veito CH2500 TW User Manual

PRECAUTIONS

CARBON INFRARED HEATER

CH2500 TW

User’s Manual

DESCRIPTION

OF USE

• Thank you for purchasing Veito Carbon Infrared Heater. Please read the instructions
thoroughly before using your heater.

• After reading the instructions, please keep it in a place accessible to all users.

• Ensure you read ‘Safety Precautions’ in advence and use the product corectly.

• We can not be liable for any damages caused by failure to observe these instructions.

• The product is specified for use with a power supply of 230V 50/60Hz

• This manual includes the product warrantly.

• Specifications and contents of this manual may be changed without prior notice, in
accordance with our commitment to product quality, design and control.

2

CONTENTS

Configuration and name

•Main body
How to use

•Operation and stop
How to diagnose safety device
Cleaning and maintenance
Storage Instructions
Troubleshooting
Wiring diagram
Specification
Product warranty

Safety Precautions
Precautions for installation and before use

•Precautions for install

•How to install

•How to use power

3
7

7
7
8

8
8
8
8
9
9
9
10
10
10
11

PRECAUTIONS

Safety Precautions

!

!

!

These precautions are designed for keeping users safe and preventing material damage.
Be sure to read them and use the product correctly.

• There are 3 classifications of safety precautions and they are listed in the box below.

Risk

Warning

Caution

Possiblity of death or severe injury in the event of mishandling.

Possiblity of death or severe injury in the event of mishandling.

Possiblity of injury and/or material damage in the event of mishandling.

*Meaning of picture signs

!

Indicate prohibition

Indicate contents that people must carry out

!

Risk

*After reading this, be sure to keep it at a place where other users can refer to it at any time.

(Can cause explosion)

Do not leave or use pressure vesel around
heater

3

4

WARNING

!

*After reading this, be sure to keep it at a place where other users can refer to it at any time.

!

Use specific 230V 16A amp
socket.
(to prevent fire & electric shock)

230V

!

Ensure both plug and socket is
clean and free from dust when
using.

Never use with a damaged
power lead, plug or loose wall
socket. (this can cause electric
shock, short circuiting or fire)

Never remove the plug from the
socket by pulling the mains lead.
Never touch the plug with wet
hands.
(risk of electrocution and/or fire)

Do not extend the power cord.
(risk of breakdown or fire)

!

Ensure you hold the power
plug properly when either
plugging in or unplugging.

Do not kink or place the main
power lead under heavy objects.
(risk of electric shock or fire)

Do not overload the dedicated
power socket with other
equipment.

Always turn off the unit by use
of its control cnob and
never by just pulling the
mains plug or tripping the
circuit breaker.

!

Ensure that the unit is properly earthed
through the mains power circuit.

Do not install, use
or place any
combustible
liquids or gases
nearthe product.
(risk of fire or
explosion)

Never place the unit near
combustible products such as
curtains, carpets etc. This can
cause a fire.

Never put hands or
objects into the main
body of the product.
Never touch it
immediately after use.
(risk of fire burns or
electric shock)

Never place combustible objects on
the product such as vinyl and
plastic items.(can
cause a risk of fire)

The heater must not be located
immediately below a socket outlet
when in use. (risk of fire)
