value between 0 and 255 is returned.

If the modem is 'on-hook' the measurement is always zero.

If you take the modem off-hook and your exchange applies a dial tone, or if a carrier is received, you will be able to see the signal voltage on the line.

To test this, enter:

10 DIAL "123456" : REM dial non-existent number

20 REPEAT : PRINT ADC :WAIT 10 :UNTIL FALSE

RUN

For specialist applications ADC, together with FREQ can be extremely useful, to evaluate what is going over the line. Most users however will have no need for these commands.

Examples:

PRINT ADC

Millivolts=ADC

Syntax:

See also:

SWITCH(1)=RTS AND CTS

IF MONTH=1 AND DDAY=1 THEN PRINT "New Year!"

IF X>0 AND Y<10 AND Z=5 THEN %calc

REPEAT PUT GET : count=count+1 : UNTIL count>80

[num-var] = [integer] AND [integer]

EOR, OR, NOT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ANSWER answer a call

ANSWER is used to make the modem answer a call and is identical to the modem command A (ATA). The modem will take the line and produce an answer tone, and a carrier or a baud rate scan, as set with the various relevant S-registers. A typical application is when you do not want to make the modem auto-answer, but first want to observe certain conditions e.g.:

50 ON RING %test

200 %TEST

210 IF DTR#2 ANSWER

220 RETURN

On exit the system variable RESULT can be read to determine the status of the modem (CONNECT, NO CARRIER). When DCD#3 is set, a successful modem connection is made. This can also be detected by the ON CONNECT event.

ANSWER can also be used to set the number of rings that is required before the modem will answer an incoming call. E.g.:

ANSWER 3

A third syntax is ANSWER ON|OFF. ANSWER ON on is identical to the modem command ATS0=1 and ANSWER OFF to ATS0=0.

Examples:

Syntax:

See also:

ON RING ANSWER

ANSWER = 3

ANSWER OFF

ANSWER

ANSWER [num]

ANSWER ON|OFF

CONNECT, HANGUP, ON RING, ON CONNECT, ON HANGUP

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ASC ASCII value

ASC returns the ASCII code of its character parameter. For example:

ASC"B"

will return the value 66.

When the parameter is a string of more than one character, the ASCII code for the first character in the string is returned, so that:

ASC"John"

will return the value 74 -- the ASCII code for the letter 'J'.

Examples:

X=ASC "@"

X=ASC X$

PRINT ASC "g"

Char=ASC GET$

Syntax:

See also:

[num-var] = ASC[string]

CHR$

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

AT AT scan

AT is used to initiate 'AT' scanning on one or both of the two serial ports. This is the means by which Hayes compatible modems determine the speed and data format being used by the terminal to which they are attached. When operating in this mode, the modem will scan the specified ports for incoming data. The bit pattern produced by the two characters 'A' and 'T' is unique and can be recognized at baud rates from 75 through to 38400 in a variety of data formats. The advantage of this is that the modem need not be pre-configured for baud rate and data format before connection -- it can determine the appropriate settings when the user first enters 'AT'.

Note that the number of stop bits cannot be recognized, so that if your terminal is set to 7, Even, 2, the modem will detect the 'AT' and configure the serial port for 7, Even, 1 operation. Most computers and terminals will not be affected by the missing stop bit, but if you do encounter problems you should set the number of stop bits explicitly, using the SBITS command.

The modem will successfully 'AT'-detect at the following speeds and data formats:

4800

150

9600

7 bits, even parity

7 bits, odd parity

8 bits, even parity

300

14400

600

19200

1200

38400

2400

57600

8 bits, odd parity

8 bits, no parity

If no port number is specified, the default input port as defined by IPORT will be assumed.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

There are four variations of the command:

AT (#[port]) (SLASH) ON/OFF

This will enable or disable the state of a port, where it is waiting for an AT to be entered. When AT is entered, the port is reconfigured. To respond to the AT entered, you will have to enable and use the ON AT event. When 'SLASH' is added as an option and the ON SLASH event is enabled, this event can also be generated when a / is received, but then the port is not reconfigured.

AT INPUT (#[port])

Will input a line and send it to the modem command line interpreter. The result of the execution of the command line is returned in the system variable RESULT. If you want a written output, you can use the command REPORT instead.

AT REPEAT

Will repeat the last command line sent to the modem.

AT [string]

Will send the string to the command line interpreter of the modem. The string itself should not start with AT. So you will have to enter:

AT "DT123"

to make the modem dtmf-dial the number 123 from BASIC. Reading the system variable RESULT will return the result of the action taken.

Notes

When the modem is 'AT' scanning, the complete reception of characters inclusive of ESCAPE is disabled for the selected port; i.e. if port 1 is being scanned, an ESCAPE on port 2 will still be recognized, and vice versa. These will be reset to their previous values when the 'AT' scan is complete.

All active background processes including any LINKs, ON TIMEOUT or ON BUTTON functions, remain active during 'AT' scanning.

After a scan, the baud rate, parity and character length can be read by your program using BAUD, LENGTH, etc.

Examples:

AT#2 ON

AT SLASH#1 ON

AT INPUT

AT REPEAT

AT "DT"+Number$

Syntax:

AT (#[port]) (SLASH) ON|OFF

AT INPUT (#[PORT])

AT REPEAT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

See also:

AT [string]

BAUD, LENGTH, PARITY, SBITS, INPUT AT,

ON AT,ON SLASH

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

AUTO automatic line numbering

AUTO is used during direct programming to enable automatic generation of the next line number each time [Return] is pressed.

The command has two optional parameters which specify the start line number and the increment.

When used without parameters, the start line number and increment are both 10, and the sequence of line numbers generated will be 10, 20, 30, etc.

If a single parameter is used, such as:

AUTO 50

this is taken as the start line number which is incremented by 10, giving the sequence 50, 60, 70, etc.

When two parameters are given, the first is used as the start line and the second as the line increment. The following example will generate numbers 100, 105, 110, etc.

AUTO 100,5

The first parameter can be omitted by including a comma before the second:

AUTO ,5

In this case the line numbers generated will be 10, 15, 20, etc.

If you use AUTO while there is already a program in memory, duplicate lines will be overwritten.

To cancel auto line numbering you must enter the appropriate ESCAPE character (which is [Ctrl-C] by default), so you should make sure that ESCAPE is enabled. If you forget to enable ESCAPE, the STOP button will also cancel auto line numbering.

'\' added behind AUTO line can be used for remarks. These remarks will not be stored as part of the program.

Examples:

Syntax:

See also:

AUTO 5,5

AUTO ,5

AUTO 100

AUTO ( [integer])(,[integer] )

RENUM

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BAUD set baud rate

BAUD is used to set or read the communications speed of the specified serial port. If no port number is specified, the default output port as defined by OPORT will be assumed. The second parameter is a code which represents the required baud rate according to the following table:

Code Baud rate

0 75 1 150 2 300 3 600 4 1200 5 2400 6 4800 7 7200 8 9600 9 14400 10 19200 11 38400 12 57600 13 115200

One or more port numbers may be specified in a single BAUD command, as in the following example, which sets ports 1, 2 and 3 to 2400 baud:

BAUD#1#2#3=5

The baud rate of Port 1 (the main port) can be set at either a positive or negative number. Setting the baud rate to a negative number will configure the port for synchronous operation. Using a positive number, will configure the port for asynchronous operation

When you set the S-register 51 of the modem to 0, the baud rate of the modem port (port #3) will also influence the modem operation. The modem will only connect to carriers that match the baud rate. However, any AT-command sent to the modem will override this baud rate setting.

It is not very practical to set the baud rate on a port if you intend to effect an AT scan on that port directly afterwards because the AT scan will reconfigure the port. In this case, either you set the port for a certain baud rate using BAUD; or you carry out an AT scan on the port and read the baud rate that results with BAUD. For example:

Print BAUD#2

Pressing the RESET button does not affect the baud rate, but does re-initialize serial communication and flush the send/receive buffers.

Examples:

BAUD 11

BAUD#1, 12

BAUD#Port, Rate

PRINT BAUD

Syntax:

BAUD ( #[integer 1..3],)(#... ,) [integer 1..15]

See also:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

AT, LENGTH, PARITY, SBITS

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BOOT ON/OFF enable/disable BOOT file

After every reset, the modem looks for a file 'BOOT' in the RAM/ROM/FLASH- or Hard-disk.

In case of a RAM-disk in an Argus Programmable Modem, it first looks in socket 1, with the first filing system and if it cannot find it, it will look in socket 2, if there is a ROM/RAM in socket 2.

If the BOOT file is found, it is loaded in BASIC at PBOT=&3000 and then executed. It overwrites the ON RESET rules.

If the BOOT file is not found, the normal ON RESET rules will apply. With BOOT ON, this feature is enabled.

With BOOT OFF, the search for the BOOT file is not done after a reset, and the normal ON RESET rules will apply.

See also:

ON RESET, ROM

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BRK transmit a break

BRK is used to make the modem transmit a break on the specified port. When no port is specified OPORT is used. The duration of the break can be controlled with S-register 43, but the default value of 0.50 seconds is usually sufficient. See ON BRK also.

Examples:

BRK#3

ON HANGUP BRK#1

Syntax:

BRK (#[port])

See also:

ON BRK

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BUFFER reserve buffer space

As a result of the fact that the various components of a communications system operate at different speeds, it is often necessary to store data temporarily in an area of memory called a buffer. The advantage of this is that one device can take data out of the buffer while another puts new data in. If the buffer is sufficiently large, the faster of the two devices will not have to wait for the other. For instance with a computer, when you read a character from a file on disk, a whole block of data from the file - perhaps 512 bytes - is read into an area of memory called a file buffer. When you read the next character the processor does not have to wait for the disk drive again, because the data is already in the file buffer.

The BUFFER command on the modem is used to create a buffer of the specified size in RAM. This buffer is treated as if it were a serial port and is addressed as port number 8. The amount of memory that can be allocated for the buffer is limited by the available memory, but the last location, or top of the buffer, is always &7FFF. Note that this is also where program variables are stored, so that if you intend to use the BUFFER command you must do so before you declare any variables.

When the BUFFER command is used, an automatic check will make sure that a program is not overwritten. If there is insufficient room for a buffer of the specified size, an error message will be given.

The command:

BUFFER &400

will reserve 1K of RAM for the buffer. The maximum buffer size is 20K.

The PUT and PRINT commands are used to store data into the buffer:

PRINT#8,"text"

PUT#8,Ch

To retrieve data from the buffer use the GET, KEY or INPUT commands.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

In the following example the next byte of data is read from the buffer and placed in the variable X:

X=GET#8

It is acceptable to use PUT#8, INPUT#8, GET#8, etc., to manipulate the buffer contents; but when frequent buffer access is required, it is more efficient to use IPORT and OPORT to select port 8 as the default port. The port number can then be omitted from the I/O commands.

The buffer can also be used in conjunction with the LINK command as if it were a normal port. For example:

LINK#1,#8

LINK#8,#2

Here, the input from port 1 will be placed in the buffer before being extracted and passed to port 2. This is particularly useful if you are speed-buffering between ports. When using the buffer in this way it is not possible to implement handshaking between the ports, so that if port 1 is very much faster than port 2 the buffer may overflow, and characters will be lost.

The CLEAR#8 or CLEAR BUFFER command is used to empty the buffer by resetting the input and output buffer pointers to the buffer start address. With a 1K buffer this will be &8000 - &400 = &7C00. Any data still in the buffer when the CLEAR command is used will be lost. However with the command RESTORE BUFFER all the data can be read again.

The BUFFER OFF command releases the space allocated for the buffer for other use. The command CLEAR is then executed automatically, so be careful here.

The buffer contents are not affected by the STOP or RESET buttons.

If no buffer space has been allocated, an attempt to access port 8 will not generate an error message, but will cause the program to 'hang'.

For more complex operations on the buffer, the programmer can use PEEK and POKE on the following buffer-related addresses:

256*PEEK&4A4+PEEK&4A5 = buffer start address 256*PEEK&4A6+PEEK&4A7 = buffer end address 256*PEEK&4A8+PEEK&4A9 = buffer start pointer 256*PEEK&4AA+PEEK&4AB = buffer ebd pointer PEEK&43 AND &80 = buffer full flag PEEK&44 AND &80 = buffer empty flag

Important:

When a modem connection is made and MNP5 is active, a buffer of 3K (&C00) must be defined. This space is used by MNP5 and must not be overwritten during the connection.

When using file transfer with the 1-K block option (Ymodem, Xmodem-1K) together with MNP5, then a buffer of at least 4K (&1000) must be defined.

Examples:

Syntax:

BUFFER 1000

BUFFER Size

BUFFER OFF

BUFFER [num]

BASIC Programmer's Reference Manual

ARGUS Programmable Modem

See also:

BUFFER OFF

IPORT, OPORT, LINK, RESTORE BUFFER

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

BUTTON read the S/A button position

BUTTON is used to read the position of the sync/async button from within your program. When the button is in the 'in' position, the function will return '1'; and when the button is in the 'out' position, the function will return '0'.

Examples:

IF BUTTON THEN GOSUB Syn_Com

PRINT BUTTON

Syntax:

[num-var] = BUTTON

See also:

ON BUTTON

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CALL jump to machine code subroutine

The CALL command is used to execute a machine language subroutine. Such routines are normally only used where high speed operations are required for which BASIC would be too slow. (Which is not very often, because Argus BASIC is fast!)

Each CALL command must be followed by the start address of the routine:

CALL &4000

In addition to the call address, parameters can be passed to the routine in the 16-bit accumulator and in the 16-bit X and Y registers.

CALL &4000, A, X, Y

where the variables A, X and Y have been set to the appropriate values before calling.

CALL &4000,1294,7,128

Here, the accumulator is set to 1294, the X register to 7 and the Y register to 128.

The last instruction of the machine code routine must be RTS in order that control is passed back to the BASIC program. On return, the contents of the accumulator and the X and Y registers are stored in locations &2E00, &2E02 and &2E04 and can be accessed using the PEEK function.

When more than three bytes of data must be passed to a machine code routine, the POKE command should be used to place the data in memory at a convenient location. The safest method is to reserve an area of memory with the DIM command, e.g.:

DIM Block 200

As the modem does not include a built-in assembler, development of machine code routines must be carried out on another computer. The assembled code may then be uploaded into the modem using the appropriate form of the RECEIVE command.

Examples:

CALL &3000

CALL Measure,2,X,Y

CALL Calculate,G1,G2

Syntax:

CALL [address] ( , [Accu], [X-reg], [Y-reg] )

See also:

PEEK, POKE, RECEIVE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CHR$ character string

The CHR$ function converts an integer in the range 0-255 to its equivalent ASCII character. It is commonly used to include control characters (ASCII values from 0-31) in PRINT commands. For example, to sound a warning at the terminal when an error occurs, the Bell character ASCII 07 (entered at the keyboard as [Ctrl-G]), could be incorporated into the error message as follows:

500 E$="Error !"+CHR$7

510 PRINT E$

Examples:

X$=CHR$(48+X)

PRINT CHR$75

Syntax:

[string-var] = CHR$ [integer 0..255]

See also:

ASC

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CLEAR clear variables/memory

CLEAR can be used in one of nine ways:

1. CLEAR

When used on its own, it will clear all BASIC program variables.

2. CLEAR ALL

Will clear the input and output buffers of all ports.

3. CLEAR (#[port])

When followed by one or more port numbers, it will clear the input and output buffers for those ports.

4. CLEAR INPUT (#[port])

CLEAR followed by INPUT empties the input buffer for the specified port. If no port is specified, the default input port as defined by IPORT will be assumed.

5. CLEAR OUTPUT (#[port])

CLEAR followed by OUTPUT empties the output buffer for the specified port. If no port is specified, the default output port as defined by OPORT will be assumed.

6. CLEAR BUFFER

This will empty the buffer you have defined, but not disable the buffer. This function will do the same as CLEAR#8 but takes less program space.

7. CLEAR PRINTER

This will clear the printer port. CLEAR#7 will also clear the printer port.

8. CLEAR! or CLEAR FILE

This deletes all files from the RAM/FLASH-disk and should therefore be used with care! If you accidentally type in this command, you should use RESTORE! immediately to recover the RAM-disk contents. Recovering the FLASH-disk is not possible.

9. CLEAR ROM

Is used when a RAM-disk is in socket 2 to clear the chip.

Examples:

CLEAR

CLEAR ALL

CLEAR OUTPUT

CLEAR INPUT#1,#3

CLEAR PORT 1

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Syntax:

CLEAR BUFFER

CLEAR FILE

CLEAR !

CLEAR

CLEAR ALL

CLEAR#[port](,...)

CLEAR INPUT ( #[port])(,...)

CLEAR OUTPUT ( #[port])(,...)

CLEAR BUFFER

CLEAR PRINTER

CLEAR (!/FILE)

CLEAR ROM

See also:

RESTORE, RESTORE ROM, ROM

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CLOCK$ read internal clock

CLOCK$ is used to read the time and date from the internal real-time clock. Output is given in the format:

DAY dd-mm-yy

HH:MM:SS

DAY is day of the week (e.g. SUN); dd is the day of the month, mm is the month, yy is the year, HH is the hour, MM is the minute and SS is the second.

CLOCK$ can be used to set the date and time, but this can usually be done more easily using the individual DAY, DDAY, MONTH, YEAR, HOUR, MIN and SEC commands.

CLOCK$ can be copied into another string to store the time and date of a certain event permanently.

Examples:

C$=CLOCK$

CLOCK$

Syntax:

[string-var] = CLOCK$

See also:

DDAY, DAY, MONTH, YEAR, HOUR, MIN, SEC,

DATE$, TIME$

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CONNECT connect to remote modem

CONNECT is identical to the modem command O (ATO). The modem will take the line, wait for an incoming carrier and try to connect to it. The connection will only be established, when the configuration of the relevant S-registers matches the remote carrier.

The ON CONNECT event can be used to detect a successful connection. This can also be determined by reading DCD#3 on exit of the CONNECT command.

The system variable RESULT can be read on exit to determine the status of the modem (NO CARRIER, CONNECT).

Examples:

CONNECT

HOOK OFF : WAIT 20 : IF FREQ > 500 CONNECT

Syntax:

CONNECT

See also:

ANSWER, HANGUP

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

COPY copy files

This command is used to copy one file on the disk to another file. The new file is identical to the original one. Using wildcards (* or ?) is not possible.

Examples:

COPY "MYPROG" , "MYPROG.BAK"

COPY "MYPROG" TO "MYPROG.BAK"

Syntax:

COPY (FILE|!) [string] (TO|,) (FILE|!) [string]

See also:

LOAD, SAVE, SEND, RECEIVE, DIR

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

CTS Clear To Send

CTS is one of the hardware handshaking signals defined in the RS232 standard, and each serial port on the modem is capable of controlling a CTS signal as an output.

CTS is a signal provided by modems and other DCEs, to inform the terminal (DTE) that it is ready to accept data for transmission. It is used in conjunction with another signal, RTS (Ready To Send) as part of the RS232 handshaking sequence.

When the CTS signal is taken low by the modem, a terminal or computer must respond by stopping further transmission of data until CTS goes high again. If the terminal does not respond, transmitted characters may be lost.

After the HANDSHAKE CTS command has been issued, the modem will respond correctly to RTS and control CTS automatically.

The CTS function is used to read or set the value of the CTS signal on the currently selected output port. When the CTS line is high, the CTS function will return the value 1; if it is low, the value 0 will be returned. If no port is specified, the output port defined by the last used OPORT command is assumed when writing (setting); and the last used IPORT is used when reading.

If the modem is unable to handle any more incoming characters because its input buffer is nearly full, it will request the sending device to wait by taking its CTS output low. This feature can be switched on or off with the HANDSHAKE command.

The modem also supports software handshaking using the XON/XOFF protocol. Refer to the commands XOFF, XON, and HANDSHAKE for more information.

Examples:

Syntax:

See also:

X=CTS

SWITCH(1)=CTS#1

PRINT CTS#2

IF CTS PRINT "READY"

CTS ON

CTS OFF

[num-var] = CTS ( #[port] )

CTS (#[port])=[numeric 0...1]

CTS ON/OFF

HANDSHAKE, XOFF, XON, RTS

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DATA define constant data

The DATA command is used to store numeric and string constants within a program. Such values may be read one or more times using the READ command.

DATA commands may appear anywhere in the program, but must be the first and only command appearing on a line. As many data items as will fit on a line may be included, with individual data items being separated by commas.

The following example contains 5 items (3 numbers and two strings):

70 DATA 5, 10, 50, Apple, Orange

Where a program contains more than one DATA command, they should be thought of as comprising a single continuous list of data items; i.e. having read the last item of data on a particular line, the next READ command will take the first item of data from the next DATA command in the program.

To include leading spaces within a string it must be enclosed in double quotes:

50 DATA " This string contains leading spaces"

As the comma is used as a separator in DATA commands, you may only include a comma as an item of data by enclosing it within double quotes:

60 DATA <,>,?,",",/

To include a double quote mark in a DATA command you must use four sets:

80 DATA """"

90 READ x$

After line 90 has been executed x$ will have the value '"'

Examples:

DATA 1,2,3,5,7,11,13,17,19

DATA Peter,15, Clare,12, Robert,13, James,18, Alison,15

Syntax:

DATA [string] | [integer](,...)

See also:

READ, RESTORE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DATE$ read system date

DATE$ is used to read the date from the internal clock/calendar, and format it into a text string in the form DD-MM-YY. When I wrote this text on the 23rd of July 1990, PRINT DATE$ reported 23-07-90.

The date can also be obtained in integer format by using the individual functions DAY, DDAY, MONTH and YEAR.

DATE$ can also be used to change the system date.

Examples:

D$(I)=DATE$

Today$=DATE$

PRINT DATE$

DATE$ = "23-07-90"

Syntax:

[string-var] = DATE$

DATE$ = [string]

See also:

CLOCK$, TIME$, DAY, DDAY, MONTH, HOUR, MIN, SEC, YEAR

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DAY read/set day of week

DAY is used to read or set the 'day of week' on the internal clock/calendar.

When reading it returns an integer from 1 to 7, day 1 being Sunday. Similarly, when setting the day of week, the day number from 1 to 7 must be specified. An incorrect value will cause the current setting to remain unchanged.

Examples:

DAY=5

IF DAY=1 THEN Day$="Sunday"

PRINT DAY

Syntax:

DAY = [integer 1..7]

[num-var] = DAY

See also:

DATE$, DDAY, MONTH, YEAR

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DCD Data Carrier Detect

DCD is the RS232 signal used by modems to indicate that a connection has been established with a remote system. It is activated by the modem when a connection occurs, and is normally used as an output from the modem. However within the BASIC environment, it can also be used to read the connect status of modem port #3.

With port #1 or #2 the DCD command is used by the modem to control or read the status of the DCD line on the specified port. If no port is specified, the default port defined by OPORT will be assumed. The DCD signals of port 1 and port 2 are connected via hardware; thus DCD signals on both ports will influence each other, and it is impossible to set them separately.

With port #3 it is only possible to read the status. For example, the following command causes program execution to jump to the label %Connect2 if the DCD input on port 2 is active:

IF DCD#3 GOTO %Connect2

However, in order to detect incoming calls correctly using the DCD function, a program must continuously check the appropriate DCD signal in a loop, until its status changes from FALSE to TRUE. This is because a single DCD call gives only a momentary reading of DCD status. For this reason it is more efficient to use the ON CONNECT and ON HANGUP event handlers to achieve the same result.

It is sometimes necessary to control the use of DCD as an output from the modem - for example, where you have protected entry to your host computer by using auto-dial back from your modem. In this case, you would tell the computer that a connection has been established only after the user has been correctly identified and authorized to proceed. Before that you would keep DCD low, and your computer would not know that any communication was already going on. To keep DCD low on the ports while your modem is connected, AT&C has to be set first, and afterwards DCD has to be enabled by your program:

Examples:

Syntax:

See also:

DCD=1orDCDON will activate DCD

DCD=0orDCDOFF will clear DCD

IF DCD#3 GOTO %Connection

PRINT DCD#3

DCD=1

DCD OFF

[num-var] = DCD(#[port])

DCD = [integer 0..1]

DCD ON/OFF

DSR, ON CONNECT, ON HANGUP

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DDAY read/set day in month

DDAY is used to read or set the day within the month for the internal clock/calendar. When reading it returns an integer from 1 to 31. Similarly when setting, the day number from 1 to 31 must be specified; an incorrect value will cause the current setting to remain unchanged.

Examples:

DDAY=15

IF (DDAY=1 OR DDAY=21 OR DDAY=31) Suffix="st"

PRINT DDAY

Syntax:

DDAY = [integer 1..31]

[num-var] = DDAY

See also:

DATE$, DDAY, MONTH, YEAR

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DELETE / DEL delete program lines/files

The DELETE command, in its various forms, is used to delete lines from a program and to delete files from the disk filing system.

Deleting program lines

DELETE may be followed by two line numbers which define the range of lines to be removed. The command:

DELETE 50,100 or DELETE 50 TO 100

will remove all program lines from 50 to 100 (inclusive).

If the first parameter is omitted all lines from the start of the program to the specified last line will be deleted:

DELETE ,50

To delete a single line, just type the line number followed by [Return].

Labels can be used to specify the range in place of line numbers:

DELETE %Dial, %Dialend

Deleting files from the RAM-, FLASH- or Hard-disk

DELETE can also be used to remove files from the disk filing system. In this case the command is followed by !,FILE and/or a string.

To delete the program "TEST.PROG" you could alternatively use the following:

DELETE !"TEST.PROG"

DELETE "TEST.PROG"

DELETE FILE "TEST.PROG"

F$="TEST.PROG" : DELETE F$

To delete multiple files the '*' may be used as a wildcard character. Note however, that unread files will not be deleted by this form of the command, and a report will be printed of the number of files deleted and unread. For example, if there were 7 files with the suffix " MSG ", two of which were unread, the command:

DELETE "*.MSG"

would result in the following report:

2 Unread

5 Deleted

To delete unread messages the DELETE command must be followed by ',U ':

DELETE "*.MESS",U

After deleting files, the system variable MATCH holds the number of deleted files.

Examples:

DEL 10,200

DELETE %Search, 500

DEL "*.JOHN"

BASIC Programmer's Reference Manual

ARGUS Programmable Modem

DELETE "*.ANN",U

Syntax:

Program lines:

DELETE [line-num | label] TO|, [line-num | label]

RAM-, FLASH - or Hard-disk files:

DELETE (!/FILE) "[string]" ( ,U )

See also:

MATCH

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DIAL dial number

This command will dial a number for you. It is the same as ATD in modem mode, and is provided mainly to make your program easier to read.

After the command DIAL, the system variable RESULT can be read to determine the status of the modem (BUSY, NO ANSWER, CONNECT, etc.). When a successful modem connection is made, DCD#3 will be set. This can also be detected with the ON CONNECT event.

Examples:

DIAL TONE "2702719"

DIAL PULSE VIDICODE$

Syntax:

DIAL (TONE|PULSE) [string]

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DIM reserve space for arrays

DIM (short for dimension), is used to reserve space for single dimension arrays of integers or strings. The maximum number of elements allowed in integer arrays is theoretically 32767, but is in practice limited by the amount of memory available for variables after the program has been loaded. The limitation of a maximum string length of 254 bytes still current in the Argus Communicator has now been removed.

The command:

DIM A(100)

defines A as being an array of 100 integers (indexed from 0099); i.e. the first element is numbered 0. To access the fifth element use:

A(4)

Similarly:

DIM A$(8)

reserves space for the array A$ with 8 strings of up to 255 characters. The actual amount of space used by the array will depend upon the values assigned to the elements.

A very different use of the DIM command is to find and reserve free space in memory. If you need free space just enter:

DIM [num-var] [integer]

The number of bytes as given by the integer is reserved, and the numeric variable will point to the first location of the memory space reserved for you.

Examples:

Syntax:

DIM Names$(20) , ID$(5)

DIM Primes(10)

DIM A 256

DIM [num-var] ( [integer])(,...)

DIM [string-var] ( [integer 0..254])(,...)

DIM [num-var] [integer]

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DIR list file directory

The DIR command is used in its various forms to list and inform you about the contents of the RAM-disk.

Because of the need to retain compatibility with earlier versions of Argus BASIC, DIR might be followed by 'FILE' or '!'. This is optional however, and thus will not normally be used.

The DIR command will list files stored in the RAM-disk. The format and level of information given in the listing depends on the parameters used in the command. The following options are available:

DIR ([string]) standard listing

DIR ([string]),A All available information

DIR ([string]),B information Block listing

DIR ([string]),D standard listing plus file creation Date

DIR ([string]),F special File information listing

DIR ([string]),N file Names only listing

DIR ([string]),R Restricted listing

In each case the [string] parameter provides a template for filenames to be included in the listing. The asterisk, '*', can be used as a wildcard to match any valid character. If no [string] parameter is given, all files will be listed.

The formats of the various directory listings are as follows:

Standard

,B (Blocks)

,A (All)

,D (Date)

,F (special)

,N (Name)

,R (Restricted)

[FN] [Size] [Name+Ext]

[Information block contents]

[FN] [Name+Ext] [Date] [Time] [Read] [Type]

[FN] [Size] [Name+Ext] [Date] [Time]

[FN] [Size] [Name] [Date] [Read] [Info]

[Name]

[FN] [Size] [Name]

where the following definitions are used:

[FN]

[Size]

the file number

the number of 256-byte RAM disk blocks occupied by the file

[Name+Ext]

[Name]

[Date]

[Time]

[Read]

[Type]

the full name of the file (including extensions)

the first part of the file name (e.g. MESSAGE1)

the creation date of the file (DD/MM)

the creation time of the file (HH/MM)

R for Read, U for Unread

the type of file

After these options there are two more, which can always be added

,U (Unread only)

,M (more function)

The 'more' function will, after sending a screenful of lines, ask you for confirmation before it will send the next screenful.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

There are four possible file types:

: BASIC program

: Text file; created by RECEIVE ...,T

: binary file created by RECEIVE ...,X (X-MODEM or Y-MODEM)

The directory command lists files in date order, oldest first, and prints the number of free blocks remaining at the end of the list (not with DIR,N).

The command DIR, B is used to list the contents of the information block associated with the file. This block contains 32 bytes of application-dependent information and is terminated with [CR] (see SEND and RECEIVE for further information).

Directories are listed to the specified port, or if this is omitted, to the default output port as defined by OPORT.

Examples:

DIR, U

DIR, M

DIR#2

DIR#1 "*.MSG?", N

DIR !"LETTER"+VAL$(nn), D

DIR !A$

DIR FILE "PETE."+Ext$, N

Syntax:

DIR ( #[port] , ) (FILE|!) ( [string])(,[option] ) [option]=A|B|D|F|N|R|U|M

See also:

LOAD, SAVE, RECEIVE, SEND

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DIR ROM list ROM directory

The DIR ROM command is used to access the ROM or RAM disk in socket 2. The command is used in its various forms the same as listed in the DIR command.

However, to access a RAM disk in socket 2, the command CLEAR ROM must be entered first.

See also:

DIR, ROM

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DIV integer divide

The DIV command is used to carry out integer division operations. As the modem does not support 'real' numbers, DIV is exactly equivalent to division using the '/' operator.

Examples:

Result=XDIV5

Q1 = (Q2*4) DIV (Q3+2)

Syntax:

[num-var] = [integer] DIV [integer]

See also:

MOD

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DSR Data Set Ready

DSR is an RS232 signal used by modems to indicate that they are powered-up and ready to transfer data. DSR will be active dependant on the setting with the modem command &S. The signal is an output to the modem.

The DSR command is used to set or read the status of the DSR line on the specified port. When used for reading it returns TRUE if DSR is active, and FALSE otherwise.

Examples:

DSR ON

DSR=0

Status = DSR

PRINT DSR

Syntax:

DSR= [num-var]

DSR ON/OFF

[num-var] = DSR

See also:

DCD, DTR

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DTMF ON/OFF dial tone multiple frequency

DTMF ON turns on the DTMF receiver. Reading the first DTMF value and the command VOICE will also turn it on. Therefore, use of the command, is optional.

DTMF OFF turns off the DTMF receiver.

In most cases, the modem has 2 DTMF receivers build in. They can be selected with S-register 23 bit6 as follows:

SREG23=SREG23 AND &BF : Select External DTMF-chip (default)

SREG23=SREG23 OR &40 : Select Modem-chip

Example:

DTMF ON

Syntax:

DTMF ON | OFF, VOICE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

[var] = DTMF read DTMF receiver

Reading this function will return 0 or an ASCII number. When it is used for the first time, it will also turn on the DTMF receiver.

Values: 0 = No DTMF detected 48 = '0' detected 49 = '1' detected 50 = '2' detected 51 = '3' detected 52 = '4' detected 53 = '5' detected 54 = '6' detected 55 = '7' detected 56 = '8' detected 57 = '9' detected 42 = '*' detected 35 = '#' detected 65 = 'A' detected 66 = 'B' detected 67 = 'C' detected 68 = 'D' detected

Examples:

Syntax:

See also:

PRINT DTMF

Var=DTMF

REPEAT D=DTMF : UNTIL D

IF DTMF=52 GOTO %TONE4

[var] = DTMF

DTMF ON/OFF, PLAY [filename], VOICE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DTR Data Terminal Ready

DTR is the RS232 signal used by data terminals - also (host-) computers - to indicate that they are powered up and ready to transfer data. The modem will automatically control the response to DTR according to the instructions given with the modem command &D.

The DTR function is used to read the status of this signal on the specified port. If no port is specified the default port defined by IPORT will be assumed.

We would suggest that if you wish to make use of the DTR signal from within your BASIC application, you disable the automatic response to DTR.

For enabling or disabling the automatic response (and also the ON DTR and ON DTD events), we suggest that you use the modem commands &D0 and &D1,&D2,&D3.

Examples:

PRINT DTR

IF DTR Welcome_User

X=DTR

Syntax:

See also:

[num-var] = DTR ( #[port] )

CTS, DCD, DSR, RTS

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

DUTCH select language and screen mode

The command DUTCH will, like ENGLISH, select the language for the few written messages that are part of the system. The reason for this is that these messages will also occasionally be sent over the telephone line to remote users. This is especially the case when the modem is used as an electronic mail computer.

The 5 possible parameters behind DUTCH will have effect on the SEND,T and FAX SEND commands.

DUTCH <1>,<2>,<3>,<4>,<5>

<1> = 0-255 = Characters per Line (0=OFF) <2> = 0-255 = Lines per Page (0=OFF) <3> = 0/1 = No/Yes Left Margin <4> = 0/1 = No/Yes Page Fillout <5> = 0/1 = No/Yes Clear Screen (ASCII 12) after 'Verder'

Examples:

DUTCH

DUTCH 80, 23, 1, 0, 1

DUTCH 255, 66, 1, 1, 0

Syntax:

DUTCH ( [int 0..255] ), ( [int 0..255] ), ( [int 0..1] ), ( [int 0..1] ), ( [int 0..1] )

See also:

ENGLISH

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ECHO enable/disable character echo

ECHO is used to turn local character echo on or off. While in command mode or when using the INPUT or AT commands, characters received via the input port are echoed back so that the sender can see what has been received (or, in the case of a terminal, what he is typing). This is known as local echo. If both the modem and the user's terminal provide echo in this way, the user will see two of everything he types, and echo should then be disabled on either the modem or the terminal.

Examples:

ECHO ON

ECHO OFF

Syntax:

ECHO (#[PORT],) (#...,) ON|OFF

See also:

AT, INPUT, RECEIVE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

END end of program

The END command is used to terminate program execution and return to command mode. For example:

50 Ch$=GET$

60 IF Ch$="Q" or Ch$="q" THEN END

END is also used in conjunction with the TIMEOUT command to indicate the end of a timeout subroutine.

Example:

END

Syntax:

END

See also:

ON TIMEOUT, STOP

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ENGLISH select language and screen mode

The command ENGLISH will, like DUTCH, select the language for the few written messages that are part of the system. The reason for this is that these messages will also occasionally be sent over the telephone line to remote users. This is especially the case when the modem is used as an electronic mail computer.

The 5 possible parameters behind ENGLISH will have effect on the SEND,T and FAX SEND commands.

ENGLISH <1>,<2>,<3>,<4>,<5>

<1> = 0-255 = Characters per Line (0=OFF) <2> = 0-255 = Lines per Page (0=OFF) <3> = 0/1 = No/Yes Left Margin <4> = 0/1 = No/Yes Page Fillout <5> = 0/1 = No/Yes Clear Screen (ASCII 12) after 'More'

Examples:

ENGLISH

ENGLISH 80, 23, 1, 0, 1

ENGLISH 255, 66, 1, 1, 0

Syntax:

ENGLISH ( [int 0..255] ), ( [int 0..255] ), ( [int 0..1] ), ( [int

0..1] ), ( [int 0..1] )

See also:

DUTCH

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

EOR logical Exclusive OR

EOR performs a bitwise logical 'Exclusive OR' operation on two numeric values; i.e. each bit of the first operand is Exclusive ORed with the equivalent bit in the second operand. The result of 12 EOR 5 is therefore calculated as follows:

operand1 12 = 00000000 00001100

operand2 5 = 00000000 00000101

result 9 = 00000000 00001001

The most common use of EOR is to toggle a bit value within an item of data. For example, to toggle the state of user port line 5 you would use:

OLINE(5) = OLINE(5) EOR 1

If the state of the line was previously high, the command is the same as:

1 EOR 1

which gives 0 - i.e OLINE(5) goes low.

If OLINE(5) was already low, the command is the same as:

0 EOR 1

which gives 1 and sets OLINE(5) high.

Examples:

Syntax:

See also:

DCD=DCD EOR 1

PRINT 15 EOR 4

[num-var] = [integer] EOR [integer]

AND, OR, NOT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ERL error line

ERL is a system variable that contains the number of the line that is currently being executed. As a result of this, when an error occurs, ERL contains the line number in which the error occurred. Therefore you should be careful. ERL should be stored or printed in the first line of the error handler routine.

Examples:

ON ERROR PRINT ERL

ON ERROR PRINT "Program halted due to error at

line ";ERL : STOP

Syntax:

[num-var] = ERL

See also:

ERN, ON ERROR, REPORT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ERN error number

ERN is a system variable that contains the number of the last error that occurred. A complete list of error messages and the associated codes generated by the Argus BASIC interpreter is given in the Error Messages section of this manual.

ERN is also an important variable for the filing system.

Example:

PRINT ERN

Syntax:

[num-var] = ERN

See also:

ERL, ON ERROR, RECEIVE, REPORT, SEND

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

ESCAPE set Escape character

The ESCAPE command is used to define the ASCII character that the modem treats as an 'Escape' code (this is only sometimes related to the [Esc] key on your keyboard). An Escape is used to interrupt the execution or listing of a program.

The default value for ESCAPE is [Ctrl-C].

For instance, to use ASCII character 04 ( [Ctrl-D] ), as the ESCAPE character you would use the command:

ESCAPE=4

On reception of the ESCAPE character, error number 3 will be generated and any pending ON ERROR routine will be executed. All I/O buffers will be emptied, all RTS lines will be activated, and all output buffers will be enabled.

There can be only one escape character for all ports at any time.

Escape recognition can be disabled using ESCAPE OFF, and is re-enabled using ESCAPE ON. Enabling and disabling of escape recognition can be per port. When no port number is specified, the default port as defined by OPORT will be assumed. In any other case you must specify the port; e.g. ESCAPE#3 OFF.

After pressing the STOP button, the Escape character for each port will be reset to [Ctrl-C], with handling of ESCAPE characters being enabled for port 1, and disabled for all other ports.

Examples:

Syntax:

ESCAPE 3

ESCAPE=27

ESCAPE#1,#2,#3,1

ESCAPE ON

ESCAPE ( #[port], ) (#...) (=) [integer 1..128]

ESCAPE ( #[port], ) (#...) ON|OFF

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FALSE Boolean system variable

FALSE is a system variable which returns the value 0, and it is used in many logical operations to make programs more readable. A further advantage of using FALSE (in the correct context), is that it uses only 1 byte of storage, whereas the integer 0 occupies 2 bytes.

Examples:

Ready=FALSE

REPEAT ... UNTIL FALSE

IF X=FALSE

Syntax:

[num-var] = FALSE

See also:

NOT, TRUE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FAX MODEM ON/OFF enable/disable selector

This is used in the programming environment to enable/disable the Fax <> Modem selector. Same as AT "*F3".

The selector is used during the first stage after answering a call. It will wait some time for a Fax or Modem Calling Tone (1100 or 1300 Hz). Default 5 seconds is waited and this can be changed by setting SREG62 per 100 ms. If no Calling Tone is ‘seen’ the modem continues as a Fax (bit0 in SREG62 is 0) or as a modem (bit0 in SREG62 is 1).

Example:

ON HANGUP FAX MODEM ON

Syntax:

FAX MODEM [ON|OFF]

See also:

ANSWER, FAX

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FAX ON/OFF turn FAX on or off

With FAX ON the modem will wait for an answer tone after dialing and then return with result code 19 (=ESCAPE). The FAX SEND and FAX RECEIVE commands will both automatically set FAX ON. With FAX OFF the modem tries to connect as a modem.

Examples:

FAX ON

DIAL TONE "123456"

IF RESULT=19 GOTO Continue ELSE GOTO Error

Syntax:

FAX [ON|OFF]

See also:

FAX SEND, FAX RECEIVE

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FAX RECEIVE receive fax

The FAX RECEIVE command is a powerfull tool that allows the Argus to receive a fax directly onto the disk filing system. Before using the FAX command a RAM buffer of at least 1024 bytes big must be defined with the BUFFER command.

The FAX RECEIVE command consists of three parts.

FAX RECEIVE [file]

Filename can have a maximum of 10 characters. No wildcards are allowed. After connecting, a file is stored which starts with page number '01'. Also the resolution is added to the file name. Example:

FAX RECEIVE "test"

will receive file 'TEST.01.S' or ('TEST.01.F') next page 'TEST.02.S' or ('TEST.02.F') etc.

There is 1 exceptions on the file name, namely when the name starts with a '#' (hash):

FAX RECEIVE "#"

the modem will first connect and then send all the received G3 data through the fax printer driver. It will then be printed out on the printer on port 1, port 2 or port 7 (depending on OPORT).

FAX RECEIVE [file], [option]

These are the same options as for FAX SEND. The ',U' and ',T' and ',N' options have no effect.

If you only want to receive in standard resolution you can add ',S'. Example:

FAX RECEIVE "test",S

If you add ',F', it depends on the sending fax whether it will be received as a standard or fine resolution file.

The speed register (S51) can also be set to ensure reception at a known speed. If it is set at 0 (S51=0) then the highest speed, after negotiation with the other fax machine, is used.

During the handshaking process, the two faxes exchange their ID's. The ID numbers are strings with a maximum length of 20 characters and may only contain numbers and the characters '+' and '-'. The ID of the sending fax machine will be stored at address &2950 after leaving the FAX RECEIVE command, while your own ID must be stored at address &2970 before executing the FAX RECEIVE command. The commands POKE$ and PEEK$ are used to write and read the ID strings.

FAX RECEIVE [file] TO [number]

A number can be added in a special case, namely polling. Example:

FAX RECEIVE "test" TO "01223-1227"

The modem will dial up another fax machine and will look for a ready to send document (polling). If there is a document it will receive it and store it in the usual way.

See also:

ERN, FAX SEND, MATCH, RESULT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FAX SEND ...TO... send fax

The FAX SEND command is a powerfull tool that allows the Argus to send a fax from the disk filing system. Before using the FAX command a RAM buffer of at least 1024 bytes big must be defined with the BUFFER command.

The FAX SEND ... TO ... command consists of three parts.

FAX SEND [file]

The file name can be any name up to 16 characters long. If the file name is 10 characters or less, the system will automatically add ".01*.*" as the first page number. If found, the sending continous with ".02*.*", ".03*.*", etc until no more files/pages are found. Example:

(file) = "TEST" will send 'TEST.01'

'TEST.02'

etc.

'TEST.01.S'

'TEST.02.S'

etc.

If the file name is more than 10 characters long OR a wildcard is used (* or ?), the system just sends the matching files, without adding page numbers. If you are using wildcards in the file name, many files can be sent with one command. Example:

(file) = "TEST*.*" will send 'TEST'

'TEST1'

'TEST999'

'TEST-ALL'

'TEST-TEXT.01'

'TEST-TEXT.02'

'TEST-BIN.S'

'TEST-BIN.F'

'TEST.T'

'TEST50.01.T'

When a file name ends with '.T ' or nothing, it will be treated as a text-file. Convertion to G3 format is done on the fly during sending.

When a file name ends with '.S ' it will be treated as a Standard resolution G3 file. Standard resolution can not be converted to Fine resolution by the modem!

When a file name ends with '.F ' it will be treated as a Fine resolution G3 file. Fine resolution is automatically converted to Standard during sending if the receiving fax doesn’t support Fine or if sending is fixed to Standard.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

When a file name ends with ‘.G‘ it will be treated as a G3 file with an unknown resolution. How the file is sent depends on the negotiation of the 2 fax machines and on the way the resolution is set with S-register 17.

Page numbers can be maximum of '.99' (after that it will continue with '.AO', '.A1', .....til '.Z9').

FAX SEND [file], [option]

Some options can be added to the command:

,U ,S ,F ,T ,N

; Unread files only ; Send in Standard resolution only ; Send in Fine resolution only ; Include Top Line and strip lines of a '.F' or '.S' file ; Don't send Top Line and don't strip from a G3 file

Examples:

FAX SEND Text$,U,T,S TO Tel$

FAX SEND Text$,N TO Tel$

FAX SEND Text$,F TO Tel$

These options can also be selected by S-register 17:

S17 ; Fax flags

b7 b6 b5 b4 b2+b3 b0+b1

=0/1= Fax connection disabled/enabled (FAX OFF/ON) =0/1= No/Yes send own Top Line (,N/,T) =0/1= Standard/Fine resolution (,S/,F) =0/1= No/Yes strip Top Line of bin file (,N/,T)

= Select line-time: 0,10,20,40 ms = Don't alter (not for faxing)!

Stripping the Top Line from a G3 file will remove the first 16 (Standard) or 32 (Fine) scan-lines during the sending of that file. This is equal to 2 text-lines when compared to a text-fax. Adding your own Top Line is enabled by setting bit6. Bit7 is automatically set/cleared by the system when using the FAX command. Selecting the line-time is only used when receiving faxes and normally doesn’t have to be changed.

After '&F ' the register is set on 83, which means:

Standard resolution and Top Line included (,S,T).

The speed at which the modem is transmitting depends on S-register 51. It also depends on the negotiation with the other fax-machine.

S51=0 S51=11 S51=7 S51=5 S51=6

S51=28

S51=29

; Transmit at highest speed possible after negotiation ; Transmit at 9600 (V29) only ; Transmit at 7200 (V29) only ; Transmit at 4800 (V27ter) only ; Transmit at 2400 (V27ter only

; Transmit at 14400 (V17) only

; Transmit at 12000 (V17) only

The V17 speeds can be disabled (excluded from the negotiation) by setting bit3 in S-register 23 (SREG23=SREG23 OR

8). After sending or receiving a fax, the used speed can be read from S-register 50 (X=SREG50).

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

During the handshaking process, the two faxes exchange their ID's. The ID numbers are strings with a maximum length of 20 characters and may (officially) only contain numbers and the characters '+' and '-'. The ID of the receiving fax machine will be stored at address &2950 after leaving the FAX SEND command, while your own ID must be stored at address &2970 before executing the FAX SEND command. The commands POKE$ and PEEK$ are used to write and read the ID strings.

The top line text must be stored at address &2990. This text is a string with a maximum length of 100 characters and can be written and read using the commands POKE$ and PEEK$.

FAX SEND ... TO [number]:

This can be a telephone number. A 'D' (Dial) is automatically put in front of the string, and is treated as a normal 'ATD' command. Examples:

FAX "TEXT" TO "0-123456"

FAX "TEXT" TO "T018282"

FAX "TEXT" TO "p0w111111"

If the modem is already on-line, then this string will be ignored.

There are three (3) special cases:

When the command starts with a less than sign ("<"):

After dialing, connecting and sending the file(s), the modem will not stop sending, but will return with result code 19 (= ESCAPE). A second FAX-command can then be given and sending will continue with another file on the same page. This is especially useful for adding footers.

When the command starts with a greater than sign (">"):

After dialing, connecting and sending the file(s), the modem will not stop sending, but will return with result code 19 (= ESCAPE). First, however, it will end its current page and start a new page on the other fax-machine. A second FAX-command can then be given and sending will continue with another file on a new page. This is especially useful for adding documents.

When the command starts with a hash ("#"):

The converted fax data is now routed through the fax printer driver. It will then be printed out on the port selected by OPORT. No dialing is needed or done. For example:

FAX SEND "TEXTFILE" TO "#"

Program example:

FAX ON ; DIAL Tel$ ; IF RESULT<>19 GOTO Err ; FAX Head$ TO "<" ; IF RESULT<>19 GOTO Err ; FAX Text$ TO "<" ; IF RESULT<>19 GOTO Err ; FAX Foot$ TO ">" ; IF RESULT<>19 GOTO Err ; FAX Dcmt$ TO "" ; IF RESULT GOTO Err ;

Enable fax connection Dial number and wait for Answer tone Result = ESCAPE (Answer tone found)? Go back on-line, connect/negotiate and send header Successful so far? Go back on-line, and continue sending text file on same page Still successful? Go back on-line and continue sending footer on same page Still successful? Go back on-line and continue sending document on next page Overall successful?

There are 3 system variables which can be read or checked after the FAX SEND/RECEIVE command: MATCH, RESULT and ERN.

MATCH is a function which acts as a counter:

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

After FAX SEND, it contains the total number of files sent.

After FAX RECEIVE, it contains the number of pages received.

RESULT is a function which holds the status of the last modem activity:

RESULT = 0 OK RESULT = 2 RING RESULT = 3 NO CARRIER RESULT = 4 ERROR

: Sending or Receiving was successful : File not found with FAX SEND (special case) : Initiate handshake with other fax has failed : No confirmation from other fax after sending a page or

failure during receiving a page

RESULT = 6 NO DIALTONE RESULT = 7 BUSY

: No dialtone found before dialing out : Other fax found busy after dialing out or disk is full during

receive (special case)

RESULT = 8 NO ANSWER RESULT = 18 OFF-HOOK

: No answer (answer tone) found after dialing out : Modem is not connected to telephone system or line is

already in use

RESULT = 19 ESCAPE RESULT = 20 VOICE

: Used when sending, meaning 'continue' : Human voice (or much noise) found after dialing

ERN is only set when a filing system error has occured:

ERN = 0 OK ERN = 22 Out of memory ERN = 73 Not found

: No error : Disk is (became) full during FAX RECEIVE : File not found during FAX SEND <filename> RESULT

is set to 2 also in this case

The only real BASIC errors which can occur are:

'No filing system' 'No fax system' 'No/Bad BUFFER'

: No filing system ROM available : No fax system ROM available : No or too small RAM buffer is defined (must be at least BUFFER &400, 1k bytes, 1024 bytes)

Sending TEXT faxes

ASCII text files are converted to G3 format on the fly. The output on the remote fax machine depends on the 4 parameters set with the DUTCH or ENGLISH command:

1. Characters per line:

0 = Word Warp disabled, 10 chars/inch, max. 80 chars on a line 1-88 = Word Wrap enabled, 10 chars/inch, max. 80 chars on a line 89-112 = Word Wrap enabled, 12 chars/inch, max. 96 chars on a line 113-254 = Word Wrap enabled, 17 chars/inch, max. 136 chars on a line

Word Warp means that a whole word is started on a new line if it doesn’t fit on the current line. A new line is always generated after a character with the value equal to S-register 3 which defaults to control-character 13 (=Cariage Return). All characters with a value equal to S-register 4 are ignored; default control-character 10 (=Line Feed).

2. Lines per page:

The maximum number of lines per page can be set with this parameter. If more lines are in the file, then a new page is negotiated first with the remote fax before sending continues. For standard A4 format this parameter must be set to 68 if the top line is enabled or 70 if the top line is disabled.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

Setting this parameter to 0 will disabled the automatic page-break generation. A new page is also forced if the file contains a control-character 12 (=CTRL-L=Form Feed). If a control-character 26 (=CTRL-Z=End Of File) is encountered the sending stops.

3. Left margin:

Enabling the left margin will add some spaces in front of a line, if that line is less than 80, 96 or 136 characters.

4. Page fillout:

Enabling the page fillout will fill the page with empty lines on the bottom until the ‘lines per page’ is reached. This is done before starting a new page and at the end of the file.

For use inside a text file, a few embedded commands are recognized:

@D+

= Use 12 chars/inch

@D-

= Use 10 chars/inch

@C+

= Use 17 chars/inch

@C-

= Use 10 chars/inch

@I+

= Use 8 lines/inch vertical

@I-

= Use 6 lines/inch vertical (default)

@B+

= Bold on

@B-

= Bold off

@U+

= Underlined on

@U-

= Underlined off

See also:

ERN, FAX RECEIVE, MATCH, RESULT

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FOR ... (TO) ... (NEXT) ... (STEP) loop structure

The Argus BASIC FOR ... NEXT loop construct is very similar to that used in most versions of BASIC, and allows a sequence of commands to be executed a fixed number of times depending upon the value of a 'loop variable'.

For example:

10 PRINT "Start"

20 FOR X=1 TO 10 : PRINT X;" "; : NEXT X

30 PRINT "End"

will display:

Start

12345678910

End

i.e. the first time the FOR command is encountered, the numeric variable X is set to 1 and printed. The loop is then repeated, X being incremented to 2 and printed again. This procedure is repeated until X is 10, after which line 30 is executed and the program ends.

By default, the loop variable X, is incremented by 1, but this can be changed by including the optional STEP clause in the

FOR command:

10 PRINT "Start"

20 FOR X=1 TO 10 STEP 2 : PRINT X;" "; : NEXT X

30 PRINT "End"

Here, X is incremented by 2 each time the loop is executed, so only the numbers 1, 3, 5, 7, 9 are printed.

More complicated loops can be constructed by including multiple commands between FOR and NEXT:

50 FOR X=1 TO 5 : PRINT X : PRINT X*X :

PRINT X*X*X : NEXT X

This program line prints X, the square of X and the cube of X for each value of X between 1 and 5. The number of commands executed is limited only by the maximum line length of 255 characters.

Up to sixteen FOR ... NEXT loops can 'nested' within each other, each operating on a different loop variable:

FOR A=1 TO 10 : FOR B=5 TO 15 :

PRINTA+B:NEXT B : NEXT A

Here, there are two loops. This example could in fact be shorter (and more efficient) by combining the two NEXT commands:

FOR A=1 TO 10 : FOR B=5 TO 15 :

PRINTA+B:NEXT B, A

It is also possible to omit the variable following NEXT completely; in which case the variables are incremented innermost first. The example above would then become:

FOR A=1 TO 10 : FOR B=5 TO 15 :

PRINTA+B:NEXT ,

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

The trailing comma in this example is necessary to ensure that the outer NEXT loop variable is incremented.

Examples:

FOR Code = 32 TO 126 : PRINT CHR$(Code) : NEXT

FORX=0TO-10STEP -2 : PRINT X : NEXT

Syntax:

FOR [num-var] = [integer] TO [integer] (STEP [integer]) : [command] :

.... NEXT ([num-var]) (,)

See also:

REPEAT ... UNTIL, WHILE ... WEND

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

FREQ frequency measurement

The frequency of the signal on the telephone line is permanently measured by the modem. When the modem is off-hook, the command FREQ will read this value. This is only useful for specialist applications; but we can think of some very special ways of using it for access control of your computer.

The value is updated every 100ms by the operating system. Reading the value faster than 100ms will return the last/same values and has no use.

Examples:

PRINT FREQ

Tone = FREQ

Syntax:

[num-var] = FREQ

See also:

ADC

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

GET get byte (with wait)

GET is used to obtain the next byte from the specified input buffer, and returns an integer between 0 and 255. Program execution is suspended until data becomes available. If no port is specified, the default input port as defined by IPORT is assumed.

Examples:

Code=GET

Char=GET#1

REPEAT UNTIL GET=13

PRINT GET#2

Syntax:

[num-var] = GET ( #[port] )

See also:

GET$, KEY, KEY$

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

GET$ get character (with wait)

GET$ is used to obtain the next character from the specified input buffer, and returns a 1-character string. Program execution is suspended until data becomes available. If no port is specified, the default input port as defined by IPORT is assumed.

Examples:

Ch$=GET$

A$=GET#2

REPEAT UNTIL GET$#2="Y"

PRINT GET$#4

Syntax:

[string-var] = GET$ ( #[port] )

See also:

GET, KEY, KEY$

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

GOSUB ... RETURN jump to subroutine

The GOSUB command causes program execution to branch to the specified line number or label. Execution proceeds from this line until a RETURN command is encountered, at which point execution resumes at the command immediately following the GOSUB. The section of code executed by the GOSUB is referred to as a subroutine, and may be executed any number of times within the program. For example:

10 PRINT "Main program start"

20 GOSUB 500

30 ...

400 END

500 PRINT "Now in subroutine"

510 WAIT 5

520 PRINT "Leaving subroutine"

530 RETURN

In many versions of BASIC, subroutines are referred to by the line number of their first line, as in the example above. In Argus BASIC however, it is better to make use of the label facility, and precede each subroutine by a label that indicates the function of that routine. You could then rewrite the example as:

10 PRINT "Main program start"

20 GOSUB Demo

30 ...

400 END

500 %Demo

510 PRINT "Now in subroutine"

520 WAIT 5

530 PRINT "Leaving subroutine"

540 RETURN

Proper use of labels can make the main program much easier to read and understand. The use of % preceding a label with GOSUB is optional. Thus GOSUB Dial is identical to GOSUB %Dial.

A subroutine may also be called from within another subroutine, and up to sixteen calls may be 'nested' in this way.

Examples:

GOSUB 1000

GOSUB Dial

Syntax:

GOSUB [line-num | label]

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

See also:

ON GOSUB

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

GOTO unconditional jump

GOTO causes an unconditional branch to the specified line number or label.

Examples:

GOTO 70

GOTO %Check_Password

Syntax:

GOTO [line-num | label]

See also:

ON ... GOTO, GOSUB

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

HANDSHAKE select/enable handshaking

HANDSHAKE is used to select the action taken when an input buffer is almost overflowing during receipt of data. Correct selection of the type of handshaking to be used is necessary to avoid loss of data.

Each port on the modem has a 256-byte input buffer. When characters are received at a higher speed than they can be processed, the input buffer will gradually fill. In order to avoid loss of data due to input buffer overflow, when there are only 5 bytes left free in a buffer, the modem will check to see if a handshake protocol has been selected; and if it has will take the appropriate action as follows:

RTS/CTS selected:

The modem will take CTS low until the input buffer is half empty and then take CTS high again to restart ÿransmission.

XON/XOFF selected:

The modem will send an XOFF character to the remote system, wait until the input buffer is half empty, and then send an XON character to restart transmission.

To select the type of handshaking used there are two commands:

HANDSHAKE CTS

and

HANDSHAKE XOFF

which select hardware or software handshaking respectively.

It is also possible to use both software and hardware handshaking at the same time. Use:

HANDSHAKE CTS,XOFF

A further command is used to disable the previously selected handshaking method:

HANDSHAKE OFF

Each of these commands can specify the appropriate port. If no port is specified, the default input port as defined by IPORT will be assumed. Note that the modem will always obey the RTS/CTS handshake protocol on ports defined as outputs.

Handshaking via LINKed ports

The situation becomes more complex when ports have been connected using a LINK command.

To visualize this situation, assume that ports 1 and 2 are LINKed, and that the two character streams are crossed; i.e. all characters received by port 1 are sent to the port 2 output buffer, and all characters received by port 2 are sent to the port 1 output buffer.

Assume also that port 1 is operating at a higher baud rate than port 2 (e.g. 9600 vs. 1200). All characters received via port 1 will be re-transmitted via port 2 at a lower speed, so that the output buffer for port 2 will gradually fill up. When it is almost full, port 1 should take steps to stop the receipt of data by either issuing an XOFF to the connected system, or by taking CTS low. To ensure that this happens, a further command is used:

HANDSHAKE LINK ON

To summarize, handshake should always be defined for input ports. Check always whether a linked port can cause the buffers of output ports to overflow. This is especially important when baud rate conversion is used.

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

The handshake of the input ports has to be set with the HANDSHAKE command. This is normally HANDSHAKE RTS. When the data stream on a linked port is not to be monitored by a program, then the command HANDSHAKE LINK OFF should be used.

The HANDSHAKE command may specify one or more port numbers, but if these are omitted, the default port as defined by OPORT will be assumed.

After the STOP button has been pressed, HANDSHAKE RTS will be set for each port, and HANDSHAKE LINK will be set to OFF.

Note that the XON and XOFF characters can be configured using the XON and XOFF commands.

Examples:

HANDSHAKE RTS

HANDSHAKE#1,#2,XOFF

HANDSHAKE#3,OFF

HANDSHAKE LINK OFF

HANDSHAKE#1,#2,LINK ON

Syntax:

See also:

HANDSHAKE #[port] (, #...) CTS|XOFF|OFF

HANDSHAKE #[port] (, #...) LINK ON|OFF

LINK, RTS, XOFF, XON

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

HANGUP disconnect a call

HANGUP is used to terminate a call and is identical to the command HOOK ON and the modem command AT "H0".

The command itself will not cause an ON HANGUP event.

HANGUP will also put the modem-chip in sleep-mode, if bit6 in S-register 64 is set (see RESET MODEM 2).

Examples:

HANGUP

MATCH#3 "ABC" , 10 : IF MATCH HANGUP

Syntax:

HANGUP

See also:

ANSWER, CONNECT, ON HANGUP, RESET MODEM 2

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

HOOK hook control

HOOK is used to control the modem relay that puts your modem on-line.

HOOK OFF is the same as the modem command ATH1.

HOOK ON is the same as the command HANGUP and the the modem command ATH0.

HOOK on its own can be used to toggle between the two states of the relay.

Examples:

HOOK

HOOK OFF

HOOK ON

Syntax:

HOOK (ON|OFF)

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

HOUR read/set hour of day

HOUR is used to read or set the hour of day on the internal clock/calendar.

The clock uses the 24 hour system, so that when reading, HOUR will return an integer from 0 to 23.

Similarly, when setting, the hour number from 1 to 23 must be specified; an incorrect value will cause the current setting to remain unchanged.

Examples:

HOUR=14

IF HOUR > 12 THEN D$="PM" ELSE D$="AM"

PRINT HOUR

Syntax:

HOUR = [integer 0..23]

[num-var] = HOUR

See also:

CLOCK$, MIN, SEC, TIME$

ARGUS Programmable Modem

BASIC Programmer's Reference Manual

VidiCode ARGUS BASIC User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
