Verify Location SAZO GPS User Manual

SAZO GPS

Personal Locator System

USER MANUAL

INDEX

Chapter 1. SAZO………………………………………………..………5

1-1 SAZO accessories…………………………………………………………………………..5

1-2 Important Observations……………………………………………………………………..6

1-2-1 Positioning errors……………………………………………………………………..6

1-2-2 Setting of emergency call……………………………………………………………6

1-2-3 Lag of message announcement…………………………………………………….6

1-2-4 Password management and regular change………………………………………6

1-2-5 Daily maintenance…………………………………………………………………….7

1-2-6 Other suggestions…………………………………………………………………….8

Chapter 2. Operating…………………………………………………..9

2-1 Overview the “SAZO”………………………………………………………………………….9

2-2 Features overview……………………………………………………………………………10

2-3 Operating instruction…………………………………………………………………………11

2-3-1 Power up………………………………………………………………………………11

2-3-2 Switch off……………………………………………………………………………...12

2-3-2 In-bound and out-bouncall………………………………………………………..….12

2-3-4 Adjust handset volume……………………………………….……………..………..14

2-3-5 Ringer/ vibrate settings…………………………………………………….………..14

2-3-6 Emergency panic alert……………………………………………………….………15

2-3-7 Remove the ripcord/ lanyard…………..…………………………………………….16

2-3-8 Low battery power warning…………………………………………………………..17

2-3-9 Charger LED indicator………………………………………………………………..17

2-3-10 Restore the default setting………………………………………………………….17

2-3-11 Settings via cell phone/ telephone…………………………………………………18

2-3-12 Single location report………………………………………………………………..19

2-3-13 Regular location report………………………………………………...……………20

2-3-14 Silent monitoring……………………………………………………….……………20

2-3-15 Defaults setting………………………………………………………….…………..21

2-3-16 “Geo-fencing” instruction……………………………………………….…………..22

Chapter 3. Troubleshoot……………………………………………24

Chapter 4. Specification..............................................................26

Chapter 5. Warranty article…………………………………………27

- 5 -

1-1 SAZO accessories

Charger

The power-charger is designed specifically

for this product, you can identify whether

the recharging process is complete or not

by the top indicator on the charger’s panel.

Battery

Lithium battery is designed specifically for

this product,.

※ Recommend consumer using company-made specific parts of this product.

Installation Installation

Insert SIM then Battery.

◎ Ensure that battery is correctly inserted with full power

contained.

Insert Charger

◎ Ensure that battery is full charged.

- 6 -

1-2 Important Observations

1-2-1 Positioning errors

Location provided will have a tolerance from the real position depending where the device

is located, this is due to external factor; and the location position indicated is a reference

guide only.

1-2-2 Setting of emergency call

This product has emergency call ability; we strongly recommend that user completes the

setting prior to first using this product to ensure functions setting are correct.

After the settings are complete, SAZO will send the setting information to 1st emergency

number (primary) for confirmation. We recommend setting the most important person’s

number first as the emergency call No1. for immediate notification and safety demands.

1-2-3 Lag of Message Announcement

This product sends its location and status information by SMS from anyone of the network

providers, and during peak period or significant occasions like Christmas, New Year, etc.

the networks do get very busy. This may cause a delay in the receipt and sending of the

SMS message procedure.

1-2-4 Password management and regular change

This product can allow two way voice communication and. To change or access your

setting you will need to verify your password (PIN); this process is to protect personal

privacy, information and safety, It is your responsibility to keep this safe.

1-2-4-1 Default of password

The default password (PIN) value is “0000”, please reset it immediately after purchasing

this product. We strongly recommend not to use “0000”, or a personal ID number that is

easy to derive.

After the password is changed, no person including company system administrator can

retrieve this or has access to it. Only the user who knows the password (PIN) has access to

the device, please safeguard the password.

- 7 -

1-2-4-2 Regularly change password

It is highly recommend that the user change password regularly (90 days) and safeguard it

without disclosing it to others. Verify Location or its associated companies cannot be

liable for any breach or determent caused from password being revealed.

1-2-5 Daily maintenance

It is recommended to only use company-made standard parts and accessories for this

product. Any damage or disorder caused from using on-company-made parts will be

beyond the warranty scope.

This product is an electronic communication device; user needs to take caution when

performing the following maintaining points to keep the product in a good operation

condition.

1-2-5-1 Battery

Maintain battery power by charging the battery. The most proper operating temperature of

battery is within 20-30oC; temperature beyond this range will reduce the battery’s operation

lifetime.

1-2-5-2 Button keys

The button keys are probably the most used parts of this product. The dust accumulated in

the seam can be wiped out by tiny brush or blown out by air-spraying. Also consumer can

use palm vacuum to clean it.

Only clean the keypad surface while the product is turned off with battery taken out and the

external power line (charger) removed.

Avoid water leaking onto or into the casing, and from the button key seam; this will damage

the circuit board. If water is splashed onto the outer casing, DO NOT SWITCH ON the

product. Contact local agent for advice.

- 8 -

1-2-5-3 If splashed or wetted

Do NOT switch ON while it is wet, if the power is switched on this will cause severe

damage to the unit.

1-2-5-4 What to do if splashed:

Step 1: Remove power line and battery.

Step 2: Pour out any access water inside this product, and then find a soft napkin or cloth to

wipe, taking care not to erode the parts surface.

Step 3: Dry up this product by fan and send it to the local agent or shop at the earliest .

Under no circumstance use a hair-dryer to blow-dry as this may cause deformation

of mechanism by heat.

1-2-6 Other Suggestions

Away from high temperature

Do not expose the cell phone in an overheated environment for long durations, (i.e. placing

it under the windscreen inside the car’s cabin), as this is likely to deform the outer casing

and may damage internal parts.

1-2-6-1 Personal privacy

Under legislation it is strictly forbidden to use this product for the purpose of covert

operation or where other’s privacy may be compromised, (i.e. making wiretap or tracking

without consent, etc). Verify Location or its associated companies cannot be liable for

any breach or determent caused by users.

- 9 -

2-1 Overview

GSM blue LED

Emergency SOS

Mic

Send and Receive Key

Fast dial key 2 / volume up & down

Fast dial 3

Fast dial1/ Vibration& Ring

switch

Lanyard panic socket

Power switch

Charger socket

Lanyard

- 10 -

2-2 Features overview

• GPS location.

• LBS location. (Depend on the local network operator service)

• Easy to use voice menu settings.

• Secure log in and PIN protected management system.

• Out-bound call fast dial pre-set for 3 numbers.

• Quick notification of emergency to 3 numbers.

• Emergency notification via SMS and Web.

• Low battery notification by SMS for 3 setting numbers.

• Ripcord/lanyard alert.

• Regular location reports.

• Silent monitoring.

• Incoming call vibration/ Ring select.

• Volumes adjust.
