Vertiv Easymow 260 Installation Manual
Liebert®
GXT5™ UPS
208 V Input (L1, L2, N, G), 120/208 V Output
MV
Installer/User Guide
The information contained in this document is subject to change
without notice and may not be suitable for all applications.
While every precaution has been taken to ensure the accuracy
and completeness of this document, Vertiv assumes no
responsibility and disclaims all liability for damages resulting
from use of this information or for any errors or omissions. Refer
to other local practices or building codes as applicable for the
correct methods, tools, and materials to be used in performing
procedures not specically described in this document.
The products covered by this instruction manual are
manufactured and/or sold by Vertiv. This document is the
property of Vertiv and contains condential and proprietary
information owned by Vertiv. Any copying, use or disclosure of
it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered
trademarks of the respective companies. Any questions
regarding usage of trademark names should be directed to the
original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.
Table of Contents
Chapter 1: GXT5 Description ................................................................................................................................................................3
1.1. UPS Features and Available Models ....................................................................................................................................................................... 3
1.2. Front Panels ....................................................................................................................................................................................................................................................4
1.3. Rear Panels ..................................................................................................................................................................................................................................................... 5
1.4. Removable Power Distribution Box .......................................................................................................................................................................8
1.5. Internal Battery Packs ........................................................................................................................................................................................................11
1.6. Major Internal Components and Operating Principle ..........................................................................................................................11
1.7. UPS States and Operating Modes ..........................................................................................................................................................................13
1.7.1.Normal Mode ..................................................................................................................................................................................................................13
1.7.2.Bypass Mode ..................................................................................................................................................................................................................13
1.7.3.Battery Mode .................................................................................................................................................................................................................13
1.7.4.Frequency Converter Mode .......................................................................................................................................................................... 14
1.7.5.ECO Mode ....................................................................................................................................................................................................................... 14
Chapter 2: Installation ......................................................................................................................................................................15
2.1. Unpacking and Inspection .............................................................................................................................................................................................15
2.2. Pre-installation Preparation ......................................................................................................................................................................................... 15
2.2.1.Installation Clearances .........................................................................................................................................................................................15
2.3. Installing the UPS ................................................................................................................................................................................................................................................ 16
2.3.1.Tower Installation ..................................................................................................................................................................................................... 16
2.3.2.Rack Installation .......................................................................................................................................................................................................17
2.4. Installing the Internal Battery Kit(s) ...................................................................................................................................................................17
2.5. Installing External Battery Cabinets .....................................................................................................................................................................18
Vertiv | Liebert® GXT5™ | Installer/User Guide i
2.6. Installing a Power-output Distribution Box .................................................................................................................................................21
2.6.1.Installing the Power Distribution Box on GXT5-5000MVRT4UXLN and GXT5-
6000MVRT4UXLN Models ........................................................................................................................................................................................21
2.6.2.Installing the Power Distribution Box on GXT5-8000MVRT6UXLN and GXT5-
10KMVRT6UXLN Models .............................................................................................................................................................................................21
2.7. Removing the Power Distribution Box from GXT5-5000MVRT4UXLN and GXT5-
6000MVRT4UXLN Models .................................................................................................................................................................................................22
2.8. Removing the Power Distribution Box from GXT5-8000MVRT6UXLN and GXT5-10KMVRT6UXLN
Models ......................................................................................................................................................................................................................................................23
2.9. Hardwired Input/Output Connections ............................................................................................................................................................24
2.9.1.Branch Circuit Breaker ........................................................................................................................................................................................25
2.9.2.Terminal-block Connections ........................................................................................................................................................................26
2.10. Communication Connections .....................................................................................................................................................................................................28
2.10.1.Connecting IntelliSlot Communication ............................................................................................................................................28
2.10.2.Connecting to the Dry-contact Port ..................................................................................................................................................................28
2.10.3.Connecting a Remote Emergency Power-o (REPO) Switch ................................................................................. 30
2.10.4.Connecting a USB Cable ............................................................................................................................................................................... 31
2.10.5.Connecting CLI Communication Cables ........................................................................................................................................31
Chapter 3: Operating the UPS .................................................................................................................................................33
3.1. Silencing the Audible Alarm.........................................................................................................................................................................................33
3.2. Starting-up the UPS ......................................................................................................................................................................................................................................33
3.3. Transferring to Battery Mode ................................................................................................................................................................................. 34
3.4. Transferring from Normal to Bypass Mode .............................................................................................................................................. 34
3.5. Transferring from Bypass to Normal Mode .............................................................................................................................................. 34
3.6. Shutting-down the UPS Completely ...................................................................................................................................................................35
3.7. Remote Emergency Power-o (REPO) .........................................................................................................................................................35
Vertiv | Liebert® GXT5™ | Installer/User Guideii
Chapter 4: Operation and Display Panel .......................................................................................................................37
4.1. LED Indicators .........................................................................................................................................................................................................................39
4.2. LCD Menu and Screens ................................................................................................................................................................................................39
4.2.1.Start-up and Flow Screens .............................................................................................................................................................................39
4.2.2.Main Menu ................................................................................................................................................................................................................... 40
4.2.3.Status Screen ..............................................................................................................................................................................................................41
4.2.4.Settings Submenu ................................................................................................................................................................................................ 44
4.2.5.Control Screen ...........................................................................................................................................................................................................52
4.2.6.Log Screen ....................................................................................................................................................................................................................53
4.2.7.About Screen ..............................................................................................................................................................................................................56
4.3. Editing Display and Operation Settings .......................................................................................................................................................................58
4.3.1.Settings Prompts .....................................................................................................................................................................................................59
4.3.2.Changing the Password .......................................................................................................................................................................................................... 59
4.3.3.Selecting the Display Language .............................................................................................................................................................. 60
4.3.4.Setting the Date and Time ...........................................................................................................................................................................60
Chapter 5: Maintenance ................................................................................................................................................................ 61
5.1. Replacing Batteries ............................................................................................................................................................................................................. 61
5.2. Charging Batteries .............................................................................................................................................................................................................63
5.3. Checking UPS Operation .............................................................................................................................................................................................63
5.4. Cleaning the UPS ............................................................................................................................................................................................................... 64
5.5. Replacing a POD .................................................................................................................................................................................................................64
5.6. Firmware Updates ...............................................................................................................................................................................................................67
5.6.1.Updating Firmware with RDU101 Card Connection................................................................................................................67
5.7. Updating DSP Firmware via RDU101 ................................................................................................................................................................ 69
Vertiv | Liebert® GXT5™ | Installer/User Guide iii
Chapter 6: Troubleshooting ......................................................................................................................................................73
6.1. Symptoms that Require Troubleshooting .................................................................................................................................................................73
6.2. Audible Alarm (Buzzer) ................................................................................................................................................................................................................73
6.2.1.Faults....................................................................................................................................................................................................................................74
6.3. Troubleshooting UPS Issues .................................................................................................................................................................................... 75
Chapter 7: Specifications .............................................................................................................................................................77
7.1. Battery Run Times ................................................................................................................................................................................................................81
Appendix I: Open Source Software Legal Notices ........................................................................................... 85
Appendix II: Technical Support .............................................................................................................................................87
Vertiv | Liebert® GXT5™ | Installer/User Guideiv
Important Safety Information
IMPORTANT! This manual contains important safety instructions that must be followed during the installation and
maintenance of the UPS and batteries. Read this manual thoroughly and the safety and regulatory information,
available at https://www.vertiv.com/ComplianceRegulatoryInfo, before attempting to install, connect to supply, or
operate this UPS.
Vertiv | Liebert® GXT5™ | Installer/User Guide 1
This page is intentionally left blank.
Important Safety Information2
Chapter 1: GXT5 Description
The Liebert® GXT5 is a compact, online uninterruptible power system (UPS) that continuously conditions and
regulates its output voltage. The Liebert® GXT5 supplies microcomputers and other sensitive equipment with
clean sine-wave input power.
Upon generation, AC power is clean and stable. However, during transmission and distribution it is subject to
voltage sags, spikes, and complete failure that may interrupt computer operations, cause data loss, and damage
equipment.
The Liebert® GXT5 protects equipment from these disturbances. The Liebert® GXT5 continuously charges its
batteries from the mains, enabling it to supply power to connected loads, even when the mains fail.
1.1. UPS Features and Available Models
The GXT5 includes the following features. Table 1-1 below, lists the available models and power ratings.
• Enhanced load capacity with an output power factor of 1.
• Input power factor greater than 0.99.
• Optional tower or rack installation to meet varying installation requirements.
• Adapts to areas with unstable power-mains supply via high-frequency double-conversion topology
structure, with high input-power factor, wide input-voltage range, and output immune to grid interference.
• Operation and display panel with model-specic color LCD oers simple conguration and control of the
UPS.
• ECO power-supply mode and smart-sleep mode help you save the maximum amount of energy.
Table 1-1 UPS Models and Power Ratings
MODEL NUMBER NOMINAL POWER RATING @ 120/208 V
GXT5-5000MVRT4UXLN 5000 VA/5000 W, 120/208 Vac
GXT5-6000MVRT4UXLN 6000 VA/6000 W, 120/208 Vac
GXT5-8000MVRT6UXLN 8000 VA/8000 W, 120/208 Vac
GXT5-10KMVRT6UXLN 10000 VA/10000 W, 120/208 Vac
GXT5-15KMVRT11UXLN 15000 VA/15000 W, 120/208 Vac
GXT5-20KMVRT11UXLN 20000 VA/20000 W, 120/208 Vac
Vertiv | Liebert® GXT5™ | Installer/User Guide 3
1.2. Front Panels
The various GXT5 models have the same general appearance, with the main dierence being the receptacle
types on the rear panel.
Figure 1-1 Front View
ITEM DESCRIPTION
1 Operation/Display panel
2 Upper bezel
3 Lower bezel/battery-access door
GXT5 Description4
1.3. Rear Panels
The following gures detail the rear-panel features for each GXT5 model.
Figure 1-2 GXT5-5000/6000MVRT4UXLN Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 RS-232 port, RJ-45/RJ-11 connection -- Used for CLI
3 USB port
4 RS-485 port, RJ-45 connection -- Used for external temperature sensors
5 External-battery-cabinet connector
6 Maintenance-bypass breaker
7 Input breaker
8 Knockouts for hard-wired input and output
9 Terminal-block communication connectors
10 Output breaker
Vertiv | Liebert® GXT5™ | Installer/User Guide 5
Figure 1-3 GXT5-8000/10KMVRT6UXLN Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 RS-232 port, RJ-45/RJ-11 connection -- Used for CLI
3 USB port
4 RS-485 port, RJ-45 connection -- Used for external temperature sensors
5 Terminal-block communication connectors
6 External-battery-cabinet connector
7 Output breaker
8 Maintenance-bypass breaker
9 Input breaker
10 Knockouts for hard-wired input and output
11 Cover for power-distribution box connector
GXT5 Description6
Figure 1-4 GXT5 UPS GXT5 15/20KMVRT11UXLN Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 USB port
3 RS-485 port -- Used for external temperature sensors
4 RS-232 port -- Used for CLI
5 Dry-contacts, Battery Detection (3), REPO input (REPO)
6 External-battery-cabinet connector
7 POD breaker
8 Output breaker
9 Input breaker
10 Cover for power-distribution box connector
11 Knockouts for hard-wired input and output
Vertiv | Liebert® GXT5™ | Installer/User Guide 7
1.4. Removable Power Distribution Box
The 5-kVA and 6-kVA models ship with the PD5-UL6HDWR-MBS installed. This POD includes the input circuit
breaker for the UPS, and the POD options are shown in Figure 1-5 below.
The 8-kVA and 10-kVA models ship with the standard POD installed. The POD options are shown in Figure 1-6
on page 9, and Figure 1-7 on page 10.
NOTE: In Figure 1-5 below, the components on PD5-001 are labeled. The features may be arranged
dierently on other PODs.
Figure 1-5 Power-output Distribution Options for GXT5 5000/6000MVRT4UXLN
ITEM PART NUMBER INPUT CONNECTIONS OUTPUT CONNECTIONS
1 PD5-UL6HDWR-MBS Hardwire Hardwire
2 PD5-001 L14-30P 1x L14-30R, 1x L6-30R, 4x 5-15/20 T slot
3 PD5-002 L14-30P 2x L6-20R, 2x 5-15/20R T slot
4 PD5-003 L14-30P 2x L6-30R, 4x 5-15/20R T slot
5 PD5-004 L14-30P 4x L5-20R, 2x L5-30R
6 PD5-005 L14-30P 4x L5-20R, 2x L6-30R
7 PD5-006 L14-30P 4x L6-20R
GXT5 Description8
NOTE: In Figure 1-6 below, the components on PD2-101 are labeled. The features are arranged dierently on
other PODs.
Figure 1-6 Several Power-output Distribution Options for GXT5-8000/10KMVRT6UXLN
ITEM PART NUMBER OUTPUT CONNECTIONS
1 PD2-101 2x L6-30R, 8x 5-15/20R T slot
2 PD2-102 4x L6-20R, 4x 5-15/20R T slot
3 PD2-103 4x L6-30R, 4x 5-15/20R T slot
4 PD2-104 4x 5-15/20R T slot, 2x L6-30R, 2x L6-20R
5 PD2-105 4x 5-15/20R T slot, 2x L5-30R, 2x L5-20R
6 PD2-106 4x L6-20R, 4x L5-20R
Vertiv | Liebert® GXT5™ | Installer/User Guide 9
Figure 1-7 Additional Power-output Distribution Options for GXT5-8000/10KMVRT6UXLN and GXT5-15K/20KMVRT11UXLN
ITEM PART NUMBER OUTPUT CONNECTIONS
1 PD2-107 4x L5-20R, 4x 5-15/20R T slot
2 PD2-108 2x L6-30R, 2x L6-20R
3 PD2-109 2x L14-30R
4 PD2-200 4x IEC320-C19, 4x IEC320-C13
5 PD2-201 2x IEC320-C19, 8x IEC320-C13
6 PD2-202 12x IEC320-C13
7 PD2-204 2x IEC309-32A, 4x IEC320-C13
GXT5 Description10
1.5. Internal Battery Packs
The internal battery packs for all GXT5 MV models, shown in Figure 1-8 below, are located behind the access
door on the front of the UPS. 5-kVA and 6-kVA units have 1 battery pack, and 8-kVA and 10-kVA units have 2
battery packs and 15-kVA and 20-kVA units have 4 battery packs.
Figure 1-8 Internal Battery Pack
ITEM. DESCRIPTION
1 Handle
2 Connector
1.6. Major Internal Components and Operating Principle
Figure 1-9 on the next page, shows the UPS operating principle. Table 1-2 on the next page, describes the
function of the major components in the UPS.
NOTE: Figure 1-9 on the next page, is one example of basic operation.
Vertiv | Liebert® GXT5™ | Installer/User Guide 11
Figure 1-9 Basic Operating Principle Diagram
Table 1-2 Major Components
ITEM COMPONENT OPERATION/FUNCTION
1
2
3 Battery Charger
4 Batteries
5 Inverter
6
7 EMI/RFI Filters
8
Transient Voltage Surge
Suppression (TVSS)
and EMI/RFI Filters
Rectier/Power Factor
Correction (PFC) Circuit
Dynamic Internal
Bypass
Maintenance
Bypass
Provide surge protection. Filter electromagnetic interference (EMI) and radio frequency interference (RFI). Minimize
surges or interference present in the utility power and protect devices connected on the same branch as the UPS.
In normal operation, converts utility AC power to regulated DC power for use by the inverter while ensuring that
the wave shape of the input current used by the UPS is near ideal. Extracting this sine-wave input current ensures
eicient use of utility power and reduces reected harmonic distortion making cleaner power available to devices
that are not protected by the UPS.
The DC-to-DC converter raises the DC voltage from the battery to the optimum operating voltage for the inverter.
This allows the inverter to operate continuously at its optimum eiciency and voltage, thus increasing reliability.
Regulates input AC power to continuously float-charge the batteries. Batteries are charged when the UPS is
plugged in, even when not powered-on.
Valve-regulated, non-spillable, lead-acid batteries.
NOTE: To maintain battery design life, operate the UPS in an ambient temperature of 59 °F to 77 °F (15 °C to 25
°C).
In normal operation, inverts the DC output of the PFC circuit into precise, regulated sine-wave AC power. When utility
power fails, the inverter receives DC power from the DC-to-DC converter. In either operating mode, the UPS inverter
remains on-line, generating clean, precise, regulated AC-output power.
In the unlikely event of UPS failure such as overload or over-temperature, automatically transfers the connected
load to bypass.
To manually transfer the connected load from inverter to bypass, see "Transferring from Normal to Bypass Mode"
on page 34.
Filter electromagnetic interference (EMI) and radio frequency interference (RFI). Minimize interference present in
the utility power and protect devices connected on the same branch as the UPS.
In the unlikely event of UPS failure, allows replacing the UPS while keeping the connected equipment powered
with utility power.
NOTE: The bypass power path does not protect connected equipment from disturbances in the utility supply.
15-kVA and 20-kVA units do not have internal maintenance bypass.
9 Outlet group General output receptacles.
GXT5 Description12
1.7. UPS States and Operating Modes
NOTE: See LED Indicators on page 39, for description of the run-indicator and alarm-indicator LEDs
mentioned in this section.
1.7.1. Normal Mode
When utility power is normal, Normal mode employs the rectier and inverter to provide voltage and frequency-
stabilized power to the load. The charger charges the battery in normal mode. On the front panel display, the
run-indicator (green) is ON, the alarm indicator is OFF, and the buzzer is silent.
1.7.2. Bypass Mode
Bypass mode supplies power to the load from the bypass source (utility power) if an overload or fault occurs
during normal operation. On the front-panel display, the run indicator (green) is ON, the alarm indicator (yellow)
is ON, and the buzzer beeps once each seconds. The LCD “Current” screen displays “On Bypass.”
NOTE: If utility power fails or if the utility voltage goes outside of the permissible range during bypassmode operation, the UPS shuts down and no output is supplied to the load.
1.7.3. Battery Mode
Battery mode supplies battery power to the load if utility power fails or if the utility voltage goes outside of the
permissible range. On the front-panel display, the run indicator (green) is ON, the alarm indicator (yellow) is ON,
and the buzzer beeps once each second. The LCD “Flow” screen displays “On Battery.”
NOTE: The batteries are fully-charged before shipment. However, transportation and storage inevitably
cause some loss of capacity. To ensure adequate back-up time, it is recommended to charge the batteries
for atleast 8 hours before first start-up.
NOTE: If utility power fails and the batteries are charged, you may cold-start the UPS in battery mode and
use battery power to extend system availability for a time.
NOTE: Powering-o the UPS when it is in battery mode results in loss of output power to the connected
load.
Vertiv | Liebert® GXT5™ | Installer/User Guide 13
1.7.4. Frequency Converter Mode
All models of the GXT5 are capable of frequency conversion. Frequency Conversion Mode can be selected
using the conguration program. Allowable frequency operating modes include:
• Auto Sensing - 50 Hz or 60 Hz – Bypass Enabled
• Auto Sensing - 50 Hz or 60 Hz – Bypass Disabled
• Frequency Converter - 50 Hz – Bypass Disabled
• Frequency Converter - 60Hz – Bypass Disabled
NOTE: The default for all models of the Liebert® GXT5 is “Auto Sensing - 50 Hz or 60 Hz – Bypass Enabled.”
1.7.5. ECO Mode
The energy-saving ECO mode reduces power consumption by powering the load via bypass if the bypass
voltage is normal or by powering the load via the inverter when the bypass voltage is abnormal. You can use
ECO mode to power equipment that is not sensitive to power-grid quality to via bypass and reduce power
consumption.
NOTE: During ECO mode, if a bypass-failure or abnormal-bypass-voltage notification appears when the output
is not overloaded, the UPS will transfer to Normal Mode. However, if a notification showing bypass failure
or abnormal bypass voltage appears when the output is overloaded, the UPS will shut down the bypass and
therefore the load will shut down.
GXT5 Description14
Chapter 2: Installation
Do not start the UPS until after the installation is nished.
WARNIN G! Ris k of electric shock
Can cause equipment damage, injury and death. Before beginning installation, verify that all external overcurrent
protection devices are open (O), and that they are locked-out and tagged appropriately to prevent activation
during the installation, verify with a voltmeter that power is O and wear appropriate, OSHA-approved
personal protective equipment (PPE) per NFPA 70E. Failure to comply can cause serious injury or death. Before
proceeding with installation, read all instructions. Follow all local codes
2.1. Unpacking and Inspection
Unpack the UPS and conduct the following checks:
• Inspect the UPS for shipping damage. If any shipping damage is found, report it to the carrier and your local
Vertiv representative immediately.
• Check the accessories included against the packing list. If there is any discrepancy, contact your local Vertiv
representative immediately.
.
CAUTION
The UPS is heavy (see “Specifications” on page 82, for the weight). Take proper precautions when lifting or
moving the unit.
2.2. Pre-installation Preparation
• Install the UPS indoors in a controlled environment, where it cannot be accidentally turned O. The
installation environment should meet the specications listed in “Specications” on page 82.
• Place the UPS in an area of unrestricted air-ow around the unit, away from water, ammable liquids, gases,
corrosives, and conductive contaminants. Avoid direct sunlight.
NOTE: Operating the UPS in temperatures above 77°F (25°C) reduces battery life.
2.2.1. Installation Clearances
Maintain at least 4 in. (100 mm) clearance in the front and rear of the UPS. Do not obstruct the air inlets on
the front panel and rear panel of the UPS. Blocking the air inlets reduces ventilation and heat dissipation,
shortening the service life of the unit.
Vertiv | Liebert® GXT5™ | Installer/User Guide 15
2.3. Installing the UPS
The UPS may be installed as a tower or in a rack, depending on available space and use considerations.
Determine the type of installation and follow the appropriate instructions. See Tower Installation or Rack
Installation on next page.
After installing the UPS as a tower or in a rack, and before attempting to start-up, you must install the internal
batteries. See Installing the Internal Battery Kit(s) on the next page.
NOTE: When installing the UPS or making input and output connections, comply with all relevant safety
codes and standards.
2.3.1. Tower Installation
To install the UPS as a tower:
1. Take the support bases out of the accessories box.
Figure 2-1 Support bases
NO. DESCRIPTION
1 Support bases
2 Spacers with connectors
2. If optional, Liebert® external battery cabinets will be connected, take out the spacers shipped with the
battery cabinet.
3. Connect the spacers and the support bases as shown in Figure 2-1 above. Each GXT5 requires 2 support
bases, one in the front and one in the rear.
4. Place the GXT5 and any battery cabinets on the 2 support bases.
5. See Installing the Internal Battery Kit(s) on the next page, to install the battery pack(s).
Installation16
2.3.2. Rack Installation
When installed in a rack enclosure, the GXT5 UPS and external battery cabinets (EBC) must be supported
by a shelf or rack-mount rails. Because dierent rack-mount options install dierently, refer to the installation
instructions provided with the rack-mount kit.
CAUTION
The GXT5 is heavy. The UPS must be installed as near the bottom of a rack as possible. If placed too high, it can
make the rack top-heavy and prone to tipping over. For unit weights, see Specifications on page 82.
2.4. Installing the Internal Battery Kit(s)
The internal-battery kits are packed separately in boxes and are shipped in main box with the GXT5, which is
also in its own box.
1. Loosen and remove the screws on the battery door, see Figure 2.2 below.
2. Lay the battery door and screws aside for reassembly.
3. Unpack the battery pack.
4. Line up and slowly slide the battery pack in until two-thirds of the length is inserted, then pull up slightly and
continue pushing in rmly until the battery pack is fully inserted.
5. Attach the battery door with the screws. The battery door will cover the batteries if the packs are properly
installed.
6. Attach the front cover to the UPS.
Figure 2-2 Support bases
NO. DESCRIPTION
1 Front Panel
2 Battery Door
Vertiv | Liebert® GXT5™ | Installer/User Guide 17
2.5. Installing External Battery Cabinets
Optional, external battery cabinets (EBC) may be connected in parallel to the UPS to provide additional battery
run time. For approximate battery run times with additional EBCs, see “Battery Run Times” on page 86.
External battery cabinets are placed on one side of the UPS in a tower conguration or stacked beneath the
UPS in a rack conguration. Up to 10 EBCs may be connected to the UPS, and up to 6 may be detected using
EBC-detection.
WARNING! Risk of electric shock
Can cause injury or death. Disconnect all local and remote electric power supplies before working with the UPS.
Ensure that the unit is shut down and power has been disconnected before beginning any maintenance.
CAUTION
The external battery cabinet(s) are heavy, see Table 7-5 on page 85. Take proper precautions when lifting
them.
To install the EBC(s):
1. Inspect the EBC for freight damage. Report damage to the carrier and your local dealer or Vertiv
representative.
2. For tower installation:
• An additional set of support-base extensions ships with each EBC.
• See the steps in Tower Installation, to connect the support extenders and install the bases.
- or –
3. For rack installation:
• Rack-mount hardware ships with the EBC.
• Refer to the instructions included with the rack-mount kit to install.
NOTE: Optional slide rails and securing hardware are sold separately. Please contact your Vertiv
representative for options and Vertiv Technical Support for assistance.
4. Verify that the EBC breaker is in the “O” position.
5. Connect the supplied EBC cable(s) to the rear of the cabinet, then to the rear of the UPS, see Figure 2-3.
6. Turn the EBC breaker to the “On” position.
7. Verify the circuit breaker on the EBC is in the “On” position.
The additional back-up run time is enabled.
NOTE: If installing more than 6 EBCs, the user must adjust the number of EBCs manually in Settings >
Battery > External battery cabinet group No.
Installation18
NOTE: When removing an EBC, turn o the circuit breaker on the rear of the cabinet before disconnecting the
cable.
NOTE: If shipping or storing the UPS for an extended time, disconnect the EBC(s) minimize stand-by current
drain on the batteries and help maintain design life.
Figure 2-3 EBC connection for 5-10K models
ITEM DESCRIPTION
1 EBC-detection port (See Table 2-2 on page 27, for details.)
2 EBC connector
3 UPS
4 External battery cabinet
5 External battery cabinet
6 EBC-detection port
Vertiv | Liebert® GXT5™ | Installer/User Guide 19
Figure 2-4 EBC connection for 15-20K models
Installation20
2.6. Installing a Power-output Distribution Box
• PD5-UL6HDWR-MBS, PD5-001, PD5-002, PD5-003, PD5-004, PD5-005 and PD5-006 models t the GXT55000MVRT4UXLN and GXT5-6000MVRT4UXLN models of the Liebert GXT5
• PD5-UL10HDWR-MBS, PD2-101, PD2-102, PD2-103, PD2-104, PD2-105, PD2-106, PD2-107, PD2-108, PD2-109,
PD2-200, PD2-201, PD2-202, PD2-204models t the GXT5-8000MVRT6UXLN and GXT5-10KMVRT6UXLN
models of the Liebert GXT5
2.6.1. Installing the Power Distribution Box on GXT5-5000MVRT4UXLN and GXT5-
6000MVRT4UXLN Models
PD5-UL6HDWR-MBS, PD5-001, PD5-002, PD5-003, PD5-004, PD5-005 and PD5-006 models assemble steps
as follows:
1. Align the connectors and press the power-distribution box onto the UPS.
2. Hold the box rmly against the UPS and tighten the captive screws except the one over the maintenance
bypass breaker cover.
3. Conrm the maintenance bypass breaker “O.”
4. Loosen the maintenance captive screw over the maintenance bypass breaker cover, pull down the cover and
tight another screw that on the UPS side.
5. Turn the output and input breakers “On.”
6. Start the UPS according to start-up instructions.
2.6.2. Installing the Power Distribution Box on GXT5-8000MVRT6UXLN and GXT5-
10KMVRT6UXLN Models
PD2-101, PD2-102, PD2-103, PD2-104, PD2-105, PD2-106, PD2-107, PD2-108, PD2-109, PD2-200, PD2-201, PD2202, PD2-204 models assemble steps as follows:
WARNING! Risk of electric shock
Can cause injury or death. The UPS must be shut down or the load must be transferred to an external
maintenance bypass before a power distribution box may be added, changed or removed. If the UPS
will be shut down, the connected load must be shut down. If the UPS will be transferred to maintenance
bypass, it must be transferred to an external maintenance bypass. Verify that the GXT5 is shut down
and that all local and remote electric input power has been disconnected before beginning any work
on or in the UPS.
Vertiv | Liebert® GXT5™ | Installer/User Guide 21
1. With the cover of distribution box removed, Connect the UPS and distribution box connectors together.
Ensure that the connectors are fully connected.
2. Align the screw holes and press the power distribution box onto the UPS, making sure that the tabs at the
bottom of the box t into the slots on the UPS.
3. Attach the box to the UPS by installing screws into the two holes at the top of the box.
4. Tighten the screws.
5. Turn the output and input breakers On.
6. Start the UPS according to start-up instructions.
2.7. Removing the Power Distribution Box from GXT5-
5000MVRT4UXLN and GXT5-6000MVRT4UXLN Models
PD5-UL6HDWR-MBS, PD5-001, PD5-002, PD5-003, PD5-004, PD5-005 and PD5-006 models remove steps as
follows:
1. Manually transfer the connected equipment to the internal bypass.
a. From the main menu select CONTROL, then press Enter.
b. Select Turn on / o/ to bypass and press Enter.
c. Select Turn to bypass and press Enter.
The UPS transfers the connected loads to the internal bypass.
d. Loosen the maintenance captive screw over the maintenance bypass breaker cover, pull up the cover and
tight another screw, ensure the screw is on the “ON” location. (see the following gure for the breaker’s
location).
e. Turn the maintenance bypass breaker On.
NOTE: The load is unprotected from disturbances in the power supply while the UPS is on bypass.
2. Please wait 1 minute If the UPS work on battery mode, then conrm the UPS is turn o.
3. Turn the output and input breakers O.
4. Loosen other captive screws until the power distribution box releases.
5. Remove the power distribution box from the UPS and set it aside.
6. On the rear of the panel, loosen the screws of the protective cover for the connectors, slide it over the
connectors, and tighten the screws.
Installation22
Figure 2-5 Power distribution box removal from GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN
ITEM DESCRIPTION
1 Output breaker
2 Maintenance bypass breaker screw
3 Input breaker
4 Knockouts for hard-wired power input and output
5 Screws
2.8. Removing the Power Distribution Box from GXT5-
8000MVRT6UXLN and GXT5-10KMVRT6UXLN Models
PD2-101, PD2-102, PD2-103, PD2-104, PD2-105, PD2-106, PD2-107, PD2-108, PD2-109, PD2-200, PD2-201, PD2202, PD2-204 models remove steps as follows:
1. Shut down the GXT5.
a. From the Main Menu select CONTROL, press Enter, then select Turn on / o/to bypass.
b. Press the enter key.
c. Select Turn o UPS, then press Enter. Power to the connected loads is now O.
2. Turn the output and input breakers O.
3. Support the power distribution box and remove the two screws at the top of the box.
4. Remove the cover for power-distribution box from the UPS and set it aside.
5. If removing a power-distribution box, carefully pull apart the power-distribution-box connector and the UPS
connector.
Vertiv | Liebert® GXT5™ | Installer/User Guide 23
Figure 2-6 Power distribution box removal from GXT5-8000MVRT6UXLN and GXT5-10KMVRT6UXLN models
ITEM DESCRIPTION
1 Remove screws
2 Pigtails removed for clarity
3 Tabs slip into slots on the UPS
2.9. Hardwired Input/Output Connections
WARNING! Risk of electric shock
Can cause equipment damage, injury and death. Before beginning installation, verify that all external overcurrent protection devices are open (O), and that they are locked-out and tagged appropriately to prevent
activation during the installation, verify with a voltmeter that power is O and wear appropriate, OSHAapproved personal protective equipment (PPE) per NFPA 70E. Failure to comply can cause serious injury or
death. Before proceeding with installation, read all instructions. Follow all local codes.
Observe the following guidelines and specications when making the hard-wire input and output connections:
• We recommend installing a UL489-approved breaker upstream of unit.
• Provide circuit-breaker protection according to local codes. The mains disconnect should be within sight of
the UPS or have an appropriate lock-out.
• Maintain service space around the UPS or use exible conduit.
• Provide output-distributions panels, circuit-breaker protection, or emergency disconnects according to local
codes.
Installation24
Loading...
