Vibra-Tite 140 Technical Data
Technical Data Sheet
0%
20%
40%
60%
80%
100%
120%
5 min 10
min30min
2 hr
4 hr 8 hr 24 hr
Cure Time
% of Full
Stre ngth
Steel Phosphate/oil Zi nc
Vibra-Tite® 140
Product Description
Vibra-TITE 140 is a high strength, anaerobic thread
locking compound. Vibra-TITE 140 is designed for
the p ermanent locking o f t hreaded f asteners. T he
product pe rforms on a luminum, s teel, pl ated
fasteners, stainless steel, a nd s pecial alloy parts.
Vibra-TITE 1 40 e xhibits good te mperature s tability
and is solvent resistant.
Typical Applications
Vibra-TITE 140 w ill lo ck a nd s eal la rge f asteners.
Vibra-TITE 1 40 is used i n applications where shock
and vibration may cause the fastener to loosen.
Properties of Uncured Material
Chemical Type Anaerobic
Appearance Red
Toxicity Low
Solids 100%
Viscosity @ 25ºC, cPs
Brookfield RVT,
Spindle 3 @ 20 rpm 400-600
Specific Gravity 1.10
Typical Curing Performance
Cure Speed
The cure speed is depended on temperature and
substrate. T he g raph b elow s hows t he B reakaway
Strength on M-10 Steel, Phosphate/oil, and Zinc
finishes.
Threadlocker
November 2016
Performance of Cured Material
Typical Values
Fixture Time 15-20 min@ 72
Full Cure Time 24 hrs @ 72
Temperature Range -60
(-51
o
F to 300oF
o
C to 150oC)
Breakaway Strength
3/8” Plain Steel nut and bolt @24 hr 140-300 lb
3/8” Zinc plate nut and bolt@ 24 hr 200-350 lb
Environmental and Fluid Resistance
(Shear strength values after 1,000 hours.)
Typical Values
Heat age @ 150
Engine oil @ 150
Brake fluid @ 150
ATF @ 150
50/50 water/
ethylene glycol @ 120
Water @ 100
Gasoline @ 25
Diesel fuel @ 25
Ethyl Alcohol @25
o
C 100%
o
C 80%
o
C 100%
o
C 100%
o
o
C 85%
o
C 100%
C 85%
o
C 100%
o
C 95%
Instructions for Use
Ensure p arts ar e cl ean, d ry and f ree f rom o il an d
grease.
Compatible Primers
Primers such as Vibra-TITE Excel 611 (Primer N) or
Excel 612 (Primer T) can be used to speed the fixture
time of the adhesive. Fixture times can improve by as
much as 50%. The use of primers can result in lower
strength a nd performance s hould b e tested af ter f ull
cure.
o
F
o
F
-in
f
-in
f
Technical Data Sheet
Vibra-Tite® 140
General Information
Storage
Product should be stored in a cool and dry location at
temperatures b etween 1 4°F (-10°C) t o 86°F ( 30°C).
Shelf l ife is 2 years from date of manufacture when
stored at 72±8°F (22±4°C).
Note
Vibra-TITE 140 is r ecommended for t hreaded
components un der 1" i n di ameter. I t i s c olor c oded
red and on ce c ured, s eals a nd v ibration pr oofs t he
assembly giving controlled breakaway and prevailing
torques. Product conforms to MIL-S-46163A, ASTM
D-5363, NSF.
Health & Safety in use
IRRITANT: C ontains M ethacrylate E sters which
may i rritate e yes, r espiratory o rgans a nd s kin. I n
case o f co ntact with t he skin, wash i mmediately
with plenty of water.
Threadlocker
November 2016
