VIDAR SD4400 User Manual

Professional Scanning Solutions

SD Series

Architects - Engineers - Contractors

Government - Municipalities

Technical Documents - Infrastructure

Maps - Geographic Information Systems

VIDAR

SD4400

SD large format scanners give companies an easy and affordable way to save time on in-house
scanning activities. You get exceptional professional-grade performance with true 1200dpi optical
resolution with speeds of up to 10 inch/second. The VIDAR SD4400 series is designed for high-volume
productivity for businesses-critical imaging tasks. Whether you are a private business or government,

VIDAR’s range of SD4400 scanners is the right solution for improved efciency and productivity. The

44” imaging area is designed to produce clean, sharp image quality on technical documents, sketches,
and maps. Fast, simple image clean-up on old, faded, or poorly shaded documents, and safe handling
of sensitive originals with no data loss in capture. Expand your business opportunities with VIDAR’s
versatile SD4400 scanners.

See more at www.vidar.com

The Image of Reliability

Professional Scanning Solutions

SD Series

Features

• 1200dpi optical resolution standard

• All-Wheel-Drive (AWD) for a perfect grip on your

documents

• See what you scan with face-up scanning

• Ultra fast USB 2.0 interface with xDTR (Extended

Data Transfer Rate)

• Scan-to-Net function for scanner sharing across

  anetwork,andsendinglestoremotePCs

• ComplieswithcurrentEnergyStarrequirements 

using less than 5W at rest

The Image of Reliability

Lightweight scanner in a sleek and
modern design making transport and
setup an easy task.

Experience the competitive edge with true 1200dpi
optical resolution and fast USB with xDTR.

Value for Money

VIDAR makes it easy to scan technical documents, maps and
drawings. VIDAR’s SD4400 series is built to withstand high-volume
use on daily basis and are available in a sleek and lightweight de­sign. With SD4400 you get a total scanning solution with leading-

edge software that ts with your existing tools and business

Ease of Use and Productivity

Instant-on scanning and one-touch interface saves time in loading
and scanning large documents. Nextimage software and WIDEsys-

tem drivers make scanning to le, to print, or to the network fast

and simple. Intuitive software makes the scanner easy to use and
maintain.

processes.

SPECIFICATIONS

Optical Resolution 1200dpi 1200dpi 1200dpi 1200dpi

Maximum Resolution 9600dpi 9600dpi 9600dpi 9600dpi

Maximum Scan Width 44in. (1118 mm) 44in. (1118 mm) 44in. (1118 mm) 44in. (1118 mm)

Maximum Media Width 47in. (1194 mm) 47in. (1194 mm) 47in. (1194 mm) 47in. (1194 mm)

Maximum Media Thickness

Accuracy ± 0.1% ± 0.1% ± 0.1% ± 0.1%

Data Capture (color/mono) n/a /16-bit 48-bit/16-bit 48-bit/16-bit 48-bit/16-bit

Color Space - sRGB sRGB sRGB

Scanning Speed* (inches/sec.) : Scanner speed while scanning 36-inch wide document.

400dpi (Turbo) RGB Color - 1.0 1.5 3.0

400dpi (Turbo) Index Color - 1.0 1.5 3.0

400dpi (Turbo) Grayscale/Monochrome 10.0 5.0 10.0 10.0

Productivity** (documents/hour) : Batch scanning for 60 minutes. Includes paper load and eject time. Measured in

D-size, RGB Color, 200dpi - 136 198 336

D-size, Monochrome, 200dpi 780 516 780 780

A1-size, RGB Color, 200dpi - 132 192 324

A1-size, Monochrome, 200dpi 744 492 744 744

Interface :

High Speed USB 2.0 with xDTR

Power Requirements 110V / 220V / 240V, 60/50 Hz

Power, Operational 44 W

Power, Sleep Mode less than 3W (ENERGY STAR compliant)

Weight & Dimensions WxDxH 30 kg / 60” x 19” x 6.3” inches (1525x480x161 mm)

Device Drivers Windows XP, Server 2003, Vista (32-bit only)

Certications ENERGY STAR, RoHS, UL, CE, GOST-R, CCC

* Scanning speeds depend on document width and computer conguration. For best performance, VIDAR recommends Intel Core Duo, Core 2 Duo, or

better processors, at least 1GB RAM, Hi-speed USB2.

**Scanning speed tests performed using Nextimage software, PC with intel Core 2 Quad processor, 3GB RAM, Hi-speed USB2, Windows XP Professional.

(exible documents only) 0.08-inch (2 mm) 0.08-inch (2 mm) 0.08-inch (2 mm) 0.08-inch (2 mm)

VIDAR

SD4410

ü ü ü ü

VIDAR

SD4430

VIDAR

SD4450

completed

VIDAR

SD4490

scans.

See our entire product range and download further details at www.vidar.com

Copyri ght 20 09 © VIDAR A /S.
