Veilux VP-1 Specsheet

V-WEB SERIES

VP-1

1 Port Encoder

1CH

Key Features

•1 Channel

•All channels D1 resolution, H.264 at 30fps

•Dual Stream

•Video loop-outs

•Encoder-based motion detection

•De-interlaced images

•PTZ support

•1 channel Audio in and out

•Digital Input and Output

Powered by

Specifications VP-1

VIDEO / AUDIO INPUT

Video Compression H.264

®

Video Input 1-CH

Video Input Interface BNC (1.0V p-p, 75 Ω)

Audio Compression OggVorbis, 16Kbps

Audio Input 1-CH

Audio Input Interface BNC (2V p-p, 1k Ω)

Voice Talk Input 1, RCA (2V p-p, 1K Ω)

VIDEO / AUDIO OUTPUT

Encode/Decode Resolution 4CIF / DCIF / 2CIF / CIF / QCIF

Frame Rate 4CIF: 25(P) / 30(N) fps

Stream Type Video / Video & Audio

Support Dual Stream Yes

Video Bit Rate 32Kbps -2Mbps, or user-defined (Max. 8Mbps)

EXTERNAL INTERFACE

Audio Output 1 Channel RCA (Linear Electrical Level, 600 Ω)

Network Interface 1 RJ45 10M / 100M adaptive Ethernet interface

RS-232 Port 1 RJ45 RS-232 Port

RS-485 Port 1 (T+,T-)

Alarm Input 1-CH

Alarm Output 1-CH

ELECTRICAL

Power Supply 12 VDC

Consumption

ENVIRONMENTAL

Temperature 14°F ~ 131°F

Humidity 10% ~ 90%

PHYSICAL

Dimensions 4.72x2.76x1.77in

Weight (without HDD)

< 12W

<1.1lb

Veilux Inc

802 Greenview Dr. Suite 200, Grand Prairie TX. 75050 USA
Toll Free: 1-800-510-6528 Direct: ([phone] Fax: [phone]
[e-mail] www.veilux.net

RoHS
