Safety precautions

Move/U np ac k

• The M odel One is pretty heavy and it is

strongly recommended to move it by 2 pe op le
in case it hurts others.

After unpacking

• Please keep all the package and use the
original package for all further transport.

• Please check the ca bi ne t and see i f any
damage caused by th e transport. If found a ny
t r a c e o f d a m a g e , pl e a s e c o n t a c t t h e
authorized distributor of VIBRATOTM and will
help solve it properly.

• Please take out and check th e accessory box
according to the following l is t. Make sure all
the accessories are included. Please co nt ac t
the authorized distributor of VIBRATOTM if it
is incomplete.

Accessories List：
1 pc of IEC power cables

1 pc of remote control
1 pc of 3V button cell

Yo u m a y d o w n l o a d t h i s m a n u a l o n
www.nsraudio.com

Warranty Service

• Please se nd back the wa rr an ty card to the
follow i n g add r e s s wi t h i n 15 days after
purchasing:
Ro om 1103, Buildi ng 1,Ph ase 6, Tian’a n
Digital New City, No.12 , Jia npi ng Road,
Guicheng Subdistrict, Na nh ai Di st ri ct , F os ha n
City, Guangdong Province, China

• Please keep the dated original receipt as a
proof for warranty.

• Please keep the pa ck ag e and send back to
a f t e r - s a l e s d e p a r t m e n t wi t h the w h o l e
package when needed repairing

•MODEL ONE is en ti tl ed to 3 years free
warranty. Please refer to the warranty terms
by the warranty card.

Caution: The internal of Mod el One is
afforded by a ci rc ui t that higher than the
safety voltage, with a precision of high
integration ci rc ui t design, and there i s not
any spare parts that cou ld be repaired by
user. To remain the best setting and reduce
the risk of electronic shock, please do not
tak e a p art t he cabi n et in case bein g
canceled the warranty service .

1

1. HDMI n ative D SD inte rface

HDM I in terfa ce could supp ort both 1080 p video an d 8­chann el hig h de finit ion digit al aud io w ith ba ndwid th a s high
as 18 Gbps. The N ative 12 S a nd DS D d igita l audio inter nal
bus ar e buil t in the ma in i ntern al bus of t he HDM I in terfa ce,
makin g audio tra nspor t withou t any fo rma t con ver sion. It
could tra nsm it 8-chan nel of PC M audio wit h 24bit 192Khz
direc tly and D SD nati ve audio str eam wit h 1bit 5. 6Mbps .

The deco ding proc ess is that HDMI native D SD b us
inter face c ould t ransp ort th e DSD o rigin al form at audio
strea m receive d from the outpu t of SAC D or blue r ay S ACD
HDMI inter face to DS D int ernal bus of ESS9 018 c hip
witho ut any format con versi on proc ess, whic h re alize s an
authe ntic DSD nat ive data decodi ng dir ect ly and ensur es
the 100 % reali stic re producti on of mus ic.

2.Bas ed on the L atest X mos D SD Solu tion

Ano ther bi ggest f eatur e is that t he l atest X mos is eq uippe d
with buil t-in DCA , wh ich not onl y su pport s Na tive DS D da ta
trans porta tion prov ided by USB A udi o Cl ass 2.0 but also be
compa tible with the curr ent commo n DS D mo de of Dop
mode. The Xmos USB core techn ology could in put Nat ive
D S D d at a w h i ch is u p t o 32 - b i t / 38 4k H z P CM ,
DSD64 /2.8M hz, DSD12 8/5 .6Mhz and DSD 256/11 .2M hz to
the USB a udio in terfa ce. E xcept f or the tr aditi ona l PCM
digit al strea m, it supports al l popula r PC digita l audi o
forma t but also t he de codin g for the na tiv e stream of DXD
and DSD .

3. D ual ESS 9018 DA C de sign wi th 8 -ch annel para llel
mono ou tput mo de

Aud io decod ing is powere d by 2 grou ps of ES SSabr e
ESS90 18 chi p w ith p ate nted techno logy of 3 2 b it”Time
Domai n”eli minat e jitter cl ock , and digit al audio da ta is
c o m p l e t e l y a v a i l a b l e f o r P C M u p t o
32bit /384k Hz,DS D64/DSD1 28 and DSD2 56 by Xmos USB
inter face. As a resul t, i t could be compati ble with those high
resol ution fo rmat wit hout any fu rther up grade. At th e s ame
t i m e , i t is e q u i p p e d w it h a TC X O ( Te mp er atur e
Compe nsate d Cr ystal Osc illato) with ult ra h igh accur acy as
littl e as 1p pm s o that the high dyna mic high co ntras t
chara cteri stic o f hi gh re solut ion digit al au dio co uld be
pe rfectly re main. You co uld e njoy an unp re cedente d
exper ience even t hough playi ng the compr essed audio like
MP3.

4.Pur e analo gue pow er de sign

T he p ower syst em o f di gital cir cui ts a nd a nalog ue c ircui ts
ar e se pa rated th at e nsu re s the p ure an d ac cu ra te
repro ducti on. Dig ital pa rt is totally isolate d from anal ogu e
parts from powe r to cir cuit boar d, and the internal cable s
are as less a s possi ble so as t o re duce th e inter fere wi th the
sound . The cir cuit boa rd desig n use the qu ality so und as a
start ing poi nt with s ophistic ated ma teria ls.

Th e app aratu s has a bu ilt-i n aut hentic hi-end analogue
pream plifi er fe aturing with a fin ely tune d DAC whic h cou ld
set a prope r level bal anced XL R output to am pli fier. The
pream plifi er part has a buil t-i n Pre out output interf ace so
as to connec t the exte rna l aud io eq uipme nt. T he ou tpu t of
singl e-end ed signal is pr ovide d by hig h qu ali ty bandwi dth
and ultra CMRR transfo rmer, bein g co mplet ely consi stent
with th e so und fro m the XLR output and provid ing a mor e
su itabl e sou nd f or t he a ud io phile wi thin t he s ou nd
chara cteri stic of b ig dynamic , high de nsity a nd vigo rous.

5. Floa ting de sign

The fl oatin g de signe d DAC h as a instr ument lev el sin gle­ended output module (audi o co uplin g tr ansfo rme r) w ith
CMRR up to 90dB and band width up to 22M hz. It could
provi de la rge dyna mic and wi de ba ndw idth audio sing le­ended out put with red uction rate of 1 00% sy mmetr ic
int er fac e , mak i ng th e sou nd m or e l i ste na ble a nd
inter estin g. A udiop hiles co uld enjo y t he high quality sound
from sy mmetr ic inte rface by the s ingle -ende d outpu t.

Product description

6. Ult ra-lo w di stort ion with h igh p recis ion balanc ed
analo g volum e poten tio meter

The out put vol ume fro m th e tradi tio nal DAC decod er
which sup ports hig h le vel pre ampli fier outp ut is ad juste d
by DA C chip di gi ta l a ttenuator, ho we ve r, we ch os e
balan ced anal og amplif ied volu me attenu ation system
modul es , as a result , li near regu latio n co uld be a ccura te t o

0.5db per step, ma kin g the vol ume con trol mo re smoo thly
wi thout any d istor tion and noise from th e t radit io nal
poten tiome ter.

Mo del one could be use d as a p reamp lif ier as the DA C
symme tric o utput lev el cou ld be u p to 2. 7v rms and the no n
symme tric one c oul d be up t o 1.2v rms. A pure anal og
symme tric high pr ecision po tenti ome ter is desig ned a t the
outpu t, whi ch cou ld con trol the outpu t volume lev el mor e
preci se w ith 0.5 db p er s tep fro m 90 db t o 0d b. The an alogu e
symme tric a udio s ignal out puts d irect ly via sym metri c leve l
adjus tment so as to re alize the contro l to the prea mplifier
outpu t volum e which i s co nve nient f or c onn ectin g dual
ampli fier or h igh qua lity activ e subwo ofer.

7. The he avy wei ght dou ble s andwi ch chas sis des ign

T he ultra- thick com bined san dwich cha ssis is made by
mixed ma terial with a d esign of u nique su spension an d
sh ock-a bs orbin g techno lo gy. T he c us to mized sh ock­absor bing ma teria l is sand wiche d betwe en stee l casin g and
thick alumi num alloy chass is bas e, which could elimin ate
the ba d effec t of vibra tion to the so und subtl y wi th the lar ge
bronz e s pikes and real ize a perfect sus pensi on. Th e e ffe ct
of perfec tly isola ting from the interfer ence of the exter nal
vibra tion and el imina ting the mechani cal reson ance it self is
far more tha n a c ommon so-cal led h eavy weigh t mat erial s
desig ned wit h singl e material .

The interna l ci rcuit b oards and com pon ents are all co ated
by sho ck ab or ti on m at er ia l, w hi ch cou ld co mp le tely
elimi nate the e ffe cts of s ubtle vibratio ns due to the vol tage
and curr ent that generat ed by wo rki ng co mpo nent to the
sound , a s a re sult i t c ould s ignif icant ly in creas ed th e
clean lines s and flue ncy of th e so und. Al l th e elec troni c
compo nents are wor king in exa ctly the same tem perat ure
due to t he h ermet ic c has sis, whic h pr event s th e compo nent
and circu its fro m be ing corro ded by dust and moi sture, thus
incre asing t he serv ice life.

8. Full y balan ced hig h-s peed an alog am plifi er circuit

The av ailable ban dwidt h o f t he appar atus cou ld reach to
650 kHz in (-3dB ) an d en sure the flat of the fr equ ency
re sp onse withi n lis te ning range , whi ch ca n p er fe ctly
repro duce the hi gh r esolu tion file s and the essen ce of high­co ntras t a nd high ban dwidt h f or the new gen eration
recor ding. Not onl y en sur es the availa ble wide ba ndwid th
but it also al lows the rot ati on rate to rea ch to e xcell ent as
85Vus(p- p), and the result is th at the repr oduct ion det ails
will not be dr agged an d fuzzy, like accu ratel y focusi ng a
high res olution pic tures . Th anks to t he selec tive t ransi stor,
the High po wer coul d c oexis t w ith lo w d istor tion, an d t here
is absolu tely no roughn ess like th e norma l trans istor. The
paire d trans istors are w orkin g in th e env ironm ent of the
same tem perat ure and low vi bra tion due to th e b uilt- in non
reso n a nce t he r mal de s ign a nd f u r the r t h e mus ic
repro ducti on perf ectly . The key t o ma ke t he musi c alive a nd
rich is t hat th e f ull ra nge ha s a very l ow dis torti on while full
power o utput .

22

Power requirement

MODEL ONE with d ef au lt setting ap pl ie s to 50 Hz /2 20 v AC p ow er. Please m ak e sure th e AC power
is consistent with the specification marked on the label of the apparatus before using i t.

If MODEL ONE i s applied with a improper AC voltage, it may cause damage to i t and will lead to
safety and fire problem.

Position and ventilation

• In order for ventilation, please do n ot put an yt hi ng above the apparatus if it is installed on the rack,
such as the roof of the rack . Please do not put the apparatus into the inclosed rack or closet.

• Please place the apparatus on a flat, smooth and stable surface.

• To reduce th e len gh t of the inter connecting cables, please mount the appar at us as close as
possible to the other components

• The place for mounting should be dry and well-ventilated without being exposed to the sunlight.

•The apparatus should not be exposed to hig h temperature, moisture, steam, smoggy, or dusty
environment.

• To avoid damaging and the risk of electronic shock, do not pour the w at er d ir ec tl y on t he a pp ar at us

Warning：

1.Make sure th at all components in th e audio system are properly grounded. Please do n ot
use the gr ou nd in g disconnector which could destroy the polarity or grounding p lu g t ha t has
the safety performance, since it wi ll cause a dan ge ro us voltage between components and
lead to personal and property losses.

2.MODEL ONE could deliver a elegant and unforgettably within ultra high power.

Your power supply conditions ma y become as one of the factors to limit the system
performance based on your l is te ni ng ha bi ts , as well a s the quantity of speakers an d power
amplifiers th at yo u require in yo ur system requirements. You ma y consider to in st al l a
specified AC c ir cu it if it ha pp en s. Pl ea se cons ult a q ua li fi ed el ec tr ic ia n if the power i s
supplied by multiple AC circuit so as to ma ke sure all the c om po ne nt s are working in sa me ,
stable and low imp ed an ce gro un di ng condition. Unplug the MOD EL ONE during lightening
storms or when unused for long period of time.

3. U np lu g the MODEL ON E from the power socket before re mo ve i t and make sure the power i s
off.

3

Install Caution

PO WE R SP IK E

INPUT S ELE CT

VO LU MELE D DI SPL AY

Front panel

POWER

Power button is hidden in the lower left side of the spikes, and could s wi tc h on /off

KNOB

Input so ur ce select：Push the Source knob before selecting the input source, then switch to different
sources by left-right rotating. The source name would be shown on the LED display.

VOLUME

This is a volume knob without sections, and it ranges from -9 9d B to 0dB with precise adjustment.
Increase the volume when turning to right, and decrease the volume by turning le ft.

LED DISPLAY

It is OLED display and could show information as follows:
Volume
Input source name
Input source format(DSD/ PC M)
Sample frequency and quantization accuracy
Mute

Bronze spikes

It could precisely adjust the level of the machine as a part of suspension system.

Warning:

The apparatus could mem orize t he volume o f t he last s ta tu s. In o rder to avoid da ma gi ng th e
drivers by the sudden high volume, please turn down the volume b ef or e s wi tc hi ng off or switching
the input source.

4

Coaxial 44.1k PCM

30.0dB

Rear panel

IEC outlet

Please use the apparatus according to the specifications of the voltage/frequency an d fu se .

DIGITAL IN

COAXIAL（RCA)；HDMI；USB；AES／EBU（XLR);Optical

PRE OUT

Through the t er mi na l before the level signal transmission to th e level or ultra-low sound box, can be
used as independent with the front-end decoder

Pre-amp signal co ul d be transmitted to Amp. o r subwoofers by this terminal, an d could be used as a
independent decoder with pre-amp.

SPEAKERS OUTPUT

Could be connected to the speakers by banana or spade plug s

Warning
A lt ho ug h MODEL ONE has a sp ea ke r protective device, it s ti ll could lead to the p er ma ne nt

irreparable damage to the amplifier in individual cases, such as speaker output terminals in
short-circuited st at e at a high volume. As a r es ul t, tou ch in g of the positive and negative
speakers wire is prohibited.

L SPE AKE RS OU TPU T R SPEAK ERS O UTP UT

IEC out let

DIGITAL I NPRE OUT

5

Remote Control

Up and down button：Control the volume by press up or down。

Left and Right buttons：Select the input source when used with the Menu button.

MENU：Press th is button when you want to switch the i np ut source, then press left or right to sele ct

the source.

Mute:Volume could be turned down 20dB when press it, and back to normal by press it again.

Operating the Remote control

•Point it to the front panel o f t he MO DE L ONE When using the remote control . Make sure there are
no obstructions between the M od el One and remote control , such as furniture. The interference of
Light, fluorescent and plasma video displays may affect normal operation of the remote control.

•The effective distance of the remote control is about 5 meters, depending on the lighting conditions

•You can use the remote control toward to the MODEL ONE within 45°angle on both sides.

• The Valid range of t he remote control will be weakened wh en the MODEL ONE i s placed behind a
tinted glass.

• If i nt er mi tt en t failures happen when using the remote control, pl ea se r eplace old batteries with new
batteries.

Mount the battery

A 3.0V Br2032 or CR2032 lithium-ion coin cell will be attached to the Remote Co nt ro l.
To mount th e battery, please use a coin into the groove t he n rotate to the left fo r opening the battery
cover, then mount battery with correct polarity, then put the battery cov er back and turn right to
tighten it.

MENU

MENU

Mute

Left an d Rig ht bu tto ns

Up and do wn bu tto n

Open

Close

6

1 . Based on the Latest 32 bits Xmos and PCM/Native of Exx-Sabre DSD Solution

2.USB audio class 2.0 interface supports up to 32bit 384khz PCM decoding

3. Support decoding for Native DSD64/ 2.8Mhz，DSD128/5.6Mhz ，DSD256/11.2Mhz

4.1ppm Ultra-high-precision dual-clock TCXO

5.Ultra-low jitter clock to 0.01UI(p-p)

6.Support Audio class 2.2 asynchronous drive at Windows

7. Native DSD及DSD audio over USB，Dop Mode

8. Dual ESS9018 DAC design with 8-channel parallel mono output mod e

9. Digital CPLD logic signal processing technology could deal with all t he digital au di o input s ig na l
effectively.

10. With former high-level output stage i nc re as es the analog volume control system, low d is to rt io n,
and support IR infrared volume control

11. The sound effe ct of Single-ended an al og output is consistent with the effect of the symmetric
interface by u si ng the single ended o f 2 2M bandwidth audio ou tp ut transformer with high CMRR
floating design, which is convenient for users to connect dual amplifiers or high qu al it y su b wo of er.

12. Multi digital input: HDMI；USB；AES/EBU；SPDIF，Optical

13. Built-in C PL D logic processor could switch th e audio signal and r ea li ze the error correction
technology.

14. Clear OLED LCD display with large screen

15. All the audio out pu ts could protect you r terminal equipment by th e an ti -i mp ac t sound switch
design.

16. All t he e lectronic components are working in the s ta bl e status due to the hermetic chassis, which
prevents the component and ci rc ui ts from being corroded by du st and moisture, thus increasing the
service life.

17. The reproduction o f th e music comes to unprecedented by t he s hock isolation design of a variety
of materials with a long-term experiment verification.

18. Unique and adjustable bronze alloy spikes

19. The internal audio cables are all 6N OCC customized by Atlas Cables in Scotland.

20. The external terminal are all 75 ohm customized by WBT with bandwidth over 1G

21. Digital and analogue part are independent.

Warning: The apparatus has a 200 hours a gi ng process before it leaves factory, a nd it c ou ld
enter the work state each time after booting 30 minutes. Please feel relieved the use.

7

Characteristic

Pre amp RCA analogue output:
Frequency response： Hz-20Khz -0.1dB；
THD-N：<0.001% @ 1khz/20khz,
SNR：-100dB
output amplitude：1.2V
Output impedance：50 watt

Amplifier Parts：
Output power： 100 watt RMS／channel@8 ohm；160watt RMS／channel @4ohm
Frequency Response ： 20Hz- 20kHz ±0.1dB；3Hz-650kHz -3dB
Slew Rate： 85v /uSec
Dampening Factor： At 100hz 8Ω = 800
THD-N：<0.02% @ 1khz/20khz,100W,8 ;

Digital Part：
receivable sample frequency／bit depth：PCM：16bit44.1khz；24bit 44.1k hz，4 8k hz，9 6k hz，

176.4khz，192khz，352.8khz，384khz；
1Bit DSD：DSD56/2.8Mhz；DSD128/5.6Mkhz；DSD256/11.2Mhz

Digital audio input：
HDMI；USB；AES／EBU（XLR） ；S/PDIF（RCA）；Optical
Pre amp analogue output：RCA non symmetric
Speakers output：WBT terminal

Power：AC 220V 50Hz
Static power consumption ：25Watt
Maximum power consumption：500
Net weight：30kg
Size：45x43x18.5cm(Width*depth*height)
Package size：71x58x32cm(Width*depth*height)
Gross weight：48kg

20

Ω

Watt

Photo s and techn ical specifications for refere nce only and are sub ject to c hange wit hout noti ce.

Technical specification
