Verykool T7440 User Manual

1

1. Introduction

1.1 Verykool T7440

Introduction

Details Description

CPU ARM Cortex A7 1.2GHz Quad core Processor

Memory 512MB RAM

Storage

8GB Built-in storage (Approx. 4GB of built in storage is used by OS and

application files)

Micro SD Slot with up to 32GB expandable

Operating

System

Android™ 4.4 Kitkat.

Network GSM Single SIM Quad-band 850/900/1800/1900 MHz; WCDMA

Dual Band 850/1900MHz; HSPA+ 42 Mbps downlink and 11.5

Mbps uplink,

Connectivity 3G, EDGE, GPRS, Wi-Fi 802.11 b\g\n, Bluetooth (4.0), GPS/

A-GPS, USB OTG.

G-Sensor

Rotate screen

2

Camera

5.0 MP Rear camera with Flash, Front camera for video calling

Display

17.78 cm (7”) Display with HD Screen Resolution 1024x600 Full

Capacitive Multi Touch

Video

Formats

Support 3GP,AVI,MP4,M4V,MKV, WMV,MOV, FLV (With 3

rd

party application)

Image Viewer

Support JPG,PNG,BMP,GIF

Audio

Formats

Support AAC,AMR, FLAC, MP2, MP3, OGG

FM Radio

Yes

Audio Port

Speaker /3.5mm Earphone Jack / Internal Mic. and Earpiece

Hardware Keys

Power and Volume controller

Soft Keys

Return , Home, & Menu

Battery/

Power

2500mAh Polymer / 3.7V

Power

5V—1A

Dimension

192 x 108.2 x 9.9mm

Weight

250 gram

3

1.2 Know Your

Device

4

5

2. Getting Started

Installing the SIM card and Memory card

You need to remove a portion of the back cover before you can install the

SIM card and Micro SD card. Also, make sure to always turn off the power

before installing or replacing the SIM card and Micro SD card.

To install the SIM card: The SIM card contains your phone number,

service details, and phonebook/ message memory. Your device supports

both 2G& 3G SIM cards.

To install the memory card: To have additional storage for your images,

videos, music, and files, you can purchase a memory card and install it into

your device.

6

3. Read your notifications
