Victaulic 867-42T Installation, Operation And Maintenance Manual

HANG THESE INSTRUCTIONS ON THE

INSTALLED VALVE FOR FUTURE REFERENCE

WARNING

• Read and understand all instructions before attempting to install, remove, adjust, or perform maintenance on any Victaulic piping products.

• Depressurize and drain piping systems before attempting to install, remove, adjust, or perform maintenance on any Victaulic piping
products.

• Wear safety glasses, hardhat, and foot protection.

• Save this installation, operation, and maintenance manual for future reference.

Failure to follow instructions and warnings could cause system failure, resulting in death or serious personal injury and property damage.

I-867-42TINSTALLATION, OPERATION, AND MAINTENANCE MANUAL

867-42T Pressure Reducing Valve

I- 867- 42T

REV_B

I-867-42T / Pressure Reducing Valve / Installation, Operation, and Maintenance Manual

TABLE OF CONTENTS

Hazard Identification ..................................4

Safety Instructions ................................... 4

Introduction ........................................4

Pressure and Flow Ratings ..............................5

Head Loss .........................................5

Installation .........................................6

Operation ..........................................7

Start Up..............................................8

Readjusting ...........................................8

Maintenance And Inspection Tests ........................9

Weekly Inspection ......................................9

Monthly Inspection And Test ..............................9

Troubleshooting......................................9

Difficulty In Performance ..............................9
