Introduction
(
The information in this manual covers the installation, operation, configuration and maintenance of the SVFTMSH Maximum Security Housing. This unit should only be installed by a qualified technician using approved
materials in accordance with national, state and local wiring codes. Read this manual through completely
before attempting installation.
Vicon’s SVFT-MSH offers a rugged, tamperproof and IP65 rated enclosure for the SurveyorVFT Camera
Dome. The SVFT-MSH is sold in thirteen (13) prepackaged configurations with choices in camera type. All
versions use the same firmware for programming and operation. For setup and operational information, refer
to the SurveyorVFT Programming Manual XX134-4X. In addition, refer to the SurveyorVFT Installation
Manual XX134-0X for complete configuration and operation information. This housing can be ceiling or wall
mounted with the appropriate mount. A clear Acrylic Lower Dome is included. Options for this housing are
Mounts and Power Supplies as listed in Table 3. Refer to Table 2 for complete product descriptions.
SVFT-MSH Maximum Security Housing Components
The SVFT-MSH consists of a thick steel enclosure, a sealed Lower Dome assembly, and mounting studs for
the SurveyorVFT Camera Drive. In addition, the housing provides outside holes for external mounting
brackets and tamperproof hardware for Lower Dome removal.
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to
provide suitable delivery. Inspect the cartons upon delivery and, if damage is present, make detailed notes on
the carrier’s bill. Obtain the carrier agent’s signature and file a damage claim as soon as possible.
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage is
present, contact the carrier and file a damage claim immediately. If the equipment must be returned to Vicon
for repair, follow the instructions in the Shipping Information section of this manual.
Accessory Kit
There is one (1) kit included with all configurations of the SVFT-MSH. It provides the necessary hardware to
assist in assembling and wiring the SVFT-MSH. The screws and washers are spares for the Lower Dome.
DESCRIPTION PART NUMBER QUANTITY
Liquid Tight Conduit Fitting, 3/4 in. (19 mm) NPT 8001702800
Screw, 8-32 x 1/2 in.
Washer, Flat, Nylon 8004948501
Bit, Tamperproof, 1/4 in. (6.5 mm) hex drive 8003735406
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Introduction • 3
13 mm), button head 8003729302
Table 1
Accessories
1
2
2
1
Model Product
g
Code
Description
1/4-in. color camera, NTSC version, 23x zoom, high-resolution day/night camera,
SVFT-MSH23 8714-00
variable-speed camera dome, aluminum upper housing with lower acrylic dome,
mountin
bracket not included
1/4-in. color camera, PAL version, 23x zoom, high-resolution day/night camera,
SVFT-MSH23C 8714-01
variable-speed camera dome, aluminum upper housing with lower acrylic dome,
mounting bracket not included
1/4-in. color camera, NTSC version, 22x zoom, high-resolution camera with
SVFT-MSH22 8713-00
ExView technology, variable-speed camera dome, aluminum upper housing with
lower acrylic dome, mounting bracket not included
1/4-in. color camera, PAL version, 22x zoom, high-resolution camera with ExView
SVFT-MSH22C 8713-01
technology, variable-speed camera dome, aluminum upper housing with lower
acrylic dome, mounting bracket not included
1/4-in. color camera, NTSC version, 18x zoom, high-resolution camera, variable-
SVFT-MSH18 8712-00
speed camera dome, aluminum upper housing with lower acrylic dome, mounting
bracket not included
1/4-in. color camera, PAL version, 18x zoom, high-resolution camera, variable-
SVFT-MSH18C 8712-01
speed camera dome, aluminum upper housing with lower acrylic dome, mounting
bracket not included
For the ViconNet (V) option, add -20 to the product code; for Fiber Optic (F) option, add -30 to the product code;
for the Twisted Pair (T) option, add -40 to the product code.
Table 2
Models, Product Codes and Descriptions
Model Product
Code
Description
SVFT-MSH-WM 8375-00 Wall Mount with Tamperproof Bit
SVFT-MSH-CM 8376-00 Ceiling Mount with Tamperproof Bit
S28PS 7029-00 28 VAC output, 2.5 amps, for indoor SurveyorVFT Camera Domes
V284-175PS 6421-00 Four channel, 120 VAC input, 28 VAC output, 7.25 amps
V288-360PS 6422-00 Eight channel, 120 VAC input, 28 VAC output, 13 amps
V2816-720PS 6423-00
Sixteen channel, 120 VAC input, 28 VAC output, 26 amps
Optional Equipment Models, Product Codes and Descriptions
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Introduction • 4
Table 3
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Introduction • 5
Figure 1
Exploded View
Installation
Mounting the Unit
The SVFT-MSH is intended for ceiling or wall installation using the optional Mounting Brackets. The primary
mounting surface must be a hard ceiling or wall able to support the weight of the entire assembly that is
approximately 30 lb (14 kg). It is recommended to use 3/8-in. (9.5-mm) diameter hardware. Mounting
hardware should consist of lag-type screws or bolts with accompanying lock and flat washers.
Also, be sure the area behind the selected location is clear of obstacles (such as steel beams, headers,
pipes, electrical wiring, etc.), which would interfere with mounting. Verify that there is access and sufficient
space behind the mounting location to route video and power cables and termination boxes. Refer to the
Cable Recommendations in the Reference section of this manual.
1. With the SVFT-MSH removed from the box and laid on a flat table, remove the Lower Dome Assembly by
uninstalling the nine (9) Tamperproof Screws. Use the provided Tamperproof Bit, located in the
Accessory Kit, for screw removal. Allow the Lower Dome Assembly to hang during installation.
2. Install the provided Liquid Tight Conduit Fitting, found in the Accessory Kit, into the Hole provided on back
of the Housing. Tighten the hex-mounting nut using an adjustable wrench until its snug.
3. Install the Mounting Bracket. There is either a Wall or Ceiling Mounting Bracket available. As previously
stated, it is recommended to use four 3/8-in. (9.5-mm)-diameter lag-type screws or bolts with lock and flat
washers. Choose one of the two available four (4) hole mounting patterns. Lift the Housing to the
Mounting Bracket and connect it using the four (4) pre-installed Tamperproof Screws. Use the
Tamperproof Bit provided with Mounting Bracket for installing screws.
4. Verify a maximum of 5 cables for power, video, communications, alarm and relay. Route the cables
through the Liquid Tight Conduit Fitting and leave about 12-in. (305-mm) length for connection to the
Customer Interface Board.
5. Unlatch the Customer Interface Board by pressing the latch and swinging it down about 90 degrees.
6. Remove the terminal blocks from the Accessory Kit. Cut and terminate all cables into the terminal blocks
in accordance with Tables 4, 5 and 6. All wired terminal blocks should easily reach their mating
connectors with the board re-latched. DO NOT APPLY POWER AT THIS TIME.
7. Install the terminal blocks into the Customer Interface Board, swing the board up and latch it into the
Housing.
Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source.
Voltage irregularities such as surges, drops, and interruptions can affect the operation of your
equipment and, in severe cases, damage certain components. Vicon strongly recommends the use of
line conditioners, voltage regulators, and uninterruptible power supply (UPS) systems.
Caution: Be sure to make pin connections correctly. Wrong pin connections will cause damage to the unit.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Installation • 6
CO
r
A
8. Configure communication and address DIP switches as shown on the label in Figure 2. For a detailed
description of DIP switch configuration, refer to the Configuration section of the SurveyorVFT Installation
& Operation Manual.
9. Lift the Camera Drive and connect it to the Housing by attaching the Safety Cable Clip to the Latch on the
Camera Drive.
10. Holding the Camera Drive under the housing, align the two slots on the Housing with the two tabs on the
Drive. While lining up the two arrows, push the Camera Drive into the Housing until it snaps securely into
place.
11. Attach Lower Dome using previously removed nine (9) Tamperproof Screws.
12. Installation is complete.
NNECTOR/PIN
CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME
NUMBER
BNC (female)
J1
AMP Heade
VIDEO (J1)
VIDEO
J2
Video output
J2 (Fiber Optic board)* Video/RS-422 data
TERMINAL BLOCK
TB1-1
TB1-2
TERMINAL BLOCK
TB2-1
TB2-2
TB2-3
TB2-4
TB2-5
TB2-6
TB2-7
TB2-8
TERMINAL BLOCK
TB3-1
TB3-2
TB3-3
TB3-4
TB3-5
TB3-6
TB3-7
TB3-8
POWER (TB1)
H
N
LARM (TB2)
ALARM 1
GND
ALARM 2
GND
ALARM 3
GND
ALARM 4
GND
COMM/RELAY (TB3)
COMM IN +
COMM IN -
RESP OUT +
RESP OUT -
GND
RELAY C
RELAY NO
RELAY NC
Hot
Neutral
Alarm input 1
Ground
Alarm input 2
Ground
Alarm input 3
Ground
Alarm input 4
Ground
Command in +
Command in -
Response out +
Response out -
Ground
Relay, common
Relay, normally open
Relay, normally closed
*J2 connection provided to accommodate optional fiber optics interface board that provides video and
RS-422 full duplex data through a standard fiber optics connector.
Table 4
Electrical Connections – Coaxial/Fiber Optic Configurations
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Installation • 7
CO
NNECTOR/PIN
A
NUMBER
CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME
TERMINAL BLOCK
VIDEO NVT (TB4)
TB4-1
TB4-2
TB4-3
TB1-1
TB1-2
TB2-1
TB2-2
TB2-3
TB2-4
TB2-5
TB2-6
TB2-7
TB2-8
TB3-1
TB3-2
TB3-3
TB3-4
TB3-5
TB3-6
TB3-7
TB3-8
TERMINAL BLOCK
TERMINAL BLOCK
TERMINAL BLOCK
UTP +
UTP -
GND
POWER (TB1)
H
N
LARM (TB2)
ALARM 1
GND
ALARM 2
GND
ALARM 3
GND
ALARM 4
GND
COMM/RELAY (TB3)
COMM IN +
COMM IN -
RESP OUT+
RESP OUT -
GND
RELAY C
RELAY NO
RELAY NC
Unshielded twisted pair +
Unshielded twisted pair -
Hot
Neutral
Alarm input 1
Ground
Alarm input 2
Ground
Alarm input 3
Ground
Alarm input 4
Ground
Command in +
Command in Response out+
Response out -
Ground
Relay, common
Relay, normally open
Relay, normally closed
Table 5
Electrical Connections - UTP Configuration
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Installation • 8
CO
NNECTOR/PIN
A
NUMBER
TB1-1
TB1-2
TB2-1
TB2-2
TB2-3
TB2-4
TB2-5
TB2-6
TB2-7
TB2-8
TB4-1
TB4-2
TB4-3
J1-1
J1-2
J1-3
J1-4
J1-5
J1-6
J1-7
J1-8
CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME
TERMINAL BLOCK
TERMINAL BLOCK
TERMINAL BLOCK
RJ-45
POWER (TB1)
H
N
LARM (TB2)
ALARM 1
GND
ALARM 2
GND
ALARM 3
GND
ALARM 4
GND
RELAY (TB4)
RELAY C
RELAY NO
RELAY NC
LAN (J1)
TX +
TX -
RX +
RX -
Hot
Neutral
Alarm input 1
Ground
Alarm input 2
Ground
Alarm input 3
Ground
Alarm input 4
Ground
Relay, common
Relay, normally open
Relay, normally closed
Transmit +
Transmit Receive +
Receive -
Table 6
Electrical Connections - LAN Configuration
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Installation • 9
Figure 2
DIP Switch Label
Operation
When power is applied to the camera, the SVFT-MSH will boot up through a diagnostic routine and view the
currently selected scene. Refer to the SurveyorVFT Programming Manual for details on setup and operation.
Maintenance
The SVFT-MSH Camera Dome requires no scheduled maintenance except for the occasional cleaning of the
Lower Dome.
Care and Cleaning of Clear Acrylic Domes
1. Always handle the Lower Dome by the flange and avoid touching the inside surface.
2. If dust or dirt accumulates in the Lower Dome's interior, remove it with clean dry pressurized air.
3. If spots, streaks or stains appear on the exterior, they can be removed with a solution of mild soap or
isopropyl alcohol and water using a lint-free soft paper towel. Dry with clean, dry pressurized air.
4. Scratches or surface blemishes on the exterior may be removed with a nonabrasive wax using a soft
cleaning cloth.
Caution: Excessive rubbing of the Lower Dome surface can cause permanent scratches.
5. Clean all surfaces with any soft cleaning cloth and a mild glass cleanser suitable for acrylic plastic.
Fuse Replacement
Two fuses (F1 and F2) are located on the Communication/Power Supply Board of the Camera/Drive. When
necessary, replace them with the following Fuse values:
F1: 2AG, 1.6 amp, 250 volt, slo-blo
F2: 2AG, 2.5 amp, 250 volt, slo-blo
Note: Refer to the SVFT Installation & Operation Manual for Camera Drive maintenance.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Operation • 10
Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name
of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 631-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 631-951-CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Europe Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: +44 (0)1489/566300; Fax: +44 (0)1489/566322
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Shipping Instructions • 11
Cable Recommendations
Coaxial Cable
Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no
responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases,
coaxial cable impedance should be 75 ohms.
Materials
Use only a pure copper center conductor. Do not use a copper-plated steel or aluminum center conductor, as they will
result in poor quality video. Solid-core bare copper conductor is the best type where flexing and bending will be minimal. If
severe bending and flexing is required for installation, use a stranded center conductor. Never exceed the manufacturer’s
minimum bend radius specification. Use cellular (foam) polyethylene dielectric except where heavy moisture exists. For
moisture conditions, use solid polyethylene dielectric cable with a heavy exterior insulation. The shield must be copper
braid providing 95% or better coverage.
Cable Types
The cable types listed below are the most common 75-ohm types used. They vary in size (diameter), dielectric type and
net DC resistance. The larger cable results in a lower DC resistance and better video quality, with increased difficulty in
handling and installation. Use the required picture quality and cable distance to provide a guide in choosing the best cable
type. For cables other than the approved Vicon types below, contact the manufacturers listed below. Note that “BC” refers
to bare copper and “TC” refers to tinned copper.
Recommended Coaxial Cable Types
Cable
Type
RG-11/U 8213 9847 811,4811 14 Solid BC BC braid (95%) 2.6 (8.5)
RG-6/U 9248 9804C 806,4806 18 Solid BC Foil + 61% TC braid (100%) 7.5 (24.6)
RG-59/U 8281* ---- 815 20 Solid BC 2 TC braids (96%) 9.9 (32.5)
RG-59/U 9259 9803 816 22 Stranded BC BC braid (95%) 15.0 (49)
RG-59/U 9659 ---- ---- 22 Stranded BC BC braid (95%) 15.0 (49)
*Requires special BNC-M connector due to 0.305 nominal O.D.
Belden Inc. http://www.belden.com/ (800) 235-3361
Alpha Wire Company http://www.alphawire.com/ (800)-52 ALPHA (522-5742)
West Penn Wire http://www.westpenn-cdt.com/ (800)-245-4964
Belden
Type No.
Alpha
Type No.
West Penn
Type No.
Type Center
Conductor
Type Shield and
% Coverage
DC Resistance
ohms/1000 ft (1 km)
Picture Quality vs. Cable Length
Picture Quality
Maximum Cable Run** ft (m)
RG-59/U RG-6/U RG-11/U
Usable picture 1100 (350) 1500 (450) 2400 (750)
Clean picture 820 (250) 1000 (300) 1600 (500)
Best picture 400 (120) 530 (160) 820 (250)
** For longer cable runs, use a Vicon Video Amplifier to obtain a suitable picture
Usable Vicoax Signal vs. Cable Length
Maximum Cable Length ft (m)
Usable Vicoax
signal.
RG-59/U RG-6/U RG-11/U Fiber
1500 (450) 1500 (450) 5000 (1524) 5000 (1524)
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Cable Recommendations • 12
Twisted-Pair Cable
(
)
(
)
)
)
)
)
(
)
CAUTION: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes
no responsibility for poor performance when cables other than those recommended are installed.
Materials
Use a pure copper stranded conductor with or without a tin plating to obtain a low DC resistance. Do not use cable with
either a steel or an aluminum stranded conductor because these do not transfer signals effectively for long distances. The
preferred insulation and cable jacket is Polyvinyl chloride (PVC). It has better electrical characteristics than polyethylene
and resists flames, sunlight and most solvents, but is more vulnerable to moisture.
Cable Types
The most commonly used cable types are dual individually-shielded, twisted pair in a single jacket. This configuration is
the most convenient for RS-422/ RS485 applications. Single twisted pair is also a suitable cable.
Choose a Belden cable type by referring to the characteristics and maximum distances listed below. The maximum
distance for the most reliable digital control refers to the distance between the CPU/Keypad and the Camera Dome
Assembly. The characteristics of the cables in the table should be used as a guideline when cables other than Belden are
used. Materials and construction must follow the guidelines above.
Recommended Individually-Shielded, Twisted-Pair Cable Types
CABLE
TYPE
Belden 9406 22 PVC PVC 5000
Belden 9402 20 PVC PVC 5000 (1500
Belden 8723 22 Polypropylene PVC 8000 (2400
Belden 8162 24 Datalene¹ PVC 15000 (4600
Belden 9729 24 Datalene¹ PVC 15000 (4600
Belden 9182
¹Datalene is a Registered Trademark of Belden.
Belden Inc. http://www.belden.com/ (800) 235-3361
WIRE SIZE
AWG
INSULATION
MATERIAL
JACKET
MATERIAL
22 Datalene¹ PVC 25000
DISTANCE ft (m)
max.
1500
7600
NUMBER OF
TWISTED PAIRS
2
2
2
2
2
1
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing • 13
Technical Information
ELECTRICAL (SurveyorVFT Camera Drive only)
Drive Type: Electrical motorized pan and tilt, electronic control.
Camera Types: Units available in color and day/night (NTSC/ PAL) formats
and a variety of zoom and feature capabilities.
Input Voltage: 18 - 32 VAC.
Maximum Wire Distance for Power Cable: See Table 7.
Wire Size
(AWG)
Annealed
Copper Wire
20 215 (65) 165 50) 350 (107) 280 (85)
18 336 (102) 258 (79) 547 (167) 438 (134)
16 538 (164) 413 (126) 1250 (381) 700 (213)
14 860 (262) 660 (201) 2006 (611) 1120 (341)
12 1344 (410) 1031 (314) 3125 (953) 1750 (533)
Coax, Fiber, UTP ViconNet Coax, Fiber, UTP ViconNet
24 VAC 28 VAC
Maximum Power Cable Distance
Current:
Coax, Fiber, UTP: 1.4 A.
ViconNet (TCP/IP): 1.8 A.
Power:
Coax, Fiber, UTP: 35 W.
ViconNet (TCP/IP): 45 W.
Heat Equivalent:
Coax, Fiber, UTP: 2.0 BTU/min (0.5 kg-cal/min).
ViconNet (TCP/IP): 2.6 BTU/min (0.64 kg-cal/min).
Distance ft(m)
Table 7
Note: These figures represent the conversion of 100% of the electrical energy to heat. Actual percentage of
the heat generated will be less and will vary from product to product. These figures are provided as an
aid in determining the extent of cooling required for an installation.
Connector Types:
Video: Various, version dependant.
Power: Removable Screw Terminal Block, 2-position.
Control Input/Output: Various, version dependant.
Relay Output: Removable Screw Terminal Block, 3 or 8-position (version
Alarm Input: Removable Screw Terminal Block, 8-position.
Video Output Impedance: 75 ohms.
Fuse: F1: 2AG, 1.6 A 250 VAC, slo-blo.
F2: 2AG, 2.5 A 250 VAC, slo-blo.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 14
dependant).
Radio Frequency Emission Rating: FCC Class A.
OPERATIONAL (SurveyorVFT Camera Drive only)
Video Pan View: 360°.
Video Tilt View: -2.5° (-2.5° above horizon) to 92.5° (-2.5° past vertical).
Pan Speed: Variable, 0.1 - 360°/ sec (120°/ sec in 18X version).
Autopan Speed: Variable, 0.1 - 42°/ sec, enable/disable.
Tilt Speed: Variable, 0.2 - 150°/ sec (90°/ sec in 18X version).
Zoom and Focus Speed: Less than 1.8 sec. from end to end.
Sectoring: 16 max, programmable for size and titling; capability to be
blanked out (22X and 23X versions only).
Preset Capabilities: 79 individual programmable preset positions.
Tour Capabilities:
18X Version: 4 available.
22X/23X Versions: 8 available.
32 programmable events per tour.
positions with speed control, alarm acknowledgement with
dwell time control, relay control, call autotours, tour repeat or
another tour and save/recall camera status.
Autotour Capabilities:
22X/23X Versions: 2 autotours available with 256 pan, tilt and zoom functions
per autotour. Programming is done in real time with joystick
and push buttons. Autotours not available on 18X model.
Preset Solving Speed: 1 second nominal.
Preset Accuracy: 0.23° maximum in pan and tilt motion.
Alarm Capabilities: 4 alarm inputs, individually programmable. Functional state
enable/disable. Report state (report on/off). Active state
(high/low). Mode (manual, momentary or automatic) with
programmable dwell time control. Set and reset action
(preset solve, relay on/off, tour, autotour. Alarm titling.
Relay Capabilities: 1 relay output. Power-on state definition (on/off). Output type
definition (momentary or latching). Relay function status
titling.
Resistive Load: 0.3 A @125 VAC, 1.5 A @30 VDC.
Inductive Load: 0.15 A @125 VAC, 0.75 A @30 VDC.
Control Display: On-screen, menu-driven system allowing full configuration of
the dome.
Privacy Masks:
22X and 23X: 16 individual, programmable, zoom-scalable.
Events may be preset
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 15
Screen Titling Capabilities: Programmable for camera, preset, sector, relay and alarms.
Camera: 1 for each.
Preset: 79 maximum.
Sector: 16 maximum (not on 18X).
Alarm: 4 maximum.
Individual type date and time enable/disable; 20 characters
maximum. Selectable position. Three text sizes for top two
lines. Fade capability. Compass/azimuth, 8 compass
headings (N, NE, E, SE, S, SW, W, NW). Not available on
18X version.
Scheduling: Real time clock allows scheduling of up to 64 events,
including presets, relays, alarms, tours or autotours. Not on
18X.
Multilanguage Menu: English, Spanish, French and Italian.
Day/Night Features: 6 programmable motion detection zones with 3 sensitivity
levels; image freeze during preset solve; flip (invert) video
image.
Auto Baud: Auto baud detection in RS-422/ RS-485 mode; 4800, 9600,
19,200 bps baud rates supported.
Absolute Position Control: Available in RS-422/RS-485 mode. Pan/tilt: 0.125°; zoom:
0.125X.
Competitive Protocols: DIP Switch selectable. Available in coaxial and UTP versions
only. Protocols are:
Pelco: Pelco D Protocol (3/2/99); RS-485 N.8.1, simplex
2400 bps, duplex 4800 bps.
Sensormatic/AD: RS-422/RS-485 communication protocols
user’s guide Rev. A (csd 05/00); RS-422/RS-485 duplex
N.8.1 4800 bps. May require RS-422 converter, RCSN422.
Ultrak: KD6, KD6-Z control protocols; RS-485 simplex E.8.1,
9600 bps. (Released in future.)
Philips: Receiver/Driver/Auto Dome control code protocol;
RS-232 simplex N.8.1, 2400 or 9600 bps. (Released in
future.)
Kalatel: Non-repeating transmit commands; RS-422 simplex
N.8.1, 9600 bps. (Released in future.)
Available Versions: Video Zoom:
18X optical, 12X digital, 216X total.
22X optical, 12X digital, 264X total.
23X optical, 12X digital, 276X total.
Video Output and Control:
Coaxial output, RS-422/RS-485 control.
UTP output, RS-422/RS-485 control.
Fiber Optic output, Fiber Optic control.
LAN output, LAN control.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 16
MECHANICAL (SVFT-MSH Housing only)
g
Application: Indoor or outdoor in warm climates.
Mounting: Ceiling or Wall mounting with separately purchased
Mounting Brackets. See Table 3.
Cable Access: 1.09 in (28 mm) hole size utilizing provided 0.75 in (19 mm)
Liquid Tight Fitting.
Mounting Pattern: Two four (4)-hole patterns on each mount sized to
accommodate provided 3/8 in. (9.5 mm) hardware.
Lower Dome: Clear Acrylic (impact resistant).
Dimensions: See Table 8 and Figure 3.
Configuration Width (W) (in./mm) Height (H) (in./mm) Depth (D) (in./mm)
Housin
Wall Mount
Ceiling Mount
Alone
Weight: SVFT-MSH: 11.5 lb (5.2 kg). 15 lb (6.8 kg) with SVFT
SVFT-MSH-WM: 11.75 lb (5.3 kg).
SVFT-MSH-CM: 9.5 lb (4.3 kg).
Construction: Housing: 13 gauge (0.089 in./23 mm thick) welded steel.
Mounts: 0.19-in (4.8-mm) thick steel.
Finish: Paint.
Color: White.
11.8/300 10.0/254 11.7/297
12.2/310
12.2/310
10.0/254
10.9/277
14.6/371
11.7/297
Table 8
Dimensions
included.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 17
Figure 3
Dimensions
ENVIRONMENTAL
Operating Temperature Range: 32 to 110°F (0 to 43°C).
Operating Humidity Range: 100% relative humidity.
Storage Temperature Range: -40° to 150° F (-40° to 65° C).
Storage Humidity Range: Up to 90% relative, noncondensing.
Ingress Protection: EN60529, IP 65 rated.
Wind Load: 90 mph, using optional ceiling or wall mount.
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 18
NOTES
XX077-01-00 Rev 204 SVFT-MSH Maximum Security Housing Technical Information • 19
Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, New York 11788
631-952-CCTV (2288) 800-645-9116
Fax: 631-951-CCTV (2288)
✆Infofax: 800-287-1207
Vicon Europe
Headquarters
Brunel Way
Fareham, PO15 5TX
United Kingdom
44/(0) 1489/566300
Fax: 44/(0) 1489/566322
Brussels Office
Planet II - Unit E
Leuvensesteenweg 542
B-1930 Zaventem
Belgium
322 712 8780
Fax: 322 712 8781
Far East Office
Unit 5, 17/F, Metropole Square
8 On Yiu Street, Shatin
New Territories,
Hong Kong
(852) 2145-7118
Fax: (852) 2145-7117
Internet Address: www.vicon-cctv.com
Loading...
