Veilux VLPR-68L922 Specsheet

V-RECON SERIES

VLPR-68L922

Car License Plate Camera

700TVL

0.001Lux

AUTO IRIS V/F

IP66

WDR

Key Features

• High Resolution 700 TV Lines

• SONY 1/3” Super Ex-View HAD II CCD

• True Day & Night (ICR-IR Cut Filter Removable)

• IR LEDs (Main) 40 Units Infrared LEDs 20,000 Hrs 850nm

• SRLED (Single Reflection LED) 20+20 Units SRLED 20,000 Hrs 850nm

• Night View Distance: Outdoor 120m

• External Control: Tele/Wide, Near/Far, OSD, Service Video

• Privacy Function / Electronic IRIS

• DNR (Digital Noise Reduction)

• Heater and Blower

Recommended Accesories

• VPS-12810

• VPS-121630

• VPS-241630

• VPS-24910

OSD

12VDC

24VDC

Specifications VLPR-68L922D

Sensor 1/3” Sony Ex View HAD CCD II

Signal System NTSC / PAL

Max Pixels 1020(H)x508(V) (NTSC) 1020(H)x596(V) (PAL)

Resolution ; DSP Color 680 TVL, B/W 700TVL ; Sony Effio WDR

Min Illumination 0.0001Lux (IR LEDs on at 2 Lux)

Wide Dynamic Range 512X Normal Camera (54dB)

Video Ouput 1.0Vp-p Composite, 75Ω (BNC)

S/N More than 55dB(AGC off)

Gamma Correction 0.45

Mechanical IR Cut Filter (ICR) Automatically Switches (B/W mode<2Lux,

IR LED 30 Units (IR LEDs on<2Lux, IR LEDs off>5Lux)

Title TITLE (Location)

Sync System INTERNAL / LINE LOCK (AC Version Only)

Digital Day & Night Mode COLOR / B&W / AUTO

Electronic Shutter AUTO (1/50(60)~1/100,000 sec.)

Automatic Gain Control 0~200 Levels (Adjustable Level Settings)

White Balance ATW / AWB / PUSH LOCK / MANUAL / 3200K /

Wide Dynamic Range / Back
Light Compensation

High Light Compensation ON / OFF / AUTO

Flickerless ON / OFF

Digital Noise Reduction 3D / 2D

Sense Up AUTO (Limit x2~x512) / OFF

Digital Image Stabilizer ON / OFF

Language ENGLISH

E-Zoom x1~x256, Pan / Tilt Adjustable

Motion Detection ; Privacy ON / OFF (24x16 Zones) ; ON / OFF

Camera Control Interface N/A

Automatic IRIS ; Connector DC

Lens Mount Built-in DC Auto IRIS Lens

Lens, Angle of View (H) f3.8~9.5mm/F1.2 Aspherical D/N Lens/74.2°~30

Max. Breaking Strength N/A

Operating Temperature Operating: 14°F to 131°F (-10°c to 55°C)

Operating Humidty 10% -90% RH

Power Supply ; Consumption Standard:12Vdc±10%; IR on: 5.5W,IR off: 2.5W,

Dimensions (W x D x H) 93(DIA)x163(D)mm

Unit Weight 1,000g

Color mode>5Lux, B/W to Color mode, Switching
Time:3~5 min.)

MANUAL: 1/50(60), FL 1/120(100), 1/200, 1/250,
1/300, 1/350, 1/400, 1/450, 1/500, 1/600, 1/750,
1/1,000, 1/1,500,1/2,000, 1/3,000, 1/4,000,
1/10,000, 1/30,000, 1/60,000,
1/100,000 sec.

6300K / ANTI CR

WDR / BLC / OFF

(15 Zones Programmable, Quadrangle Mosaic)

.0°/2~6M(6.6~19.7Feet) ; Option:f9.0~22.0mm;
6~13M(19.7~42.7Feet

Storage: -4°F to 140°F (-20°C to 60°C)

Option: 12Vdc/24Vac (10.8~39Vdc/24Vac); IR on:

6.0W, IR off: 3.5W
