Vello RFW-LR, RFW-LR-R User manual

FREEWAVE
FLASH TRIGGER LR

USER MANUAL

INTRODUCTION

Thank you for choosing Vello.

The Vello FreeWave Flash Trigger LR is an
8-channel, extended range wireless flash
trigger with digital circuitry. This device
uses a powerful 2.4 GHz radio signal,
maximizing your photographic potential
by extending the signal strength.

With an extended range of up to 600 ft.
(183 meters), you can use the Vello
FreeWave Flash Trigger LR confidently in
nearly all photography settings. The wireless
signal empowers you to trigger your hot
shoe or studio flash units without a line­of-sight view, making it easier to set up
wireless connections separated by a barrier.

2

Multiple triggering modes enable you to fire
all channels simultaneously or separate your
receivers into separate channels. With a 1/250
sec. sync speed, the Vello FreeWave Flash
Trigger LR’s transmitter and receiver are easy
to set up and use. The wireless capabilities
and embedded antenna eliminate clutter,
and the transmitter’s ability to tilt makes it
very compact while being used on-camera.

BOX CONTENTS

RFW-LR

• Transmitter

RFW-LR-R

• Receiver

RFW-LR

RFW-LR-R

• Receiver

• 4x AA batteries

• 3.5 to 3.5 mm

sync cable

• 3.5 mm to 1/4"
monoplug adapter

• 2x lanyards

• Pouch Case

• User manual

• 2x AA batteries

• 3.5 to 3.5 mm

sync cable

• 3.5 mm to 1/4"
monoplug adapter

• 1x lanyard

• User manual

3

FEATURES

Extended Range: Up to 600 feet (183 m)

Powerful 2.4 GHz signal: Reduced

interference and improved wireless signal
strength

Hot shoe and studio ash use:

Compatible with most ashes

Internal antenna: Embedded antenna

reduces unit size

8 digital channels: Avoids interference

from other wireless remote controls

All trigger mode: Can re all channels

at once

Low-prole construction: Tilting

joint reduces transmitter’s on-camera
presence

4

Compatible with the Vello Captain

TTL transmitter Ch. 1-4: Receiver

can be triggered via Vello Captain TTL
Transmitter

COMPATIBLE DEVICES

The Vello FreeWave Flash Trigger LR
transmitter and receiver is compatible with
most hot-shoe and lights, studio lights. The
Vello FreeWave Flash Trigger LR does not
transmit through-the-lens (TTL) settings;
therefore, we recommend using a fully
manually controlled hot-shoe flash with
this device. The power output must always
be set manually. Most flashes that can be
operated manually are compatible, except
Pentax, Sony/Minolta, and Sony Multi­Interface flashes. The Vello Flash Trigger LR
Receiver is also compatible with the Vello
Captain TTL transmitter channels 1-4.

5

PRECAUTIONS

• Please read and follow these instructions
and keep this manual in a safe place.

• There are no user-serviceable parts
inside the devices. Do not attempt
to disassemble or perform any
unauthorized modification.

• Do not operate the transmitter or receiver
in the presence of flammable gas or vapors.

• Do not handle with wet hands or
immerse in or expose to water or
rain. Failure to observe this precaution
could result in fire or electric shock.

6

• Keep out of reach of children. This
device contains small parts which
may pose a choking hazard.

• Observe caution when handling batteries.
Batteries may leak or explode if improperly
handled. Use only the batteries listed
in this manual. Make certain to align
the battery with the correct polarity.

• Batteries are prone to leakage when
fully discharged. To avoid damage to
the product, be sure to remove the
batteries when leaving the product
unattended for prolonged periods
or when no charge remains.
