VBrick EtherneTV-STB Quick Start Manual

EtherneTV-STB
Set Top Box

Set Top Box v3.7.3b
Quick Start Guide

September 14, 2006

4410-0134-0005

Copyright

© 2006 VBrick Systems, Inc. All rights reserved.
12 Beaumont Road
Wallingford, Connecticut 06492, USA
www.VBrick.com

This publication contains confidential, proprietary, and trade secret information. No part of this document may be
copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic format without
prior written permission from VBrick. Information in this document is subject to change without notice and
VBrick Systems assumes no responsibility or liability for any errors or inaccuracies.VBrick, VBrick Systems, the
VBrick logo, StreamPlayer, and StreamPlayer Plus are trademarks or registered trademarks in the United States and
other countries. Windows Media is a trademarked name of Microsoft Corporation in the United States and other
countries. All other products or services mentioned in this document are identified by the trademarks, service
marks, or product names as designated by the companies who market those products. Inquiries should be made
directly to those companies. This document may also have links to third-party web pages that are beyond the
control of VBrick. Use these links at your own risk. The use of such links does not imply that VBrick endorses or
recommends the content of any third-party web pages. Some VBrick products use open source software provided
by third parties. VBrick supports the Open Source Initiative (OSI) and this source code is freely available at http:/
/www.vbrick.com/opensource.

About VBrick Systems

Founded in 1997, VBrick Systems, an ISO 9001 certified vendor, is a privately held company that has enjoyed rapid
growth by helping our customers successfully introduce mission critical video applications across their enterprise
networks. Since our founding, VBrick has been setting the standard for quality, performance and innovation in the
delivery of live and stored video over IP networks—LANs, WANs and the Internet. With thousands of video
appliances installed world-wide, VBrick is the recognized leader in reliable, high-performance, easy-to-use
networked video solutions.

VBrick is an active participant in the development of industry standards and continues to play an influential role in
the Internet Streaming Media Alliance (ISMA), the MPEG Industry Forum, and Internet2. In 1998 VBrick
invented and shipped the world's first MPEG Video Network Appliance designed to provide affordable DVD­quality video across the network. Since then, VBrick's video solutions have grown to include Video on Demand,
Management, Security and Access Control, Scheduling, and Rich Media Integration. VBrick solutions are
successfully supporting a broad variety of applications including distance learning and training, conferencing and
remote office communications, security, process monitoring, traffic monitoring, business and news feeds to the
desktop, webcasting, corporate communications, collaboration, command and control, and telemedicine. VBrick
serves customers in education, government, healthcare, and financial services markets among others.

STB v3.7.3b Quick Start Guide

This guide explains how to get your EtherneTV Set Top Box up and running in a few easy
steps as shown below. For more detailed installation and configuration instructions, see the

Set Top Box Admin Guide.

Step 1. Choose a Start Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Step 2. Connect the Set Top Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Step 3. Set the IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Step 4. Configure the Start Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Step 1. Choose a Start Mode

The first step is to choose a Start mode from among the following options. This determines
how the Set Top Box will behave when started. A network administrator will generally
determine the
configure the Start mode.

MCS Mode When installed with an ETV Portal Server (formerly MCS), the

Start mode based on your network configuration. In Step 4, you will actually

features and options of the VBrick EtherneTV Set Top Box are
controlled through the Portal Server. See the ETV Portal Server
Admin Guide for more information.

Local Mode The VBrick EtherneTV Set Top Box contains software that enables it

to work as a standalone device. When used in standalone applications,
the set top box features and options are similar to MCS Mode but are
controlled locally—not by the ETV Portal Server.

Local-Fullscreen
Mode

The VBrick EtherneTV Set Top Box also can operate in a fullscreen
mode. This allows the user to tune in one channel and display the
received stream on the entire screen of the attached monitor.

Step 2. Connect the Set Top Box

The VBrick EtherneTV Set Top Box is shipped with Audio/Video, S-Video, and power
cables and a handheld IR remote control unit. An optional wireless keyboard is also available.

T To connect the Set Top Box:

1. Using the provided cables, attach the set top box video out to a monitor using the left
(yellow) connector or the S-Video connector.

2. Using the provided cables, connect the set top box audio out (left and right) to a monitor
(left and right) monitor.

3. Using customer provided cables, connect the set top box to the network, using the left
(LAN1) Ethernet port as viewed from the back of the unit.

4. The set top box comes configured to assign an IP address using DHCP. To find the IP
address it is necessary to attach a keyboard using the PS/2 port connection or use the
VBrick software application VBDirectory.

5. Connect the power cord, and if desired, connect a VGA monitor.

STB Quick Start Guide 1

Table 1. Front Panel – Left to Right

Infrared Sensor Above LEDs. Used for IR remote control and wireless keyboard.

Waiting Blinks red during initial start-up.

Transfer Blinks white when accessing flash memory.

Power Steady green when power is applied.

On/Off On/Off push button.

Table 2. Rear Panel – Left to Right

Power Plug Connects to power cord.

VGA Port Used to view video on a VGA monitor.

Serial Port Used for Serial Port Passthrough or to open a Command Prompt.

PCI Card Slot Not Used.

S-Video Connect to standard TV.

Video Composite video out.

Audio Left/Right Audio out left and right.

USB Ports (2) Connect USB mouse and/or keyboard.

SPDIF Digital audio. Not supported.

LAN1 Connect to local area network.

LAN2 Not used.

PS/2 Connect PS/2 keyboard or mouse.

Step 3. Set the IP Address

You need to know the IP address in order to run the web-based STB Admin Configuration
application. By default, the set top box is configured for DHCP (Dynamic Host
Configuration Protocol) and will automatically retrieve an IP address from a DHCP server if

2EtherneTV Media Distribution System
