Verizon Connect AT-250 User Manual
AT-250 User’s Manual
Plug In
Your Device
Conrm Installation
888.665.9901
Drive Safely
Watch your
Discount Grow!
Getting Started
Box Contents
Quick Start Guide
Plug In
Conrm Installation
Drive Safely
888.665.9901
Your Device
In-Drive
Communicator
In-Drive
Visor Clip
In-Drive
Visor Clip
Car Charger
Quick Start
Watch your
Discount Grow!
Guide
Return Label
Before you begin, make sure you:
Verify all contents are in the box (as shown to the left).
›
In-Drive Communicator
›
In-Drive Visor Clip
›
In-Drive Visor Clip Car Charger
›
Quick Start Guide
›
Return Label
Review the In-Drive Customer Agreement & Privacy Policy located
at www.in-drive.com/sf.
Installation and ongoing use of this device indicates your
acknowledgement and acceptance of the In-Drive Customer
Agreement & Privacy Policy found at www.in-drive.com/sf.
Keep the Quick Start Guide in your glove box for future reference.
For more information, visit www.in-drive.com/sf
1
Important Time-Sensitive Steps
Welcome to the In-Drive® system from Verizon Telematics, a suite of
connected services that are part of the State Farm® Drive Safe & Save™
program. Central to the In-Drive solution is a simple device that you plug
in to collect essential vehicle data and helps you earn a discount on your
insurance. Getting started with the In-Drive program is easy.
You’ve already taken the biggest step towards saving on your insurance
premium by enrolling in the program. The In-Drive 12-month, FREE
introductory offer began shortly after shipment of the device, so take full
advantage of your service by completing the remaining three steps listed
below. You have 30 days after the device has shipped to plug it in before
your discount is removed which may result in a balance due.
Plug the device into your vehicle. See page 3 for detailed instructions.
Installation is easy and only takes a few minutes!
1
Locate the Quick Enroll number on the outside of the shipping box.
This number will help to expedite your phone call.
2
Final Step: Call 888.665.9901 to conrm your service choices and that
the device has been successfully plugged in and is working properly.
3
After this call, you’re done!
For more information, visit www.in-drive.com/sf
2
Installing Your Device
Install your In-Drive Communicator (Figure A)
Step
Step
›
1
2
Locate your vehicle’s On-Board Diagnostic (OBD-II) Port.
- This port is usually located under the dashboard, beneath
the steering wheel column. If you can’t locate your OBD-II
Port, refer to your vehicle’s Owner’s Manual.
›
Plug the In-Drive Communicator into the OBD-II Port.
›
Your In-Drive Communicator does NOT need to be charged.
Install your In-Drive Visor Clip
›
Place the In-Drive Visor Clip on the driver’s side visor.
Charging Your In-Drive Visor Clip
›
Charge your In-Drive Visor Clip in your vehicle before you
install; the battery indicator will be solid yellow while charging
and turn solid green when the battery is fully charged.
›
Allow two hours to charge up to 75% battery life and about
six hours to charge 100% when the battery is at zero capacity.
›
A fully charged Visor Clip offers approximately six weeks of
standby time or 16 hours of hands-free talk time.
›
When the battery is low, the indicator will blink red.
Please note: Switching your hands-free on/off button on the right
hand side of the Visor Clip to the off position will extend battery
life considerably while maintaining the availability of emergency
and roadside calling features.
1
(Figure B)
Tip: The Visor Clip can
also be charged on a
universal cell phone wall
charger in your home.
(Any time the visor clip is
removed from the vehicle,
Guardian services will not
be available.)
A
B
3
1 The In-Drive Visor Clip is optional for In-Drive Connect customers and can be paired with your Bluetooth® capable mobile phone.
Conrm Installation
Step
Final Step: Call 888.665.9901
3
to conrm your service choices and that the device has been successfully plugged
in and is working properly.
For installation help, general service, and support, call the In-Drive Support Center at 888.270.0267.
What To Expect Next: Take a Drive and Start Collecting Driving Statistics
›
During your rst trip, the In-Drive Communicator will begin collecting your driving statistics, which will
be shared with State Farm.
›
Most diagnostic information will be available immediately online.
›
Your MPG information will be available after a full calendar month of driving data has been
collected (e.g. June 1st through June 30
View your Personal In-Drive Dashboard
Login at www.statefarm.com, select your enrolled vehicle, then select “Manage Drive Safe & Save.”
On this site you can:
›
learn safe driving tips
›
personalize your account
›
review your driving performance
›
calculate your potential premium discount
›
see your discount grow!
th
equals a full calender month).
For more information, visit www.in-drive.com/sf
