UNKNOWN
BOOT
ROM
IRQ
JC/JE
MEM
I/O
J1
ROM
E2000A-1
NIC Type
Transfer Rate
Data Bus
Topology
Wiring Type
Boot ROM
Ethernet
10Mbps
16-bit ISA
Linear Bus, Star
DIX transceiver via DB-15 port
RG58A/U 50ohm coaxial
Available
Address
Setting
BASE MEMORY ADDRESS SELECT
MEM
BOOT ROM
ClosedOpenClosedí C800h - CBFFh
ClosedClosedClosedC000h - C3FFh
ClosedClosedOpenC400h - C7FFh
ClosedOpenOpenCC00h - CFFFh
OpenClosedClosedD000h - D3FFh
OpenClosedOpenD400h - D7FFh
OpenOpenClosedD800h - DBFFh
OpenOpenOpenDC00h - DFFFh
ROM
Opení Disabled
ClosedEnabled
Continued from previous page. . .
UNKNOWN
E2000A-1
Type
All Pins designated should be in the closed position.Note:
IRQ
CABLE TYPE
JC/JE
INTERRUPT SELECT
I/O ADDRESS SELECT
ssAddre
SYSTEM TYPE
Type
IRQ
I/O
. . . continued from previous page
Pins 1 & 2Pins 1 & 2Pins 1 & 2Pins 1 & 2Pins 1 & 2Pins 1 & 2Pins 1 & 2í Thin
Pins 2 & 3Pins 2 & 3Pins 2 & 3Pins 2 & 3Pins 2 & 3Pins 2 & 3Pins 2 & 3Thick
OpenOpenClosedOpení IRQ3
OpenOpenOpenClosedIRQ2
OpenClosedOpenOpenIRQ4
ClosedOpenOpenOpenIRQ5
ClosedClosedí 300h - 31Fh
ClosedOpen320h - 33Fh
OpenClosed340h - 35Fh
OpenOpen360h - 37Fh
J1
Pins 1 & 2 closedí All Other
Pins 2 & 3 closedCOMPAQ 286 portables, IBM PS/2 Model 30-286, C & T shipset systems
