VIA Technologies VNT6656G6A4X, VNT6656G6A1X User Manual
VNT6656G6A10/
VNT6656G6A40
USER'S MANUAL
Revision 1.0
February 22, 2006
VIA TECHNOLOGIES, INC.
Copyright Notice:
Copyright © 2005, VIA Technologies, Incorporated. All Rights Reserved.
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise without the prior written permission of VIA
Technologies, Incorporated.
VNT6656G6A10/VNT6656G6A40 may only be used to identify WLAN products of VIA
Technologies, Inc.
is a registered trademark of VIA Technologies, Incorporated.
All trademarks are the properties of their respective owners.
Disclaimer Notice:
No license is granted, implied or otherwise, under any patent or patent rights of VIA
Technologies Inc. VIA Technologies Inc. makes no warranties, implied or otherwise, in
regard to this document and to the products described in this document. The information
provided by this document is believed to be accurate and reliable as of the publication date
of this document. However, VIA Technologies Inc. assumes no responsibility for any errors in
this document. Furthermore, VIA Technologies Inc. assumes no responsibility for the use or
misuse of the information in this document and for any patent infringements that may arise
from the use of this document. The information and product specifications within this
document are subject to change at any time, without notice and without obligation to notify
any person of such change.
Offices:
USA Office: Taipei Office:
940 Mission Court 8th Floor, No. 533
Fremont, CA 94539 Chung-Cheng Road, Hsin-Tien
USA Taipei, Taiwan ROC
Tel: (510) 683-3300 Tel: (886-2) 2218-2078
Fax: (510) 683-3301 or (510) 687-4654 Fax: (886-2) 2219-8461
Web: www.vntek.com Web: www.vntek.com.tw
VIA Technologies, Inc.
User's Manual
Revision History
Release Date Revision Initials
1.0 2006-02-22 Initial release. RTW
Revision 1.0 • February 22, 2006 - iii - Revision History
1.
2.
3.
VIA Technologies, Inc.
User's Manual
Table of Contents
Features........................................................................................................................1
1.1.
Drivers and Applications.......................................................................................... 1
1.2.
Certifications ........................................................................................................... 1
1.3.
Software Packages ................................................................................................. 1
1.4.
Programming Guide ................................................................................................ 1
Drivers and Utilities ..................................................................................................... 2
2.1.
Drivers..................................................................................................................... 2
2.2.
Utilities for end users............................................................................................... 2
2.3.
Utilities for manufacturers........................................................................................ 2
Software Package Information ................................................................................... 3
3.1.
Directory structure................................................................................................... 3
3.2.
Driver Keywords/Parameters .................................................................................. 4
4.
Windows Utilities ......................................................................................................... 6
4.1.
WiFiset .................................................................................................................... 6
4.1.1. Status................................................................................................................... 6
4.1.2. Config................................................................................................................... 6
4.1.3. Site Survey......................................................................................................... 10
4.1.4. Statistics............................................................................................................. 11
4.1.5. Signal ................................................................................................................. 11
4.1.6. Profiles ............................................................................................................... 12
4.2.
WPA Networking ................................................................................................... 16
Appendix A: Terminology................................................................................................... 19
Appendix B: Important Notices.......................................................................................... 20
Revision 1.0 • February 22, 2006 - iv - Table of Contents
VIA Technologies, Inc.
User's Manual
1. Features
1.1. Drivers and Applications
Drivers available for Microsoft Windows 95/98/ME/NT/2000/XP and all major
distributions of Linux.
Setup utility for automatic driver installation on Windows.
Mass-production support tool.
Mass-production application interface for custom programs.
PATCH utility for driver customization. This utility allows the manufacturers to customize
the driver packages, such as changing the drivers’ icons and file names.
1.2. Certifications
"Designed for Microsoft Windows" Logo.
Wi-Fi Certified.
1.3. Software Packages
Software package for manufacturers: A complete set of drivers and utilities.
Evaluation package (CD version) for manufacturers: Includes MPTOOL, Winsetup, and
drivers for Windows only.
Software package for end users: Includes all drivers and utilities, except MPTOOL and
PATCH.
1.4. Programming Guide
All drivers are available in the binary format. Source codes are not released.
An EEPROM layout guide is available.
Revision 1.0 • February 22, 2006 - 1 - Features
VIA Technologies, Inc.
User's Manual
2. Drivers and Utilities
2.1. Drivers
DRIVER TYPE DESCRIPTION
NDIS 5 Supports Windows 98, 98 SE, ME, 2000, XP, XPe, and Sever 2003.
NDIS 4 Supports Windows NT 4.0.
NDIS 3 Supports Windows 95 and 95 OSR2
WinCE 4.2 Supports Windows CE 4.2.
WinCE 5 Supports Windows CE 5.0.
x64 Supports AMD 64-bit CPUs.
.
2.2. Utilities for end users
UTILITY NAME DESCRIPTION
Winsetup Automatic driver installation, uninstallation, and updating utility for
Windows 95, 95 OSR2, 98, 98 SE, ME, NT 4.0, 2000, XP, and Sever
2003.
WiFiset Wireless configuration setup tool for Windows 95, 95 OSR2, 98, 98
SE, ME, NT 4.0, 2000, XP, and Sever 2003.
2.3. Utilities for manufacturers
UTILITY TYPE DESCRIPTION
MPTOOL Mass-production tool for Windows 2000/XP.
MP API Mass-production application interface for manufacturer-specific
programs.
Revision 1.0 • February 22, 2006 - 2 - Drivers and Utilities
VIA Technologies, Inc.
3. Software Package Information
3.1. Directory structure
DIRECTORY DESCRIPTION
User's Manual
/ (Root directory)
/XPe Driver for Windows XP Embedded.
/WIFISET Wireless configuration setup tool for Windows.
/WINSETUP Windows driver setup utility for Windows 95, 95 OSR2, 98,
/MPTOOL Mass-production tool and the EEPROM layout guide.
/Win CE
/ CE4.2
/ CE5
/x64 Software for supporting AMD 64.
Drivers for Windows 95, 95 OSR2, 98, 98 SE, ME, NT 4.0,
2000, XP, and Sever 2003; release note; and other
documentations.
98 SE, ME, NT 4.0, 2000, XP, and Sever 2003.
Drivers for Windows CE 4.2 and 5.0.
Revision 1.0 • February 22, 2006 - 3 - Software Package Information
VIA Technologies, Inc.
3.2. Driver Keywords/Parameters
Figure 1. Properties—Advanced
User's Manual
Adhoc Beacon Interval
Defines the beacon interval in the ad hoc mode.
Antenna Diversity
Enables or disables antenna diversity.
Connection Rate
Specifies the connection rate (in Mbps): 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54, or Auto.
Default Channel
The user-defined connection channel—applicable in the ad hoc mode and AP mode.
Desired SSID
The user-defined SSID—to be automatically connected at driver startup.
Fragment Threshold
Defines the size at which packets are fragmented.
Revision 1.0 • February 22, 2006 - 4 - Software Package Information
