Welcome to choose the R80 mobile phone. This user manual states the
outstanding performance of the R80 mobile phone in detail. In addition
to the basic call features, the R80 mobile phone and the system
network also provide you with a variety of useful features and services
to facilitate your work and leisure activities.
The Company reserves the right to make any amendment on the
technical specifications without any advance notice.
Reading Statement for the Manual
In manual, different typesetting styles are used to interpret different
operating details, and the specific interpretation is as follows:
OperationDescription of ContentsExample
Showing
contents
General
key
Functional
key
Menu itemShow in bold italicsHold a call
Note:
The picture shown in the manual are only used as function hint
pictures which may be different from the ones shown in the mobile
phone, and the ones in your mobile phone shall prevail.
Show with normal characters0-9
All the keys except functional keys are
shown by normal characters with frames
Functional key is shown with bold and
frame
Health and safety
Batteries
Never use a charger or battery that is damaged in any way.
Properly use the battery. Do not short-circuit the battery, which may
damage the battery, cause heat or cause fire.
Do not dispose of batteries in high temperature of in a fire as they may
explode.
Return the waste battery to the dealer or designated recycling center.
Do not dispose as household waste.
Battery charging time depends on the remaining battery charge, the
type of battery and the charger used. The battery can be charged and
discharged hundreds of times, but it will gradually wear out. When your
phone’s operating time is noticeably shorter than normal, it is time to
buy a new battery.
Use only original or approved chargers and batteries.
Unplug the charger from the electrical plug and the device when not in
use.
Do not overcharge, which will damage the battery and shorten its life.
Leaving the battery in extremely hot or cold places will reduce the
capacity of the battery. Cool down or heat up the temperature to normal
level (Li-ion batteries are particularly affected by temperatures below
0 (32°F)).℃
Road safety
Your wireless phone gives you the powerful ability to communicate by
voice, almost anywhere, anytime. Therefore, you must uphold some
important responsibility.
When you are driving, driving is your first responsibility. When using
your wireless phone while driving, be more alert and follow local
regulations.
Understand the wireless phone and features, such as speed dial and
redial which can help you make a call more conveniently without
disturbing your driving.
Use a hands-free set if possible. Hands-free accessories may promote
the convenience and safety of using your wireless phone.
Place your phone where it is easy to access and does not require you
to move your eyesight. If receiving a call at an inconvenient moment, let
your voicemail answer for you.
When on the phone, tell your conversation partner that you are driving.
Hang up in traffic jams or bad weather. Rain, rain with snow, snow, ice
and traffic may be dangerous.
Air bags, brakes, speed control systems and fuel injection should not be
influenced by radio transmission. If you have these problems, contact
your car dealer immediately.
Switch off your mobile phone when fueling or anywhere two-way radio
equipment usage is prohibited. Do not put your phone near flammable
and explosive substances. Internal spark may cause fire or explosion.
Switch off the mobile phone prior to airplane take-off. To prevent
interference to communication systems in the plane, never use a phone
during flight. Using a phone before the plane takes off may be allowed
by the crew in accordance with safety regulations.
During flight, make sure that your phone will not be automatically
switched on by an alarm you have set.
Operating environment
Remember to follow any special regulations in force in your area and
always switch off your phone whenever it is forbidden to use it, or it may
cause danger.
When connecting the phone or any accessory to another device, read
its user’s guide for detailed safety instructions. Do not connect
incompatible products.
It is recommended that the equipment only be used in the normal
operating position (held to your ear with the antenna pointing over your
shoulder) for your satisfactory operation of the equipment and for the
safety of personnel.
Do not expose the equipment to temperature below -10 (14°F) or℃
above 50 (122°F).℃
Electronic devices
Most electronic equipment is shielded from radio frequency signals.
Consult the manufacturer for relevant information.
Pacemakers: Maintain a minimum distance of 6 inches (15cm) between
a wireless phone and a pacemaker; do not put your phone in a pocket
near the chest; use your ear furthest from the pacemaker to reduce
possible interference. If you have any reason to suspect that
interference is taking place, switch off your phone immediately.
Hearing aids: Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may consult your
hearing aid manufacturer.
Other medical devices: If you use any other personal medical devices,
consult the manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able to assist
you in obtaining this information. Switch off your phone in health care
facilities when regulations posted in these areas instruct you to do so.
Vehicles: RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer.
Emergency calls
This phone, like any wireless phone, operates using radio signals,
which cannot guarantee connection in all conditions. Therefore, you
should never rely solely on any wireless phone for essential
communications like medical emergencies.
To make or receive calls, the phone must be switched on and in a
service area with adequate signal strength.
To make an emergency call, enter the local emergency number in
standby mode and press Snd to call.
Other important safety information
Use original or approved accessories. Any unapproved accessory may
affect the performance of your phone, damage your phone or even
cause personnel injury.
Your wireless phone sends out an electromagnetic field. Do not put the
phone near magnetic storage media such as computer disks.
Neighboring electric appliances such as TVs, phones, radio receivers
and PCs may affect the use of your phone and its performance.
Do not connect the phone to an incompatible device.
Only qualified personnel should service the phone or install the phone
in a vehicle.
Care and maintenance
Your phone is a product of superior design and craftsmanship and
should be treated with care. The suggestions below will allow you to
enjoy this product for many years.
Keep your phone out of the hands of small children and pets. They may
accidentally damage the phone or choke on small parts.
Keep the phone dry and avoid liquids that corrode the phone.
Do not use the phone with a wet hand, which may cause an electric
shock.
Do not store the phone in hot areas, which can shorten the life of
electronic devices, damage batteries or melt accessories.
Do not store the phone in cold areas. When the phone warms up to its
normal operating temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit boards.
Do not expose your phone to hot sun which may overheat your phone.
Do not place your phone near flammable liquids, gases or explosive
substances.
Do not drop or knock the phone. Rough handling can break internal
circuit boards.
When cleaning your phone, use a slightly damp or anti-static cloth. Do
not use a dry or static cloth. Do not use chemicals such as cleaning
solvents to clean the surface. Switch off the phone first and then do the
cleaning.
Do not paint the phone. Paint can prevent proper operation.
If your phone has a flash, do not use it too close to the eyes. This may
cause damage to eyes.
If the phone or battery gets wet and the label in the phone is damaged,
phone repairs are no longer guaranteed by the manufacturer’s
warranty, even if the warranty for your phone has not expired.
Improper use will invalidate the warranty! These safety instructions also
apply to originalaccessories.
Warning: The original manufacturer will not take on any responsibility
for the users who are not in compliance with the above advices or
improperly use the mobile phone.
Note: The application of value-added services of the mobile phone is
provided by relevant service providers. Please refer to the relevant help
or providers’ notes for detailed information.
Statement: The Company reserves the right to improve the
product without making any advance notice, and keeps final
interpreting rights on the product performance. The company
commits to improve the product quality and gradually launches
new versions of products. So if the contents stated in the manual
are slightly different from the function, specification or design,
please refer to the mobile phone. Such changes are not notified
additionally, your understanding is appreciated.
1Start Using
1.1 Battery
The battery is attached with the mobile phone. The battery is not
charged when the mobile phone is purchased but can support power
on. Please recharge it for use after complete use up the battery for the
first three times, which makes this battery easier to achieve the best
using state.
1.1.1 Uninstallation and installation of battery
!Put the back of the mobile phone upward; release the bolts first
then take off the rear cover according to the chat below.
!Dig out the bottom of the battery and get the battery out.
!When installing the battery, insert the metal teeth at the top of the
battery into corresponding slot of the mobile phone, and then press the
battery down to install the battery in place. The battery must be ensured
to be installed before power on.
!Finally install the rear cover and fix the bolts of the mobile phone.
1.1.2 Charging the battery
When the power of the battery was lower than normal, the phone will
prompt battery low. Please charging for the battery, otherwise you will
lose the files which not saved. If you don’t charge for a long time, the
phone will be powered off automatically.
When charging, the battery icon at the right upper corner of the screen
will appear in a dynamic rolling manner. During the charging period, the
battery, mobile phone and charger will become hot, which is normal a
phenomenon.
Warning:
The stated charging temperature ranges from 0 to 40. Please℃℃
do not use charging equipment if the temperature exceeds the
range. Please do use the charger provided by the supplier.
Application of unauthorized charger may trigger danger and
breach the mobile phone maintenance warranty.
1.1.3 Use of battery
In actual use, the standby time and talk time of the mobile phone varies
with the network status, working environment and different using
manners.
1.2 SIM card
Your network operator will provide you a SIM card which is the key for
your access to the digital GSM network. Prior to use the phone, you
need to insert effective SIM card in the mobile phone.
All relevant information concerning network connection will be recorded
in the SIM card. SIM card can be removed from your mobile phone and
be used in any other GSM mobile phone (new mobile phone
automatically read SIM card).
In order to prevent loss and damage to the information in the card, you
should avoid touching the metal area and keep it away from electricity
and magnetic places. SIM card once being damaged, you will not be
registered to the GSM network.
Warning:
You must power off the mobile phone before removing the SIM
card. Inserting or removing the SIM card is absolutely prohibited
when the external power supply is connected, otherwise SIM card
and mobile phone may be damaged.
1.2.1 Insertion of SIM card
!Power off the mobile phone, remove the rear cover and battery.
!Insert the SIM card correctly in the card slot; finally install the rear
cover and battery of the mobile phone.
1.2.2 Unlock the SIM card
In order to prevent illegal use, SIM card adopts PIN code (personal
identification code) encryption protection.
If this function is selected, PIN code should be input correctly each time
when you power on the mobile phone, thus to unlock the SIM card for
normal use. Users can disarm the SIM card protection but illegal use of
the SIM card cannot be prevented.
If the PIN code input is error for three consecutive times, your SIM card
will be locked by the network. The mobile phone will enquire the PUK
code which will be provided by your network operator. If the PUK code
input is wrong for 10 times, the SIM card will be permanently barred.
Note:
Your network operator will set a standard PIN code (4 to 8
numbers) for you and you should change it to private password as
soon as possible.
1.3 Plug and unplug the Memory card
!Power off the mobile phone, remove the rear cover and battery.
!Open the memory card holder, and insert the memory card into the
slot at the bottom according to the chat below, then close the memory
card holder.
1.4 Plug and unplug the earphone
Open the USB cover and insert the connector of the earphone to the
earphone jack at the right side of the mobile phone. Gently pull out the
earphone to remove it.
1.5 Status bar and content
In standby screen you can get the information that you need from the
indication icons on the screen.
Indicating the current signal strength
Indicating that the phone is connecting to current network
Indicating the unread text message
Indicating there is MMS sending or downloading
Indicating the unread MMS
Divert all voice calls has been set
Indicating missed call
The current alert type is ring only
The current alert type is vib. only
The current alert type is vib. and ring
The current alert type is vib. then ring
Indicating that silent mode activated
The mobile phone is locked
Indicating that earphone has been inserted
Indicating that the Bluetooth has been activated
Alarm has been set
Indicating current battery capacity
1.5.1 Keys
Functions of the keys are described as following:
SNKeysFunction description
Left soft key
1
(LSK)
OK; pop-up menu; short press in the
standby screen to enter the main menu.
Right soft key
2
(RSK)
3Send key (Snd)
4End key
5OK key
6Navigation key
7Keypad
8Receiver
9GPS keyEnter into GPS module in standby screen.
10MFD keySwitch displays on sub screen.
11LED
12Hand StrapAppend the accouterment for your phone.
Clear; back; short press in the standby
screen to enter the Phonebook.
Making a call; in dual SIM mode, press Snd
key to select the SIM card for dialing out;
answering a call; in the standby screen
press the Snd key to enter the Call history.
Hang up a call; go back to the standby
screen.
OK; short press to enter the Shortcuts
screen.
Left navigation key (L): moving to the left; in
the standby screen, press it to switch to the
next module clockwise.
Right navigation key (R): moving to the right;
in the standby screen, press it to switch to
the module anticlockwise.
Up navigation key (U): moving upward; short
press in the standby screen to turn up the
volume.
Down navigation key (D): moving
downward; short press in the standby
screen to turn down the volume.
Input; in the main menu screen short press
the number key to enter corresponding
menu; in standby screen, long press 2-9 key
to speed dial out (need set); press LSK then
* key to lock the keypad; long press # key to
active Silent mode; in the editing state, short
press # key to switch input method; short
press * key to enter the symbol choosing
screen; long press 0 key in dial screen to
input +, p, w.
Listen to the voice of the other side when
calling.
Turn on/off LED light according to the state
of the LED key.
13LED key
14USB jack
15Camera key
16Camera lensFor finding a view with the camera.
17Sub screen
18Speaker
Turn on LED light when pressing the key
down and turn off when release the key.
Connecting USB cable, charger or insert the
earphone to answer calls and to listen to the
music, and so on.
Press to launch the camera in standby
screen; in preview screen press camera key
to take a photo.
Show some defined information and the
display will switch by pressing MFD key.
For activating the speaker, you can listen
audio or calls in hands-free mode.
1.5.2 Text input and edit window
Enter the text input screen, you can short press the * key to enter the
symbols selecting screen; short press the # key to switch input method.
There are preset some input methods in your phone; you can select the
one which you liked.
1Dial and answer the call
1.6 Making a call
When the network operator’s logo appears on the screen, the mobile
phone enters into the normal standby state in which you can dial or
answer a call. The network signal strength indicator at the top of the
screen. The call quality is relatively largely impacted by obstacles.
Therefore, movement in a small range can effectively improve the
signal strength.
1.6.1 Direct dial
Making domestic call
In the standby screen, input the call numbers (please add the area code
for domestic long-distance calls), then press the Snd key to make the
call.
Calling extension of fixed number
When calling the extension number of a fixed number, you need to dial
the host number and then dial the extension number according to the
corresponding voice hints. If you insert “p” between the host number
and extension number, the mobile phone will automatically dial the
extension number for you.
Making an international call
To make an international call, you simply need to input the symbol “+”
(long press 0 key to switch), then input the country code and complete
phone number that you want to dial.
1.6.2 Making a call from the Phonebook list
In the Phonebook list, select corresponding contact person and phone
number press Snd key the phone will dial out the contact directly.
1.6.3 Speed dial
In Speed dial, you can separately set number keys 2-9 to set up phone
numbers.
On the standby screen, long press the number keys and you can
automatically dial the number that has been set up. If speed dial has
not been set for the number key you long pressed, the mobile phone
will hint you “No speed dial number”.
1.7 Answering a call
1.7.1 Answering new call
If there is a new incoming call when in call progress, the mobile phone
will pop up caller screen (call waiting is activated) and the mobile phone
will give a short prompt to tell you that you have a new call. At this time,
you can press Snd key or activate Options to select Answer to answer
the new call. When you answer a new call, the original call will enter
holding status. At this time, you can activate Options to select Swap to
the original call, and the new call will enter holding status.
Note:
When you are in call progress, the new call to another SIM card
can’t be dialed in.
1.7.2 Connecting two calls at the same time
When two telephone numbers are connected, activate Options, and
you can operate as follows:
Swap: switch call.
Conference: when making conference call, you can have a talk
separately with designated conference participant.
End single call: hang up the current call.
End all calls: hang up all the current calls.
Transfer (network support is required): transfer the current call to your
designated phone number.
New call: input new phone number to dial.
Phonebook: enter the phonebook screen.
Messages: edit the message to send it.
Call log: enter call history screen.
Sound recorder: record the current call.
DTMF: on/off settings can be conducted. If the function is activated,
when calling the telephone exchange, you can call the extension in
accordance with voice clews; the aforesaid functions are unavailable if
the function is off.
1.7.3 Conference call
During the conference call, activate Options, and you also can operate
as follows:
Hold conf. call: hold the current call with members of the conference,
then others cannot hear your voice; and the option of Hold conf. call
changed to Retrieve conf. call, select it and you can recover normal
conference call.
Split: separate the selected member from the conference call.
1.8 Emergency call
In any country using the digital GSM network, if you are in the network
coverage area (you can check the network signal strength at the top of
mobile phone screen), even without the SIM card, you also is able to
make an emergency call.
Inputting the PIN code or unlock the phone unlocking screen, press
SOS and you can make an emergency call.
Note:
The emergency call numbers in different countries or regions are
different. Please refer to the local numbers for specific emergency
service numbers.
2Menu operation
1.9 Main menu structure
The main menu of the phone is composed of Phone, Fun and Sports.
On standby screen, you can switch the module via the navigation key.
1.10Selection of main menu
In the standby screen, press LSK to enter the main menu of
corresponding module. On the main menu screen, you can press
navigation keys to select the menu you want to enter. You can also
enter the menu screen through pressing corresponding number keys
with the function menu.
1.11 Menu Functions Form
Phone
Phonebook
Call history
User profiles
File manager
Messages
Email
Organizer
STK
Services
Settings
Connectivity
Java
Fun
Fun & Games
Image viewer
Media player
Video recorder
Camera
Melody composer
FM radio
Sound recorder
Schedule FM record
MSN
YAHOO
Ebook reader
Sports
GPS
Temperature
UV sensor
Ecompass
Pedometer
Sunrise
3Sub screen
The mobile have sub screen, you can press MFD key to light the sub
screen and short press the key to switch the display screen.
Date and time display screen
Display the date and time according to the settings in phone.
Ecompass display screen
You can judge the direction by the pointer (pointer indicate north), but
the ecompass have not been calibrated so the result may not nicety.
Please enter ecompass and calibrate it before using.
Temperature display screen/ Pressure display screen/ Altitude
display screen
Display the data of temperature/ pressure/ altitude, the same to the
display in Temperature module.
GPS display screen
Display the longitude, latitude and height of the position. The default
display is zero before GPS orientation is completed. Enter GPS display
screen, the phone will turn on the GPS function automatically. It will cost
some time to collect satellite data and establish its current location; the
time required could also be affected by the signal strength of GPS.
When the backlight of sub screen is off, the phone will exit GPS
function. It is suggested that you set the backlight period to longer, or
enter GPS module in Sports to complete the orientation before using
the sub screen for GPS result. The GPS data will not be displayed in
sub screen until the orientation is completed; GPS data will
automatically clear to zero after turning off GPS.
4Phone
1.12Phonebook
Enter the phonebook screen, input the first letter of name, you can
search the accordant records in Phonebook. Select Add new contact to
add the contact. When the record is not empty; activate Options to
conduct the following operations:
IP dial: add IP number and call the current contact.
Send message: send message to current contact.
Send vCard: send the information of current contact as vCard mode.
Edit: edit the current contact.
Delete: delete the information of current contact person.
Import contacts: import the stored contact that of .vcf format to phone,
SIM or memory.
Mark several: you can do the copy, move, delete or export operation
for the marked contact.
Advanced: you can set speed dial, delete duplicated contacts, also can
view my vCard, extra numbers and memory status.
1.13Call history
Enter call history, there displays the records of dialled calls. You can
press left/right navigation key to switch to other sheet, such as all calls,
received calls and missed calls.
In every sheet, activate Options, you can operate as follow: IP dial,
send message, add to call blacklist, add to SMS blacklist, edit before
call, delete, delete all, advanced.
1.14User Profiles
User Profiles are a group of preset characteristic definition. You can
also change and save other definitions in the profiles according to your
own preferences. The phone provides a set of default profiles including
the General, Meeting, Outdoor, Indoor, Silent, Headset and Bluetooth.
In standby screen, long press # key can active Silent mode quickly.
Only when the earphone is inserted the headset profile can be
automatically activated, while all other profiles will be automatically
disabled.
After selecting the other profiles except the headset and bluetooth
profile, press OK key to active the lighted profile. Then the working
styles of the mobile phone are set according to the selected profile.
When the earphone is inserted, the headset profile will be automatically
activated.
Active LSK to enter the customize settings; you can set the parameters
under different profile such as tone setup, volume, alert type, ring type
extra tone and answer mode.
1.15File manager
Enter into file manager, then the screen shows phone and memory card
(memory card is inserted in the phone). At the top of the screen, the
capacity and surplus capacity of the phone or memory card are
displayed. The following operations are available:
Open: enter the files list under the root directory.
Format: format the phone/memory Card, which will delete all the data
stored in the current phone/memory card.
Rename: rename the memory card. This menu only displays in the
options when select the memory card.
Details: shows the name, total size, and free size information of the
memory card. This menu only displays in the options when select the
memory card.
1.16Messages
Enter messages, you can press LSK to create a new message, you
also can switch to MMS in message editing screen by use the menu. In
messages screen, the following operations are available:
Inbox: you can view the received messages including SMS and MMS;
you also can do some operations, such as view, reply, call sender,
forward, delete and so on.
Drafts: store the messages that confirm to save.
Outbox: store the messages that sent unsuccessfully.
Sent messages: store the message that sent successfully according to
the common settings.
Archive: store the messages that move to archive.
Delete messages: you can choose to delete messages in defined
folders.
Broadcast message:you can set the receive mode, languages and
channel for receive the broadcast messages to read.Templates: you can edit or remove the templates in text message or
user defined templates of multimedia message; you also can write
message from the templates.
Message settings: set the correlative parameter of text message and
multimedia message.
Note:
Please set correct network connections in server profile before
setup and send MMS. Here, insure your SIM card support GPRS
connection, and turned on the MMS. Please consult with your
network service provider.
1.17Email
Enter Email; you can conduct the following operations:
Send and receive: send and receive the mail of current account.
Write Email: edit the new mail.
Inbox: store the received mails.
Outbox: store the mails that are not successfully sent out.
Sent: store the sent mails.
Drafts: store the current saved mails.
Clear mailbox: you can delete all the mails in selected mailbox.
Delete marked Emails: delete all marked mails.
Email accounts: set up the Email account according to the information
provided by mail service provider.
Templates: store the current templates of the phone.
Note:
Please set corresponding mode in Email profile before edit Email
and insure your SIM card support GPRS connection. Please
consult with your network service provider.
1.18Organizer
1.18.1 Alarm
There are 5 alarms in your mobile phone. The functions and using
methods of the 5 alarms are completely same. You can set to turn
on/off respectively.
Set alarm
Select an alarm, enter the settings screen of this alarm, you can turn
on/off this alarm, and set the time of the alarm, at the same time, you
can set this alarm in detail.
Alarm remind
When the alarmingtime comes, there is alarm hint in handset
(according to alarm settings).
If the mobile phone is in power off state, after the time of alarm sound
come, pop up the power on confirmation screen, here, you can select
power on or not.
Pay attention to that the alarm still sounds according to the former
setting time after you adjust the date and time. You can reset the date
and time of next alarm according to the changed date and time.
1.18.2 Calendar
Enter calendar screen, the current month calendar is displayed and the
current date has a frame around the number with special color. Activate
Options, and you can operate as follows:
View: you can view the calendar that effectives in today. You also can
add a new calendar or edit, delete and send the selected calendar.
View all: you can view the entire calendar. You also can add a new
calendar or edit, delete and send the selected calendar.
Add event: you can choose one type and add a new calendar.
Delete event: delete current event.
Jump to a date: input the date need to be switched (in a valid period of
time), there will display the inputted date.
Go to weekly view (Go to monthly view): Set the display mode of
calendar as weekly view chart/monthly view chart.
1.18.3 Tasks
This function is used for add and view task items.
1.18.4 Calculator
The calculator performs four operations as addition, subtraction,
multiplication and division. Enter calculator screen, you can input
numbers directly and press navigation key to switch the operation which
you need, then start calculation.
When the calculation of dividing 0 overflows, the result is larger than
999999999999 or less than -999999999999, the mobile phone will
display the wrong hint “E”.
1.18.5 Currency converter
In this function, if you input the rate and the amount of money in local,
you can get the result of the equivalence money of foreign.
1.18.6 Typical stopwatch
In typical stopwatch screen, you can select the split timing or lap timing
and view records that you have saved.
1.18.7 World clock
Enter world clock screen, active Options you can select the city by
press OK key.
1.18.8 Unit converter
Enter into Unit Converter you can select Weight or Length to converter.
In converter screen, select the unit then input the relative data, press
LSK, the result will be displayed automatically.
1.19STK
This function is provided by the network operator. According to the
services provided by the SIM card, there will be different options
appearing in this directory. The name and content of the menu are
based entirely on the services provided by the network operator. For
more information, please contact with the network operator.
Note:
This function depends on whether the network operator provides
this service and whether you have ordered this service.
1.20Services
1.20.1 WAP
Enter WAP there displays the following options:
Homepage: you can access the preset website directly.
Bookmarks: bookmark is used to save the websites that you are
interested.
Recent Pages: look over the recent history that browsed.
Offline pages: look over the pages that saved as offline pages.
Input address: enter the website editing screen.
Service inbox: storedthe service message.
Settings: enter the Settings menu list and the following operations are
available:
Edit account: you can edit and activate the selected account for
the SIM card. You can surf on the internet only when you set and
activate correctly according to local network.
Browser options: set relevant parameter of browser.
Service message settings: turn on/off receiving service message.
Clear cache: the messages that you have visited will be stored in
the cache of the mobile phone. Select the operation to erase the
temporary message in the cache. Please erase the temporary files
recording your internet surfing message.
Clear cookies: remove the browsed website message stored in
the cache of the mobile phone.
Trusted certificates: view the trusted certificates.
1.20.2 Data account
GSM Data: enter into GSM Data; you can add account for GSM data.
GPRS: enter into GPRS; you can add account for GPRS.
1.20.3 Connection management
You can view the current connection states.
1.21Settings
1.21.1 Phone settings
Time and date: modify the current city, time, date and the format.
Schedule power on/off: after setting and activating this function, the
mobile phone will be automatically powered on/off at the corresponding
setting time.
Language: you can set the language of the mobile phone.
Preferred input methods: there are multiplicities input methods to be
selected. You can choose one as the default original input method for
text editing.
Display setup: you can set the function such as screen saver, main
menu effect, show date, show operator name, greeting text and so on.
LCD backlight: you can set the Brightness and Time of the LCD
backlight respectively.
MFD LCD backlight: you can set the time of the MFD LCD backlight.
1.21.2 Call settings
Caller ID: you can set whether to allow your phone number being
displayed or not through select set by network, hide ID or send ID. This
function needs to be supported by the network service provider. Please
get in touch with the related network service provider to open the
relevant service.
Call waiting: you can activate/deactivate the function and also can
query the status of call waiting. After the function being activated, if you
have a new incoming call while in calling process, your mobile phone
will display the new call screen, and the call can be received normally. If
the function is deactivated, new incoming calls cannot be displayed.
Call divert: this function is used to transfer the call to your designated
phone. The success of call divert setting is related with the network and
SIM card. The system will give appropriate setting tips.
Note:
If the transfer call you set is a fixed phone, please add the area
code before the fixed phone.
Call barring: this function needs network support. Please contact your
network provider to open this business. Network provider will provide
the corresponding network password for you activate call barring
service.
Line switching: switch the phone current line.
More: you can set the function such as black list, auto redial, IP dial,
background sound, call time reminder, auto quick end, reject by SMS
and so on.
1.21.3 Network settings
In network settings, you can select appropriate network.
Note:
Please do not register networks inconsistent with the SIM card, so
as to prevent unavailability of normal use. For details, please
consult your service provider.
Network selection: search new network according to the network
searching mode or select the network you need from the network list.
Preferences: select and set the preferences of network.
GPRS Connection: you can set GPRS as always connectted or
connected when needed.
Flight Mode: you can set the phone standby profile as Normal Mode,
Flight Mode or Query When Power On.
1.21.4 GPS settings
You can set the mode for receiver, AGPS and time sync.
If you want to use the function of AGPS, you should make it on first and
then to enter the edit screen of AGPS profiles to select the correct data
account from GPRS and active this profile. Thus, you can use the
AGPS function in GPS mode.
1.21.5 Security settings
SIM lock: this function can prevent others from using your SIM card
without your permission. After the SIM card PIN code is activated,
correct PIN code must be input every time when the mobile phone is
powered on; otherwise you can only make emergency call.
Note:
PIN code is the operating password and relative with the SIM card.
The SIM card will be locked, if the PIN code is wrong for 3
consecutive times. At this time, you need the PUK code to unlock
the SIM card. The PUK code may be provided for you together with
the PIN code and the SIM card. If not, please contact your network
provider.
Phone lock: this function is to lock the phone and prevent other people
from using the mobile phone without permission (default password is
0000). After enable the phone lock, you must input the correct
password every time powering on the mobile phone, unless the mobile
phone cannot be used normally.
Auto keypad lock: after this function is activated, when the phone is in
standby status and without any operation, the keypad will be locked
automatically after the set time. Then the standby screen will show
keypad locked icon. At the left bottom corner of the screen, word of
Unlock will appear. If you need to unlock the mobile phone, you can
press PWR key, and then operate according to relevant screen
prompts.
Fixed dial: after the function is activated, the mobile phone is only
allowed to be used to dial the telephone numbers existing in the list. To
turn on the function, you need to input your PIN2 code. Please consult
your network service provider for specific situations.
Note:
When the Fixed dial function is active, the function of SIM card will
be restricted, such as dial call, send SMS, and send MMS and so
on.
Barried dial: this function needs to be supported by SIM card. Please
consult your network service provider for specific situations.
Change password: you can change the password of PIN, PIN2 and
phone password through the system prompts.
Certificate manager: you can view the certificates.
Theft tracker: enter the function, the password inputting screen
displays. After you input the correct password (default password is
0000), and enter the phone guard menu list, you can set the status and
receiving number of phone guard.
The function is activated and receiving number is set, when your phone
is inserted with another SIM card. The receiving number can receive
the current prompt message.
Remote control: enter into the password inputting screen, you can
enter the security control menu list if you input the correct password
(default password is 0000).
When the function is activated, there will remind the command identifier,
you can set the private command identifier, but it should contain Capital
and Lowercase, Numbers and Symbols, and should not less than 8
characters.
If this function is set, you can send editing order in form of SMS to the
phone that you lost with another phone and the lost one will perform
automatically the instruction, thus reaching effect of remote control.
The order format of the security control is:
Command identifier+order(+phone number)
Use security control order can achieve the function below:
Content of order
Function
(e.g. Command identifier is “123@!abC”;
Receiving number is “13987654321”)
Privacy protection: entering privacy protection and the password
inputting screen appears, you can enter the security control menu list if
you input the correct password (default password is 0000). Then you
can select Phonebook, Messages, Call history, File manager to setup
the privacy protection. For example: If you have setup the privacy
protection operation of Phonebook, when you enter the Phonebook, the
password inputting screen appears. You should input the correct
password for enter the Phonebook and do the corresponding operation.
123@!abCformat
123@!abCpower off
1.21.6 Miscellaneous settings
Sound effects: you can set the audio effect for your phone.
Motion life: if the function is on, you can shake the phone to switch the
media file for next or last when shaking in media player or mute the ring
when incoming call.
1.21.7 Restore factory settings
Enter into the restore factory settings, the mobile phone will prompt you
to input password (default password is 0000). You can carry on
corresponding operation after inputting the correct password.
After running the Restore factory settings, the environment setup (e.g.
user profile) restore to factory default setting.
After running the Restore settings and data, the phone clear up the
messages saved in phone while the environment setup (e.g. contact
person and sms that saved in phone) restore to factory default setting.
1.22Connectivity
1.22.1 Bluetooth
In connectivity, you can find the connectivity mode of Bluetooth. Enter
into Bluetooth menu list screen, you can operate as follows:
Power: turn on/off the Bluetooth function. When Bluetooth function is
turned off, all Bluetooth connection are ended, you can transmit and
receive data by using Bluetooth. Please turn off the Bluetooth function
when your phone is used for other operations, because Bluetooth
connection will consume the battery capacity.
Visibility: set on/off visibility of Bluetooth.
My device: enter into my device, if has not connected with other
device, you can select Search new device to search and compare with
the mobile phone, else the records of Bluetooth devices which has
connected with this handset are shown on the screen.
Inquiry audio device: system will automatically search the hands-free
device, and then shows the results after searching.
My name: you can change the phone name.
Advanced: you can view my address, set the audio path, storage,
sharing permission and remote control.
Note:
The received file that transmitted by bluetooth are stored in
Received folder automatically.
1.22.2 Synchronization
Enter synchronization screen, select an account, active Options, you
can operate as follows:
Sync now: after set the account correct, select this function to sync the
data.
Edit account: you can set the parameters of account, such as account
name, transport type, server settings, applications to sync and so on.
Sync log: you can view the log of the synchronization.
Note:
The server you have set should support synchronization. Please
insure your SIM card support GPRS connection. Please consult
with your network service provider.
1.22.3 Phone sync
Enter phone sync screen, you can operate as follows:
Sync: select the paired Bluetooth device to process synchronization.
Applications to sync: to select the application to transfer the data.
Phones: you can view the paired bluetooth device, active Options; you
can do the operation such as sync, rename, delete and so on.
1.23Java
You can install java file and play in the application, you also can edit the
settings for java.
5FUN
1.24Fun & Games
For richness your entertainment life, the mobile phone provides you the
interesting application. Please get more information in the instructions
of the phone.
1.25Image viewer
Enter the pictures list screen and activate Options, then the following
operations are available:
Slide show: you can select play to view the current picture according to
the settings.
Browse style: set the picture display mode.
Send: send the current picture.
Use as: use the picture as screen saver or caller picture.
Rename: rename the current picture.
Delete: delete the current picture.
Sort by: sort all pictures in the list.
Delete all files: delete all the pictures in the image viewer.
Select directory: set the path of folder to display.
1.26Media player
Enter the media player screen; activate Options, then you can operate
as follows:
Media library: there are many sorts for media; you can select All
media files to update all the media file to playlist, you also can select
add to update the media file in appointed folder.
Note:
If you select the update function in all media files, the entire media
file contained in your phone and memory card will be updated and
added to the playlist, maybe there have some files you don’t want
to play. So, you can use add function to add the appointed media
file.
My playlists: you can view the media that recently played or most
played, you also can view the media that have been adding to my
favorites.
Settings: set the parameters for player settings, audio settings, video
settings and Bluetooth settings.
1.27Video recorder
Enter into video recorder, activate Options, and you can conduct the
following operates:
Media player: play the current video file that saved in phone or
memory card.
Switch to camera: Switch to camera.
Camcorder settings: set the related parameter of video recorder.
Video settings: set the related parameter of the video file.
White balance: set the white balance state.
Effect settings: set effect styles of the video record.
Storage: set the storage location of video record.
Restore default: recover the parameters as factory default setting.
1.28Camera
Enter the screen of finding a view, you can operate as follows:
Switch to video recorder: Switch to video recorder.
Photos: the photo stores the pictures taken by mobile phone.
Camera settings: set the correlative parameter of camera.
Image settings: set the photo image size and image quality.
White balance: set the white balance state.
Scene mode: set the scene mode of shooting.
Effect settings: set effect style of the pictures taken.
Storage: set storage of picture.
Restore default: recover theparameters to factory default setting.
1.29Melody composer
Enter Melody composer, you can compose and save a new melody.
1.30FM radio
Enter into option list and conduct operations as follows:
Channel list: display all thechannels existed in the list.
Manual input: manually input the channels.
Auto search: automatically search channels and update the current
channel list.
Settings: set the correlative parameter of FM radio.
Record: you can record the current playing content of the radio.
Append: used for storing the recorded file while listen to the FM radio.
File list: list the audio file that recorded and stored..
1.31Sound recorder
When the recorder list is not empty, select one of the recording files and
activate Options, you can conduct the following operations:
New record: start the new recording.
Play: play the current selected recording file.
Append: continue to add record on the previously selected recorder
file.
Rename: rename of the current recording file.
Delete: delete the current selected recording file.
List: list the recorder file.
Settings: you can set the preferred storage location, file format, audio
quality of the recording file.
Use as: use thecurrent selected recording as ring tone or SMS tone.
Send: send current selected recording file.
1.32Schedule FM record
Activate the function, the phone turn on automatically FM radio and
record current program when time out.
1.33MSN
Enter MSN; you can conduct the following operations:
Start: you can input username and password to sign in.
Settings: you can do the operations of update settings, data account.
Updated Version: updated the version to the latest.
1.34YAHOO
Enter YAHOO; you can conduct the following operations:
Start: you can input username and password to sign in.
Settings: you can do the operations of update settings, data account.
Updated Version: updated the version to the latest.
1.35Ebook reader
This function can be used for read the files which are stored in the
phone or memory card (confirm the memory card is inserted).
Enter the screen of Ebook file list, activate Options and you can
conduct the following operations.
Open ebook: read the file current selected.
Clean up bookshelf: rearrange the files in the folder.
Global settings: set the font style, font size, scroll by, auto scroll, scroll
speed, full screen, Encoding, alignment and select storage for reading
of Ebook.
Book info: display the content of Ebook such as title, size, and format.
Delete: delete the selected file.
Delete all files: delete all files displayed in Ebook menu.
Sort by: arrange all files in sequence which is displayed in Ebook.
Apply global settings: renew the relative settings of Ebook.
Help: introduce shortcut key of Ebook functions.
6Sports
Please note that the accuracy of some of these functions
may vary depending on the surroundings and take a while to get
the accurate result.
1.36GPS
When the GPS is turned on, the phone must collect satellite data and
establish its current location. If the AGPS function has been
successfully set on, the phone also can be helped to establish its
location via GPRS.
Solemnly Tip: This system is only as a reference for your driving due
to the rapid development of urban transport. In this system, the map
may differ from the actual road conditions, please do not ignore traffic
rules and the actual road conditions. If there is traffic accident or any
other consequences during using this system, it is not responsible for
the company.
Note:
The software cannot be uninstalled, but you can remove digital
map data from the memory card manually. It is suggested you
backup the data before deleting. For the GPS application will not
work without map data. Some uses of the GPS function will
generate a fee for the connecting of GPRS. Please contact
Customer Service Center for detail information.
1.37Temperature
Enter into Temperature; the screen displays the temperature, pressure,
altitude of current location.
Press LSK to set the correct elevation at your first using, because it
requires a reliable source elevation data to determine the current height
of your location. If you cannot confirm, you can complete the height
definition through GPS function, for reference only because of accuracy
problems.
1.38UV sensor
Enter into UV sensor, select Ultraviolet Measure, test UV intensity
according to the phone hint. There will prompt the UV intensity and
advice in the screen after testing.
You can also enter Ultraviolet Explanation to learn about UV-related
content.
1.39Ecompass
Enter into the ecompass; you should calibrate the ecompass at first,
press LSK to enter and complete the calibration according to the
prompt information to determine the direction through the pointer. You
may have to repeat the calibration process more than two times
depending on the magnetic field surroundings.
Note:
The ecompass uses magnetic induction to sense earth’s magnetic
field, if there is a strong magnetic field around the phone, the
calibration will be affected. When using the ecompass to indicate
direction, please keep away from magnetic objects, so as not to
affect its accuracy.
1.40Pedometer
Enter into the pedometer, select Start pedometer, the count will show a
gradual increase as the movement. Please hold the phone in your
hands, and make sure your arm swing with the pace of nature during
performing this function.
You also can set stride length and view the history that has been saved.
1.41Sunrise
Enter into Sunrise; the screen displays the time of sunrise and sunset.
Press LSK to enter settings, you can set the date and the position; the
time will change according to the position and time zone you set.
7Other Functions
1.42 Mass Storage Function
The mobile phone supports Mass Storage function. Insert the Memory
Card in the mobile phone; connect the mobile phone and PC with the
attached USB cable, then the mobile phone becomes a mass storage.
If you connect USB cable to PC under the power on status, according
to tips you can select Mass Storage to enable USB mass storage
function or select Back to maintain the power on status, and charge the
mobile phone.
1.43 Webcam Function
In power on status, connect the phone to PC through USB cable and
select Webcam, the Webcam function is activated, you can do the
video chat with other person.
Requirements on PC configuration for use of webcam function:
1. The PC’s operation system is or newer than Windows XP SP2.
2. The tools for video chat need to be installed.
3. Internet network connection is smooth.
Other descriptions:
1. This function supports plug-and-play function.
2. The actual refresh rate of video chat is related with Internet network
speed, instead of the reasons of the mobile phone.
1.44COM port
In power on status, connect the phone to PC through USB cable and
select COM port; you can synchronize your phone with PC. Details
about the related tools, please consult with Customer Service Center.
8Common Questions
The mobile phone cannot be powered on
!The mobile phone cannot be powered on since the battery voltage
is too low. Please recharge the battery.
Unable to make some calls
!Call barring has been set and barred utilization of the mobile
phone. Please check and cancel call barring.
Other person is answering my call
!The mobile phone has been set into divert your calls to another
phone number. Please check and cancel call divert.
The mobile phone cannot search for the network
!The mobile phone is outside of the network coverage area (or there
are physical obstructions between the mobile phone and the
transmitter), and calls cannot be made or answered. If you are in one
room, please move close to the window.
In the operation process, the mobile phone may display the following
operating tips:
“PleaseInsert SIM”
!You must insert the SIM card before using the mobile phone. If the
SIM card has been inserted, please get it out and wipe clean with a dry
cloth on the golden region, and then insert the SIM card.
“Emergency”
!You are outside the network coverage area of the service provider.
But another network area where you locate allows you to make
emergency call according to the signal strength.
“Invalid SIM”
!The SIM card of the mobile phone is locked and the inserted SIM
card is unable to be accepted. Please insert the correct SIM card or
contact with the vendor.
“Please Enter PUK”
!The SIM card has been locked since the wrong PIN code has been
inputted for three times. You must consult your network provider for
special PUK code with eight numbers to unlock the SIM card (The PUK
code may have been provided with your PIN code at the same time).
Warning:
The SIM card will be permanently locked if you input the wrong
PUK code for ten consecutive times and you must apply for a new
SIM card from your network provider.
10 Maintenance Guideline
Welcome to use R80. If there is a problem when you using the mobile
phone, please contact with the vender or consult the local maintenance
center. If your mobile phone is in need of repair, you can take your
mobile phone to local maintenance center, if there is no local
maintenance center, please pass your phone and the purchasing
invoice to the vendor.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over
one gram of tissue. Device types R80
(FCC ID: WA6R80) has also been tested against this SAR
limit. The highest SAR value reported under this
standard during product certification for use at the
ear is 1.315W/kg and when properly worn on the body is
1.108W/kg. This device was tested for typical body-worn
operations with the back of the handset kept 1.5cm from
the body. To maintain compliance with FCC RF exposure
requirements, use accessories that maintain a 1.5cm
separation distance between the
user's body and the back of the handset. The use of
belt clips, holsters and similar accessories
should not contain metallic components in its assembly.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure
requirements, and should be avoided.
FCC WARNING
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause
undesired operation.
NOTE 1: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help.
NOTE 2: Any changes or modifications not expressly
approved by the manufacturer could void
the user’s authority to operate the equipment.
NOTE 3: The manufacturer is not responsible for any
radio or TV interference caused by
unauthorized modifications to this equipment. Such
modifications could void the user’s authority
to operate the equipment.
FCC Hearing-Aid Compatibility (HAC) Regulations for
Wireless Devices
On July 10, 2003, the U.S. Federal Communications
Commission (FCC) Report and Order in WT Docket 01- 309
modified the exception of wireless phones under the
Hearing Aid Compatibility
Act of 1988 (HAC Act) to require digital wireless
phones be compatible with hearing-aids. The intent of
the HAC Act is to ensure reasonable access to
telecommunications services for persons with hearing
disabilities. While some wireless phones are used near
some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or
whining noise. Some hearing devices are more immune
than others to this interference noise, and phones also
vary in the amount of interference they generate. The
wireless telephone industry has
developed a rating system for wireless phones, to
assist hearing device users find phones that may be
compatible with their hearing devices. Not all phones
have been rated. Phones that are rated have the rating
on their box or a label located on the box.
The ratings are not guarantees. Results will vary
depending on the user’s hearing
device and hearing loss. If your hearing device happens
to be vulnerable to interference, you may not be able
to use a rated phone successfully. Trying out the phone
with your hearing device is the best way to evaluate it
for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements
and are likely to generate less interference to hearing
devices than phones that are not rated. M4 is the
better/higher of the two ratings.
R80 is rated M3.
T-Ratings: Phones rated T3 or T4 meet FCC requirements
and are likely to be more
usable with a hearing aid’s telecoil than phones that
are not rated. T4 is the better/higher
of the two ratings.
R80 is rated T3.
Please power off the Bluetooth function while using
hearing aid devices with your R80.
Hearing devices may also be rated.
Your hearing device manufacturer or hearing health
professional may help you find this rating. Higher
ratings mean that the hearing device is relatively
immune to
Interference noise.
Safety and regulatory guide
The hearing aid and wireless phone rating values are
then added together. A sum of 5 is considered
acceptable for normal use. A sum of 6 is considered for
better use. A sum of 8 is considered for best use. In
the above example, if a hearing aid meets the M2 level
rating and the wireless phone meets the M3 level
rating, the sum of the two values equal M5. This should
provide the hearing aid user with “normal usage”
while using their hearing aid with the particular
wireless phone. “Normal usage” in this context is
defined as a signal quality that is acceptable for
normal operation. This methodology applies equally for
T ratings. The M mark is intended to be synonymous with
the U mark. The T mark is intended to be synonymous
with the UT mark. The M and T marks are recommended by
the Alliance for Telecommunications
Industries Solutions (ATIS). The U and UT marks are
referenced in Section 20.19 of the FCC Rules. The HAC
rating and measurement procedure are described in the
American National Standards Institute (ANSI) C63.19
standard.
For information about hearing aids and digital wireless
phones
FCC Hearing Aid Compatibility and Volume Control:
http://www.fcc.gov/cgb/dro/hearing.html
Gallaudet University, RERC:
https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSear
ch.cfm
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
