LED
Floor Lamp
by
SmartLight
™
Model: VF09
Dear Customer,
Thank you for purchasing the LED SmartLight Floor
Lamp by Verilux. You now own an innovative product,
manufactured to the highest standards and backed by
a one-year limited warranty.
Many other healthy-lighting products are available
online. Visit us on the web at www.verilux.com to learn
more about all our quality Verilux products, or call us
toll-free at 1-800-786-6850.
As a Verilux customer, your satisfaction means
everything to us. We look forward to serving you now
and in the future.
Have a bright day!
Nicholas Harmon
President, Verilux, Inc.
2
DANGER :
WARNING:
READ ALL INSTRUCTIONS BEFORE USING
CAUTION:
Important Safeguards
• To avoid electrocution, do not operate this lamp near water.
• Do not use with power supply voltage other than 120 VAC.
• To prevent risk of shock or personal injury when cleaning this lamp, make sure
you have turned it off and unplugged it.
• Do not cut or shorten the power cord.
• Never cover the lamp or place anything on top of it when it is in operation.
• Do not operate this lamp in close proximity to flammable or combustible
vapors, such as aerosol spray products, or where oxygen is being
administered.
• For indoor use only.
• Do not use this lamp with light dimmers, timers, motion detectors, voltage
transformers or extension cords.
• This product may cause interference with radios, cordless telephones or
devices that use a wireless remote control, such as televisions. If interference
occurs, move the product away from the device, plug the product or device
into a different outlet or move the lamp out of the line of sight of the remote
control receiver.
• Do not operate this lamp if it has been damaged in any way. For example:
– the power supply cord or plug has been damaged
– liquid has been spilled or objects have fallen onto the lamp
– the lamp has been exposed to rain or other moisture
– the lamp does not operate normally
– the lamp has been dropped
• Do not dismantle. There are no user-serviceable parts in this lamp.
• Unplug lamp during lightning storms or when unused for extended periods of
time.
• Protect the power cord from being walked on or pinched, particularly at the
plug, convenience receptacles and the point where the power cord jack enters
the lamp.
• Do not pull the cable of the AC adapter when unplugging it from the outlet to
avoid failure or electric shock.
†
3
Important Safeguards – continued
CAUTION:
— continued
• Use only the power cord supplied with your lamp. If other power cords are
used, damage to your lamp may occur.
• Avoid placing the lamp in areas that are dusty, humid/moist, lack ventilation, or
are subject to constant vibration.
• Avoid placing this lamp in areas that are exposed to direct sunlight or close to
heat-radiating products such as heaters.
• After cleaning the lamp, properly wipe away and dry all moisture before
restoring power.
SAVE THESE INSTRUCTIONS
†
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.”
This Class B digital apparatus complies with Canadian ICES-005.
Features
• Long-life, energy-efficient LEDs greatly reduce operating costs over the life of
the lamp.
• Simple and easy operation with touch controls. On/Off, five light-intensity levels
and three color temperatures, or modes, can all be adjusted with easy-to-read
touch “buttons” or controls.
• Dimmable light intensity with a range from very dim to very bright in five
different levels with Up/Down touch control buttons. At the very lowest light
level, the LED SmartLight Floor Lamp can be used as a night light.
• Light intensity stays the same when different color temperatures are selected
with the color temperature touch control.
• The color temperature of the light can be changed depending upon the ambient
mode desired. It is recommended that the warmer light at the 3000K* color
temperature be used in the evenings. Studies have shown that the blue in
cooler light sources may impact sleep quality. The color temperature of 5000K
is recommended for reading and tasks that involve a high level of visual acuity.
The light at 5000K improves clarity of reading materials and reduces eyestrain
and fatigue.
* “K” represents degrees in Kelvin. Kelvin is the measurement of correlated
color temperature (CCT). The CCT rating for a lamp is a general “warmth” or
“coolness” measure of the color appearance of the light emitted. However,
opposite to the temperature scale, lamps with a CCT rating below 3200 K are
usually considered “warm” sources, while those with a CCT above 4000 K are
usually considered “cool” in appearance.
4
Components
What’s Included
Remove all packaging material. Please refer to the Assembly Instructions on the
previous page to assemble the lamp. Check the carton for these items:
• LED lamp
• User manual
• Power adapter
• Allen wrench
• Screw (1)
Assembly Instructions
1. Find the wire on
gooseneck (A) and
insert it into the pole
(B), then twist the
pole (B) clockwise to
connect.
A
2. Find the pole (C), and
insert the wire through
it, then connect the
two poles together
twisting (C) clockwise.
B
B
3. Connect the two wires
together and insert
the pole into the base
(D). Tighten the screw
using the supplied allen
wrench underneath the
base (E) after you make
sure the touch panel is
facing the front.
C
C
D
E
allen wrench
5
WARNING:
CAUTION:
CAUTION:
Instructions for Use
Power Supply: Plug in the AC adapter into an electrical outlet. Plug
the connector of the AC adapter into the LED SmartLight Floor Lamp.
(Only use with the supplied AC adapter to avoid damage and fire.)
On/Off: To turn on the light, gently touch the on/off touch sensitive
control button. (When you turn off the light using the on/off button, it
will return to the last setting of brightness and temperature when you
turn it on again.)
Mode: Initial Correlated Color Temperature is 5000K. To change the
temperature simply touch the mode button to change from 5000K
(daylight) to 4000K (natural) and then to 3000K (warm).
Up/Down: There are five illuminance levels of light intensity on the
lamp at each color temperature. Use the Up/Down touch buttons to
adjust the illuminance accordingly.
Unplug the power cord if the lamp will not be used for long periods of
time.
Operation
Care and Cleaning
Your lamp is made from high-quality materials that will last for many years with
minimum care. You may want to periodically clean the lamp using a mild nonabrasive cleaner and soft cloth. When cleaning, make sure you have turned off
and unplugged the unit.
To prevent risk of shock or personal injury when cleaning this
lamp, make sure you have turned it off and unplugged it.
ammonia-based cleaners.
before restoring power.
Do not use solvents or cleaners containing abrasives, or
After cleaning the lamp, properly wipe away and dry all moisture
6
Technical Specifications
CAUTION:
LED SmartLight Floor Lamp
Adapter input voltage: 80-240 VAC, 50/60Hz
Adapter output voltage: DC19.2V, 0.65A
Power consumption: 14 watts
Operating temperature: -20°C to 40°C
Color temperatures: Warm: 2700K – 3000
General Ambient: 3500K – 4500K
Reading/Tasking: 4745K – 5311K
CRI: >80
Illumination intensity: 2000 LUX
Warranty: 1 Year
CETL Listed
RoHS Compliant
Proposition 65 Compliant
Troubleshooting
Before Requesting Service On Your Verilux® Lamp, Please:
• Make sure the power cord is inserted fully and securely.
• Make sure there is power to the wall outlet or try another outlet.
Use only the power cord supplied with your lamp. If other power
cords are used, damage to your lamp may occur.
Problem Check Solution
Outlet end of power
cord
Light won’t come on.
Input jack of the
power plug
Wire in pole and base
during assembly
7
Be sure it is properly plugged
into a working outlet.
Be sure it is properly seated
in the receptacle on the base.
Be sure wires were properly
connected during assembly.
One-Year Limited Warranty
ATTENTION! ONCE OPENED, PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
WHERE IT WAS PURCHASED FOR REPAIR OR REPLACEMENT!
Many questions may be answered by visiting www.verilux.com, or you may call our Customer
Service Department at 800-786-6850 during normal business hours.
This limited warranty is provided by: Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673
Verilux warrants this product to be free from defects in material and workmanship for a period
of 1 year from the date of the original retail purchase from Verilux or an authorized Verilux
distributor. Proof of purchase is required for all warranty claims. During the limited warranty
period, Verilux Inc., will, at its option, repair or replace defective parts of this product, at no
charge to the customer, subject to these limitations: This limited warranty does not include
any postage, freight, handling, insurance or delivery fees. This warranty does not cover
damage, defect or failure caused by or resulting from accident, external destruction, alteration,
modification, abuse, misuse or misapplication of this product.
This warranty does not cover damage to the product resulting from return shipping or handling.
Verilux recommends purchasing shipping insurance to protect your investment.
Return Authorization is required for all returns. To obtain a Return Authorization, please
contact the Verilux Customer Service Department at 800-786-6850.
If, during the first year of ownership, this product fails to operate properly, it should be returned
as specified at www.verilux.com/warrantyreplacement or as instructed by a Verilux customer
service representative at 800-786-6850.
Note: Verilux recommends using a quality surge suppressor on all electronics equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges and may be
purchased at electronics stores.
Due to ongoing improvements, actual product may have slight variations from the one described in this manual.
Representatives are available Monday — Friday 9:00a.m to 5:00p.m. EST
VF09_MAN_Rev1
Please visit our web site at: www.verilux.com or call
1-800-786-6850
340 Mad River Park, Waitsfield, VT 05673
Made in China
Printed in China for Verilux, Inc.
© Copyright 2017 Verilux, Inc. All rights reserved.
