VF01
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Thank you for purchasing the Original Natural Spectrum
Please read the following safety information before using. To reduce the risk of
fi re, electrical shock, or injury to persons:
• Do NOT dismantle.
• Do NOT alter power cord.
• Turn off/unplug and allow to cool before replacing bulb or cleaning.
• For indoor use only.
• The lamp is an electrical device. DO NOT USE NEAR WATER.
®
Deluxe Floor Lamp.
GENERAL PRECAUTIONS
• Before plugging in the lamp, check to make sure the voltage of the wall
socket does not exceed 120 volts.
• Do not use the lamp outside or in wet locations such as bathrooms. It is
intended for indoor, dry use only.
• Not for use with light dimmers, timers, motion detectors or extension cords.
• This product may cause interference with radios, cordless telephones,
or devices that use a wireless remote control, such as televisions. If
interference occurs, move the product away from the device, plug the
product or device into a different outlet, or move the lamp out of the line of
sight of the remote control receiver.
• Do NOT use lubricating agent in assembly; please see troubleshooting
section if you are having diffi culty assembling your lamp.
• Unplug from electrical outlet for extended periods of non-use or during
lightning storms to ensure protection of the electronics.
3
Main Parts & Controls
A. Lamp Head
B. Gooseneck
C. Shaft
D. Lamp Base
E. Power Cord
Close-up of Lamp Head
GETTING STARTED
F. Polarized Plug
G. Parabolic Grid Diffuser
H. Bulb
I. High/Off/Low Switch
A
H
G
Attention!
DO lift your lamp by the shaft. DO NOT lift the lamp by the gooseneck.
I
B
C
D
E
F
4
UNPACKING YOUR LAMP
1. Remove all pieces from box.
Locate 2 screws and tightening tool.
2. Detach red plastic pieces and store them in the event you need to
return the lamp.
3. Important: To avoid scratching the metal shaft, do not use a sharp
object to cut the plastic covering. The clear plastic covering on the
shaft is specially designed to tear away easily.
IMPORTANT NOTE:
Remove red plastic protective pieces prior to assembly.
5
ASSEMBLY INSTRUCTIONS
Read Instructions Carefully Before
Assembly:
1. Connect the two ends of the Power
Cord (between the base and the
Shaft) using the lock connectors.
2. Carefully tuck excess Power Cord
into the Shaft. DO NOT CUT OR
SHORTEN THE POWER CORD.
3. Insert the Flex Pole and the Shaft
into the Base.
Fig. 1
4. Check direction of the lamp and
the hole on the Base, then use
a Philips Head Screwdriver (not
included) to tighten the screw into
the hole. BE VERY CAREFUL
NOT TO PINCH ANY PART OF
THE CORD BETWEEN ANY
METAL PIECES.
6
ASSEMBLY INSTRUCTIONS cont.
5. Carefully remove bulb from its box, hold by the white base, and
insert 4 pins into socket. Push on the base until the bulb snaps into
the socket completely, and push into metal bulb clips.
6. Attaching the Parabolic Grid Diffuser
• Remove grid diffuser from protective plastic bag
• Insert plastic pegs at bottom of grid diffuser into openings near bulb
socket
• Snap tab into place
7. Plug lamp into outlet and turn on. If bulb does not illuminate
instantly, please refer to the troubleshooting section of this manual.
7
Removal
BULB REPLACEMENT INSTRUCTIONS
1. Unplug lamp from power source.
2. To access to the bulb, remove grid
diffuser by depressing the tab and
lifting it out. (See page 7)
3. Firmly hold bulb base (B) and pull
bulb (C) from the socket (A) in
an outward motion.
Installation
1. Unplug lamp from power source.
2. Firmly hold base (B) and push bulb
(C) into the socket (A).
3. Be sure bulb is fi rmly seated in the
socket (see below) and snapped
into the metal bulb clip (D).
4. Replace grid diffuser.
YES NO
A
A
B
B
C
C
No
gap
Correctly seated bulb Incorrectly seated bulb
large gap
8
Notice
TROUBLESHOOTING
Before requesting service on your Verilux® lamp, please read the
following:
• Make sure all power connectors, cords, and plugs are inserted fully
and securely.
• Be sure the bulb is securely seated into the socket. (See page 8)
• Make sure there is power to the wall outlet or try another outlet.
• Problem with aligning screw holes? Always start with the base and
work your way up with the shaft and attach the head last. Place your
foot on the base of the lamp on the fl oor. While holding the shaft with
your hand, gently rock the unit back and forth. Shaft should ease into
socket and screw holes will align.
9
CARE & CLEANING
Your lamp is made from high quality materials that will last for many
years with minimum care. You may want to periodically clean the lamp,
using a mild non-abrasive cleaner and soft cloth. When cleaning, make
sure you have turned off and unplugged the unit, and allowed suffi cient
time for the unit to cool. All liquid should be properly wiped away and
dried prior to restoring power.
DO NOT USE SOLVENTS OR CLEANERS CONTAINING
ABRASIVES, OR AMMONIA BASED CLEANERS
Note: All moisture should be properly wiped away and dried prior to
restoring power.
10
Please visit our web site at: www.Verilux.com
340 Mad River Park, Waitsfi eld, VT 05673
1-888-544-4865
VF01-MAN-Rev3
© Copyright 2008 Verilux, Inc. All rights reserved.
Printed in China for Verilux, Inc.
