Page 1
Burlington
High Performance Direct Vent
Gas Fireplace
Come home
to a gorgeous glow.
Page 2
VERMONT CASTINGS®ELECTRONIC COMFORT
CONTROL SYSTEM (only on DVA4136IFN)
• Fan function 6 plus off from a hand held remote
• Flame modulation: 6 plus off for main burner and 3 plus
off for rear burner
• Thermostat governs flame and fan together for maximum
comfort
• Timer Control will shut off fire at a later time
• Electronic Intermittent pilot eliminates gas usage when
fireplace is off. Manual pilot override on remote.
• Battery Back-up for power failures
• Fan Kit
DVA4136 Burlington shown with Black filigree Louvers
with Arcadia Mantel finished in Sienna Brown
Burlington
Outstanding features and great style come together in this direct vent gas fireplace from
Vermont Castings®. This high performance fireplace offers our Ambiance Lighting feature that
can create a true fireplace glow even without the burner lit, making the Burlington especially
energy efficient! Plus, our authentic-looking logs create an especially robust flame.
Available in several trim and cabinet options.
Standard Features
• Direct Vent Circulating Gas Fireplace
• Heat Output: 38,000 BTUs
• Insta-Flame Ceramic Radiant Burner
System with limited lifetime warranty
• Bar Iron Grate
• Full Features Electronic (IPI) Comfort
Control System for the ultimate in
carefree, comfortable, space heating,
plus the security of automatic
battery back-up
• Features 5-piece Enhanced Ceramic
Fiber Split Round Oak Log Set with
curved Steel Grate
• Ambiance lighting is easily controlled
with comfort control remote
• Ember Wool enhances glow of
Ember Bed
• Ceramic Glass Panel
• Electrical Junction Box
• Flex Connector with Shut-off
• Shipped as Natural Gas can be
field converted to LP
• Uses Majestic 4”/ 7” Direct Vent
components
• Large flame viewing area
• Six-speed circulation Blower
• LP conversion kit
• Battery Back Up Kit (DVTBBK)
DVA4136 shown with Black Louvers
Options
• Black Louvers
• Variety of trims available to customize
your fireplace
Page 3
Fea tur ing
C O L L E C T I O N
andstone
S
ountry Gray
C
Silver-Gray
Optional Trims for DVA4136
• Baron Mission Style Square Face Kit
with clean straight lines and well
balanced design available in
3 finishes: Modern Pewter,
Rustic Bronze and Ebony Black
• Belmont Rustic Style Arched
Face Kit with twisted iron bar detail
available in 3 finishes: Modern Pewter,
Rustic Bronze and Ebony Black
• Baron and Belmont Face Kits:
- Allow consumers to face to edge
of Face Kit
C
Colonial Red
Styled to look authen tic, with a patina that gives every fireplace
just the right flair and look. Optional on Burlington firepla ces.
eatures & Benefits
lassic Black
- Adjustable depth to overlap 4” tile
and w” marble
- Hinged access panel to prevent
damage to hearth or Face Kit itself
• Marquette Face Kit available in square
and arched profiles in 3 finishes:
Modern Pewter, Rustic Bronze and
Ebony Black
• Romanesque Face Kit available
in square and arched profiles in
3 finishes: Modern Pewter, Rustic
Bronze and Ebony Black
F
Authentic looking brick & mortar
design in 5 choice colors:
• Country Gray with distinctive
soft gray tones and dark gray
mortar for a natural and nicely
aged look
• Colonial Red Brick with light
gray tone mortar – A traditional
look and texture of reclaimed
& weathered brick
• Sandstone Brick with light
ray tone mortar – A traditional
g
color and texture for fireplace
brick
• Classic Black with black mortar
– A monotone brick that is subtle,
but stylishly enhancing a gas
fireplace interior
• Silver-Gray with dark gray tone
mortar – A contemporary color
for fireplace brick
• Enhances the look of your
fireplace
• Allows you to customize your
Majestic Burlington direct
ent gas fireplace
v
• Dramatic backdrop to our glowing
logs & dramatic, golden flames
• Easy to install
• Georgian Cast Surround and Bay
Front available in Classic Black and
Ebony Black Enamel
• Medium Perimeter Trim Kits in Black,
Pewter and Polished Brass
• Arched Screen Door Kits in Black
and Pewter
• Black Arched Surround and Door Kits
in Black and Rustic Bronze
• Screen Kit (used in commercial
applications)
DVA4136 shown with Belmont Arch
Face Kit in Modern Pewter finish
DVA4136 shown with Romanesque Face Kit
in arched profile with Modern Pewter finish
DVA4136 shown with Baron Square
Face Kit in Ebony Black finish
DVA4136 shown with Marquette Face Kit in
arched profile with Rustic Bronze finish
• All DVA4136 images above are shown with BrickWorks Sandstone Refractory
DVA4136 shown with Black medium perimeter
trim, Black filigree louvers and
Pewter arched screen doors
DVA4136 shown with Georgian Cast
Surround and Bay Front in Ebony Black
Page 4
urlington High Performance
B
irect Vent Gas Fireplace
D
Model • DVA4136
Romanesque Face Kit in
Arch Profile
DVA4136 Top Vent
Romanesque Face Kit in
Square Profile
EFFICIENCY RATINGS
odel EnerGuide Ratings Steady State (%) D.O.E.
M
DVA4136IFN 70 81 68
MODEL SPECS
iewing Height 212”
V
Viewing Width 328”
Rough Framing Depth 41”
ough Framing Height 42
R
Rough Framing Width 202”
BTUs Max. input 38,000 NG/LP
TUs Min. input 7,100 NG/LP
B
Marquette Face Kit in
ireplace Efficiency (%) Fan-On (AFUE%)
F
DVA4136
7
/16”
Marquette Face Kit in
Arch Profile
Square Profile
Baron Face Kit
Belmont Face Kit
Georgian Cast Surround
and Bay Front
NOTE: Please refer to the Vermont Castings TrimWorks Premium Face Kits Brochure for more details and specifications.
YOU R DEA LE R
© 2008 CFM Corporation - All rights reserved. Vermont Castings®is a registered trademark of CFM Corporation.
In the interest of constant product improvements, we reserve the right to change sp ecifications without notice.
Before installations, please read Installation Instructions and check all local Building Codes and Gas Regulations.
Please see your Dealer or visit www.vermontcastings.com for complete warranty information.
Printed in Canada
HC017-2001-4035
