Vemco VR2W User Manual

How to use the VR2W

www.vemco.com

7 Apr 2014 DOC-4400-18

family of receivers.

Summary of Manual

This manual is intended to provide VEMCO users with the information they require to use the

VR2W receivers. VEMCO highly recommends that the user fully read the manual before using the

equipment or the VUE software.

Section 1: Introduction

Getting to know the VR2W receivers

Section 2: Getting started

Getting the VR2W ready, including powering the VR2W, opening and closing the case, and initial t est s

Section 3: Communication

Talking to the VUE software, and how to use VUE with a VR2W

Section 4: Deployment

Important points to consider in a deployment plan and the most common attachment method

Section 5: Maintenance

How to care for the equipment and prepare it for storage, including removing the battery

Section 6: Additional Information

Additional information about the VR2W that is good to know but not mandatory for basic operations

Section 7: Common Questions

Answers to frequently asked questions relat ed to using the VR2W receivers

Section 8: Troubleshooting

Solutions to common issues that may arise

Section 9: Appendix

For the latest versions of user

manuals and software, visit

www.vemco.com.

Table of Contents

1 Introduction ........................................................................ 1

1.1 System Overview ................................................................................................................... 1

1.2 VR2W Case ........................................................................................................................... 2

1.3 Case parts ............................................................................................................................. 3

2 Getting Started .................................................................... 4

2.1 Open the VR2W Case ........................................................................................................... 4

2.2 Install Battery ......................................................................................................................... 7

2.3 Close the VR2W Case ........................................................................................................... 9

2.4 Testing ................................................................................................................................. 11

2.4.1 In-Air Test .................................................................................................................... 11

2.4.2 In-Water Test .............................................................................................................. 11

3 Communication ................................................................... 12

3.1 Install VUE software ............................................................................................................ 12

3.2 Activate Wireless feature ..................................................................................................... 14

3.3 Establish communication ..................................................................................................... 15

3.4 Record mode ....................................................................................................................... 17

3.4.1 Start a Study ............................................................................................................... 17

3.5 Offload Data ......................................................................................................................... 19

3.5.1 Disconnect communication with receiver .................................................................... 20

3.5.2 Update Firmware ......................................................................................................... 20

4 Deployment ....................................................................... 23

4.1 Deployment Facts/Tips ........................................................................................................ 23

4.1.1 Mooring ....................................................................................................................... 23

4.1.2 Spacing ....................................................................................................................... 23

4.1.3 Biofouling .................................................................................................................... 23

4.2 Mooring Line Attachment ..................................................................................................... 24

5 Maintenance ...................................................................... 26

5.1 Battery Replacement ........................................................................................................... 26

5.1.1 Disconnecting and Removing Battery ......................................................................... 26

5.2 O-ring Care .......................................................................................................................... 27

5.2.1 Remove O-rings .......................................................................................................... 27

5.2.2 Clean O-ring Surfaces ................................................................................................. 28

5.2.3 Install O-ring ................................................................................................................ 30

5.3 Storage ................................................................................................................................ 30

6 Additional Information .......................................................... 31

6.1 Flash Memory ...................................................................................................................... 31

6.1.1 Time required to fill memory ........................................................................................ 31

6.1.2 Time required to offload memory ................................................................................ 32

6.2 LED Flashes ........................................................................................................................ 32

6.3 Set Local options ................................................................................................................. 33

6.4 Battery ................................................................................................................................. 34

6.4.1 Battery Life .................................................................................................................. 35

6.5 Case External Dimensions .................................................................................................. 36

6.6 Map Updating ...................................................................................................................... 37

7 Common Questions .............................................................. 39

7.1 VUE related questions ......................................................................................................... 39

7.1.1 How/when do I change my receiver code map? ......................................................... 39

7.1.2 What is initialization? ................................................................................................... 39

7.1.3 Why does VUE create two .vrl file types? ................................................................... 39

7.1.4 What Date/Time format is my data stored in the receiver and displayed in VUE? ...... 40

7.1.5 What does the “Hide this (window) in future” mean? .................................................. 40

7.1.6 How do I open the Options window? ........................................................................... 40

7.2 VR2W related questions ...................................................................................................... 41

7.2.1 How much detection range can I expect from my tags and receivers? ....................... 41

7.2.2 How long will my VR2W battery last?.......................................................................... 41

7.2.3 Does receiver orientation matter? ............................................................................... 41

7.2.4 At low tide my VR2W receiver will be exposed to direct sunlight, does this matter? .. 41

8 Troubleshooting .................................................................. 42

8.1 VUE related troubleshooting ................................................................................................ 42

8.1.1 Bluetooth Troubleshooting .......................................................................................... 42

8.1.2 I cannot connect to my VR2W receiver ....................................................................... 43

8.1.3 These detected ID’s don’t belong to me ...................................................................... 43

8.2 VR2W case related troubleshooting .................................................................................... 44

8.2.1 The threads have been damaged ............................................................................... 44

8.2.2 I think the case might be pressurized .......................................................................... 44

9 Appendix .......................................................................... 45

9.1 VR2W Metal/PVC Casing .................................................................................................... 45

9.2 Cleaning Instructions ........................................................................................................... 47

9.3 Contact Information ............................................................................................................. 47

9.4 VR2W Specifications ........................................................................................................... 48

9.5 Warranty and Disclaimer ..................................................................................................... 49

9.6 Glossary ............................................................................................................................... 50

9.7 Index .................................................................................................................................... 51

Regulatory Compliance Information

© (2014) AMIRIX Systems Inc. All rights reserved. The information contained herein includes

their respective owners.

If the VR2W is not used in the manner
the manufacturer protection may be impaired.

The VR2W-xxxx-110/111 complies with Par t 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and (2) this device
must accept any interference received, in cluding interference that may cause un desir ed operation

The VR2W-xxxx-110/111 has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reori ent or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected

• Consult the dealer or an experienced radio/TV technician for help

Warning: Changes or modification not expressly approved by AMIRIX Systems Inc. could void
the user’s authority to operate the equipment.

WARNING

specified by

information which is confidential and proprietary to AMIRIX Systems Inc. and may not be used
or disclosed without prior written consent of AMIRIX Systems Inc.

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such
marks by AMIRIX Systems Inc. is under license. Other trademarks and trade names are those of

VR2W Quick Facts

Receive
Frequency

VR2W-69kHz: 69.0 kHz
VR2W-180kHz: 180.0 kHz

VR2W-69kHz: Approximately 15 months
VR2W-180kHz: Approximately 8 months

Operating
temperature

static depth

Physical shocks to the receiver, such as
bumping into a solid object, when it is at
any depth can result in a considerably
higher pressure on the casing than just
the depth pressure and water may enter
the VR2W case. If the O
mating surface
then water may also enter the receiver
case. If you are suspicious that water has
entered the receiver, then follow the
suggestions in
troubleshooting a pressurized case.

1 Introduction

1.1 System Overview

The VR2W is a submersible, single-channel acoustic receiver capable of identifying VEMCO
coded transmitters. The receiver operates on a factory set frequency of either 69 kHz or 180
kHz. VR2W receivers can decode uniquely coded pingers and sensor transmitters that operate
on the same frequency as the VR2W.

The VR2W is housed in a corrosion resistant cylindrical plastic high pressure case, an d
incorporates an integral hydrophone at the tapered end of the case. The VR2W features include
Bluetooth® wireless technology, a Smart LED, 16 megabytes of data storage, record mode, and
a replaceable battery (single Lithium cell).

The VR2W records the tag code number, the date/time of valid detections, and sensor data if the
tag received is equipped with a sensor. This information is stored in the VR2W memory until it
is downloaded from the receiver using Bluetooth wireless communication and a PC running
VUE software.

Some common uses for VR2W receivers are:

• Monitoring fish movements using acoustic gates across shorelines

• VEMCO Positioning System (VPS ) arrays to trac k animals within a specific area

Dimensions 308 mm (12.125") x 73 mm (2.875") diameter
Weight 1190 g in air; 50 g in water

Battery Life

Memory

Maximum

Depth
Software VEMCO User Environment (VUE) software

VEMCO - VR2W Manual 1

8 MB (~0.8 million detections) or
16 MB (~1.6 million detections)

-5°C to +40 °C; Water must not freeze.

500 meters (730 psi)

WARNING

The VR2W pressure case and
seal have a maximum
rating of 500 meters (730 psi).

-rings or their

s are dirty or damaged,

section 8.2.2 for

VR2W-69kHz

VR2W-180kHz

Visible External Differences:

1.2 VR2W Case

The VR2W receiver is housed in the black plastic high pressure case. The case consists of an outer cylinder
that is removed to install the D-cell Lithium battery, and the endcap which houses the hydrophone and
connects to the plastic internal casing. When the outer cylinder is removed, the internal casing protecting the
electronics can be seen. There are two types of internal casing, the older metal/PVC casing and the current
plastic casing. This manual focuses on the current case type; instructions for the older case are found in the
appendix (section 9.1).

A crucial part of the VR2W is the hydrophone, located at the top of the receiver. The hydrophone is similar
to a microphone – it “listens” for sounds and transfers them to the electronics inside the receiver. Be very
careful not to bump the hydrophone or damage may occur that may prevent the receiver from detect ing tags.

The VR2W is only capable of listening to one frequency so that frequency must be selected at the time of
ordering. The frequency chosen is based on the coded tags that will be used and can be either 69 kHz or 180
kHz. The frequency is reflected in the name of the r eceiver, the VR2W-69kHz or the VR2W-180kHz.

Externally there are physical differences between the VR2W-69kHz and the VR2W-180kHz which make it
easier to identify the operating frequency at a glance. The VR2W-180kHz has a smaller hydrophone than the
VR2W-69kHz, and the identification band around the middle of the VR2W-180kHz receiver has green text
while the VR2W-69kHz has blue text. The dimensions of the two cases are slightly different – diag rams are
found in section 6.5.

The cases operate in the same manor so they’ll be
described simply as a VR2W in this manual.

1. Hydrophones are different sizes

2. Serial Number label is a different
colour.
Blue = 69 kHz
Green = 180 kHz

VEMCO - VR2W Manual 2

Cable Tie Groove: This is the second
of the two grooves.

Hydrophone: the

Attachment Hole: This hole, which is

has more attachment details.

Cable Tie Groove: These grooves
VR2W to a line – see section 4.2.

Identification Label: Contains product

VR2W-180kHz.

Comm Key Hole: Place the narrow en d of the Comm Key in here to prepare for
communication. Section 2 has more information on the Comm Key.

Status Light (LED)/Release Valve: The light flashes red to indicate the receiver’s

Do not bump the hydrophone or

unable to detect transmitters.

1.3 Case parts

The VR2W is shipped closed, as shown below. The battery may be installed in the case but not connected.
The case only needs to be opened when the battery must be connected or replaced. Connecting the b attery is
explained in Section 2, along with opening and closing the receiver case. Replacing the battery is explained
in Section 5.1.

receiver’s “microphone”
and most delicate part.

status. Section 6.2 has the full description.
The Release Valve will open if the internal pressur e i s greater than the external

pressure (see section 8.2.2). Never cover this valve.

(there are two) are used to attach the

the receiver may be damaged and

Status Light (LED) Meanings:

No flashes =

no power

name and number, contact information,
serial number, and important warnings.

At a glance, the blue text indicates

receiver is a VR2W-69kHz and green text a

almost 10 mm in diameter, is used with
the Cable Tie Grooves to secure the
VR2W while it is deployed. Section

4.2

2 quick flashes every 5 sec =

Recording Mode

2 quick flashes every 10 sec =

Memory Full

1 quick flash =

acoustic ping received

1 bright, long flash =

detection written to memory

1 long flash per sec =

Ready for Bluetooth communication

On (solid) =

communicating with VUE

VEMCO - VR2W Manual 3

WARNING

Make sure there is absolutely no water on or near the VR2W case.
Water, even in a small quantity, can damage the VR2W internal circuits
beyond repair. If the VR2W is attached to a wet rope,
remove the receiver fr

STEP 1

Want to watch this? Go to

Place the VR2W on a clean, flat surface so the hydrophone (t apered end) is
hanging over the edge enough that the large hole is past the edge of the
surface. DO NOT let the receiver fall off the surface.

TIP: A non
while opening it.

STEP 2

Continued…

2 Getting Started

Before the VR2W can begin recording detections, it must be powered. VR2W receivers are either shipped
with the D-cell Lithium battery inside the case but not connected to the receiver, or with no battery inside the
case. In either case, the VR2W case must be opened to power the receiver.

2.1 Open the VR2W Case

Two steel rods are necessary to properly open and close the VR2W case. Every shipment of new VR2W
receivers includes a pair of steel rods.

The procedure for opening a VR2W case is th e same
regardless of the operating frequency of the receiver.

www.vemco.com/products/vr2w-

69khz/?tutorials-and-tools to see the video.

om the rope before opening the case.

This also means the electronics cannot be exposed to a sudden change
in temperature and humidity that will cause condensation to develop on
the electronics and destroy the receiver.

It is vitally important that the electronics insi de the receiver case do not come in contact
with any water or the receiver will be damaged. For this reason, VEMCO recommends the
VR2W be opened in a controlled environment and not in the field or on the deck of a boat.

-slip surface, such as a rubber mat, helps keep the VR2W in place

VEMCO - VR2W Manual 4

WARNING

Remove the steel rods from the VR2W case
careful not to let the one in the Comm Key slide through the hole and
cause damage below.

C
direction until the end

STEP 5

Insert one steel rod into the hole that runs through the diameter of the
case near the flat end of the VR2W.
the left side of the

STEP 3

Place a hand on the back of t
hold it in place. The back of the receiver
often “jumps” during Step 4 so be prepared.

Insert the other steel rod into the hole in the Comm Key Hole
on the end
slide right through the hole and potentially damage
something below. Make sure the rod is fully inserted into the
hole or damage may occur to the Comm Key Hole.

Apply pressure to
a counter
hydrophone. The r
brace while you apply pressure
off the flat surface

Continue to r
turning become easier.

STEP 4

Continued…

receiver as shown.

Position it so most of the rod is on

he receiver to

-cap of the receiver and hold on to the rod – it will

-clockwise direction when you are facing the

the rod in the COMM Key hole to turn it in

od at the back of the receiver acts as a

, but be careful of it “jumping”

.

otate the rod, and therefore the end-cap, until

ontinue by hand twisting the end-cap in a counter-clockwise

-cap and outer cylinder separate.

and set them aside. Be

DO NOT impact the threads on the end-cap or they will dent
and prevent the VR2W case from closing. See section 8.2.1
for tips on thread care.

VEMCO - VR2W Manual 5

WARNING

Slide the end
careful not to damage the threads on the end

STEP 6

Plastic Internal Casing

Battery

Outer Cylinder

Threads

End-cap

If the VR2W has a metal and PVC internal casing inst ead of the plastic internal casing shown,

-cap and cylinder apart until the battery compartment has cleared the cylinder. Be very

Compartment

instructions are found in sect i on 9.1.

The internal casing surrounding the electroni cs is not
waterproof. Water, even condensation from a hum id
environment, will enter the case and damage the electronics.

-cap or the VR2W won’t close and seal properly.

VEMCO - VR2W Manual 6

Insert the battery pin into one of the
holes in the edge around the battery
cavity and slide the pin across the end
of the battery until
are both in the receiver case.

STEP 3

Downward force
(see red arrow) may
be required on
battery end to get
the pin started.

Slide the Lithium
D
battery section at the
end of the receiver so
the battery’s wires are
outside the case.

STEP 2

Check that both
ends of the pin are
flush with the
case.

STEP 4

Place the battery
into the gap in the end
of the receiver case
closest to the battery
connector on the case.
There are two gaps in
the end of the case.

STEP 5

Verify
inside the battery
cavity is still at the
back of the cavity.

STEP 1

Continued…

Want to watch this? Go to

2.2 Install Battery

With the case open, you can install the new battery. If there is a used b attery in the receiver, use the
instructions found in Section 5.1.1 to remove the battery before inserting the new one.
Some VR2W receivers are shipped wit h the battery inside
the receiver but not connected. If this is the case for your
receiver, then move to Step 7 in the instructions below to
power your VR2W.

that the O-ring

VEMCO - VR2W Manual 7

the ends of the pin

http://vemco.com/products/vr2w-

69khz/?tutorials-and-tools to see the video.

-cell battery into the

wires

Gather any excess battery wire
the battery cavity
of the receiver casing. This reduces the chance of damage
to the battery

STEP 8

Place the O

the
battery wires are inside the O
place.

STEP 6

Position the receiver so you can see the LED light.
Connect the two battery connector halves together until a

“click” is heard and the VR2W receiver’s
flashing

NOTE

was in Recording mode (i.e. as Study
had been initialized) when the battery was disconnected,
then it will immediately return to recording detections after
the battery has been replaced. Settings are not lost when
the power is disconnected

STEP 7

-ring in the O-ring groove around the end of the case so

-ring. This also holds the battery pin in

.

: If the VR2W

(circled in yellow) and not along the side

wires.

.

into the area at the end of

light begins

VEMCO - VR2W Manual 8

Place a new desiccant pack (if the existing one has been deployed) in the
bottom of the

f the pack are touching opposite

sides of the cylinder’s wall.

STEP 3

A desiccant pack has been included in the bottom of the
VR2W to reduce the occurrence of
VR2W. One o
case during storage and deployment.

We recommend that you replace the desiccant pack with
each deployment and with each battery replacement cycle.

More information on the availability and usage of t hese packs
is located on our website,

Make sure the serial number around the outer cylinder
matches the serial number on the internal casing. This is
particularly important when more than one VR2W receiver is
open at the sa

STEP 1

If this is the first time closing the VR2W case, then make a visual
ins
cylinder to be sure
and debris free.

If the VR2W has been deployed previously, then follow the O
inspection/replacement instructions in section
seal in the case.

STEP 2

Continued…

Want to watch this? Go to

2.3 Close the VR2W Case

Before deploying or storing a VR2W receiver, the case
must be properly closed and sealed to prevent damage to
the electronics. Even humidity in the air can, over time,
cause damage to the electronics so it’s very important to
keep the case sealed, with a functioning desiccant pack
inside, as much as possible. Important information about storing a VR2W is found in section 5.3.

me time.

pection of the O-rings and the O-ring surface inside the outer

they are clean, properly greased, undamaged,

Details are found in section 5.2.

5.2 to improve the

Outer Cylinder so both ends o

f these packs should remain in the receiver

condensation in the

www.vemco.com.

VEMCO - VR2W Manual 9

69khz/?tutorials-and-tools to see the video.

www.vemco.com/products/vr2w-

-ring

Slide the plastic internal casing into the Outer
Cylinder, battery end first, until the first threads
are
O
properly seated in
their grooves as the
end
into the outer
cylinder.

STEP 4

Place the VR2W on a clean, flat surface so the hydrophone
(tapered end)
is past the edge of the surface. DO NOT let the receiver fall off the
surface.

rubber mat, helps keep

the VR2W in place while closing it.
Insert one steel rod into the hole that runs through the diameter of

the case near the flat end of the VR2W.
majority of the rod is on the right side of the case. This helps brace
the receiver while the case is being closed.

STEP 6

Turn the end-cap in
a clockwise direction
(when looking at the
hydrophone) until it
becomes too hard to
turn

STEP 5

Insert the other steel rod into the Comm Key Hole on the end-cap and hold on to the rod – it will slide
through the case and potentially damage something below
damage may occur to the Comm Key Hole.

STEP 7

Place a hand on the back of the receiver to hold it in
place.

Apply pressure to
clockwise direction when you are facing the

Continue moving the rod until
edge of the outer cylinder. Don’t over
pieces together or they may be damaged.

Remove the steel rods from the VR2W case.

inside the outer cylinder. Ensure that the

-rings remain

-cap is moved

by hand.

is hanging over the edge enough that the large hole

TIP: A non-slip surface, such as a

Position the rod so the

. Make sure the rod is fully inserted or

the rod in the endcap so it turns in a

hydrophone.

the end cap touches the

-tighten the case

VEMCO - VR2W Manual 10

2.4 Testing

Before deploying a VR2W, it is wise to test it with a tag to verify that it is
operating properly. This test also creates a VRL file containing all the
configuration information for this receiver – handy to keep as a record of
the receiver’s configuration.

Tests can, and should, be done in both air and water.

2.4.1 In-Air Test

The VR2W can detect coded pingers in air, but at a much reduced range compared to their r ange capabilities
in water. Perform air tests away from electrical noise sources such as motors, PC screens, or fluorescent
lights.

To perform an in-air test, follow the steps below.

1. Activate the Bluetooth feature on the VR2W (section 3.2

2. Establish communication between the VR2W and VUE software (section 3.3).

3. Begin a Study. Section 3.4.1 has the details of how to begin a study, also known as initializing a

receiver.

4. Disconnect the wireless communication with the VR2W (click the red box with

the “X” in the receiver ribbon

5. Activate a tag that operates on the same fr equency that the VR2W operates and

place it near the hydrophone. For 69 kHz equipment, place the tag less than 30
cm (12”) away from the VR2W-69kHz hydrophone; for 180 kHz, place the tags
less than 8 cm (3”) from the VR2W-180kHz hydrophone. Position the tag so the
side of the tag is facing the side of the VR2W hydrophone.

6. Wait while the VR2W records the tag(s) near it. You can watch the flash patterns

as the tag is detected and the data is stored in memory. Each faint flash of the
Status Light (LED) is a received ping and a long, bring flash is a stored detection.
If the flash patterns are different, compare i t to the Status Light Meanings
(section 6.2).

7. Communicate

number of detections and pings received listed in the receiver status information.

8. Offload the data that was collected dur ing the test (section 3.5), creating a VRL file.

9. View the data to verify that the data was stored and retrieved without problems. Instructions for

viewing data are found in the VUE manual.

, using VUE, with the VR2W again. Before continuing, take a quick look at the

).

).

2.4.2 In-Water Test

Perform air tests away from
electrical noise sources such
as motors, PC screens, or
fluorescent lights.

chart

Tests performed in water are almost iden tical to the in-air test explained above. The only difference is that
the tags should be positioned farther from the receivers – 5 meters is suggested. In-water tests are often
performed to establish an ideal range for the VR2W receivers in the environment in which they are moored.
Details of conducting a Range Test are found at www.vemco.com/customer-service/?cs-tutorials

VEMCO - VR2W Manual 11

.

Run the latest “Install_VUE
application file. The latest file
is always available from our
website,

STEP 2

Click “Next” when the
Install Shield Wizard
begins.

STEP 3

Attach the VEMCO supplied
shown)
window opens, which may happen if your PC uses Windows XP or Vista,
then select “Cancel” and continue with these instructions.

STEP 1

If you are using Windows XP or Vista, then you mu st i nst all V UE
greater have the necessary drivers instal led.

Continued…

3 Communication

The VR2W uses Bluetooth communication between the receiver and the VUE software. This feature
dramatically increases data offload speed compared to the cabled communication of the retired VR2 receiver.
For example, to offload 2 MB of data requires 3.3 minutes for the VR2W to accomplish but it would have
taken the VR2 more than 75 minutes. A comparison table is located in section 6.1.2 for more information.

Bluetooth is still a relatively new standard and we have observed that not all
Bluetooth devices are created equally or work reliably. To ensure successful

operation with the VEMCO VR2W, we provide our users with a Bluetooth
USB adapter in the VR2W Communications Package that we are confident
will provide reliable functionality.

3.1 Install VUE software

VUE software is used to communicate with the VR2W family of receivers, allowing studies to be setup and
data to be offloaded. The software requires Windows XP SP2, Windows VISTA, Windows 7, or W indows 8.

The Bluetooth USB adapter is required for operatio n with the VR2W receivers because they use Bluetooth
communication. Others receivers may no t use Bluetooth communication and therefore would not need the
USB adapter.

to any USB port on your PC. If the “Found New Hardware Wizard”

2.0.6 or greater for the proper adapter drivers. Windows 7 and

www.vemco.com.

Bluetooth® USB adapter (may not appear as

”

NOTE:

Due to Bluetooth characteristics
in water, the VR2W must
communicate with the Bluetooth
USB adapter through air
(typical range is 10 meters).

VEMCO - VR2W Manual 12

Read the license
agreement and select
“I accept” and “Next”
if you agree to the
terms.

STEP 4

Click “Next” to install
VUE in the folder
shown, or click
“Change” to select a
difference folder.

STEP 5

Wait while the VUE
software is installed.

Click “Next” when it
becomes enabled.

STEP 6

Click “Finished” to exit
the setup wizard.

STEP 7

If you are opening a database created by an earlier version of VUE (version 1.4.4 or older), you will receive a
warning that the database will be converted to the new version of VUE and will no longer be compatible with
older versions of the software.

VEMCO - VR2W Manual 13

MAGNET

FLOAT

COMM KEY

Wait until the VR2W’s LED
begins flashing
long, steady flash once a
second. The
less than

Remove the Comm key.

STEP 2

Bright flash

Slide the smaller end
of the Comm Key in
the Comm
on the VR2W, near
the hydrophone.

STEP 1

3.2 Activate Wireless feature

The Bluetooth feature in a VR2W receiver must be activated before the VUE software will be able to f ind and
connect to the VR2W. Activation requ ires a sp ecially designed Communications Key (also referred to as
“Comm Key”).

The Communications Key is a stepped cylin der made of black plastic material. A strong magnet is contained
in the smaller end of the Comm Key and should be kept away from any magn etically sensitive materials. An
orange float is attached to the Com Key case for e asier handling and locating of the key. This key functions
with other VEMCO receivers that use a Comm Key, such as the VR4-UWM.

The Communication Key contains a
strong magnet. Do not put it near
magnet-sensitive materials, such as
CRT computer monitors or magnetic
stripes, as they could be seriously
damaged.

Key Hole

five seconds.

a bright,

wait time is

every second

The flash pattern in a VR2W indicates the mode ( state) the receiver is in at the time. A bright, long flash
once a second indicates that the VR2W is now ready for wireless communication but is not yet in
communication with VUE.

The Comm Key can be removed from the VR2W once the light is flashing.

TIP

It’s helpful to place the VR2W within 10 meters (32 feet) of the
operating Bluetooth® USB adapter before activat i ng the VR2W.

WARNING

VEMCO - VR2W Manual 14

Open the VUE software. The software will scan for any active devices
within communication range.

Wait while the software searches for receiver

STEP 1

All Bluetooth® activated VEMCO receivers within

When the software finds the receiver, a VR2W icon wil l be
displayed in the “Bluetooth Devices” sect i on of the Home
tab with the receiver’s serial number for identi fication. It
will display all
flashing bright, long, steady flashes) wit hin communication
range

If wireless communication has not been activated on the
VR2W, then activate communication (section

) and click

“Device Scan” on the VUE software’s Home tab.
Wait while the software searches for receiver

TIP: If VUE can’t find your receiver(s), try again. It’s

Double
and wait while communication is
established when information pertaining to this receiver is displayed and the receiver’s LED is
on continuously

STEP 2

TIP: VUE can communicate with up to seven wireless receivers simultaneously.

3.3 Establish communication

After the VR2W has been activated (sect ion 3.2), it is ready for wireless communication with the VUE
software. The VR2W must be within communication range of the Bluetooth USB adapter, which is typically
10 meters (32 feet) but can vary based on physical and wireless
obstructions/interference. Due to Bluetooth® wireless technology
characteristics in water, the VR2W must communicate to the Bluetooth®
USB adapter through air.

not uncommon for a Bluetooth scan to miss devices ,
especially if other wireless devices are in t he area.

Bluetooth® activated receivers (LED is

, which is approximately 10 meters.

communication range will be displayed when a Devi ce
Scan is performed.

-click on the receiver icon of the desired VR2 W (serial number is listed under the icon)

. The “Link Status” in the VUE window also changes to “Connected”.

established. You’ll know communication was successfully

VR2W communication range:

10 meters (32 feet) through air

from Bluetooth® USB adapter.

s.

3.2

s.

VEMCO - VR2W Manual 15

Each receiver currently in communication with VUE has a tab at the top of the VUE window. This tab
identifies the type and serial number of the receiver. Click on a tab to
making the receiver’s information visible.

The Receiver Tab

Receiver information

center of the window.

Receiver type and

The ribbon section contains tasks and

A checkmark at “Save to file” will

The Detection Monitor

Selecting “Disable Timeout”

section displays detections
that are received by the
VR2W while it is connected
to VUE. These detections
are saved in the VR2W
memory. They can
immediately be saved to the
PC once “Save to File” is
selected (see box at right).

serial number

begin a file to save all detections
received from that point forward.
The file name appears in the
Detection Monitor and the file is
saved to the selected directory
(see VUE user manual).

The received detections visible in
the Detection Monitor are not
automatically saved.

bring it to the front of all the tabs,

advanced options, including offloading
data, firmware upgrades, recording
(initializing) and ending communication.

specific to this VR2W
is contained in the

will keep the VR2W “awake”
(Bluetooth communication is
active) until the VUE software
is closed. This is helpful w hen
doing in-air testing. Leaving
the Timeout in place (no
checkmark) allows the
Bluetooth communication to
eventually timeout and close.

CAUTION: Verify the receiver you are communicating with is the intended unit,

particularly before initializing and erasing rec ei ver memory files, or data

VEMCO - VR2W Manual 16

could be lost. Communication can occur with any VR2W with Bluetooth®
wireless technology activated within a 10 met er range (typical range in air).

C
tab’s ribbon
receiver and VUE software is not present.

STEP 1

Review the PC clock time listed in the dialogue box t hat opens.
The receiver will be set to UTC time based on the current t ime of
the PC so the PC time and the UTC offset must be correct. If the
time or UTC offset are not correct, then click “Cancel” and make
the necessary corrections before returning to start the s
time and UTC offset are correct, then click the “OK” butt on to
continue.

STEP 2

CAUTION: It is vital that the PC clock

Continued…

3.4 Record mode

The default operating mode of the VR2W is to record received pings and detections, even while connected to
VUE software. The VR2W enters Record Mode when any of the following events occur:

 The battery is installed
 A stu dy is started in the VUE software
 Bluetooth communication is closed while recording is paused

Bluetooth communication can close when any of the following events occur:

 The VR2W has received no communication from VUE for 10 minutes
 Th e R eceiver Tab in VUE software is closed by the user
 VUE closes communication automatically af ter 30 minutes of inactivity from the user (unless the

VUE option is disabled)

These events were chosen so that a VR2W receiver would always be deployed in Record Mode. The only
way a VR2W wouldn’t be in Record Mode is if the memory was full or the battery was removed (see section

5.1).

3.4.1 Start a Study

Setting up a study allows you to enter information in the VR2W that will aid you in
identifying its deployment location and even a description of the study, such as the
study’s title or other information. This information is stored in the VR2W and offloaded
with the data. It can be very useful when data is being organized in the VUE software.

lick the red and blue “Start Recording” button found in the receiver

VEMCO - VR2W Manual 17

. This button is not available if communication between

be correctly set to your local time,
including time zone, before the
VR2W is initialized.

Always backup

previously

offloaded data
before initializing a
new study. Internal

memory is erased.

tudy. If the

Select one of the three options displayed.

STEP 3

WARNING

VR2W is initialized.

Enter a description of the study in the Study Config uration window.
selected from a list of existing stations (if a dat abase is open) or
create a new station. If this
box and enter the latitude and Longitude.
station, then

STEP 4

Select Fix Station
location of VR2W.

Enter a
this study.

Select or enter a station

Advanced

interval.

Click OK to put the VR2W in Recorder

WARNING

Incorrectly changing the Advanced
Settings can prevent the VR2W
from hearing your tags. Only do so
under VEMCO’s direction.

How do I know the VR2W is recording?

Watch the red Status Light (LED). Two quick,
bright flashes every 5 seconds indicate the
VR2W is in Record Mode.

• ERASE: when the data stored in the VR2W has already
been offloaded and you wish to erase the data an d begi n a
new study.

• OFFLOAD: when the data has not been offloaded from the
VR2W or if there is any uncertainty about the data being
offloaded.

• CANCEL: when you wish to continue the study that is
currently running in the VR2W receiver. No changes to the
study will be made.

CAUTION: Verify the receiver you are communicating

with is the intended unit, particularly before
initializing and erasing receiver memory files, or data
could be lost. Communication can occur with any
VR2W with Bluetooth® wireless technology activated
within a 10 meter range (typical range in air).

station is a fixed position, then click a check mark in the “Fixed Station Position”

the lat/long data will appear as soon as the station name is selected from the drop-down list.

description/title for

to enter lat/long

Settings includes
changing the map
and blanking

Initializing the VR2W will erase
the receiver’s memory. Retrieve

all detection logs before the

The station name is optional and can be

by simply typing in the “Station Name” line to

If the fixed location information is already entered for an existing

Create a new station by

entering the name in

the Station Name line.

Choose unique station

names for each

deployment location.

Mode and begin the study.

VEMCO - VR2W Manual 18

Establish communication
between the VR2W and the
VUE software (section

STEP 2

Activate the wireless
feature on the VR2W
receiver (section

STEP 1

Click the “Offload data” icon in VUE’s receiver ribbon and
choose to either offload all the data stored in the VR2W, which
will duplicate the data already offloaded, or of fload just the
data that was stored since the

STEP 3

Verify that the PC clock
is correct. If it is, then
click “OK” to continue.
If not, then correct the
PC clock time and
return to VUE to offload
the data.

STEP 4

Wait while the data is
offloaded.
is shown at the
bottom of the VUE
window. The name of

successfully been offloaded.

STEP 5

3.5 Offload Data

After data has been collected by a VR2W, either during testing while in air or while in the water, that data
must be offloaded to be accessed and viewed. Data can only be offloaded from a VR2W recei ver while it is
in communication with the VUE software through Bluetooth®. Follow the steps below to offload data.

If a database is open in VUE when data is about to be offloaded, an additional dialog box appears asking if
the offloaded data should be imported directly into the open database. If “NO” is selected, then the file(s)
will be saved to the directory and in the format selected in the Offload tab of the Options window (see VUE
manual for details) and will not be imported to the database. The created file
choices are:

• VRL files only

• VRL files and CSV file

• VRL fil es and legacy VR2 files

The offloaded data will be stored in t he selected file type(s) and location
regardless of if the data is directly imported in to the VUE database or not.

VEMCO - VR2W Manual 19

3.2)

last offload was performed.

3.3).

Progress

the file created is displayed when the data has

Continued…

Decide if this is the right time to update the VR2W f irmware by
answering the following questions:

If you answere
replace the battery (see section
window will appear again the next time you connec t to this VR2W, or use the instructions for manually
updating the firmwa

If you answered “Yes” to both of these questions, then click the “Yes” button and continue with these
instructions.

STEP 1

If a database is not open when data are offloaded, then the data will automatically be saved in the file
format(s) and directory selected in the Options window.

3.5.1 Disconnect communication with receiver

Click the “Close View” button (red box with white X) to disconnect the communication between
the VR2W and the VUE software. A window will appear to confirm that you want to close the
VR2 View window.

When the communication is disconnected, the VR2W resumes recording with the last study that was
initialized. Ending communication does not re-initialize the receiver.

3.5.2 Update Firmware

Firmware refers to the internal software that operates a VR2W receiver. It is not to be confused with VUE,
the PC software used to communicate wit h the receiver. Firmware updates are rare and wi ll occur to either
deal with a hardware change or occasionally for a significant addition to functionality. VUE 2.0.10 and
greater has the ability to alert you if there is a new f irmware update (feature can be disabl ed in the “Releases”
tab of the Options window).

3.5.2.1 Update Firmware Using Automated Notification

If when you establish communication with the VR2W (see section 3.3) you receive a message indicating
VUE has detected there is a firmware updat e, then use the instructions below to upd ate your firmware. To
learn what caused the firmware upgrade, use t he “Click here to see more” option in the not ice window.

1. Does the VR2W’s battery have enough power t o perform an
update? If there is any doubt, then replace the battery before
proceeding.

during the update.

2. Has all the data been offloaded from the VR2W? I f you are updating from a firmware version older than

3.0, then all the data in the receiver will be erased. Updati ng from a version more recent than 3.0
should not erase the data, but please take the precaution of offloading all data before updating.

The VR2W could be damaged if power fails

d “No” to either of these questions, then click the “No” button in the notice window and either

re found in the next section.

5.1) or offload the data (see section 3.5), or both if necessary. The notice

VEMCO - VR2W Manual 20

Assuming all data has been offloaded from the VR2W and i s safely
stored
continue.

STEP 2

Verify that the Bluetooth activation
key is still in the receiver, or place it
in the receiver if it had been
removed. This is important as the
VR2W will require it to be in place to
re
the procedure.

STEP 3

Keep Bluetooth Activation Key in VR2W.

Wait while the firmware is loaded into the VR2W. The
status of the update is shown at the bottom of the screen.

Click

STEP 4

C
checking that th
R

STEP 5

on your PC, click “OK” to acknowledge this warning and

-establish communication during

“OK” when the firmware is installed (see below).

onfirm that the VR2W has updated to the new firmware by

eceiver tab is correct.

e firmware version number listed in the

VEMCO - VR2W Manual 21

3.5.2.2 Update Firmware Using Manual Procedure

If the automatic notification doesn’t appear, then you can manually update the firmware. Before beginning,
use Step 1 in the previous section to prepare for the update. Once the preparations are co mpleted, select
“Install Firmware” on the VR2W tab. A wind ow titled “Select Firmware File” will appear. Select the most
recent firmware file that matches your model of VR2W (based on operating
frequency). VUE software will not let you inst all a firmware file for the
incorrect model type. Click the “Open” button to continue. The rest of the
procedure matches the instructions found in Steps 2 – 5 in the automated
notification section.

VEMCO - VR2W Manual 22

Never cover the Status Light (LED)/Release Valve.

The release valve
and must not be blocked by tape or paint.

4 Deployment

How a VR2W is deployed is driven by the environment it is being deployed in and the type of study being
performed. Some important points to keep in mind when designing a deployment plan for your VR2W
receivers are explained here. The common method for attaching a VR2W to a mooring line is also given,
along with the dimensions of the VR2W cases.

4.1 Deployment Facts/Tips

4.1.1 Mooring

VR2W receivers are moored in many confi gurations often reflecting the bathymetry and
oceanographic/weather conditions. A simple mooring design generally works well. However, in rougher
conditions, heavier weights and mooring lines are usually required. If a bottom mooring is desired, the VR2W
should be positioned above the floor such that it has an unobstructed “view” of tagged animals within their
expected acoustic range. Ensure the VR2W’s hydrophone is unblocked (e.g. do not position an air filled buoy
directly above the hydrophone) and free of any biofouling. In high flow locations, you may consider using
hydro dynamically shaped buoys and low profile anchors.

For the best horizontal range, mount the VR2W receiver in a
vertical position. If the VR2W is deployed close to the
bottom of the water, mount the VR2W with the hydrophone
pointing up to the surface. If the VR2W is deployed close to
the surface of the water, then position the VR2W so the
hydrophone is pointing down.

4.1.2 Spacing

CAUTION: The hydrophone must

be kept free of mooring lines
and obstructions. Objects

around the hydrophone will
adversely affect the detection
range of the VR2W receiver.

Receiver spacing is generally determined based on range testing and historical acoustic data. Our position is
that you should try to space receivers such that you achieve good detection probabi lity in most or all weather
conditions. It is not always necessary to have 100% coverage if you have several o ther locations where you
know the animals will be passing through. However, if you wish to accurately quantify the passing of
animals through receiver locations then you should strive for 100% detection
probability. Typical spacing is usually between 100 and 1,000 meters.

4.1.3 Biofouling

Some customers use a rubber shrink tape, such as DAFLEX ST250 Cold Shrink Tape, available from Digikey
(W211-ND), to prevent biofouling on the VR2W receiver. It can be used to cover the entire receiver case or
just the Comm Key Hole and does not leave a glue residue when it’s removed. Another option is to use an
antifouling paint, such as Interlux Micron CSC.

VEMCO - VR2W Manual 23

See the Gate Design

tutorial at www.vemco.com

must be able to pop open if needed

Identify the location on the rope
where the bottom of the VR2W
receiver will be attached.

STEP 1

Twist the rope so the strands of the
rope separate from each other and
an opening in the rope is seen.
This is referred to as opening the
“warp in the rope”.

STEP 2

L
head of the cable tie is next to the rope.

STEP 4

Open the warp in the rope
again and slide another
cable tie through
lines up with the bottom half
of the lower groove
the body of the VR2W

Tighten the cable tie so the
tie’s head is next to the
rope.

STEP 5

Slide one of the cable ties
through the center of the rope
and the Attachment Hole

STEP 3

Non-reusable lashing cable ties

120 lb tensile strength

4.2 Mooring Line Attachment

The common method used to attach a VR2W recei ver to a mooring line is to use five cable ties (zip tie or tie­wrap) with the following characteristics:

A set of five cable ties is shipped with each new VR2W receiver and more may be purchased from VEMCO
(product number HWE 507450).

Follow the instructions listed below t o attach the VR2W receiver to the rope used as the mooring line. A
minimum rope size of 3/8" diameter nylon rope is suggested.

atch and tighten the cable tie so the

VEMCO - VR2W Manual 24

• 388 mm (15.25") lon g

• 7.5 mm (0.3") wide

• UV protected

•

Suggested minimum:

3/8" diameter

nylon rope

.

rope so it

around

.

Wrap a third cable tie around the VR2W receiver and the rope so
the cable tie occupies the top half of the lower groove i n the VR2W
body.
cable tie from Step 5

Latch the cable

STEP 6

Wrap a
around the VR2W
receiver and the rope so
the cable tie occupies the
bottom
used in Step 7

Latch the
cable tie so the head of
the cable tie
rope.

STEP 8

Open the warp in the rope
next to the groove closest
to the hydrophone and
slide another cable tie
through rope so it lines up
with the
groove.

Tighten the cable tie so
the tie’s head is next to
the rope.

STEP 7

Trim the cable ties so there is no excess cable tie material and no sharp edges.

STEP 9

Through Rope

Around Rope

Through Rope

Around Rope

The bottom half of the groove is already occupied b y t he

tie so the head of the cable tie is over the rope.

fifth cable tie

top half of that

half of the groove

.

is over the

IMPORTANT: Cut the cable ties when removing a VR2W from the mooring line. DO NOT re-use cable

ties. Use only new cable ties when deployi ng a VR2W receiver.

VEMCO - VR2W Manual 25

STEP 2

Open the case as explained in section
the Outer Cylinder aside.

STEP 1

Press the release lever on the battery connector
and pull the connector apart. The connector is small
and a small flat screw driver may be helpful.

Remove the O
around the end of the battery
section of the receiver.

STEP 3

Slide the pin along its long axis until
it exits the receiver case.

TIP:

the battery end while pushing pin
forwards

STEP 4

Slide battery out of case and
dispose of it according to local
regulations

STEP 5

5 Maintenance

5.1 Battery Replacement

Replacing a battery in the VR2W requires four basic steps:

1. Opening the case (section 2.1)

2. Removing the battery

3. Inserting the battery (section 2.2)

4. Closing the case (section 2.3)

Most of these topics were covered when we first setup the receiver. The only remaining topic to cover is how
to disconnect and remove the battery.

5.1.1 Disconnecting and Removing Battery

-ring from

2.1 and set

Apply pressure (see arrow) on

.

.

VEMCO - VR2W Manual 26

Each time an O-ring is
disturbed,

, it

must be checked

the unit is sealed again.

Improper care of the O-rings and their
mating surfaces can result in water
leaking into the receiver casing,
destroying the electronics.

Do not use a sharp object
near O

surface could be damaged.

U
two points on the O
with your thumb and finger,
approximately 5 cm apart.
It’s best to start with the

case threads

STEP 1

Pull your thumb and finger
towards each other while
maintaining your grip on
the O
pressure against the O
ring and should produce a
loop of exposed O

STEP 2

Grab the exposed O
pull it away from the end cap,
so it moves along the body of
the receiver.

STEP 3

Repeat
O

STEP 4

Clean any O
plastic casing.

STEP 5

5.2 O-ring Care

O-rings located in the end-cap of the VR2W case are crucial to the watertight seal of the receiver. Each time
an O-ring is disturbed, for any reason, it must be checked before the unit is sealed again. Something as
simple as a stray hair could be the differen ce between a successful study and a damaged r eceiver.

Just as the O-rings are vital to a good seal, so are the O-ring surfaces. These surfaces hold the O-ring in
position and must also be clean and damage free or the VR2W case could flood with water.

5.2.1 Remove O-rings

The O-rings must be removed from their grooves to allow the
O-rings and the grooves to be inspected and cleaned. Don’t use a
sharp object, which may damage the groove surface, when
removing the O-rings.

for any reason

before

-ring surfaces. The

se a lint-free cloth to grip

O-ring farthest from the

.

-ring

-ring and

VEMCO - VR2W Manual 27

Steps 1 -3 for the other

-ring.

-ring. This requires

-

-ring.

-ring grease on the

An O
touches. The VR2W has three, the two
grooves between the threads and the LED
on the end cap and the first flat section
inside the Outer Cylinder (2 cm).

O-Ring Surfaces

Use a lint
fr

STEP 1

Inspect the O
magnifying glass and a bright light. Scratches i n the O-ring groove
would allow water to bypass the O
receiver and destroying the internal elec tronics. If yo
(dirt, dust, hair, etc) inside a groove, then use a li nt
remove it. If you find a scratch in any of the O
contact our Support department.

STEP 2

5.2.2 Clean O-ring Surfaces

The O-ring surfaces must be clear of all deb r is and dirt. Any debris could cause water to enter the case and
destroy the receiver.

An O-ring surface is any surface the O-ring touches. The VR2W has three, the two grooves the O-rings sit in
and the smooth area inside the Outer Cylinder that sits between the threads and the end of the cylinder.

-ring surface is any surface the O-ring

It is vital that all O-ring surfaces are clean and damage free or water may work its way inside the case and
destroy the electronics within th e VR 2W r eceiver.

ee swab is very helpful for cleaning inside the grooves.

-free cloth to clean the old grease and any debris from the O-rings and the O-ring surfaces. A lint-

-ring surfaces for any scratches or debris – use a

-ring, potentially flooding the

-free swab to

-ring surfaces, then

VEMCO - VR2W Manual 28

u find debris

Inspect the O
about the condition of an O
risk damage to the receiver and therefore your data. O
purchased for VEMCO or locally. The
PARKER #2

STEP 3

CAUTION: O-rings can stretch with

Use your gloved fingers to evenly spread O
grease (we suggest Molykote 55) over the entire
surface of the O
but doesn’t have clumps of grease on it. Too
much grease can cause an O
the groove whil
little protection from water entering the V R2W .

STEP 4

While you have grease on your glove, spread a very t hi n layer of the grease
–
the inside of the Outer Cylinder (the smooth area betwee n the threads and
the end of the case). You shouldn’t be able to see grease glob s or streaks.
This thin layer of grease will make screwing the two pi eces together again
much easier and will also he

STEP 5

-rings for debris and for any damage. If there is any question

-ring, we recommend it be replaced rather than

-rings can be

replacement O-rings must be

-143 O-RING, 70 Bn NITRILE.

continued handling. We advise that
undamaged O-rings not be used for
more than three deployments.

-ring

-ring until the O-ring is slippery

e the case is being closed, giving

-ring to “pop” out of

enough to make the area appear shinny – around the O-ring surface on

lp to create a better seal.

VEMCO - VR2W Manual 29

Slowly move one of
the O
body of the VR2W to
the end cap and
carefully lift it over the
threads.

STEP 1

Push the O
the first
and check the
circumference of the
receiver to make sure
the entire O
the groove.

STEP 2

Slowly move the second O
body, over the threads, and into the
groove. Check that it’s entirely in the groove.

STEP 3

Clean any grease that may have gotten on the
body of the receiver.

STEP 4

Place the receiver on a clean surface so the
O

5.2.3 Install O-ring

Now that the O-rings and O-ring surfaces are clean and prepared, we’re ready to install the new O-rings into
the case.

-rings along the

-ring over the VR2W’s
remaining

-rings remain debris and damage free.

-ring into

O-ring groove

-ring is in

5.3 Storage

When a receiver will not be deployed for an extended period of time, remove the battery from the receiver
(section 5.1.1) to stop the VR2W from recording. This will prevent the possibility of recording pings from
noise sources during storage and also saves battery life.

Be sure to store the VR2W in a safe location where the case will not be damaged. Also be sure the
temperature of the receiver during sto r age does not exceed the operating temperatur e specified in section 9.4.

It is strongly suggested that the VR2W is not initialized prior to storage (data is not erased) and a backup of
all offloaded data is made immediately.

VEMCO - VR2W Manual 30

* Exceeds battery life of the VR2W-180kHz receiver

** Exceeds battery life of both the VR2W-69kHz and the VR2W-180kHz receivers

6 Additional Information

6.1 Flash Memory

The VR2W receiver uses a non-volatile Flash Memory (memory that can retain stored information even when
not powered) to store valid detections of coded transmitters and th e date/time at which the detection was
recorded. The VR2W will not continue to record received data once the memory is full.

A VR2W receiver contains either 8 MB or 16 MB of
memory depending on when it was manufactured. To
know the memory capacity of your receiver,
communicate with the receiver and check the
“Memory Size” value in the receiver information.

6.1.1 Time required to fill memory

A VR2W receiver with 8MB of memory is capable of storing more than 0.8 million valid detections while the
16 MB model can store more than 1.6 million detections. How long it takes to fill the memory depends on
how frequently the data is received. For example, if a valid detection is received every 20 seconds then it will
require approximately 365 days to fill the 16 MB VR2W memory. It will take less time if the detections are
received more frequently, as illustrated in the table below.

Time required to fill VR2W memory based on various detection time.

Valid detection every… Time to fill 8 MB memory Time to fill 16 MB memory

10 Sec 3 months 6 months
20 Sec 6 months 12 months*
30 Sec 9 months* 18 months**
40 Sec 12 months* 24 months**
50 Sec 15 months* 30 months**
60 Sec 18 months** 36 months**

VEMCO - VR2W Manual 31

VR2W is in record mode (records any received
pings)

6.1.2 Time required to offload memory

The time required to offload the data from a VR2W depends on how much data is stored in the memory.
Table 6-2 below lists the approximate times required to offload data from a VR2W based on the amount of
data stored in memory. These times are approximations only – actual offload times can vary on a number of
factors, including the distance between the receiver and PC, the number of connected Bluetooth devices, and
any obstacles between the receiver and the PC th at can cause interference. Offload times can also vary if a
Vemco-supplied Bluetooth dongle is not being used (i.e. built-in Bluetooth radios in laptops).

Time required offloading data from VR2W to PC based on
various amounts of data.

Amount of Memory Used

(MB)

1 1.6
2
4 6.6

6 9.8

Time to offload from VR2W

(minutes)

3.3

6.2 LED Flashes

The red Status Light on the side of the VR2W case flashes based on the task being performed or the status of
the receiver. The flashes can be interpreted using the table below. The Status Light is an LED (Light
Emitting Diode) and has been referred to as such in past documentation.

Status Light Flash (LED) meanings

VR2W LED Flashes Interpretation of Flashes

No flash Battery is disconnected or has depleted

Two quick flashes every 5 seconds

Two quick flashes every 10 seconds The VR2W memory full
One short flash An acoustic ping was received

One long flash A complete detection was written to memory
Continuous long flashes (1 per

second)

LED on constantly

When the VR2W is first powered, it will flash four times to indicate that it has successfully completed the
start-up process. After the four flashes, the Status Light will begin flashing based on its status. The most

VEMCO - VR2W Manual 32

The VR2W is ready for Bluetooth wireless
technology communication

Communicating with VUE software using Bluetooth
wireless technology

common flash pattern is two quick flashes ev er y 5 seconds to indicate the receiver is recording. If the
receiver’s Status Light flashes anything other than what is explained in this section, then con tact VEMCO’s
Customer Support team for assistance.

6.3 Set Local options

The local options feature (icon shown at right) allows you to change which suppressed pop-up queries
are visible. This feature is only enabled on the ribbon if there are queries that have been suppressed.
To enable a query, select “Always Ask” and that query will be enabled the next time that feature is
used. For example, if “Confirm before closing VR2W” is selected, then a query will open the next
time a VR2W is closed.

Changing an action is also possible in the Control Setting window,
without enabling the query. For example, i f “No” was selected when
the “Import offloaded files into database” was disabled and you now
want to import the data without being queried each time, then click the
drop-down menu next to the answer and select “Yes” f r om the list.

Be sure to select “OK” to apply the changes.

VEMCO - VR2W Manual 33

6.4 Battery

The VR2W receiver is powered by a single “D” size 3.6 Volt Lithium battery with a
connector attached – the Tadiran TL-5930/F. Specifications for the Tadiran battery are
found in section 9.4 (Appendix). Other battery options, including a non-dangerous goods
battery option, are available directly from VEMCO. Contact VEMCO if you are
interested in more information on th ese alternatives.

An important feature of the approved lithium batteries is their voltage discharge
characteristics. These batteries provide a consistent voltage for most of the life of the
battery, as demonstrated with the blue line in the graph below. This characteristic allows the receiver to
operate at the necessary voltage levels longer than a battery with a more gradual vo ltage fall-off. This can be
seen by comparing when the blue and green l ines in the graph below cross the red “cut-off voltage” line.

As the graph illustrates, the battery voltage reported by a receiver may be at the correct level for proper
operation even when the battery is close to the end of its life. The voltage value reported by a VR2W
indicates the battery is at the proper voltage at the moment but does not give any indication of the remaining
life of the battery. For that reason, we suggest you write the date on the battery when it i s installed in the
receiver.

▬ = Tadiran lithium

▬ = Alkaline sample

▬ = VR2W minimum

VEMCO - VR2W Manual 34

Lithium metal D-cell batteries are classi fied as Dangerous Goods and
must be handl
of Dangerous Goods (UN3090 for batteries alone; UN3091 for batteries
contained in equipment or packed with it). See the MSDS from the
battery company for more information.

The VR2W is usually shipped with the battery inside the VR2W but not connected – the VR2W is no t
shipped powered. Battery life is consumed from the time the battery is connected so always disconnect the
battery when the receiver is not being used for an extended period of time. The battery must be connected
before the VR2W can be initialized.

ed according to UN Recommendations on the Transport

6.4.1 Battery Life

A new Lithium D-cell battery will last approximately 15 months in a
VR2W-69kHz and approximately 8 months in a VR2W-180kHz
receiver.

Larger amounts of battery life are consumed while the VR2W is ready

Approximate Battery Life

Consumption

VR2W-69kHz = 15 months
VR2W-180kHz = 8 months

for Bluetooth communication or is communicating with the PC than
during the receiver’s Record mode. For this r eason, the VR2W exits
Bluetooth mode as soon as the Receiver tab in the VUE sof tware is closed (section 3.5.1). If the tab is left
open for 30 minutes, the PC will automatically terminate the Bluetooth link and the receiver will enter the
lower power consuming Record mode. This auto-disconnect feature, which conserves battery life, will only
occur if “Automatically close inactive recei ver connections” is enabled in the Devices section (tab) of the
Options window in VUE (see VUE manual for details).

If the study is not continuing (i.e. the last download of data for this study has occurred), then remove the
battery and store it separately. The u sed battery may be marked with the amount o f life used for future
reference or use.

Battery life is consumed from the
time the battery is installed, even
if the VR2W is not detecting tags.

NOTE

Always remove the battery when
the receiver is not being used for
an extended period of time.

NOTE

VEMCO - VR2W Manual 35

Dimensions are in inches

Dimensions are in inches

6.5 Case External Dimensions

The dimensions of the VR2W case can be useful when designing a mooring plan or mooring equipment. The
dimensions, in inches, of the two case ty pes are shown in the drawings below.

VR2W-69kHz

0.391”

diameter

attachment

hole

VR2W-180kHz

0.391”

diameter

attachment

hole

VEMCO - VR2W Manual 36

It is vital that the PC clock be correctly
set to your local time, including time
zone,

Retrieve all detection logs before the
VR2W is initialized; receiver’s memory
will be erased.

WARNING

6.6 Map Updating

Occasionally, VEMCO releases a new cod ed map. Updating the map in the VR2W is
as simple as starting a new study with the new map selected. Follow the basic steps
below to start a study with the new map. M ore details on how to initialize the
receiver is found in section 3.4.1.

1. Download the latest VUE software from www.vemco.com/downloads/

.

2. Communicate with the VR2W receiver (sections 3.2 and 3.3).

3. Click the red and blue “Start Recording” button found in the

receiver tab’s ribbon. If you have more than one receiver connected
to VUE, then make sure you have the tab of the desired receiver
selected.

4. Verify that the PC clock is correct. The receiver will be set to UTC time based on the current time of the

PC. The PC time and the UTC offset must be correct.

before the VR2W is initialized.

5. Select to erase the old data and begin the study – only select this option if the data has already been

offloaded to the computer.

Setting up a receiver

with an incorrect map

may result in no

detection data.

6. Select “Show Advanced Settings” in the Study Configuration

window.

VEMCO - VR2W Manual 37

7. Click on the down-arrow to the right of the Map name (MAP-112 in this case) and select the new map

(MAP-113).

8. Click the “OK” button to begin the study.

9. Verify that the Status light on the VR2W is fl ashing two quick flashes every five

seconds.

10. Verify that the map listed in the receiver information is th e new MAP-113.

11. Close the communication connection with the VR2W by clicking the red box with the white “X” (Close

View) on the left side of the receiver ribbo n.

VEMCO - VR2W Manual 38

WARNING

WARNING

7 Common Questions

7.1 VUE related questions

7.1.1 How/when do I change my receiver code map?

Receivers must be configured with a Code M ap that defines which type of tags the receiver can detect. Check

www.vemco.com

Changing a receiver map is not done often and should be done with careful
attention. Setting up a receiver with an incorrect map may result in no detection
data, which would not be discovered until you retrieve the receiver and offload
your data.

When a receiver is configured with a new map, t he data logs are automatically
erased as they are no longer valid in th e presence of a different code map. Please
offload stored data prior to installing a new code map.

Detailed instructions on configuring your receiver with a new code map are located in section 6.6.

7.1.2 What is initialization?

for details on currently supported Code Maps and choosing the proper map for your study.

Setting up a receiver

with an incorrect map

may result in no

detection data.

Initialization, which is also referred to as starting a study, is an important step required to configure your
receiver correctly. During initialization, you can input the station name (location) where the VR2W will be
deployed and set the receiver clock based on your computer clock. The receiver
clock is always updated based on your PC clock during the initialization process.
This information will be resident with the VR2W and will be available during
offload, regardless of whether you use the same computer or not. Initialization
also erases the receiver log files so be sure to offload data from your receiver
before initializing it. When data is offloaded from a receiver, the VRL file
created contains information abou t how the receiver was initialized.

If a VR2W receiver is deployed without being initialized, the receiver will detect tags but the receiver will not
necessarily have the correct clock setting or map configuration required for proper data detection.

Offload your data first!
Initializing a receiver will

ERASE all data!

7.1.3 Why does VUE create two .vrl file types?

When a VR2W is offloaded, VUE creates a detecti on file and an RLD data file. Both files have the “.vrl”
extension. VUE only imports the detection vrl file (e.g., VR2W180_300000_20120120_1.vrl or
VR2W_300000_20120120_1.vrl ). The RLD data file (VR2W180-RLD_300000_20120120_1.vrl or VR2W­RLD_300000_20120120_1.vrl) is used by VEMCO for diagnostic purposes and should be archived in case it
is required by our Support Department. The RL D data files have the letters “RLD” in the filename.

VEMCO - VR2W Manual 39

7.1.4 What Date/Time format is my data stored in the receiver and

displayed in VUE?

All detection data and events are stored in the receiver in UTC (Coordinated Universal Time). UTC time is
calculated by your PC and stored in your receiver during initialization. Provided your computer time and the
Time Zone settings are correct and match, i.e. your computer time is correct for the time zone you have
selected, then your detection data will be stored in the correct UTC format at the time of initialization and
data offload.

In VUE, your data is also stored in UTC format in the database. You can choose to display your detections in
UTC, your local time or in a different time zone. I t is important to know that regardless of whatever display
format you choose VUE maintains the detection data in UTC.

Export: All detection data is exported only in UTC unless specified otherwise in VUE by selecting OP TIONS
– EXPORT – CUSTOM

Important: If you are importing detection data from an older format detection file (e.g., VR2*.000) you must
specify the time zone offset used when the receiver was initialized. Earlier VR2 receiv er s were most often
initialized with the current PC local ti me unless the PC local time was set to UTC. Please contact us if you
need assistance. Once these older files are imported into VUE, a new .vrl file will be created and all
timestamps will be in UTC.

7.1.5 What does the “Hide this (window) in future” mean?

There are a number of pop-up windows that appear while using the VUE software. These windows are
wonderful when you’re just learning the software or when you’ve been away from it for an extended period
of time, but they can be very annoying when you’re in the middle of a big
study. A number of these pop-up windows have a selection box in the bottom
left corner that say something along the lines of “Hide this alert in future.”
Selecting this option means that this window will not appear the next time the
task is performed. The pop-up windows can be returned by altering the local
options or selecting “Restore All Hidd en Dialogs” in the Options window (see
section 6.3). All hidden dialogs are restored automatically if one week elapses withou t VUE being opened.

7.1.6 How do I open the Options window?

The Options window is accessed by selecting the VUE menu
(circled in picture at right) and clicking the “Options” button at
the bottom of the menu box (see arrow in picture at right). The
Options window contains the following tabs: Display, Offlo ad,
Export, Devices, and Other. These are described in detail in the
VUE manual.

VEMCO - VR2W Manual 40

7.2 VR2W related questions

7.2.1 How much detection range can I expect from my tags and receivers?

Detection range depends on so many factors that it is difficult to estimate without knowledge of the
environment and prior experience with telemetry. Range depends on transmission power, signal absorption,
line of sight, reflection/refraction, multipath and environmental noise (man-made & natural), and the
receiving quality of the receiver/hydrophone. Typically areas that have clear water, sand or silt flat bottoms
and low current exhibit the greatest ranges. Conversely, areas with turbid water, complex rocky bottom
topography and high current exhibit low ranges. In all cases, extreme weather events and periods of high
wind (waves) may significantly reduce r ange.

In most cases greater transmission power output (dB) results in greater range. For example, in good
conditions a V7-VR2W range test could yi eld a range of 300-400 m and a V16-VR2W test could yield ranges
of 800-1200 m. There are some exceptions where high po wer and a reflective and low noise environment
may cause detection breakdowns.

Please try our range calculator at www.vemco.com/customer-service/?cs-tutorials
a guide. One should always perform range test ing to determine appropriate receiver spacing. For the
enthusiast who wants to learn more about sound propagation try the widely accepted reference on underwater
sound by Urick (1983). (Urick, Robert J. Principles of Underwater Sound, 3rd Edition. New York. McGraw­Hill, 1983.).

7.2.2 How long will my VR2W battery last?

, but only use the results as

The VR2W-69kHz receiver will typically last 15 months on a single Tadiran lithium battery (model TL­5930/F). The VR2W-180kHz receiver will last 8 months on a single Tadiran lithium battery.

TIP: Write the installation date on the battery so you know how long the battery has been in use.

7.2.3 Does receiver orientation matter?

Generally, in most cases we recommend that a VR2W should be orientated with the hy drophone looking
upwards. This is typically because receivers are commonly moored closer to the seafloor than the surface. In
some situations it may be beneficial to mount the receiver with the hydrophone pointing towards the sea floor.
If a receiver is mounted near the surface or a considerable distance from the sea floor and if the researcher is
monitoring benthic creatures a bottom looking receiver may perform better because your tagged animals will
not be in a shadow zone (under the receiv er ) . If receiver orientation is a concern we recommen d that you
perform range tests using both orientations.

7.2.4 At low tide my VR2W receiver will be exposed to direct sunlight,

does this matter?

The VR2W receiver has a recommended operating temperature of between -5 to 40°C. If t here is a chance
that your receiver will exceed either o f these temperatures please consider anot her location for the receiver.
Keep in mind that direct sunlight on the black case can cause the receiver’s inter nal temperature to be much
higher than the ambient temperature.

VEMCO - VR2W Manual 41

You will require administrator access to

8 Troubleshooting

8.1 VUE related troubleshooting

8.1.1 Bluetooth Troubleshooting

VUE will display a Bluetooth® logo in the bottom right hand corner of the main VUE window when the
Bluetooth® adapter is detected and functional. If it is not detected, a red X will appear over the logo, as

shown in the sample on the right below.

Here are some things to check if VUE does no t detect a Bluetooth® adapter:

1. Is the VEMCO-supplied Bluetooth® adapter installed in a functional USB 2.0 High-Speed port on your

PC? If nothing happens when the adapter is plugged in, try a different USB port. VUE may work with
other adapters; however it is designed primarily for the adapters supplied by VEMCO.

2. Are you running the latest version of VUE? The model of VEMCO-supplied Bluetooth® adapter may

change from time to time. Updating to the latest version of VUE is the best way to ensure compatibility.
See the VUE Software section at www.vemco.com/downloads/

3. Are incompatible drivers installed? Th e Bluetooth® adapter must be configured to use drivers supplied

by Microsoft. These drivers are installed automatically in Windows 7 or manually through VUE in
Windows XP and Windows Vista. Do not install drivers from any other source. The drivers distributed
by the original manufacturer of the Bluetooth® adapter may not be compatible with VUE. If you
previously installed the Bluetooth® software, it must be removed before installing the Microsoft d r ivers.

To install the Microsoft drivers in Windows XP or Windows Vista, use the Install Bluetooth® Drivers
tool located under "Tools" in the VUE menu (shown below on left). You will require administrator
access to the PC to install the device driver.

If no compatible adapter is found, your Bluetooth® adapter or USB port is not functional.

for the latest download.

the PC to install the device driver.

VEMCO - VR2W Manual 42

4. Is the BTH.INF file missing? This driver info r mat ion file is a standard part of the Windows system,

however some computer manufacturers rename or delete it to force customers to use a particular set of
Bluetooth® drivers. This file should be located at C:\windows\inf\BTH.INF. If it is not present, then it
may have been renamed to C:\windows\inf\BTH.BAK. Simply rename this file by replacing .BAK with
.INF and rerun the VUE driver installation.

5. Remove the Bluetooth adapter and re-insert it. When laptops go into sleep mode and then re-awakened,

the connection between VUE and Bluetooth is not re-established. The Blue LED on your Bluetooth
adapter will flash when connected to VUE.

6. Windows occasionally keeps Bluetooth Devices op en in the Control Panel which interrupts VUE

communication. Open the Control Panel. If your Control Panel is set to Classic View, select Bluetooth
Devices. If your Control Panel is set to Category View, select Network & Internet Connections category,
then Bluetooth Devices. If a VR2W is listed there, highlight it, remove it and try communicating to VUE
again.

7. Though quite rare, laptops with an internal Bluetooth adapter can sometimes interfere with the VEMCO-

supplied Bluetooth USB adapter. If this is the case, you have to disable your laptop’s onboard Bluetooth
adapter under the Windows’ Device Manager. You will require administrator access to your laptop in
order to disable devices.

To access the Device Manager when the Control Panel is in Classic View, select System, then Har dware,
then Device Managers and then Bluetooth Radios. To access the Device Manager when the Control Panel
is in Category View, select Performance & M aintenance, then System, then Hardware, then Device
Managers and finally Bluetooth Radios.

Highlight any radio devices other than VEMCO devices and select Disable under the Action menu. Do
not disable the Microsoft Bluetooth Enumerator. Remove the VEMCO Bluetooth adapter from the
USB port and reinsert it. Only the VEMCO Adapter and Microsoft Bluetooth Enumerator should appear
under Bluetooth Radios (all others must be disabled). Bluetooth Device (Personal Area Network) #3 and
Bluetooth Device (RFCOMM Protocol TDI) #3 will appear under Network adapters.

8.1.2 I cannot connect to my VR2W receiver

First confirm that your Bluetooth connection between VUE and your VR2W receiver is functional. If this
Bluetooth connection is functioning correctly, try replacing the VR2W battery in the VR2W with a new

battery. If you are still unable to communicate with the unit, please contact VEMCO to receive RMA
information and send the unit back to VEMCO for assessment/repair.

8.1.3 These detected ID’s don’t belong to me

We would be very pleased to help connect you with th e owners of any unknown IDs. Please send a list of the
unknown ID’s and all associated receive r .vrl files to the VEMCO support team. VEMCO will first review
the data to identify false detections and provide you with a false detection report. Then we’ll contact the tag
owners for all the valid detections and request that they contact you directly. Please indicate if you are
willing to release your email address.

VEMCO - VR2W Manual 43

8.2 VR2W case related troubleshooting

8.2.1 The threads have been damaged

It’s very important that the threads on the end-cap are not dented or the outer cylinder will not thread onto the
end-cap properly. If the threads on the end -cap are slightly dented, use a sharp knife, such as an X-Acto
knife, to remove the deformed plastic until the sides of the thread are smooth and below the normal line of the
thread. It is important that there is nothing sticking out of the thread to damage the thread on the outer
cylinder or prevent the case from closing.

8.2.2 I think the case might be pressurized

When handled correctly, the VR2W pressure case and seal have a static depth rating of 500 meters (730 psi).
If the receiver experiences a pressure greater than this, then water may enter the case. NOTE: Physical
shocks to the receiver, such as bumping into a solid object, when it is at any depth can result in a considerably
higher pressure on the casing than just the depth pressure. Also, if the O-rings or their mating surfaces are
dirty or damaged, then water may enter the receiver case.

If water enters the receiver case under high pressure and the Release Valve was unable to open and equalize
the pressures, then some water and compressed air may still be in the case when it is returned to the surface.
This can be identified by its increased weight and a sloshing sound when the case is moved. The VR2W case
will also be very difficult to open, if at all possible. If you are suspicious there is compress ed air in the
receiver case, then check for air or water leaking from seam in the case where the end-cap and outer cylinder
meet.

To check for... then...

water leakage

air leakage

dry the seam completely and watch for drops of water around
the seam

spread soapy water around the seam and watch for bubbles
indicating air escaping

If air and/or water are found leaking from the receiver case, do not attempt to remove the end-cap. Instead,
place the receiver in a safe place and cover it with a protective layer of towels, tarpaulins, etc. until the

leaking stops. If water is still in the case after t he air and/or water have finished leaking from the
case, then attempt to open the case with the steel rod kit. If it will open, do so very slowly to allow
the compressed air to escape. If the case will n ot open using the steel rods, then it is under a greater
pressure than will allow the case to open. C ontact VEMCO for further instructions.

When the pressure has been released from the VR 2W case, carefully unscrew the end-cap from the outer
cylinder (section 2.1). Use fresh water to rinse the internal parts of the VR2W while avoiding skin contact
with any battery electrolyte that may have escaped from the battery.

Do not attempt to re-use the VR2W receiver after water has been insid e the case. The internal casing
protecting the electronics is not waterproof and the electronics have been destroyed by contact with water.

VEMCO - VR2W Manual 44

Metal/PVC Internal Casing

Battery

Outer Cylinder

End Cap

The internal casing

WARNING

9 Appendix

9.1 VR2W Metal/PVC Casing

The VR2W receiver is housed in a black pl astic high pressure case as shown in the photo below. The outer
cylinder is removed from the receiver to inst all the D-cell Lithium battery, revealing the internal casing
protecting the electronics. The older b lack VR2W receivers have a metal/PVC internal casing, which is
explained in this document. The metal/PVC internal casing has an O-ring between the metal internal casing
and the PVC battery cup to reduce vibration and is not used for water protection. Do not grease this O-ring.

The procedure for opening a black VR2W is th e same regardless of the type of internal casing so we will
begin with an open VR2W, shown below. Details on how to open the receiver are found in section 2.1.

Remove Battery

Compartment

surrounding the

electronics is not

waterproof. Water, even

condensation from a

humid environment, will

enter the case and

damage the electronics.

1. Press the release lever on the battery connector and pull the connector apart. The

connector is small and a small flat screw d r iver may help release the lever.

2. Press the back of the battery towards the body of the VR2W until the battery is not

pressing against the O-ring. There is a spring at the other end of the battery cup so
the battery will move.

3. Slip the O-ring from its groove as shown in the photo. The O-ring’s purpose is to

hold the battery from sliding out the end of the battery cup.

4. Slide the O-ring along the battery’s connector wires so they are separated f r om

each other.

5. Tip the VR2W so the battery slides out of the battery cup.

VEMCO - VR2W Manual 45

Battery wires

Sliding tube over inner casing

Desiccant pack in place

Hand tightening the case

A desiccant pack has been included in the bottom of the VR2W to reduce the occurrence of
condensation in the VR2W. This pack should remain in the receiver case during storage and
deployment.

We recommend that you replace the desiccant pack with each deployment and with each
battery replacement cycle.

More information on the availability and usage of these packs is located

Insert Battery

1. Remove the O-ring from the groove in the battery cup if it hasn’t already

been removed.

2. Slide the wire-free end of the new battery into the battery cup. The

connector wires should stick out the battery cup.

3. Thread the connector wires through the O-ring.

4. Press on the battery until the end of the battery is b elow the O-ring

groove.

5. Squeeze the O-ring into an oval shape and push it into the groove in the

battery cup as shown in the photo. Do not grease this O-ring.

6. Make sure the connector wires are not pinched in any way, especially between the

O-ring and the battery or case. Pinched wires c an break internally and disrupt power
to the receiver.

7. Connect the Tadiran TL-5930/F battery to the VR2W connector in the proper

orientation. The two connector halves should lock together with a little click.

Close the VR2W Case

The procedure for closing the VR2W with metal/PVC internal casing is very similar to the procedure with a
plastic internal casing. The only difference is the placement of the desiccant pack . That difference is covered
here but the rest of the steps required to close t he case are found in section 2.3.

1. Position the battery wire so it’s away from the end of the batter y cup as shown in the photo (at right).

2. Hold the receiver’s inner casing so the hydrophone is pointing down.

3. Place a new desiccant pack on top of the battery compartment and fold the ends of the pack over onto

itself.

4. Fold the battery wires over so they are lying on top of the desiccant pack. This is important to protect the

wires from being pinched inside the tube.

5. Slide the cylinder down over the inner casing until the first threads are inside the outer cylinder.

6. Turn the end-cap in a counter-clockwise direction with your hand until it becomes too hard to turn.

at www.vemco.com.

VEMCO - VR2W Manual 46

9.2 Cleaning Instructions

Clean the VR2W with a damp cloth and mild detergent. Do not use solvents. Do not use a scr aper or abrasive
cleaner on the LED window or the seal surfaces.

9.3 Contact Information

Product manufactured by

VEMCO Division
AMIRIX Systems Inc.

20 Angus Morton Drive
Bedford, Nova Scotia
Canada B4B 0L9

Phone: [phone]
Fax: [phone]

Web Site:

www.vemco.com

VEMCO - VR2W Manual 47

Dimensions

308 mm (12.125") overall length x 73 mm (2.875") diameter

VR2W-69kHz: 69.0 kHz

VR2W-180kHz: 180.0 kHz

Shipping & storage
temperature

1 - Tadiran TL-5930/F Lithium Inorganic battery or equivalent, 3.6 Volts

U.L. Component Recognition, MH 12193

VR2W-69kHz-110: 8 MB Flash memory (approx. 0.8 mill i on detections)
VR2W-69kHz-111: 16 MB Flash memory (approx. 1.6 million detections)

VR2W-180kHz-110: 8 MB Flash memory (approx. 0.8 million detections)
VR2W-180kHz-111: 16 MB Flash memory (approx. 1.6 million detections)

Ingress Protection

IPX8 to rated depth

Bluetooth ID: B012394
Industry Canada ID: IC-1520A-LMX9838

Standard method: 5 non-reusable lashing cabl e ties, 388 mm (15.25") long,
HWE 507450).

WARNING

The VR2W pressure case and seal have a static depth rating of
Physical shocks to the receiver, such as bumping into a solid object, when it is at any depth
can result in a considerably higher pressure on the casing than just the depth pressure and
water may enter the VR2W case. If the O
then water may also enter the receiver case. If you are suspicious that water has entered the
receiver, then follow the suggestions in the Appendix for troubleshooting a pressurized case.

9.4 VR2W Specifications

Weight 1190 g in air; 50 g in water

Receive Frequency

Operating temperature -5°C to +40 °C; Water in which VR2W is deployed must not freeze.

-5°C to +50°C

• Nominal capacity @ 4 mA, to 2 V 19 Ah

• Rated voltage 3.6 V

Battery

• Maximum recommended continuous current 230 m A

• Maximum pulse current capability 500 mA

• Weight 105 g (3.7 oz)

• Li metal content approx. 5 g

VR2W-69kHz: Approximately 15 months

Battery Life

VR2W-180kHz: Approximately 8 months (using Tadiran TL-5930/F)

Memory

Static depth rating 500 meters (730 psi)

Bluetooth wireless
certifications

Attachment:

FCC ID: ED9LMX9838

7.5 mm (0.3") wide, UV protected, 120 lb tensile strength (VEMCO number

-rings or their mating surfaces are dirty or dam aged,

(using Tadiran TL-5930/F)

500 meters (730 psi).

VEMCO - VR2W Manual 48

AMIRIX Systems Inc.

9.5 Warranty and Disclaimer

WARRANTY

AMIRIX Systems Inc., doing business under its trade name VEMCO, provides a one (1) year warranty period for the Product from date of shipment.
VEMCO warrants that on the date of shipment all Products manufactured by VEMCO are free from defects in material and workmanship under normal use and service. This warranty

applies to the components necessary for equipment upgrades, i.e. the VR1/VR2 to VR2W upgrade. With respect to transmitter products, while VEMCO is able to predict battery life with
some certainty, VEMCO cannot guarantee that these Products will remain functional while submerged for extended periods of time. This warranty does not apply to any equipment,
materials or design supplied by Buyer or a third party; re-battery services provided by VEMCO; Products for which VEMCO has not received payment; problems that results from: external
causes such as accident, abuse, misuse; servicing not authorized by VEMCO; usage not in accordance with Product instructions; failure to follow the Product instructions or failure to
perform preventative maintenance; usage of accessories, parts or components not supplied by VEMCO.

This warranty shall survive delivery only on the conditions and subject to the limitations set forth below.

NOTICE PERIODS

To receive a warranty remedy for a Product, Buyer must contact VEMCO’s Customer Support Department during the warranty period to receive the Return Material Authorization (“RMA”)
instructions. Each defective Product returned for warranty remedy must be shipped at the Buyer’s expense according to the RMA instructions and must include reasonable proof that the
claimed defect is due to a matter embraced within the warranty set forth above and that such defect did not result from any act or omission of Buyer, including but not limited to any failure
to operate and maintain the Product in accordance with VEMCO’s applicable written instructions.

REMEDY

VEMCO’s liability, and the Buyer’s exclusive remedy under this warranty, as to a defect in material or workmanship, is limited to the repair of such defect in the accessory, equipment or
part in which the defect appears or, at VEMCO’s option, to the replacement of such accessory, equipment or part with a similar item free from defect. As to any it em repaired by VEMCO
or furnished as a replacement by VEMCO, VEMCO’s liability and the Buyer’s exclusive remedy to the repair or replacement of such item for any further defect in material or workmanship,
provided VEMCO receives written notice at Halifax, Nova Scotia, of such further defect from BUYER within ninety (90) days after the repaired or replaced item is shipped to BUYER and
provided that BUYER returns same to VEMCO as provided under “Notice Periods”.

RETURNED ITEMS

All repairs, replacements and corrections described above shall be performed by VEMCO at its plant at Halifax, Nova Scotia, or at such other place as may be mutually agreeable, and
with reasonable care and dispatch in order that the Product, accessory, equipment or part will not be kept out of service longer than necessary. Return to BUYER of a repaired,
replacement, or corrected accessory, equipment, part or Product shall be at VEMCO’s expense. Title to and risk of loss of the Product, accessory, equipment, or part returned to VEMCO
pursuant hereto shall at all times remain with the BUYER, except that title to a returned accessory, equipment, part, or Product shall pass to VEMCO concurrently with shipment to
BUYER of any item furnished by VEMCO to BUYER as a replacement therefore. VEMCO shall have only such responsibility for any Product, accessory, equipment, or part owned by the
BUYER and in the possession of VEMCO as is chargeable by law to a bailee for hire, but shall not be chargeable for loss of use thereof.

WEAR AND TEAR

Normal wear and tear and the need for regular maintenance shall not constitute a defect under this warranty.

DISCLAIMER AND RELEASE

THE WARRANTIES, OBLIGATIO NS AND LIABILITIES OF VEMCO AND T HE REMEDIES OF BUYER SET F ORTH HEREIN ARE EXCLUSIVE AND IN SUBSTITUTION FOR, AND
BUYER HEREBY WAIVES AND RENOUNCES, ALL OTHER WARRANTIES AND OBLIGATI ONS OF VEMCO AND ANY ASSIGNEE OF VEMCO AN D ALL RIGHTS, CLAIMS AND
REMEDIES OF BUYER AGAINST VEMCO, EXPRESS O R IMPLIED, ARISING BY LAW OR OTHERWISE, WITH RESPECT TO ANY NON-PERFORMANCE OR DEFECT IN THE
PRODUCT OR IN ANY OTHER THING DELIVERED UNDER THIS AGREEMENT, INCLUDING BUT NOT LIMITED TO:

(A) ANY IMPLIED WARRANTY OF MERCHANTABILI T Y O R FITNESS FOR A PARTICULAR PURPOSE;
(B) ANY IMPLIED WARRANTY ARISING OUT OF CO UR SE OF PERFO R MAN C E, C O U R SE OF DEAL ING OR USAGE OF TRADE;
(C) ANY OBLIGATION, LIABILITY, CLAIM OR REMEDY IN TORT, WHET HER OR NOT ARISING FROM THE NEGLIGENCE OF VEMCO OR ANY

ASSIGNEE OF VEMCO, ACTUAL OR IMPUTED;

(D) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM, OR REMEDY FOR LOSS OF OR DAMAGE TO THE PRODUCT , FOR LO SS OF USE, REVENU E, OR

PROFIT WITH RESPECT TO THE PRODUCT; OR FOR ANY OTHER DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES; AND

(E) VEMCO MAKES NO REPRESENTATION THAT T HE PRODUCT WILL NOT INFRINGE ANY PATENT OR OTHER RIGHTS OF ANY PERSON AND

BUYER AGREES TO INDEMNIFY VEMCO AND HO LD VEMCO HARMLESS FROM ANY AND AL L CLAIMS AND LIABILITIES WI TH RESPECT TO
SAME TOGETHER WITH ANY CLAIMS AND LIABIL ITI ES WIT H RESPECT T O ANY I NF RIN GEMENT OF ANY PAT ENT OR O THER RI GH TS OF AN Y
PERSON ARISING AS A RESULT OF BUYER'S PRODUCT S, TEC HN O L O GY, ACTIVITIES, OR OTHERWISE.

LICENSE AGREEMENT

VEMCO grants to the Buyer a limited, personal license, with no right to sub-license, to use the Intellectual Property (“IP”) and Embedded Software in the manner set out in the
Documentation. The Embedded Software and IP are not sold to Buyer. All property rights, including Intellectual Property Rights, remain with VEMCO. All rights related to the Embedded
Software not expressly licensed to the Buyer are reserved to VEMCO. BUYER shall not permit any person other than BUYER and its employees to use or make use of the Embedded
Software and/or IP. BUYER shall not, and shall not permit any third party to, modify, adapt, translate, reverse engineer, decompile, disassemble, or create derivative works based on the
Embedded Software and/or IP. This license is assigned to the Product with which you have acquired the Embedded Software and/or IP. If the Product purchased is a Transmitter product,
be advised that the license life is equal to the operational life.

EXPORT

Products and associated materials supplied or licensed hereunder may be subject to various export laws and regulations. It is the responsibility or BUYER to comply with such laws and
regulations.

NEGOTIATED AGREEMENT

It is fully understood by the parties that the price of the Product and other mutual agreements of the parties set forth in this agreement were arrived at in consideration of this warranty,
SPECIFICALLY INCLUDING THE WAIVER, RELEASE AND R EN U NC IATION BY BUYER SET FORTH ABOVE (DISCLAIMER AND R ELEASE) .

Warranty and Disclaimer

VEMCO - VR2W Manual 49

9.6 Glossary

Bluetooth wireless technology: A technology based on the Bluetooth standard which provides for

fast wireless communication in air, typically over a 10 meter range.

Bluetooth USB Adapter: This is a physical device that attaches to the PC USB port and enables

your PC to communicate wirelessly to the VR2W receiver.

Code Map: Collection of code spaces that define the types of transmitters the receiver can detect.
Code Space: Nomenclature for VEMCO tags which provides unambiguous description of the

coding parameters for that tag type.

Firmware: A computer program that is contained as a read-only memory in a hardware device.

This program controls the hardware device and may be able to be upgraded, depending
on the design of the product. The VR2W firmware can be upgraded if there is a design
change.

Offloading: Retrieving data from a VEMCO receiver and storing it in a VRL file.
Station Name: Name for a specific deployment location including lat and long parameters.
UTC: Co-ordinated Universal Time is a worldwide standard for time, sometimes referred to as

Greenwich Mean Time. VUE configures VEMCO receivers in UTC time.

VRL files: Binary file format for VEMCO Receiver data logs read from VEMCO receivers.
VUE : VEMCO User Environment PC Receiver software from VEMCO.
VUE Database: A collection of imported VRL files. VRL files are all that is needed to recreate a

database or to create other databases.

VEMCO - VR2W Manual 50

9.7 Index

Battery, 34

Discharge, 34
Installing, 7
Life expectancy, 35
Replacement, 26
Specifications, 48

Case

Closing, 9
External Dimensions, 36
Inside, 6
Introduction, 2
Opening, 4
Parts, 3
Visible differences, 2

Code Map

When to change, 39

Communication

Activate VR2W, 14
Bluetooth, 12
Disconnect, 20
Establish, 15

Deployment

Fact and Tips, 23
Mooring line attachment, 24

Initialization

What is it?, 39

Memory

Flash, 31

Time to fill, 31

Time to offload, 32
Options window, 40
O-rings

Cleaning surfaces, 28

Installing, 30

Removing, 27
Quick VR2W facts, 1
Record mode, 17

Indicator, 18
Status Light (LED)

Flash meanings, 3, 32
Storage, 30
Testing

In-air, 11

In-water, 11
Update firmware, 20
VUE

Bluetooth trouble, 42

Install software, 12

Local options, 33

Offload data, 19

Receiver Tab, 16

Start a Study, 17

Study Configuration, 18

Suppressed pop-up queries, 33

VRL file types, 39

VEMCO - VR2W Manual 51
