Videocon V1517 User Manual

1

1 General Information

Legal Notices

All rights reserved. Reproduction, transfer, distribution or storage of
part or all of the contents in this document in any form without the prior
written permission of VIDEOCON is prohibited.
VIDEOCON operates on a policy of continuous development.
VIDEOCON reserves the right to make changes and improvements to
any of the products described in this document without prior notice.
Under no circumstances shall VIDEOCON be responsible for any loss
of data or income or any special, incid

ental, consequential or indirect
damages howsoever caused.
The contents of this document are provided as it is. Except as required
by applicable law, no warranties of any kind, either deselected or
implied, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document.
VIDEOCON reserves the right to revise this document or withdraw it at
any time without prior notice.
The availability of particular products may vary by region. Please check
with VIDEOCON Executive.

Software Update Information

To enhance device performance, we recommend that you get in touch
with the nearest VIDEOCON Authorized Service Center, regarding the
availability of updated firmware for your device. Please see the
enclosed Service Center Directory for the VIDEOCON Authorized
Service Center nearest to your location.

Safety Precautions

Please comply with these precautions to avoid putting yourself or other
around you in a dangerous or illegal situation, and ensure peak
perf

ormance of your device.

Icon Description

ROAD SAFETY

Do not use your phone while driving.

INTERFERENCE

All wireless devices could affect your device
performance.

2

HOSPITALS

Switch off your device near hospitals and medical
equipment.

AIRCRAFT

Switch off your device in aircraft. Wireless devices
can cause interference in aircraft.

REFUELLING

Switch off the device when refueling. Do not use the
device at refueling point.

BLASTING AREAS

Switch off the device near blasting areas.

USE SENSIBLY

Use in normal condition, as explained in the User’s
manual. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair phone.

BATTERIES

Use only approved batteries. Do not connect
incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

Important safety measures

Your phone is designed t o comply with all the necessary precautions
and requirements and should be treated with care. The suggested safety
measures will help you to use this product without causing you any
health hazards.
x When buying a cell phone, make sure it has a low SAR (Specific

Absorption Rate).

x Use a wireless hands-free system (headphone, headset) with a low

power Bluetooth emitter.

x Either keep calls short or send a SMS instead. This advice applies

especially to children, adolescents and pregnant women.

x Whenever possible, only use cell phone when the

signal quality is

good.

x People having active medical implants should keep their cell phone

at least 15cm away from the implant.

3

Specific Absorption Rate (SAR)

Your phone meets the SAR requirements for exposure to radio waves,
recommended by Govt. of India. Your mobile phone is a radio
transmitter and receiver. It is designed and manufactured so as not to
exceed the limits for exposure to radio-frequency (RF) energy, as
recommended by the Govt. of India. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The limits include a substantial safety
margin designed to ensure the safety of all persons, regardless of age
and health.
The exposure standard for mobile phones employs a unit of
measurement known as SAR (Specific Absorption Rate). The SAR
limit recommended by the Govt. of India is 1.6 Watt/kg taken over a
volume containing a mass of 1 gram of tissue.
The highest SAR value for V1517 is 1.362 W/Kg. Press *#07# to check
the SAR value on your phone display.

Disclaimer

Some applications accessible through your mobile belong to third
parties and are protected by copyright, patent, trademark and/or other
intellectual property laws. Those applications are provided solely for
your personal noncommercial use. You may not use any application in a
manner that has not been authorized by the application owner or
provider.
Without limiting the foregoing, unless expressly authorized by the
applicable content owner or service provider, you may not modify, copy,
republish, upload, post, transmit, translate, sell, create derivative works,
exploit, or distribute in any manner or medium any content or services
displayed through this device.
“Third party content and services are provided “as is.” VIDEOCON
does not warrant content or services so provided, either expressly or
impliedly, for any purpose. VIDEOCON expressly disclaims any
implied warranties, including but not limited to, warranties of
merchantability or fitness for a particular purpose. VIDEOCON does
not guarantee the accuracy, validity, timeliness, legality, or
completeness of any content or service made available through this
device and under no circumstances, including negligence, shall
VIDEOCON be liable, whether in c ontract or tort, for any direct,

4

indirect, incidental, special or consequential damages, attorney fees,
expenses, or any other damages arising out of, or in connection with,
any information contained in, or as a result of the use of any content or
service by you or any third party, even if advised of the possibility of
such damages.”
Third party services may be terminated or interrupted at any time, and
VIDEOCON makes no representation or warranty that any content or
service will remain available for any period of time. Content and
services are transmitted by third parties by means of networks and
transmission facilities over which VIDEOCON has no control. Without
limiting the generality of this disclaimer, VIDEOCON expressly
disclaims any responsibility or liability for any interruption or
suspension of any content or service made available through this
device.
VIDEOCON is neither responsible nor liable for customer service
related to the content and services. Any question or request for service
relating to the content or services should be made directly to the
respective content and service providers.

E-Waste Management

What is E-waste?

x 'E-waste' means waste electrical and electronic equipment (WEEE).

How harmful is e-waste?

E-wastes are considered dangerous, as certain components of some
electronic products contain materials that are hazardous, depending on
their condition and density. If improperly disposed, they can leach lead
and other harmful substances into soil and groundwater.
Govt. of India vide notification dated May 12, 2011 has announced
E-waste (Management and Handling) Rules, 2011 (“Rules”).
According to these Rules, the consumer now has the legal responsibility
to dispose of the waste electrical and electronic equipment (popularly
known as “WEEE”) in the prescribed manner and not by just throwing it
into a dustbin or giving/selling it to scrap dealer.
V RECYCLE , is an initiative by Videocon where we recycle your old

5

and no longer useful phones.
There are 3 easy steps to begin playing your part:
Step 1: Grab your old and useless phone (or its accessories).
Step 2: Locate a Videocon Collection Point near you, available at
http://www.videoconmobiles.com/v-recycle.htm
Step 3: Drop your old phone into the designated collection boxes.
Lets join hands today to celebrate the glory of nature earth & help in
making it a better & healthier place for all of us.

2 Before Use

SIM card

Before using the mobile phone, you should insert the valid SIM card,
which is the key for you to enter the GSM network.
All the information related to the creation of the connection to the
network and initial call records will be recorded in the metal plane area
of the SIM card as well as the names, telephone numb

ers and SMS
stored in the phone book on the SIM card. The SIM card can be taken
out from your mobile phone and can be placed in any one of the GSM
mobile phones for use (the new mobile phone will read the SIM card
automatically).
To prevent losing and damaging of the information in the SIM card,
please DO NOT touch the metal plane area and the SIM card should be
kept far away from electromagnetism. Once the SIM card is damaged,
you can not enter into the GSM network.

*Note: Please do power off your mobile phone before pulling out the
SIM card. It is forbidden to insert or pull out the SIM card with the
mobile phone connected to the external power supply; otherwise, the
SIM card is most likely to be damaged.

Insert and pull out the SIM card

6

The SIM card is generally placed in a card. Before installation, take
cautions to take out the SIM card.
Power off your mobile phone and then remove the battery and other
external power supply.
Insert the SIM card into the SIM card slot.
When you need to pull out your SIM card, please power off your
mobile phone firstly, remove the battery, pull out your SIM card

Battery

The initial battery is of 50% charge, so it can be used right after
being unpacked. The new battery should be charged at least for 14
hours. Only when the initial battery is exhausted thoroughly (the
electricity quantity runs out and the mobile phone can not power on)
can the battery be fully recharged for use, so does the second time
charging. Only when recycled for three times in this way can the
battery works in the best condition easily.

Pull out and install the battery

Follow the following steps to pull out the battery: Open the
back cover;

Pull the battery upwards and get it out.
Follow the following steps to install the battery: Insert the
battery into the battery slot;

The back cover until it fastens.

Charge the Battery

Connect the batter charger to a power supply;
USB interface at the bottom of the charger plug into the phone.
Then the power quantity indicator in the upper right corner of the
mobile phone screen will flicker. If the phone has been powered off,
the screen will display “charging” and this indicates that the battery
is being charged. If the phone is still in use despite of lack of power,
the power indicator may take some time to appear on the screen.
If the power indicator is full and stops to flicker, this means that the
charge has been finished. This process often takes 3 to 4 hours. It is

7

normal that, during charge, the battery, mobile phone and battery
charger become hot.

¾ After the charge is completed, please disconnect the AC power

supply socket and the mobile phone with the battery charger.

*Note:

--During the charge, the handset should be placed where the
ventilation is good and the temperature is between +5

0

C to +400C.
In addition, you should use the charger provided by the
manufacturer, for the unauthenticated chargers may cause danger
and disobey the recognition and maintenance clauses of this mobile
phone.

--When your mobile phone automatically powers off or displays the
warning of “Low Power”, you should charge the battery in time. In
case the battery has not run out before charge, the mobile phone
will shorten the charge time automatically.

--The standby time and call time provided by the manufacturer is
based on the ideal working environment. During the practical use,
the battery’s service time changes with the network condition,
working environment and use mode used.

--Before charging the battery, please make sure that the battery is
properly inserted and it is forbidden to take it down during
charging. .

--When charge is over, please disconnect the charger with the mobile

phone and the battery.

If you do not disconnect the charger with the power supply and the
mobile phone, after a long time (about 5 to 8 hours), the power of
the battery will drop to a certain level and the mobile phone will
resume charge once again. We do not recommend you to do so, for
this will affect the performance and service life of the battery.

--This mobile phone does not support USB port, so you can not
connect your mobile phone with PC through USB, it just use to
charging the battery.

Power on

¾ Long press Hang Up key to power on the mobile phone and also

long press the Hang Up key to power off your mobile phone.

¾ If you power on the mobile phone without inserting the SIM card,

the mobile phone will prompt you to insert the SIM card. After the
SIM card is inserted, the mobile phone will automatically check

8

whether the SIM card is ready for use or not.

¾ Then the screen will give the following prompts:
¾ -Input PIN (If you have set password for SIM card) (Please refer to

the section 4.8.5. “security settings” for detail operations)

¾ -Input the mobile phone’s password (if you have set the lock-code)

(Please refer to the section 4.8.5. “security settings” for detail
operations)

¾ When the SIM card is successfully decoded, the mobile phone will

automatically search the available network (the screen displays
“search network”)

¾ Once established connection, the name of the network supplier will

appear on the top of the screen. This means that the mobile phone is
in “standby” mode and it is available for used.

*Note: If the screen prompts “Emergency”, this means that you are
out of the normal network scope (service scope), but you can still
make the emergency call according to the signal intensity.

The use of USB data route

The method of using USB data route: Input one of the port into the
computer, and then input the other port to the phone, after that you can
transfer the data between the computer and the phone. When you are
charging, the icon for the charge is moving. If the charging is finished,
the icon will stop moving. You can use the phone as a U disk after the
phone power off.
The phone supports the USB, you can copy and move the file between
the phone and the computer after you link the USB with the computer.
You can view the information in the T-Flash card.

*Note

：

--Please power off the phone before you connect the phone with the
computer, after the phone connecting up, you will find information
of the USB on the computer, and then you can read the file into my
computer. If there is not information, you must check your phone’s
USB port and insert it again.

--If you connect the phone with computer when the phone is
powering on, there are three items displaying on the phone, you
should select the “mass storage”, and then you can copy or move
the file between the phone and the computer.

--After that, you need double click the USB icon in the right corner
of the computer, and then select “stop”, now you can withdraw the

9

USB from the computer and the phone. DO not withdraw the USB
from the computer directly, or the date in the T-flash card will be
lost, and it can also damage the phone.

You must do it on the computer which is the Windows2000 or SP2.

Install and pull out T-flash card

This mobile phone supports T-flash card, which is a kind of multimedia
memory card used t o increase memory of the mobile phone. It is so
small that you should take cautions to install or pull it out in order to
avoid damage. The method to instal

l/ pull out T-flash card:

1. Power off the mobile

phone, set memory card with the metal face
downward to the memory card slot.
To pull out the memory card, power off the mobile phone, take out the
T-flash.

*Note: The mobile phone does not support hot-plug function of
T-FLASH in “power on” m ode. Only when the mobile phone is
powered off can T-FLASH be pulled out. Restart up and T-FLASH
will come into effect.
When using or editing files stored in the memory card, DO NOT pull
out t

he memory card.

10

3 Basic Description

Phone Layout

Basic Keys

Name Functions

Center key Standby interface, when the cursor shortcut icon to

the bottom of the screen, press the center key to
confirm.

SIM1 dial key SIM1 dial keys under the standby, enter SIM1 call

history list.

SIM2 dial key SIM2 dial keys under the standby, enter SIM2 call

history list.

End key Short press: return to standby interface in any

mode
Long press: Power off(Power on in power off state)

Navigation keys Induction mobile navigation by finger.

1 Short press: go to number input screen and input

number 1
Long press: Call voicemail.

Numeric
keys

0~9 Short press: go to number input interface and input

numbers 0~9.

11

* Short press: go to number input screen and shift

input *.
Standby continuous key input "+", "P", "W".

# Short press: go to number input screen and input #

Long press: turn on / off silent mode.

Call functions

When the logo of the network service provider appears on the
screen, you then may make or answer a call. The info bar
implicates the signal intensity on the top left screen (the 4-scale
info bar means the signal is the strongest).
Call quality performs variedly under the influence of the obstacles.
Therefore the movement in a small scope may improve the signal
intensity effectively.

Make a call

Domestic call:
You can input the telephone number via numeric keys to input the
telephone number you want. Press the dial key. If you need to
change the telephone number, press the right soft key to delete the
inputted characters. During the dialing, the screen will display a
“dialing” cartoon. The screen will display the call status
information. If the answering tone is switched on, there will be a
warning tone.
When then call ends, please press Hand-up key to end the call.
zone code + dial number + Dial key
Dial the extension to a fixed phone:
Because some of the extensions to the fixed phones can not be got
through directly, you need to dial the switchboard and then the
extension to the fixed phone. When you input the telephone number,
if insert character “P” between the switchboard number and the
extension number, th e mobile phone will complete all the dialing
for you, i.e. automatically dial the extension and get through. Input
character “P” as below: Long press “*” key (“P” will appears on
the screen).

Note: In this manual, “short press” a key means press then quickly
release the key; “long press” a key means press the key and hold for not
less than 2 seconds

12

¾ Zone code+ switchboard number+ P + extension number + dial key
¾ International call:
¾ To make an international call, long press “*”key until the

international long distance call prefix symbol “+”appears on the
screen. This allows you dial in any country even if you do not know
the local international call prefix (e.g. it is 00 in China).

¾ After the prefix is input, enter the zone code of the country you

want and the complete dial number. The zone code is usually
subject to conventions, 49 for Germany, 44 for U.K. and 46 for
Sweden, etc.

¾ Like dialing a long distance call, “0” in the city code should be

dropped when dialing.

¾ E.g. To dial the service hot line of other countries, you should dial:
¾ +86 21 114
¾ +country code+ the complete dial number+ dial key
¾ Emergency call
¾ If your mobile phone is within the network coverage (you can

check the network signal intensity bar on the top left corner of the
screen), you will be able to make an emergency call (the emergency
call can be made without the SIM card). If the network supplier
provides no roaming service in the region, “Emergency Call” will
appear on the screen to tell you that you can only make this kind of
calls.

Answer a call

¾ In a normal condition, when there is an incoming call, press the dial

key to answer the call.

¾ If the “any key for answer” is set on, then you can press any key to

answer the call.

¾ If the handset is inserted, you can also press the keys on the handset

to answer a call. If it is not convenient, you can set “auto answer”
to on and make sure that the handset is inserted. The call will be
automatically got through after two seconds’ ringing or vibration.

Reject a call

¾ When there is an incoming call, press Hang-Up key to reject the

call.

Menu available during a call

¾ During a call, you can press Option key to enter call menu. The

13

operation method of the call menu is the same with that of the
function menu.

¾ The call menu can only be seen during a call. Besides, functions,

such as call waiting, holding on a call, and multiparty meeting,
need to be supported by the network. Please contact with your
network provider.

¾ In the call menu, you can do the operations as follows:
¾ Hold single call: hold on the current call or restore the held call.
¾ End single call: end the current call.
¾ Phonebook: enter the phone book menu.
¾ Call history: enter the call history.
¾ Messaging: enter the Message menu.
¾ Sound recorder: record the call voice.
¾ Mute: do not send/ restore sending of local voice.
¾ Volume: adjust the call volume.

*Note. Some of the menus only appear in the specific circumstances,
e.g. “Swap” only appears “during a call” and “hang up” call.

Hand-free function

¾ When you make a call, press the Left Soft Key to have a Hand-Free call.

4 Menu Introduction

File manager

¾ Application Functions

------ Open: display the contents in the folder.

------ Format: format the folder.

------ Delete: delete file or folder.
¾ Folder Functions

------Audio: default storage path of record audio you have taken.

------My Music: default storage path of mp3 you have taken.

------Videos: default storage path of videos.

------ Images: default storage path of images.

------ Photos: default storage path of photos you have taken.

------Received: default storage path of document you have received.

Phone book

You may make full use of phone book to store some name, mobile
phone number, family number, company number and so on. Please
choose “phone book” from main menu, and then enter it.

------Quick search: choose this option to enter into the phone book

14

browse interface. On the lower part of the screen there is a search box,
and you can input relevant information to filter the telephone record.
You can press “#” to switch the search method.

*

Note: You can save up to 200 telephone numbers in mobile phone

and 200 numbers in SIM (depends on the capacity of SIM card).

You can see the following options in phone book detailed:

View: view the details of the contact.
Send text message: edit text message and send it to this number.
Call: call this number.
Edit: edit this number and then save it to phone book.
Delete: choose this function to delete the contact.
Copy: Copy the contact.
Add to Blacklist: Add the number to blacklist.
Phonebook settings:

------Preferred storage: choose the priority for the storage location- the
mobile SIM1or SIM2 or phone or All.

------Extra numbers: You can set your phone number, fixed dialing,
SOS number (This feature requires operator support).

------Memory status: Choose this option to check the phonebook
information in the SIM card and in the mobile phone

------Copy contacts: copy all the records in t he mobile phone or the
SIM card: both SIM card to mobile phone and phone to SIM card are
workable.

------Move contacts: move all the records in the mobile phone or the
SIM card : both S

IM card to mobile phone and phone to SIM card are

workable

------Delete all contacts: choose this function to delete phone record all
from SIM card or mobile phone.

Call history

In standby mode, press the center key to go to the main menu, and then
select the call center to view the phonebook and call log. Or in the
standby interface SIM1/SIM2 dial key, to enter into the call log.
In the Call history, select a call log, you can carry out the following
operations:

------ Missed calls: view last 20 missed calls.

------ Dialed calls: view last

20 dialed numbers.

------ Received calls: view last 20 answered calls.

------ Delete call logs: delete missed calls, received calls, dialed the
phone records, and delete all call records.

15

The call log interface to enter the option to do the following:

¾ View: view details of call records
¾ Call: call the number.
¾ Send text message: edit text message and send it to this number.
¾ Send multimedia message: edit multimedia message and send it to

this number.

¾ Save to Phonebook: add the record to Phonebook.
¾ Add to Blacklist: add the number to blacklist.
¾ Edit before call: edit this number and call it.
¾ Delete: delete this entry.
¾ Delete all: delete all call entry.

View the details of the record, including date, calling time, name,
number and call times. In details interface, you can press Option to
perform following operation on selected record.

 Call: call this number.
 Send text message: edit text message and send it to this

number.

 Send multimedia message: edit multimedia message and send it

to this number.

 Save to Phonebook: Add the record to Phonebook.
 Add to Blacklist: Add this record to Blacklist.
 Edit before call: edit this number and call it.
 Delete: delete this entry.

Messaging

The message services can only be used if they are supported by your
network or your service provider and you have subscribed to them.
Also appropriate settings need to be in place.

*Note: When sending messages, your phone may display the words
Message sent. This is an indication that the message has been sent by
your device to the message centre number programmed into your
device. This is not an indication that the message has been received at
the intended destination. For more details about messaging services,
check with your service provider.

Write message

¾ Text message

 First input the contents of the short message, and insert special

marks when the punctuation simulation keypad is activated (all
punctuation marks are available when the input method of

16

capital and small letters is selected).

 Select “Option” and carry out the following operations:
 Send to: Enter number or Add from phonebook. Can add

multiple recipients here.

 Input method: change input method.
 Advanced: Insert number, Insert name from the phonebook or

Insert bookmark from WAP bookmark

 Save to Drafts: By SIM1or SIM2; save the sms to SIM1 or

SIM2.

Inbox

¾ View received messages. When the messages list of Inbox appears,

you can press OK to read the message. You can press Option to
perform the following operations.

------ Reply: reply to the sender.

------ Call sender: call the number of the sender.

------ Forward: forward this message.

------ Delete: delete this message.

------ Add to Blacklist: Add the number to blacklist.

------Advanced

 Use number: pick up the number with call or save to

phonebook or send text message.

 Use USSD: pick up the numbers with 1 or 2 digits in the

messages.

¾ Press Option to perform the following operations.

------View: View the details of the message.

------Reply: reply the sender with SIM1 or SIM2.

------Call sender: call the number of the sender.

------Forward: forward this message with SIM1 or SIM2.

------Delete: delete this message.

------Add to Blacklist: Add the number to blacklist.

------ Delete same number: choose to delete the information sent by the
same number in the list

------Delete all: delete all the messages in Inbox.

Drafts

¾ Save messages which will be sent later. When the messages list of

Drafts appears, you can press OK to read the message. You can
press Option to perform the following operations:

------ Send: send the message.

------ Edit: pick up and edit the contents of the message.

17

------ Delete: delete the message.

------Advanced:

 Use number: pick up the number with call or save to

phonebook or send text message.

 Use USSD: pick up the numbers with 1 or 2 digits in the

messages.

¾ Press Option to perform the following operations.

------View: View the details of the message.

------Send: add contact send this message.

------Edit: pick up and edit the contents of the message.

------Delete: delete the message.

------Delete all: delete all the messages in Drafts.

Outbox

¾ View sent messages. When the messages list in Outbox appears.
¾ You can press OK to read the messages. You can press Option to

perform the following operations:

------Resend: resend this message.

------Edit: pick up and edit the contents of the message.

------Delete: delete the message.

------ Advanced:

 Use number: pick up the number with call or save to

phonebook or send text message.

 Use USSD: pick up the numbers with 1 or 2 digits in the

messages.

¾ Press Option to perform the following operations.

------View: View the details of the message.

------Resend: resend this message.

------Edit: pick up and edit the contents of the message.

------Delete: delete the message.

------Delete all: delete all the messages in Drafts.

Sent messages

You can access the information has been sent

SMS settings

¾ SIM1
Store or modify the number of the SMS center necessary for sending a
short message, or get the number from the network operator, or set
short message storage time limit and set the voicemail number.
¾ SIM2
Store or modify the number of the SMS center necessary for sending a

18

short message, or get the number from
the network operator, or set short message storage time limit and set the
voicemail number.
¾ Save sent message
Can be set on / off to save the sent message function.

Multimedia

Enter the mobile navigation of multimedia, left, right induction to select
menu.

Camera

In the camera preview screen, enter the option to do the following:

¾ Switch to video recorder: switch to the video interface.
¾ Photos: switch to the photo list.
¾ Camera Settings: set the parameters of camera.
¾ Image Settings: set the size and quality of pictures.
¾ White balance: select the brightness of pictures.
¾ Scene Mode: select shooting mode.
¾ Restore default: Restore all camera settings to factory default.

Image Viewer

Save the pictures in mobile phone.

¾ View: view saved pictures.
¾ Image information. Information can be found in pictures.
¾ Browse style: change the view mode of pictures in album, matrix or

list.

¾ Send: send the selected picture to MMS or Bluetooth.
¾ Use as: send the picture to wallpaper, screen saver, power on

display, power off display, caller picture.

¾ Rename: change the file name of selected picture.
¾ Delete: delete the selected picture.
¾ Storage: change the default path to access and take pictures.

*Note: Phone default picture files in the folder of reading the file
under the administration of Photo files, It is supports viewing of
JPG

、

GIF、BMP、PNG picture.

Video Recorder

This mobile phone provides video recording function. Select menu
“Video Recorder” and press the Center key to record video.
Press Option to access:
¾ Switch to camera: switch to the camera.

19

¾ Camcorder Settings: select this option to set parameters of recorder.
¾ Video settings: set the size, quality, time limit reached and record

audio of videos.

*Note: The default format is AVI of video recorder. Recorded video is
stored in the file manager in the "Videos" file folder by default.

Video Player

Play saved video. Available options are:

¾ Play: play selected video.
¾ Send: send the selected video to Contacts or with Bluetooth.
¾ Rename: change the file name of selected video.
¾ Delete: delete the selected video.

* Note: The video player interface, press the OK button to pause
playback; press left, right navigation key operations fast-forward,
rewind; press on the navigation key to open a full-screen playback;
press the navigation button to stop playing; press "*" and "#" keys
adjust the volume Sound recorder

。

Audio Player

In the playlist interface, press the left soft key to access the song list,
enter the option to do the following:

¾ Play: play the selected track.
¾ Details: view the details of the music.
¾ Refresh list: update the playing list.
¾ Settings: set multimedia playing.

1. List auto gen.: update list automatically or not when power on.

2. Repeat: enable this option to repeat playing music.

3. Shuffle: enable this option to play in random.

4. Background Play: enable this option and the music won’t be

stopped if you exit menu.

* Note: phone the default music file folder to read the file
management, "My music "files; Music player interface, press the
joystick left and right to select the playback function sequentially
from left to right: a, play, stop, next, press the "*" and "#" buttons to
adjust the volume.

Sound recorder

Into recording interface induction navigation to the left move to the
right to select the recording, playback on an audio file, the next
recording file button, and accordingly, the lower left corner of the

20

"option" to enter the menu options, do the following:

¾ New record: record a new clip of audio.
¾ Play：play the selected audio.
¾ Append: append new clip of sound to original AMR or AWB audio.
¾ Rename: change the name of selected audio file.
¾ Delete: delete the selected audio file.
¾ List:

 Play: play the selected audio.
 Rename: change the name of selected audio file.
 Delete: delete the selected audio file.

 Send: send the recording to MMS or Bluetooth.
¾ Settings: set the storage position and the file format.
¾ Send: send the recording to MMS or Bluetooth.

*Note: Recorded audio files are stored in the file manager in the
Audio.

FM radio

The FM Radio supports auto scan and manual input. If the channel you
are listening to provides FM radio service, you can check the channel
information on the screen. The FM Radio service uses packet data
connection (network service).
To use FM Radio service, the following requirements must be satisfied:

z Both the radio channel and network operator supports this service.
z You must define the Internet access point to access the FM Radio

service provided by the network operator.
z To input radio channel manually, you need to subscribe FM Radio

service and define valid service identity code.
Warning: Adjust the volume properly when you listen to the radio.
Continuous high volume may damage your hearing.
You can make or answer a call when you are listening to radio. If the
background playing is activated, the FM Radio is off automatically
when you are calling and resumes when the call ends. You can also
listen to the radio even without a SIM card.
FM interface, function buttons from left to right: scan, play, rewind,
forward, specific functions are as follows:
¾ Scan: FM Radio interface, press the left and right navigation keys,

automatically search for channels.

¾ Play: Press the OK button to turn on / off the FM radio.
¾ Channel adjustment: Press the up and down navigation keys to

21

manually adjust the broadcast channels.

¾ Volume: press “*”and “#” key to adjust the volume.
¾ In FM Radio interface, press the Left key to access options:

——Channels List: display the channels list. (Can display up to 30
records ).
—— Manual Input: input the identity code of radio channel manually.
—— Auto search: scan radio channels automatically and display the
radio channels.
—— Settings: set the background playing and activate/deactivate the
speaker.

*Note: Before using the FM radio, you need to plug in your
headphones. .

Organizer

Calendar

Access the Calendar submenu.
Press the Left/Right key to select date, press the Up/Down key to select
week and press Option to access submenus.

¾ View: view the created memos.
¾ View all: View all the created memos.
¾ Add event: create new memo.
¾ Delete event: Delete the created memos.
¾ Jump to Date: jump to specified date.
¾ Go to today: view the calendar in today.
¾ Go to weekly view: view the calendar in week (month).

Alarm

The machine can be set 5 groups of alarm clock:

¾ Status: activate/deactivate the alarm clock.
¾ Time: set the time of ringing.
¾ Repeat:

------Once: the clock alarms only once.

------Everyday: alarm at specified time everyday.

------Custom: set the time that the alarm rings in a week.
¾ Alert type: select the alarm mode, e.g. Vibrator and Ring, Ring,

Vibrator.

Calculator

Press the Direction keys to input the four operators +, -, ×, ÷.
Press the Right soft key to clear last number or result; press the Right

22

soft key “Back” to exit calculator and press the Left soft key or OK to
calculate.

* Note: The precision of the calculator is limited and there are errors,
especially when it is indivisible
Bluetooth.

This mobile phone supports Bluetooth wireless connection. You can
establish wireless connection between mobile phone and Bluetooth
hands-free vehicle communication device, computer or handheld device
to realize voice communication, data exchange and synchronization.
Available options are:

¾ Power: activate/deactivate Bluetooth function.
¾ Visibility: enable/disable the authority of Bluetooth being searched.
¾ My Device: display current and ever connected Bluetooth devices.
¾ Search audio device: search for peripheral Bluetooth devices and

connect.

¾ My name: change the name of Bluetooth device of this mobile

phone

¾ Advanced:

------ Audio Path: change the output device of audio.

------ My address: view the address of this mobile phone.

Settings
User profiles

You can select different modes on different occasions to carry out the
personal settings in the environment modes such as ring tone, vibration,
volume, etc. This function makes it possible to get adjusted to different
situations without changing the ring tone settings at multiple places,
and you only need to switch to the pre-set environment mode.

¾ General mode: It is ringing alert by default;
¾ Silent mode: It does not have ringing and vibrating alert
¾ Meeting mode: It is vibrating alert by default;
¾ Outdoor mode: It uses the maximum volume, vibration + ringing

alert, by default;

In every mode, you can edit the following in a separate manner:

¾ Activate: start the current profile.
¾ Customize: enter the setting profile parameters:

—— Alert type: 4 manners are available: ringing only, vibration only,
vibration and ringing, and vibration then ringing.
—— Ring type: Beep once or Repeat.
—— Incoming call: set the tones for incoming calls.

23

—— Ringtone volume: set the incoming ringtone volume.
—— message: set the tones for SIM1/2 message.
—— Message volume: set the message tone volume.
—— Keypad: set the keypad tone.
—— Keypad volume: set the keypad tone volume.
—— Power on: set the power on tone.
—— Power off: set the power off tone.
—— System alert: switch on or off the system alert.
—— Intelligent call alert: Set to turn on / off the voice broadcast calls
function.
¾ Rest: restore defaults.

Dual SIM settings

This mobile phone supports dual-card dual-standby. In dual card mode,
you can switch the SIM cards according to requirements.
¾ Dual SIM open
Insert two SIM cards and they both subscribe to GSM network and
stand by.
¾ Only SIM1 open
Insert two SIM cards, but only SIM1 is activated and in standby.
¾ Only SIM2 open
Insert two SIM cards, but only SIM2 is activated and in standby.

Note: If two cards are activated, the network names are displayed in
two lines with SIM1 network in first line and SIM2 network in second
line.

Phone settings

¾ Time and date: Set city, time and date.

------ Set home City: select a city.

------ Set time / Date: set current time and date

------ Set format: set the displaying format of time and date.

¾ Language: set the displaying language of mobile phone menus.
¾ Preferred Input Methods: select a default input method.
¾ Display :

------ Wallpaper: select standby interface wallpaper.

------ Power on display: select a picture for power on.

------ Power off display: select a picture for power off.

------ Show date and Time: enable/disable displaying current time in
standby interface.

------ Show operator name: select the operator name to open or close.
¾ Dedicated key: the arrow keys can be set to standby interface

24

functions.

¾ Flight mode: set to open the flight mode.
¾ UART settings: select SIM1 or SIM2 UART.
¾ Misc. Settings

------ LCD backlight: set the brightness and time of backlight.

Network settings

------Network selection:

 New search: re-subscribe to newly scanned network.
 Select Network: select network for the SIM card.
 Selection Mode: select Manual or Auto.

------Preferences: Pre-store several networks.

Call settings

Call settings include the following sub-menus: SIM1 call settings and
SIM2 call settings and Advance settings, The specific menu operation is
as follows:

¾ SIM1 call settings

------ Call Waiting: Select Enable, Disable or Check.

------ Call divert:

 Divert all voice calls: enable this option and all the incoming

calls are diverted to the specified number.

 Divert if unreachable: enable this option and all the incoming

calls are diverted to the specified number if the other party
can’t dial through your number.

 Divert if no answer: enable this option and the incoming calls

are diverted to the number you set if your mobile phone isn’t
answered.

 Divert if busy: enable this option and all the incoming calls are

diverted to the specified number when you are busy.

 Divert all data calls: Transfer if it is data call.(Need network

support)

 Cancel all diverts: cancel all settings of call diverting.

------ Call barring: set Call barring.

 Outgoing calls: bar outgoing calls.
 Incoming calls: bar incoming calls.
 Cancel all: cancel barring (need to input the PIN2 code).
 Change barring password: change the password.

------ Line switching: select Line 1 or Line 2.

¾ SIM2 call settings

------ Call waiting: select Enable, Disable or Check.

25

------ Call divert:

 Divert all voice calls: enable this option and all the incoming

calls are diverted to the specified number.

 Divert if unreachable: enable this option and all the incoming

calls are diverted to the specified number if the other party
can’t dial through your number.

 Divert if no answer: enable this option and the incoming calls

are diverted to the number you set if your mobile phone isn’t
answered.

 Divert if busy: enable this option and all the incoming calls are

diverted to the specified number when you are busy.

 Divert all data calls: Transfer if it is data call.(Need network

support)

 Cancel all diverts: cancel all settings of call diverting.

------ Call barring: set Call barring.

 Outgoing calls: bar outgoing calls.

 Incoming calls: bar incoming calls.

 Cancel all: cancel barring (need to input the PIN2 code).

 Change barring password: change the password.

------ Line switching: select Line 1 or Line 2.

¾ Advance settings

------Blacklist: set Blacklist and save the numbers that you don’t want
to answer. The incoming call is rejected automatically if it is from the
number in the Blacklist.

 Reject number in blacklist: Switch on / off refused to blacklist

the number of calls.

 Blacklist numbers: set Blacklist and save the numbers that you

don’t want to answer.( You can save up to 20 telephone
numbers in Blacklist)

------Auto redial: enable or disable Auto Redial when the other party is
busy or the call isn’t answered.

------Call time reminder: enable or disable Call Time Alert (beep) in the
calling process and set the alert period.

------Answer mode: set any key answering and headset mode
automatically answer.

Security settings

You can set up the safety options for your mobile phone via this menu
to prevent your mobile phone or SIM card from unauthorized use
¾ SIM1 /SIM2 security :

------PIN lock: You can set on / off the SIM card lock. (the PIN code

26

can prevent your SIM card from illegal operation. If the PIN code is
disabled, select Enable and you can start PIN code protection. The
mobile phone asks you to input the PIN code the next time you switch
on the phone. If the PIN c ode is enabled, select Disable and you can
stop PIN code protection.)

------Change PIN: select Change PIN code and you can set new PIN
code. Please input old PIN code, new PIN code and repeat new PIN
code according to the prompt.

------Change PIN2: select Change PIN2 code and you can set new PIN2
code.

Please input old PIN2 code, new PIN2 code and repeat new PIN2

code according to the prompt.

*Note: If you input invalid PIN code for three times continuously, the
SIM card is locked and you need the PUK code to unlock the SIM
card. The PIN code and PUK code may be provided together with
SIM card. Please contact your network operator if not.

Phone security:
Phone lock can prevent your mobile phone from illegal operation. If
this function is enabled, you need to enter phone password every time
you turn on the mobile phone, then you can unlock the phone and make
or answer a call. You can clear mobile phone password, but illegal
operation can’t be prevented in this case.

*Note: The default phone lock password is 0000. Please change into
your own private password as soon as possible. If you have forgotten
your mobile phone pas

sword, please contact your distributor or local

authorized service center to unlock your mobile phone.

Auto Keypad Lock:
Set the waiting time of keypad lock. After setting, the keypad is locked
automatically if the mobile phone hasn’t been used in specified time

Restore factory settings

Restore the functions of mobile phone to default.

*Note: The default phone password is 0000.

Services

The mobile phone supports the SIM function. If you insert the SIM
card into phone the item will be displayed.

Letter Input Method
This mobile phone provides two kinds of input methods, i.e. capital

27

letter input, and lowercase input. What this letter input method differs
from the Intelligent English Input Method is that it has no association
function. However, you may input the needed letters by pressing keys
for multiple times continuously. A corresponding letter will be input by
pressing a key once. For instance, press keys of 2 and 3, “A” and “D”
will be input; press the key 2 continuously, you will be asked to select
among “A”, “B”, “C”, and “2”.

Note: This mobile phone provides input methods for capitalized, small
English letters and multi- input method.

Other language Letters
You can press # key to change the different language input methods.
Numeric Input Method
Input the corresponding numbers under such input method by pressing
the figure keys.

6 Common Problems.

When the mobile phone displays “Insert SIM”?

1. Contact between SIM card and mobile phone is bad or the SIM card
is not inserted.

2. Change the SIM card and try again. The SIM card may have fault if
the mobile phone operates normally. Please contact your network
operator.

3. If there is oxidation on the surface of SIM card or SIM card slot of
the mobile phone, please wipe with alcohol or clean cloth.

4. Please contact ××× Service Center or ××× Maintenance Department
if the above methods are invalid.

Checking and precautions of PIN, PIN2, PUK, PUK2
and password:

1. Please consult local network operator.

2. The SIM card is locked if you input invalid PIN code for three times
continuously.

3. Please consult SIM card operator for PUK code.

Network connection fails

1. The signals in your local place are weak or have shielding. Please
move to other places and try again.

2. Please contact ××× Service Center or ××× Maintenance Department
to do phone test.

28

You can’t be heard

1. Make sure whether it is network problem and try again.

2. The communication lines in some places are bad. Please move to
other places and try again.

3. The trunk line of network operator is bad.

4. Please contact ××× Service Center or ××× Maintenance Department
if the above methods are invalid.

Can’t charge the battery

1. The contact between charger and mobile phone is bad. Make sure
whether the installation is proper.

2. Check whether the battery is valid. The battery performance drops
after several years.

Weak signal

1. If the local network signals are unstable, the signals the mobile
phone receives won’t be stable. Please move to other places and try
again.

2. Please contact ××× Service Center or ××× Maintenance Department
if the above method is invalid.

Can’t make a call

1. The local network signals are weak and please move to places with
strong signals and try again.

2. Local network operator is busy. Please try again later.

3. Check whether Hide Number is enabled. You can’t make a call if the
local network operator doesn’t support this function and you have
enabled it.

4. Please contact ××× Service Center or ××× Maintenance Department
if the above methods are invalid.

Standby time becomes short

1. The standby duration depends on the intensity of local network
signal.

2. It is affected by environment temperature, base station distance, etc.

Appendix

Abbreviation and Explanation
GSM Global System for Mobile Communications
SMS Short Messaging Service
SMS-CB SMS Cell Broadcast
WAP Wireless Application Protocol

29

FDN Fixed Dial Number
SIM Subscriber Identity Module
PC Personal Computer
PIN Personal Identification Number. Usually refer to PIN1. It is
provided with SIM card and the code to access SIM card.
PIN2 Personal Identification Number 2. Provided by network
operator. It is used for special functions, e.g. SIM supported FDN.
PUK Personal Unlock Key. Provided along with SIM card. It is
used to unlock the SIM card if you input invalid PIN code for three
times continuously, or used to change PIN code.
PUK2 Personal Unlock Key 2. Provided along with specific SIM
card and is used to change or enable PIN2.
IMEI International Mobile Equipment Identity. It is made up of
15-digit number and one mobile phone corresponds to one unique
IMEI.
MCC Mobile Country Code, e.g. 460 for China (mainland).
MNC Mobile Network Code, e.g. 00 for CMCC and 01 for China
Unicom.
Call Waiting It is a network service that you can answer a call
without ending current call. Different from multi-party conference, you
can only talk to one party at the same time.
Call Diverting It is a network service that you can divert the
incoming calls to specified number. The options include All Call, If not
Available, If not Answered, If Busy, and Transfer All Data Calls.
Roaming
Use the mobile phone beyond the home network. It includes
international roaming and domestic roaming, while it
refers to international roaming in this manual.
STK SIM Tool Kit. It is new GSM service, which provides you
flexible information, including stocks, traffic and weather. The
functions of STK depend on the network operator. This service needs
the support of SIM card and network operator.
Dual Card Mode The mobile terminal supports two GSM SIM
cards and the cards subscribe to network simultaneously and stand by at
the same time.
