Vello BG-N11 User manual

Page 1
BG-N11
BAT T ERY GRIP
Designed for the Nikon D7100 and D7200 SLR Cameras
Page 2
Introduction
Thank you for choosing Vello and congratulations on your new BG-N11 bat tery grip purchase. Enjoy the many benefi ts that a battery grip offers , such as extended shooting time and more control and comfor t when shooting in a vertical (portrait) orientation.
The Vello BG-N11 is compatible wi th the Nikon D7100 and D7200 DSLR cameras. The BG-N11 accepts one Nikon EN-EL15 rechargeable battery, in addition to the camera’s internal batter y. Six AA batteries (alkaline, Ni-MH , lithium, or nickel-manganese) can be used instead for added convenience. The B G-N11 is equipped with an alternate shu tter-relea se button, AE-L/AF-L button, mul ti selector, and main and sub-command dials for shooting in a vertical position.
Please read through this entire manual before using the BG- N battery grip.
2
Page 3
Precautions
1. The BG-N11 should only be used with compatible
devices specified in this manual.
2. Use only with batteries and battery holders
recommended in this manual. The be used wi th other batteries or battery holders.
3. When the BG-N11 is not at tached to the camera,
cover the power terminal wi th the contact cap. This prevent s elec trical shor ts caused by metal coming into contact with the power terminals.
4. When the bat tery holder is removed from the
grip, remove the batteries or place the holder in a container to prevent electrical shorts caused by contact with other metal objects.
5. The memory card access lamp may light up
tempor arily w hen the BG-N11 is mounted or removed from the camera . This is part of the normal operation.
BG-N11
can not
6. If you notice smoke, noise, or an unusual smell from
the bat tery pack, discontinue use immedia tely.
Remove the batteries and take the device to a Vello
authorized reseller.
7. The BG- N11 does not have a power sw itch.
Instead, use the camera power switch to turn the
power on or off.
8. The battery level may not display properly if
batteries are inser ted before mounting the grip.
9. Remove bat teries from the grip when not in use .
10. Do not at tempt to disassemble.
11. Avoid water or ex treme humidity and keep in a dry
and cool place.
12 . Keep out of reach of children.
3
OVERVIEW INTRODUCTIONASSEMBLYOP ER AT I ON
Page 4
Overview
1
16
6
2
3
4
5
15
12
13
14
8
7
9
10
11
17
18
19
4
Page 5
1
Sub-Command Dial *
2
Shutter-Release Button *
3
Control Lock Switch
To prevent accidental triggering, the control lock switch locks the shutter­release but ton, AE-L/AF-L but ton, multi selector dial, as well as the main and sub-command dials on the BG ­N11. Unlock prior to use by switching to the position. The control lock is not a power s witch.
4
Tripod Socket
5
Mounting Screw
6
Contact Cap
7
Camera Contact Cover Holder
8
Power/Signal Contacts
9
AE-L/AF-L Button *
10
Main Command Dial *
11
Multi Selector *
12
Locking Wheel
13
Battery Chamber Cover
14
Battery Chamber Latch
15
Battery Chamber
16
EN-EL15 Battery Holder
Holder for Nikon EN-EL 15 battery.
5
17
Power Terminals
(EN-EL15 Battery Holder)
18
AA Battery Holder
Holds six AA batteries.
19
Power Terminals
(AA Battery Holder)
* These controls perform the same
function as their on-camera equivalents
and are affected by changes to the
Custom Settings menu (Group a for
the AE-L/AF-L button, Group f for other
controls). See camera manual for details.
OVERVIEW INTRODUCTIONASSEMBLYOP ER ATIO N
Page 6
Attaching The Grip
1. Ensure that the power is
turned off on the camera and that the Control Lock on the BG-N11 is in the L position before attaching the grip.
2. Remove the contact
cap from the BG-N11 battery grip. When the BG-N11 is not attached to the camera, replace the contac t cap to protec t the contacts.
6
3. The contac ts for the
BG-N11 are on the bottom of the camera where they are protected by a contact cover. Remove the contact cover before mounting the grip.
Page 7
OVERVIEW INTRODUCTIONASSEMBLYOP ER ATIO N
4. To prevent loss, place the
camer a contact cover in the contact cover holder on the BG-N11.
5. Connect the BG-N11
grip to the camer a while aligning the grip’s mounting screw with the camera’s tripod socket.
Removing battery from camera before mounting grip is not required.
7
6. Rotate the attachment
wheel in the direc tion shown by the LOCK arrow until it is firmly tightened.
Page 8
Inserting Batteries
1. Ensure that the power is turned off on the
camera and the Control Lock on the BG-N11 is in the L position. Turn the bat ter y-chamber
latch co unte rclo ckw ise to open the batter y chamber door.
2. Remove the battery holder from the BG-N11
grip. The EN-EL15 batt er y hold er com es pre­installed.
8
Page 9
OVERVIEW INTRODUCTIONASSEMBLYOP ER ATIO N
3. Nikon EN- EL15 Batt ery:
Line up the in dentations on the batte ry w ith the EN-EL15 holder, then press the battery dow n and slide it in the dire ction of the arrow until the power terminals click into place.
4. AA Batteries: Pl ace six
AA batteries of the same type in the AA battery holder as shown, while ensuring that they are in the correct orientation.
9
5.
Insert the battery holder into the gr ip. Close the battery chamber and then turn the latch clockwise to lock. Fold the latch down. Turn the camera on and check the battery level in the control panel or view finder.
Page 10
Battery Info
The camera displays the following battery levels.
Nikon EN-EL15 Batter y:
Control Panel Viewfinder Description
(blinking)
(blinking)
Batter y fully charged.
Batter y par tia lly discharged.
Low bat ter y. Prepare spare batteries.
Batter y exhausted. Shut ter r ele ase is disabled.
10
AA Batte rie s:
Control Panel Viewfinder Description
Batteries fully charged.
Low bat ter y power. Pre pare spare batteries.
Batteries exhausted.
(blinking)
(blinking)
Shut ter r ele ase is disabled.
Page 11
AA Battery Settings
To ensure that the camer a shows the correc t bat tery level when AA batteries are used, choose the appropriate setting in the Custom Set tings menu (Group d).
Nikon Rechargeable Batteries
The camera can display information (including calibration information) for Nikon EN- EL15 batteries via the Batter y Info option in the Setup Me nu. For A A bat teries, only battery levels are displayed.
OVERVIEW INTRODUCTIONASSEMBLYOP ER ATIO N
Ba tte ry Ty pe Menu Option To Select
AA al kal ine (L R6) LR6 (AA alka line)
AA Ni-MH (HR6)
AA Li thi um (FR6) FR 6 (AA li thi um)
HR6 (AA Ni-MH)
Note: The three images on this page are menu screens seen on the D7100 camera.
Battery Order
Set the order in which the internal camera and BG-N11 batteries are used via the Custom Settings menu (Group d). W hen the c amera is drawing power from the BG-N11, a icon is displayed in the control panel.
11
Page 12
Removing The Batteries
1. EN-EL15 Battery Holder: While pressing and
holding the PUSH button on the holder, slide the bat tery toward the but ton and lift up to remove.
12
2. AA Battery Holder: Remove the batteries
one row at a time (as shown). Be sure that the batteries do not drop during this process.
Page 13
Battery & Power
EN-EL15 Batte ries
At low temperatures of about 50° F (10° C) and below, Nikon EN-EL15 batteries will decrease in performance.
Warming up a cold bat tery can recover some of the lost charge. AA batteries have lower capacity and per formance
at low temperatures.
AA Batteries
In most cases , a Nikon EN-EL15 battery will provide better performance than AA batteries w hen used in the Vello
BG-N11. AA LR6 alkaline batteries have limited capacity. Per formance of AA batteries decreases significantly at
temper atures below 68 °F (20 °C) and is therefore not recommended.
Remove the batteries when the BG-N is not in use.
13
OVERVIEW INTRODUCTIONASSEMBLYOP ER ATIO N
Page 14
Specifications
Power So urce
Operating Temperature 32 – 104 °F (0 – 40 °C)
Dimensions Approximately 5.5˝ × 1.9˝ × 2.6˝ (14 × 4.8 × 6.6 cm)
Weig ht Approx imatel y 9.3 oz. (264 g) w ith EN -EL15 battery holder (excludi ng bat tery)
Specifi cations and design ar e subject to cha nge wi thout n otice.
One EN-EL 15 rech argea ble Li-ion ba tter y or six LR6 Alkal ine, HR6 N i-MH o r FR6 Lith ium AA b atte ries
14
Page 15
ONE-YEAR LIMITED WARRANTY
This VELLO product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Vello Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Vello along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.vellogear.com or call Customer Service at 212-594-2353. Product warranty provided by the Gradus Group. www.gradusgroup.com
VELLO is a registered trademark of the Gradus Group. © 2015 Gradus Group LLC. All Rights Reserved.
Page 16
www.vellogear.com
All other trademarks are the property of their respective owners
© Copyright 2015 Gradus Group LLC
GG4
