Victor DED10100, DED20100, DED30100, DED40100 Operating Instructions Manual

1

V

HOT PLATE

MODEL NUMBERS DED10100 DED20100 DED30100 DED40100

Thank you for buying a Victor Unit. We hope and expect that you will get many years of
satisfactory use from your purchase.

In order to achi eve the best results from your equipment please read, and follow, the
installation, operating, cleaning and maintenance instructions below. Failure to follow
them may affect the warranty.

1. UNPACKING AND ASSEMBLY

All protective coating used on st ainless st eel surfaces of the Hot Pl ate must be removed.
The exposed surfaces can then be wiped clean with a damp cloth, using a mild
detergent or soap if necessary.

DO NOT USE ANY ABRASIVE MATERIAL OR FORM OF BLEACH FOR CLEANIN G PURPOSES.

Please see cleaning section of these instructions.

2. INSTALLATION

Where the appliance is to be positioned in close proximity to a wall, partition, kitchen
furniture, decorative finishes, etc., it is recommended that they be made of a non
combustible material or clad in a suitable non-combustible heat ins ulating material and
that the closest attention be paid to fire preventative regulations.

The appliance is fitted with a 13 Amp fused plug and only requires connection to a
suitable 13 Amp socket outlet. This model is suitable for 230 – 240V A.C. supply only.
Ensure that the electricity supply is as stated on the model’s data plate.

Important: Wires in the mains lead are coloured in accordance with the following

code:

Green and Yellow - Earth

Blue - Neutral
Brown - Live

Warning: This appliance must be earthed, do not touch internal wiring.

As the colours of the wires in the mains lead on this appliance may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:

2

(a) The wi re which is coloured green and yellow must be connected to the terminal

in the plug, which is marked with letter E or the sign .

(b) The wire which is coloured blue must be connected to the terminal which is

marked with the letter N or is coloured black.

(c) The wire which is coloured brown must be connected to the terminal which is

marked with the letter L or is coloured red.

3. USE AND BEST PERFORMANCE

The Hot Plate is controlled by cont rol knob on the rear of the appliance. To obtain the
best performance, the following procedure is suggested:

(a) Turn the unit on at the mains.
(b) Pre-heat the Hot Plate empty for 30 minutes, with the control knob turned on full.
(c) Load the Hot Plate as required. Many factors will determine the best switch

position, such as the amount and temperature of the food loaded. Experience
from using the Hot Plate will soon show the best setting for any given occasion.

(d) Set the thermostat at the required temperature, No further adjustment is

necessary.

Please remember a Hot Plate is not designed to heat up or cook food, b ut is designed to
maintain it at a satisfactory temperature before serving.

4. CLEANING

SWITCH OFF THE UNIT AT THE MAINS BEFORE CLEANING.

Stainless steel surfaces will give you many years of trouble-free use as long as you follow a
few simple rules. If it appears to mark do not worry, it is usually not the steel but
something deposited on it which has stained.

Do wash all surfaces before use. You should use a damp cloth and a mild detergent or
soap, or similar cleaner. Always rinse well with clean water and dry the surface with a
soft cloth. Clean regularly when in use. Do use soft cloths, nylon or bristle brushes.

Do not use metal scrapers, wire brushes or wire wool pads as th ey can scratch the steel.
Do take care when handling sharp objects as they can scratch the surface of stainless
steel. Any scratches on stainless steel will blend together over a period of time and
become less noticeable with age. There is no detriment to the corrosion resistance or
general performance of the material.

Do not use bleach for cleaning purposes (remember dishwasher powders, sterilising
agents and similar products all contain chlorides). If used, black pit marks or other such
