Victrola VPRO-2000 Instruction Manual
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
MODEL: VPRO-2000
PROFESSIONAL TURNTABLE
Instruction Manual
PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY
BEFORE USE AND KEEP IT FOR FUTURE REFERENCE.
!
! !
2!
IMPORTANT!SAFE T Y !IN S T R U C T IO NS ................................................................................ 3!
PRODUCT!OVERVIEW ....................................................................................................... 5!
SETUP!/!BASIC!OPERATION............................................................................................... 7!
LISTENING!TO!A!VINYL!RECORD ....................................................................................... 8!
LISTENING!TO!MUSIC!VIA!RCA!LINE!OUT........................................................................ 10!
LISTENING!TO!MUSIC!VIA!BLUETOOTH!OUT .................................................................. 10!
USING!THE!ANTI-SKATE!/!PITCH!CONTROL!/!STROBOSCOPE ......................................... 11!
USB!RECORDING!OPERATION......................................................................................... 12!
SPECIFICATIONS.............................................................................................................. 12!
TROUBLESHOOTING ....................................................................................................... 13!
FCC!STATEMENT ............................................................................................................. 14!
CALIFORNIA!PROP!65!WARNING.................................................................................... 15!
WARRANTY..................................................................................................................... 15!
!
!
! !
3!
CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
WARNING: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to prevent blade exposure.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions – All the safety and operating instructions should be read before this product is
operated.
2. Keep these instructions – The safety and operating instructions should be retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water or moisture –
for example, in a wet basement or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiations, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with
one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles,
and at the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart or rack is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug the apparatus during lighting storms or when unused for
long periods of time.
!
! !
4!
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15.
-This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
-Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no
user-serviceable parts inside. Refer servicing to qualified personnel.
-The exclamation point within and equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions in the literature accompanying the appliance.
16. This equipment is a Class Ⅱ or double insulated electrical appliance. It has been designed in
such a way that it does not require a safety connection to electrical earth.
17. The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
18. WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus
shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall not
be placed on apparatus.
19. The use of the equipment in moderate climate.
20. The ventilation should not be impeded by covering the ventilation openings with items such as, newspapers,
tablecloths, curtains, etc.
21. No naked flame sources, such as lighted candles, should be placed on the apparatus.
22. The symbol with Indication AC voltage.
23. The symbol with indicate DC voltage.
24. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than that contained in the operating instructions unless
you are qualified to do so.
ACCESSORIES INCLUDED:
• INSTRUCTION MANUAL WITH WARRANTY (BACK OF MANUAL)
• 45 RPM ADAPTER
• SOFTWARE CD (FOR MAC & PC)
• RCA CABLE
• USB CABLE (FOR RECORDING)
• COUNTER WEIGHT
• SLIP MAT
• QUICKSTART GUIDE
• ACRYLIC DUST COVER
!
! !
5!
PRODUCT OVERVIEW
!
Front View:
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
1. ON/OFF: Press to turn the unit on or off.
2. START/STOP: Engages and disengages the belt drive in the turntable.
3. SPEED INDICATOR
4. TURNTABLE SPEED BUTTON: Select 33 or 45 RPM turntable speed.
(NOTE: 78 RPM is selected by pressing both 33 and 45 buttons simultaneously,
both speed indicator will light up.)
5. STROBE DOTS (On Turntable Edge): Operate in conjunction with stroboscopic light located under
the ON/OFF to provide visual indication of accurate turntable speeds.
6. TURNTABLE
7. SPINDLE
8. 45-RPM ADAPTER
9 BALANCE WEIGHT: Balances the tone arm and provides adjustment for proper downward tracking
force on the stylus.
10. ANTI-SKATE CONTROL: Applies a small outward force to the tone arm, counteracting the
tendency of the tone arm to move inward toward the center of the record.
