The VControl™
User Manual
Version 2.1
©2004 VCommand, Inc., e-Nav, LLC and Webasto Products, N.A. All rights reserved. This manual, as well as the hardware and
software described in it, are provided under license. The content of this manual is provided for informational use only and is subject
to change without notice. – VCP0000102-A
IMPORTANT SAFETY NOTICE – The VControl™, through the use of a simple control pad,
tactile to the touch and voice controlled, allows you to keep your hands on the wheel and eyes on the road – a
significant safety advantage compared to the use of cell phones directly or other speaker phone kits. For your
further safety, it is strongly recommended that you review the instructions contained in this User Manual and
that you become familiar with at a minimum the basic functionality of the product. You should also try several
test calls while not operating the car so that you can concentrate more fully on learning the initial prompts
necessary to operate the VControl™. NOTE: All states enforce driver distracted driving regulations and your
first priority as a driver is the safe operation of your vehicle.
1
CUSTOMER SUPPORT: Your safety and satisfaction are of primary importance to VCommand and
Webasto – if you are having problems with the functioning of your unit please contact us at the following
numbers or email addresses so that our well trained staff can assist you in a courteous and timely manner:
VCommand Tech Support: 1-866-826-6669
1-866 (VCOM-NOW)
email inquiries: support@vcommand.com
Webasto Tech Support: 1-800-860-7866
2
www.techwebasto.com
– or
Table of Contents
Chapter 1: Introduction............................................................................................................... 4
MODES OF OPERATION .................................................................................................................................................. 5
SPEECH AND TONES....................................................................................................................................................... 5
SYMBOLS..........................................................................................................................................................................6
FUNCTIONS AND BENEFITS OF VCONTROL™ .............................................................................................................7
Chapter 2: Main Menu ................................................................................................................9
MAIN MENU FUNCTIONS ................................................................................................................................................. 9
MAIN MENU INTERACTION DIAGRAM .......................................................................................................................... 11
Chapter 3: Initial Operation .....................................................................................................12
DESIRED LANGUAGE..................................................................................................................................................... 12
BASIC OPERATIONS ...................................................................................................................................................... 14
Chapter 4: Making and Receiving A Call................................................................................ 18
RECEIVING A CALL ........................................................................................................................................................18
ENDING A CALL .............................................................................................................................................................. 18
Chapter 5: PhoneBook............................................................................................................... 24
Chapter 6: Setup......................................................................................................................... 30
Chapter 7: Special Functions ....................................................................................................33
Chapter 1: Introduction
This chapter highlights the main features of
VControl Bluetooth phone control system, defines
terms and conditions that are important to
understand when using the system, and provides
general tips, etc.
The following terms are used extensively
throughout this manual:
• Main Menu The primary control functions of the
VControl
• Control Pad The primary
interface module for call
activation/deactivation,
volume, mute, switch
• Bluetooth
wireless radio frequency (~2.4 – 2.5 GHz) with
a range of ~10 meters – for either analog or
refers to a
3
digital transmission
• Dialog
Voice Interaction with the VControl
TIPS ON FORMATS IN THIS MANUAL
The format that is used throughout the manual is
meant to help differentiate between what VControl
says and what you can/need to say:
When VControl is the speaker:
• Text appears as a normal sentence in italic
followed by a prompt character “>”, indicating
that the unit is waiting for your response. For
example, the unit might say “Ready, say Call,
Dial, Phonebook, or Setup>”
4
When you are the speaker:
• Spoken-word commands or responses appear as
uppercase first letter and in bold (for example,
Dial).
• Digit responses appear as individual numbers
with a dash between digits (for example, 1-8-0-
0)
• Commands or responses that have multiple
words appear as uppercase words with a dash
between words (for example, JOHN-SMITHHOME). This indicates that the words should
be spoken without pausing between words.
MODES OF OPERATION
VControl is designed for use in automotive
environments. You control the unit through a
“single” touch tactile control pad, and through voice
commands you control the desired functionality.
The unit prompts you with an easy-to-follow
dialogue and recognizes a variety of accents, but
also performs exceptionally well in an environment
with typical background noise (air conditioning,
road and engine noise, etc.).
SPEECH AND TONES
VControl communicates in two (2) ways:
• Human Voice
The system says names, prompts, locations,
and numbers in a high-quality human voice.
• Beeps
VCONTROL™™ augments its speech with
a single beep through the dialogue, the
meaning of which is dependent upon
context. In most cases the beep is to signify
that the system has concluded it’s prompt
and is waiting for a command.
SYMBOLS
Please note the following symbols/conventions that
are intended to enhance the readability of the User’s
Guide.
Î When the activation symbol is displayed,
please press the corresponding key on the control
pad.
Î The minus button will decrease volume
Î The plus button will increase the volume
Î The switch button has a variety of
functionalities such as 3-way calling, privacy mode,
etc.
Î The Mute button will mute a caller
<Beep> Î A short tone emitted from the system to
signify a certain activity
“Ready” Î Words in italics and quotes represent
voice prompts from the system
Set-Up Î Bold words represent spoken commands
by the operator
Sample Dialogues appear in shaded boxes:
Sample Dialogue
“Ready” <Beep>
Call Î “Say the name”
[Information contained in brackets are either
options or special notes] – Then plain text
following the prompt describes the kits actions
or results pending a certain command.
5
6
FUNCTIONS AND BENEFITS OF VControl
• Automotive grade components
• Continuous Speaker-Independent Recognition
• Scansoft
90% recognition from idle to 60+ mph
• Sophisticated noise reduction
• Pairs up to five (5) phones per car kit
• Includes digit dialing (continuous or block), pre-
stored voice tags, re-dial, privacy mode
• Voice dialing
• Microphone mute
• Three (3) languages:
Spanish, English, Canadian (French)
• Barge-in feature (interrupts system prompts)
• Towing Assistance, Car Club, Emergency, other
direct-access numbers
®
speech engine testing at better than
o Stores up to 32 caller names with four
locations per caller (cellular, home, etc.)
o Name Add, Delete, Edit, Listing, Erase
All to Phonebook.
• Automatic transfer to Bluetooth mode when you
enter vehicle (this can take 30 to 120 seconds
approx.)
• Status Indicators available:
o Phone low battery
o Cellular weak connection
o Roaming
o No cellular connection
o Phone not connected
o Phone call completed
• DTMF** code transmission for voicemail and
device control
**DTMF stands for Dual Tone - Multi Frequency and it is the
basis for your telephone system. DTMF is actually the generic
term for Touch-Tone (touch-tone is a registered trademark of
ATT). Your touch-tone® phone is technically a DTMF
generator that produces DTMF tones as you press the buttons.
How it works is explained further in Chapter 7.
• Bluetooth
Certified
• Easy Installation
o Wiring Harness, Bluetooth
module,
microphone
o Mute radio function and external speaker
• Calls can be transferred back to the phone for
privacy or when exiting the vehicle
• Confirmation Prompts Optional which creates
two modes:
Novice Mode VControl prompts you with the
choices you may respond with when it asks you a
question. When you first use the system, the unit is
set to Confirmation Prompts “ON”.
Expert Mode You issue commands directly to the
VControl (without the benefit of command
options), thereby reducing dialog as your comfort
and ease-of-use grows. To turn Confirmation
Prompts “OFF”, see Chapter 6 (page 29-30).
7
8
Chapter 2: Main Menu
Once your phone has been activated/paired, the
VControl will automatically connect to your phone
each time you enter the vehicle and start the ignition
– this “pairing” on Bluetooth
1-2 minutes and is active (ready) when the green
LED light is illuminated (constant) on the Control
Pad.
MAIN MENU FUNCTIONS
From the Main Menu, select the desired function.
VControl prompts you with “Ready” <Beep> Say
‘DIAL, PHONEBOOK, CALL, TOWING
ASSISTANCE, SETUP, REDIAL, EMERGENCY,
CANCEL’”
Simply speak the desired function name and the unit
will respond appropriately. Note:
connections will take
• A single <Beep> will be heard after most
prompts coming from the unit. This signifies
that the system is now ready to accept input
from the operator
• You must wait for the <Beep> before speaking
a command
Call –
phonebook. This method will also ask you to
confirm the location (cellular, work ,etc.)
to place a call by the name entered into the
Dial – Used to call a number not in your phonebook
by simply speaking the numbers in sequence or by
block (a block is area code, then the three digit city
code and then the four digit number – (123-456-
7890).
Redial – to redial the last number called.
Phonebook – is the unit’s stored memory of 32
numbers, stored by name – each name can have up
to four different locations (home, work, cellular,
pager).
Setup – this allows you to access all of the set-up
functions such as phone pairing, confirmation
prompts or language.
Cancel – this will disconnect a current dialogue
session with the unit when invoked from the main
menu – from any other place in the command
structure it will return to the main menu and the
“ready” prompt.
Emergency – the emergency function allows you
with one simple command to quickly dial 911.
Towing Assistance –
command allows you to quickly connect a Roadside
Assistance Service number of your choice. This
number can be programmed to your Automobile
Club or vehicle manufacturer’s specification.
the towing assistance
9
10
MAIN MENU INTERACTION DIAGRAM
p
The following diagram shows VControl prompts as rectangles and user commands as rectangles with rounded
corners:
“Ready”
“Redial”
“Phone Book”
“Towing Assistance” “Setup” “Cancel” “Call” “Dial”
“Speak the digits you
want to dial”
Chapter 3: Initial Operation
Before proceeding with day-to-day operation, there
are several initial tasks to perform
• Language selection
• Phone Pairing
DESIRED LANGUAGE
Three different languages are available in the kit:
English, Spanish, and French Canadian. The kit
defaults to English.
In order to change to a different language, please
implement the following procedure:
• Press simultaneously and hold, for three (3)
seconds, the
and the
buttons.
“Emergency”
“Please say the
erson”
after the beep”
is not pushed and then
name of a
•
“select English by pressing the button
after the Beep” <beep> (the system waits for 1.5
seconds). – “select French by pressing the
after the beep” (spoken in French) <beep>
system waits another 1.5 seconds – “select
Spanish by pressing the
(spoken in Spanish) system waits another 1.5
seconds if the
returns to main menu.
•
If you do not press a button, the system will
return to the idle state after speaking the three
prompts above. The language will remain
unchanged.
•
The language can also be set using the SETUP
mode – please refer to that section of this guide.
11
12
PHONE PAIRING – the first step in using the kit is
to register your Bluetooth™ enabled phone with the
VControl. This process usually called “pairing” or
“registration” allows your phone to communicate
with the hands-free system and ensures that other
phones cannot inadvertently do so.
Please follow the steps below to complete this
process:
• Turn on your cellular telephone and ensure
that it is Bluetooth-enabled and supports
Hands-free profile.
• Turn on your vehicle ignition and after a few
seconds, the Power LED on the control pad
should light briefly and then go out
[signifies the system is active and ready to
use]. This will take a few seconds.
• You now need to enter the set-up mode to
register your phone; however, it is
recommended that you follow the directions
for your particular phone and turn the
Bluetooth Power “On”.
“Ready” <Beep>
Set-up Î “Phone Pairing, Confirmation
Prompts, Changing Languages”
Phone Pairing Î “Please select one of the
following: Pair or Delete the current phone”
<Beep>
Pair a Phone Î “Please pair phone as
mentioned in phone manual” <Beep>
[Pair phone: Kit will remain silent for up to 2
minutes]
• The kit will wait for approximately 2
minutes to have a Bluetooth™ enabled
phone paired with it. During this time the
LED will be flashing.
•
Once the phone has found the kit, it will
display a prompt on the phone. It should
display a message (on the phone) that is has
located “Peiker HF”. The kit will remain
silent. Continue to follow the phone’s
pairing procedure until it asks you to enter a
password. Enter “0000” on the phone’s
keypad and select the yes/dial key on the
phone. The phone will then complete the
pairing process and should hear a prompt
from the kit saying “pairing completed”
•
You have now completed the registration
process and the kit is ready to be used. The
LED on the Control Pad will remain on
(green).
•
You only need to “Pair” your phone the first
time you wish to use the kit. With all
subsequent uses, the phone will
automatically connect to the kit.
•
You can pair up to 5 (five) phones with the
Bluetooth™ kit. Only one phone will be
active (i.e. able to use the hands-free
system) for calls at any one time.. The last
connected phone will always have the
highest priority when the unit tries to
connect with a phone. If the last connected
phone is not available, then the kit will look
13
for other phones stored in its memory (other
phones that have been previously paired), in
order of the original pairing process. If you
pair a sixth phone, then the phone that was
first paired will be removed from the
memory of the kit.
BASIC OPERATIONS
After completing the registration process, your
Bluetooth™ car kit is ready for everyday use. The
kit should operate properly each time you enter your
vehicle, provided the initial requirements as defined
below have occurred.
Initial Requirements
• Ignition Switched On Î Your vehicle
ignition must be switched on and the power
LED on the kit constantly on. It takes
approximately 3 to 5 seconds after turning
on your ignition for the kit to become active.
14
• Bluetooth™ in phone is Active Î The
Bluetooth communication mode (sometimes
referred to as connection) must be activated
(turned “On”) in your cellular phone.
• Phone Distance Î The hands-free kit will
operate with the phone up to approx. 30 feet.
The quality of the audio signal will
deteriorate as the phone is moved further
away from the vehicle. The phone does not
need to be in the open (i.e. it can be in your
pocket, purse or briefcase) to operate but it
should not be blocked by metal (i.e. placed
in the trunk).
• After the system becomes active (ignition is
turned on), you will likely see an indicator
on your phone (either a message is displayed
or an icon is activated) when the kit
connects through the Bluetooth link to your
phone – this process will take approx. 15 to
30 seconds. At this time the unit is fully
operational. Also, the green LED on the
Control Pad will either remain illuminated
or blink when it is actively paired to a
Bluetooth™ phone.
The Control Pad
The Control pad is your primary control interface
with the VControl™, it activates initial operation of
the system and provides access to all of the
available features.
The basic functions of the control pad are defined
below:
1. Switch
2. Volume Up
3. Green LED
4. Call Activation, Answer and Hang-up
5. Mute
6. Volume Down
5
6
4
15
1
•
Speaking Cancel during any voice
interactive session with the unit will
• Pressing the
interface and accesses the majority
of the features
•
Pressing
session jumps immediately to the
end of the prompt
initiates the voice
during an active
exit the current menu and return to
2
3
the main “Ready” prompt
•
Always wait for the <Beep> before
speaking command/digits to the
system
•
If you are unsure how to respond to a
particular voice prompt, do not say
anything and a list of commands will
be provided.
•
If the voice recognition is having
trouble recognizing your speech, try
the following:
i.
Speak slower
ii.
Do not speak overly loudly
iii.
Emphasize/annunciate the
words or digits clearly
16
iv.
Ensure you are speaking
directly towards the
microphone
Volume Control
To initially set the volume levels for the voice
prompts and for your phone conversation, follow
the instructions below. Once you have adjusted
them they will remain as your default settings.
There are two different settings that can be adjusted.
1. Adjusting Ringer/Voice prompts Default
Volume Setting
• Press the
anything so that the “help” prompts
will be heard – you can use this to
adjust the volume.
•
To increase the volume, press the
continuously until the desired
button and do not say
volume is achieved or the maximum
setting.
•
To decrease the volume, press the
desired volume level is reached or
the minimum setting.
2.
Adjust Active Voice Conversation Default
Volume Setting. Initiate and maintain a
phone call as described previously. During
your conversation adjust the volume as
mentioned below:
•
To increase the volume, press the
volume is achieved or the maximum
setting.
• To decrease the volume, press the
desired volume level is reached or
the minimum setting.
button continuously until the
continuously until the desired
button continuously until the
Chapter 4: Making & Receiving
Calls
RECEIVING A CALL
When a call is received on your phone, you will
hear a ring through the unit’s speaker (it may also
ring through the phone, depending on your settings)
and your car stereo system may automatically mute
depending on the car radios functionality and how
your unit was installed.
To answer the call, simply press the
the call with automatically connect in 2-3 seconds.
The volume of the call can be adjusted through the
on your control pad.
ENDING A CALL
key and
17
When your call is complete, simply press the
and the call will be terminated. The system will
produce a “Phone Call Ended” prompt.
[Note: Verizon customers may have to press the call
end button on the phone due to Verizon’s current
data services implementation (December 5, 2004) –
Verizon is aware of this problem and may announce
a solution over the next several weeks]
If you do nothing, and the other party has
disconnected, the system will terminate. The same
“Phone Call Ended” prompt will be heard. Note
that this can take up to 2 minutes, depending on the
cellular carrier.
18
Placing a Call – from the “Ready” Prompt
Dial Function
The DIAL function is used to dial a phone number
by providing the kit with a series of digits. You can
enter the number as either a complete string of 7, 10
or more digits or you can break up the phone
number into segments (referred to as blocks) and
the system will piece them together before dialing
(segment dialing). The following examples
delineate both methods:
Entire Number Dialing
“Ready” <Beep>
Dial Î “Number Please” <Beep>
Speak the digits of the phone number [e.g.
8-0-0-1-2-3-4-5-6-7] Î Number is repeated +
“Complete the Number, Say Clear or Say
Dial” <Beep>
If the Number is Correct say Dial Î
“Dialing” and the Call is connected
If the Number is Incorrect say Clear Î All
digits are cleared then <Beep> then Repeat
the digits of the number (there is no furth
prompt) – this cycle will continue until you get
a correct number or say Cancel to return to the
main menu.
er
19
Block Number Dialing
“Ready” <Beep>
Dial Î “Number Please” <Beep>
Speak the digits of the phone number from 1
to 10 digits at a time [e.g. 800] Î Number is
repeated + “Complete the Number, Say Clear or
Say Dial” <Beep>
Speak the next sequence of digits [e.g. 123] Î
Number is repeated + “Complete the Number,
Say Clear or Say Dial” <Beep>
Speak the next sequence of digits [e.g. 4567]
Î Number is repeated + “Complete the Number,
Say Clear or Say Dial” <Beep>
If the Number is Correct say Dial Î “Dialing”
and the Call is connected
*** Special Note – You must speak one digit at a
time and not numbers ten or greater [e.g. eight
hundred, forty-five forty-five]
20
Call Function
The CALL command is used to dial pre-stored
phone numbers from your PhoneBook. The system
is capable of saving up to 32 names, each with four
different phone numbers. Please refer to the
PhoneBook section to learn how to program
numbers and locations.
Please note that the numbers are stored in the car
kit and not in the cellular phone. The numbers
stored in your phone are not directly accessible
but can be retrieved using the
the chapter on Special Functions to learn more
about this capability.
button. See
“Ready” <Beep>
**
stored, then the system will not ask for a location
but jump to confirming that the name and location
are correct. If you respond No to this prompt, it
Call Î “Name Please” <Beep>
Speak the Name of the Person [must have
been previously stored in the PhoneBook] ***
Î Name is repeated + “Please say a location” +
Lists Stored Locations ** <Beep>
Speak Desired Location Î Name + Location +
“Is this Correct?” <Beep>
Yes [If it is correct] Î “Dialing” and the Call is
connected
No [if any of the information is incorrect] Î
“Would you like to try again?” <Beep> [If No
the system returns to the Main Menu]
Yes Î “Please Say a Location” + Lists Stored
Locations <Beep>
Speak Desired Location Î Name + Location +
“Is this Correct?” <Beep>
If the requested name has only one location
will immediately return to the main menu since
there are no other locations.
*** If you select a name not in the PhoneBook, the
system will prompt you [up to three times] with
“Name Please” <Beep> If after three attempts, a
match is still not found, then the prompt, “Name not
found in the PhoneBook. Would you like to try
again?” <Beep> If you answer Yes then the
process will start over again. If you answer No,
then the system will return to the main menu.
The Redial Function
The Redial command is used to place a call to the
same number that was previously called.
Please note that the number called will be the
last one dialed from your cellular phone,
necessarily the last one called using the kit. If
you used your phone without the kit, it will use
that number as the last number dialed.
not
21
“Ready” <Beep>
Redial Î “Dialing”
The Call is connected
Call Waiting
The unit will <Beep> when a call is active and an
incoming call is detected. The unit supports several
options with regards to Call Waiting.
Active Call <Beep>
Press
Press
switch back to the original call. Press
one second to switch back to the original call
without disconnecting the new call.
To connect both calls in a conference call, see
Chapter 7 – Special Functions – Conferencing.
to switch to the incoming call.
for two seconds to end call and
for
22
Emergency
The Emergency command quickly allows you to
dial quickly with one touch 911. This should only
be used in actual emergencies.
“Ready” <Beep>
Emergency Î “Are you sure you want to call
911” <Beep>
No Î returns to the main menu
Yes Î Call is connected
Towing Assistance
The Towing Assistance command allows you to
quickly connect a Roadside Assistance Service
number of your choice.
“Ready” <Beep>
Towing Assistance Î “Do you want to connect
with your Towing Service” <Beep>
No Î returns to the main menu
Yes Î Call is connected
Chapter 5: PhoneBook
The “PhoneBook” command is used to setup and
modify all features relating to your phonebook.
Specifically it allows you to store new names with
up to four locations [numbers] per name. You can
also edit or delete existing entries.
When you first enter the PhoneBook menu, the
following prompt will play: “Select one of the
following: New Entry, Edit, List Names, Delete or
Erase All” <Beep>. If you do not say anything,
then “Available options are: New Entry, Edit, List
Names, Delete, Erase All or Cancel” <Beep> - this
will be repeated three times. After the three
attempts, the system will time out and return to the
idle mode.
New Entry
This function is used to store names with associated
numbers (by location) in the Bluetooth phonebook.
23
• The names are stored in the kit and not in
the phone. If you want these names stored
in your phone, you will have to re-enter
them following the procedures outlined in
the phone’s user manual.
• If you do not provide any response to the
various requests throughout the New Entry
command sequence, you will typically be
provided with a help list of commands
available then the system will automatically
return you to the main menu “Ready”
prompt.
24
Example
“Ready” <Beep>
PhoneBook Î “Select one of the following:
New Entry, Edit, List Names, Delete, or Erase
All” <Beep>
New Entry Î “Phonebook: New Entry. Name
Please” <Beep>
Speak Desired Name Î “Repeat Name
Please” <Beep>
Repeat Name Please Î “Please say a
location” <Beep>
Say a Location [home, work, cellular, pager]
Î “Adding (+ Name + Location) is this
correct?” <Beep>
Yes [No will return to the Speak Desired
Name Prompt] Î “New number please”
<Beep>
Speak the digits of the phone number [e.g.
8-0-0-1-2-3-4-5-6-7] [Digits can be entered
as described in the “Dial” dialogue]
Edit
This function is used to modify or add numbers to a
name previously stored in the phonebook. An
existing number can be changed or a new location
and number can be added to an existing name.
• If you do not provide any response to the
various requests throughout the Edit
command sequence, you will typically be
provided with a help list of commands
available (repeated three times) and then the
system will automatically time out and
return to idle mode.
• The only valid locations are: Home, Work,
Cellular, and Pager.
• If the name does not exist in the phonebook,
then you will be asked for another name
[“Name please” <Beep>] up to three
additional times. If a match is still not
found, you will be prompted to enter another
name [“Name not found in Phonebook.
Would you like to edit another name?”
<Beep>]
“Ready” <Beep>
Phonebook Î “Select one of the following:
New Entry, Edit, List Names, Delete or Erase
All” <Beep>
Edit Î “Phonebook:Edit. Name Please”
<Beep>.
Speak Desired Name -> Repeats name + “Is
this correct?”
Yes Î “Please say a location” <Beep>
Say a Location [home, work, cellular, pager]
Î “Editing” + Name + Location + “Is this
Correct?” <Beep>
Yes Î “The current number is” + Stored
Number + “New Number Please” <Beep>
Speak the digits of the phone number [e.g.
8001234567] Î Number is repeated +
“Complete the Number, Say Clear or Say Dial”
<Beep>
25
Save Entry Î “The number for” + Name +
Location + “has been changed. Would you like
to edit another location?”
Yes Î Returns to Enter another Location
No Î Returns to the Main Menu
List Names
This function allows you to list all the names
currently stored in the Phonebook. You can list just
the names, names with locations, names with
locations and with numbers.
• If you do not provide any response to the
various requests throughout the List Names
command sequence, typically the system
prompt “Yes, or No or Cancel” <Beep> will
be repeated three times. If still no input has
26
been received, the system will time-out and
return to the idle mode.
“Ready” <Beep>
Phonebook Î “Select one of the following:
New Entry, Edit, List Names, Delete or Erase
All” <Beep>
List Names Î “Would you like to List Names
with Locations? Yes or No” <Beep>
No Î [All Stored names are played back]
Yes Î “Would you like to List Locations with
Number? Yes or No” <Beep>
No Î [All Stored Names with Locations are
played back]
Yes Î [All Stored Names with Locations and
Numbers are played back.]
After Names and/or Locations and/or Numbers
are played back Î “Would you like to play the
list again from the beginning?” <Beep>
Yes Î Replays the appropriate list
No Î Returns to “Ready” <Beep>
Delete Existing Names
This feature is used to delete existing names or
specific locations/numbers of existing names.
• If you do not provide any response to the
various requests throughout the Delete
command sequence, you will typically be
provided with a help list of commands
available (repeated three times) and then the
system will prompt you to enter another
name (“Name not found in Phonebook.
Would you like to delete another name?”)
“Ready” <Beep>
Phonebook Î “Select one of the following:
New Entry, Edit, List Names, Delete or Erase
All” <Beep>
Delete Î “Phonebook: Delete. Name Please”
<Beep>
Speak Desired Name Î Repeats Name + “Is
this correct?” <Beep>
No Î “Say new name”
Yes Î “Please say a location for deleting.” +
Current Filled Locations + “Erase All” <Beep>
Say a Location [home, work, cellular, pager]
Î Location + “Is this correct?” <Beep>
No Î “Say new location”
Yes Î “Deleted” <Beep>
Number is deleted. Return to ready prompt.
27
rase All
E
his command is used to erase the entire
T
phonebook. PLEASE NOTE that your E
PHONEBOOK will be ERASED and cannot be
recovered.
• If you do not provide any response to the
various requests throughout the Erase All
command sequence, typically the system
prompt “Yes, or No or Cancel” <Beep> w
be repeated three times. If still no input has
been received, the system will time-out and
return to the idle mode.
NTIRE
ill
28
“Ready” <Beep>
Phonebook Î “Select one of the following:
New Entry, Edit, List Names, Delete or Erase
All” <Beep>
Erase All Î “Are you sure you want to erase
your whole phonebook? <Beep>
No Î [Return to the beginning of Phonebook]
Yes Î “You are about to erase your whole
phonebook. Is this correct?” <Beep>
No Î [Return to the beginning of Phonebook]
Yes Î “Phonebook Erased Return to Main”
Menu” Return to Ready Prompt
Chapter 6: Setup
Delete the Current Phone Pairing
This function is used to remove the current phone
from connecting to the Bluetooth™ kit. The pairing
can only be deleted when there is an existing phone
actually connected and communicating with the kit
when this function is invoked.
• The pairing is only deleted in the kit and
NOT in the phone. Therefore, it is possible
that the phone will try to reconnect unless
the entire pairing process is completed
again.
29
“Ready” <Beep>
Set-up Î “Phone Pairing, Confirmation Prompts,
Changing Languages”
Phone Pairing Î “Please select one of the
following: Pair or Delete the current phone”
<Beep>
Delete Î “Are you sure you want to delete the
current phone? <Beep>
No Î Return to Pair or Delete Phone
Yes Î “Phone deleted return to Main Menu”
<Beep> Returns to Ready Prompt
Confirmation Prompts
This function is used to turn the confirmation
prompts On or Off. Once you become familiar with
the kit and the various system prompts that are
played, it becomes unnecessary to always listen to
30
the prompts. This feature allows some of the basic
prompts to be turned off so that you can quickly
proceed to the next input without having to wait for
the entire prompt.
“Ready” <Beep>
Set-up Î “Phone Pairing, Confirmation
Prompts, Changing Languages”
Confirmation Prompts Î “Confirmation
Prompts are On. Would you like to turn them
Off? <Beep>
No Î “Confirmation prompts are On” “Return
to the Main Menu” [Returns to Ready Prompt]
Yes Î “Confirmation prompts are Off”
“Return to the Main Menu” [Returns to Ready
Prompt]
Changing Languages
As mentioned in Chapter 3, the VControl™
includes the option to operate in any one of three
different languages: English, Spanish and French
Canadian. The default language is English but it
can be easily changed by using the Set-up menu.
“Ready” <Beep>
Set-up Î “Phone Pairing, Confirmation
Prompts, Changing Languages”
Changing Languages Î “Select English by
pressing the Phone button after the beep.”
<Beep> (the system waits for 1.5 seconds). –
“select French by pressing the
beep” (spoken in French) <beep> system waits
another 1.5 seconds – “select Spanish by
pressing the
Spanish) system waits another 1.5 seconds in the
menu.
After you select the language, a prompt [spoken
in the selected language] will confirm the
selection Î “Language has been changed to” +
chosen language
is not pushed and then returns to main
after the beep” (spoken in
after the
31
Towing Assistance
This function is for pre-programming your
Roadside Service number of choice.
“Ready” <Beep>
Set-up Î “Phone Pairing, Confirmation
Prompts, Changing Languages”
Towing Assistance Î The unit will then ask
you for the number, as you would when entering
a phone book entry.
Say Number [e.g. 800-123-4567] Î The unit
will then ask you if you’d like to “clear” or
“Save Entry” [Number Saved for future use] Î
Return to Main Menu
32
Chapter 7: Special Functions
Your hands free kit supports a number of advanced
features including the following:
• Initiating a second call and toggling between
the calls
• Privacy – transferring calls to your cell
phone
• Conference two calls together
• Accessing voice mail and other phone
functions by sending DTMF codes
• Activating the voice dialing functions of
your cell phone
In order for these features to work on the kit, they
must also be supported by your specific phone and
in some cases by your wireless carrier.
Privacy calls – Transferring Call
During a hands-free call, the audio can be
transferred from the kit back to the cellular
telephone in order to continue the call privately.
Active Call Ongoing
<Beep> Transfer Call Î “Audio
Transferred” [Audio is transferred to the
cellular phone]
Initiating a Second Call
During an active call you can place a second
outgoing call while placing your first call on hold:
Active Call Ongoing
“Ready” <Beep> New Call Î “New Call,
Dial or Call” <Beep>
Say Dial or Call and follow the instructions for
those functions as defined earlier in the manual.
The first call will be placed on hold and the second
call will be connected as described earlier.
Toggling Between Two Calls
If there are two calls in progress (one on hold and
the other in active conversation), you can switch
between the two easily.
Press
other call is picked up.
Active Call is placed on hold and the
33
nd Active Call and Pick-up Second Call
E
ress and Hold
P
active call will h up and the second call will be
taken off hold and become active.
(more than 2 seconds). The
ang
onference Two Calls Together
C
there are two call active (one on hold the other in
If
active conversation), they can be connected together
for a three-way conference call.
he simplest way is to Press and HOLD the
T
button for more than two seconds. The two c
will be joined together.
conference call can also be activated the voice
A
interface.
alls
34
Two Calls Ongoing
<Beep> Conference Î Calls are
connected together for a three-way call
Accessing Voice Mail or Other Phone
Functions by sending DTMF tones/digits
During an active call, many times it is necessary to
send DTMF digits through the call so that voice
mail can be accessed or a number can be left on a
pager, text messaging system It works, when you
press the buttons on the keypad, a connection is
made that generates two tones at the same time. A
"Row" tone and a "Column" tone. These two tones
identify the key you pressed to any equipment you
are controlling. If the keypad is on your phone, the
telephone company's "Central Office" equipment
knows what numbers you are dialing by these tones,
and will switch your call accordingly. If you are
using a DTMF keypad to remotely control
equipment, the tones can identify what unit you
want to control, as well as which unique function
you want it to perform. This can now be activated
by voice control through your VControl™ system.
.
Active Call On-going
Voice Mail prompt Î
“Number Please” <Beep> enter appropriate
numbers [e.g. 1234]
Voice Mail – enter password Î
Dial Î enter appropriate number sequence [e.g.
1234] Continue this for as many prompts as
necessary
For * pronounce Star for # pronounce Pound
<Beep> Dial Î
<Beep>
Special Note Î with prompts on it sometimes
becomes possible to invoke DTMF codes before
your voicemail or PBX sequences to the next
response, etc.; therefore if you use this feature
frequently it is suggested that you go to Set-up and
turn off Confirmation Prompts.
Activating the Voice Dialing Function of Your
Cell Phone
Many phones or wireless carriers provide voice
activation features which are invoked from your
phone rather than the hands-free kit. To access your
phone functions use the
.
This example is taken from the Motorola V710
Press and hold the
seconds] until the phone prompts Î ‘Say a
Command” [Name Dial, Digit Dial, Camera,
Voicemail, Redial, Received Calls]
It should be noted that once a command is issued
such as Voicemail and the phone connects to
your voicemail you can still depress the
Button and utilize the DTMF functions;
however, with some phones you will have to
pick-up the phone and press the keys as
designated by the voice prompts.
Please refer to you phone manual for specific
functions pertaining to your phone or wireless
carrier.
button [approx. 2
.
35
36
Loading...
