Let’s talk safety

Basic safety precautions

This vacuum cleaner is intended for household use only and NOT for commercial or industrial use.

READ ALL THE INSTRUCTIONS BEFORE USING THIS APPLIANCE

• Only use the vacuum cleaner indoors and keep the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing from moving parts and openings whilst using the vacuum cleaner.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should not play with the vacuum cleaner. Cleaning and user maintenance should not be made by children.

• Only Vax recommended tools and accessories should be used with this vacuum cleaner

• Do not use charger with damaged cord or plug. If appliance or charger is not working as it should, has been dropped, damaged, left outdoors or dropped into water, take it to a Vax authorised repair agent prior to continuing use. Please contact our Customer Care Line on: AU: 1300 361 505 / NZ: 0800 800 900 (Mon-Fri 8.30am to 5.00pm) or visit www.vax.com.au / vax.co.nz for your nearest Vax authorised repair agent.

Please keep instructions for further use.

Battery Safety Precautions:

• Do not place vacuum or batteries near re or heat. This will reduce the risk of explosion and possible injury.

• Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has been dropped or received a sharp blow. A damaged battery is subject to explosion. Properly dispose of a dropped or damaged battery immediately.

• Batteries can explode in the presence of a source of ignition, such as a pilot light. To reduce the risk of serious personal injury, never use any cordless product in the presence of open ame. An exploded battery can propel debris and chemicals. If exposed, ush with water immediately.

• Do not charge vacuum in a damp or wet location. Following this rule will reduce the risk of electric shock.

• For best results, charge the battery tool in a location where the temperature is more than 10°C but less than 37°C. To reduce the risk of serious personal injury, do not store outside or in vehicles.

• Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes in contact with the skin, wash immediately with soap and water, then neutralize with lemon juice or vinegar. If liquid gets into the eyes, ush them with clean water for at least 10 minutes, then seek immediate medical attention. Following this rule will reduce the risk of serious personal injury.

• Store the battery pack where the temperature is below 27°C.

• The battery must be removed from the appliance before it is scrapped.

• The appliance must be disconnected from the supply mains when ever removing the battery.

• The battery is to be disposed of safely.

WARNING: For the purpose of recharging the battery, only use detachable supply unit type YLJXA-A300050 provided with this appliance.

Charger Safety Precautions:

• The charger must not be damp, and should never be used in a damp environment.

• Do not use the charger if it has suered any heavy shock or jolting, or is damaged in any other way.

• Do not conduct charging in a position which may become exposed to sunlight or other heat source. Recommended temperature range at charging vicinity is 10° to 25° C.

• Do not conduct charging operations in the vicinity of ammable materials. Example: Cloth, packaging materials, paint, spray paint or aerosols, lubricant, thinners, petrol containers, gas containers or gas appliances.

• Do not cover any ventilating slots and provide adequate ventilation during operation.

• Never modify, disassemble or attempt to repair the product yourself.

• Do not allow the charger or batteries to become contaminated with any material which could be conductive.

• Remove the plug of the product from the power socket when it is not in use or when cleaning it.

• Protect battery contacts to avoid a short circuit caused by metallic objects which could cause a re or explosion!

• Do not charge batteries which show signs they have leaked electrolyte. Dispose of them properly.

• Never charge a damaged battery.

Don’ts

Do’s

Let’s talk safety

• Do not pull or carry by charger cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not place product on cord. Do not run appliance on cord.

• Don’t handle the charger plug or use the vacuum cleaner with wet hands.

• Don’t use this vacuum cleaner if it has been dropped, damaged, immersed in water or left outdoors.

• Don’t leave the vacuum cleaner in one spot for an extended period of time when the brushbar is activated. This vacuum cleaner is tted with a rotating brushbar which if left in one place may cause damage to the oor surface.

• Don’t attempt to remove blockages with sharp objects as this may cause damage to the vacuum cleaner.

• Always make sure the lter and dirt container are tted correctly before using your vacuum cleaner.

• Always turn o and unplug from charger and remove the battery before carrying out any maintenance.

• Turn o all controls on the vacuum cleaner before disconnecting or connecting the battery.

• Take extra care when cleaning on the stairs.

• Always protect the charger cord from heated surfaces or near open ames.

• Keep all openings clear and free from debris as this may aect the airow/suction.

• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as per user guide instructions ensure they are thoroughly dry before storing away.

• Always use the charger supplied with the vacuum cleaner.

• Use only SAA approved 10amp extension cords. Care should be taken to arrange the extension cord as it can be a trip hazard.

• Always carry the vacuum cleaner by the handle.

• Don’t try to short the terminals of the battery and the charger.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in damage or injury to the user. The correct voltage is listed on the rating label.

• Don’t vacuum up hot coals, cigarette butts, ash, matches or smoking hot burning items or use in an area where there may be harmful uids (chlorine, bleach, and ammonia drain cleaner).

• Do not vacuum hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t not vacuum plaster dust, concrete dust or any other building or vitreous material.

• Do not vacuum our, baking soda or any other powder-based carpet refresher or deodoriser.

CAUTION: The battery used in this device may present a risk of re or chemical burn if mistreated. Do not disassemble, heat or incinerate. Do not disassemble and do not dispose of in re. Do not attempt to disassemble the battery or remove

any component projecting from the battery terminals. The battery and charger have no user serviceable parts. Fire or injury may result. Prior to disposal, protect exposed terminals with heavy insulating tape to prevent shorting.

WARNING: For best performance terminals on battery, battery charger and vacuum cleaner must be clean and free from dust and dirt.

Thank you for buying this Cordless Verso.

Taking care of your carpets and hard  oors

The Cordless Verso series is designed to make vacuuming carpets and hard  oors regularly, as e ective and eﬃ cient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard  oors will ensure they keep their appearance for longer and Vax will help you take good care of them.

Taking care of your Cordless Verso

Also inside this guide are instructions on maintaining your new machine, so that it’s ready when you are to tackle your carpets and hard  oors.

We’re here if you need us

For troubleshooting simply visit or call:

Australia: 1300 361 505* New Zealand: 0800 800 900* vax.com.au vax.co.nz

*Monday – Friday: 8:30am -5:00pm Calls are charged at the standard local rate. Please make note of the serial

number and model number of the product before calling.

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Cordless Verso

Included with your machine

Charger

2-in-1 Crevice Tool/

Dusting Brush

Accessories

What to do if it goes wrong

Getting in touch

Getting to know your machine

On/O button

Suction control button

2-in-1 crevice tool/dusting

brush and holder

Machine charging port

Handheld release button (hidden)

Handheld On/O switch (hidden)

Dirt container release button (hidden)

Brushbar

Technical Speciﬁ cation Charger Speciﬁ cation

Name Verso 25.2V

Model number VX62

Battery voltage 25.2V

Run time Up to 80 mins

Charge time 5 hours

Weight 3.4kg

Dust bin capacity 0.8l

Model number YLJXA-A300050

Input voltage 100-240V ~ 50/60Hz 0.5A

Output voltage 30.0V

Battery Speciﬁ cation

Rating 2.0 Ah

50.4Wh / 25.2V

LED charging indicator light

Dirt container

Floorhead

LED headlights

Accessories & Consumables

Pre-motor  lter Model No. VX62F

500mA

To purchase consumables and accessories, please visit vax.com.au

Subject to technical change without notice. *Turn oﬀ brushbar on hard ﬂ oors. Images are illustrative only.

Getting started

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Before you begin

CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the handheld/attachments or

removing and emptying the dirt container.

IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will automatically turn the vacuum cleaner o . If this happens, switch the vacuum cleaner o . Remove and empty the dirt container. Also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool for approximately 1 hour (if you have washed the  lter please wait 24 hours for the  lter to fully dry before putting back into the machine). For best cleaning results,  lters require cleaning every 4-6 uses or as needed depending upon use. If the vacuum cleaner is blocked, switch o before removing the blockage.

Assembling your 2-in-1 vacuum cleaner

Line up the handle with the main body and lower into place.

Insert the screw into the back of the handle. Using a cross head screw driver tighten until the handle is secured into place.

Line up the handheld nozzle with the back of the main body. Push the handheld onto the main body until it clicks into place.

Store the 2-in-1 Tool on board the vacuum cleaner by pushing the tool  rmly into the tool holder located on the back of the handle.

Charging your 2-in-1 vacuum cleaner

NOTE: Initial charge is 5 hours, charging will be required before  rst use. Failure to fully charge the battery before

 rst use may result in poor battery performance. Charge time is 5 hours thereafter. The vacuum can be charged with the handheld either attached to or detached from the main body.

Plug the charger into the charging port, located on the top of the handle of the handheld and plug into the mains.

Once fully charged (5 hours) the LED indicator on the handheld will illuminate green.

When the vacuum needs recharging the LED light on the handheld will  ash red and the machine will cut out.

Using your machine

As an upright vacuum cleaner

CAUTION: Never leave the vacuum cleaner in one spot for an extended period of time when in use as this may

damage the  oor surface. Vax cannot be held responsible for damage to the  oor surface if this recommendation is not followed.

Unplug the charger from the mains and from the handheld.

Place foot on the  oorhead and pull the handle backwards to recline the machine.

Press the On/O button on the handle to switch the machine on.

To select between high and low suction press the extended runtime button.

The brushbar will not rotate when the vacuum cleaner is locked in the upright position.

As a handheld vacuum cleaner

CAUTION: Always take extra care when cleaning stairs. Always switch the handheld o before connecting or

disconnection the accessories, carrying out any maintenance or troubleshooting checks and before returning the handheld to the main body.

TIP

Press the handheld release button.

Lift to remove the handheld from the main body.

Push the On/O switch forward to switch the handheld on.

Using your machine

Dusting brush

Crevice tool

For a more detailed clean, line up the 2-in-1 Tool with the nozzle on the handheld and push rmly into place.

Before returning the handheld to the main body, pull the On/O switch backwards to switch the handheld o. Pull to remove the 2-in-1 Tool from the handheld nozzle.

Taking care of your machine

Emptying the dirt container

CAUTION: Always switch o the vacuum cleaner before carrying out any maintenance or troubleshooting. Do not use

your vacuum cleaner without the  lters in place.

Press the handheld release button.

Lift to remove the handheld from the main body.

Press the dirt container release button to remove the dirt container.

Pull to separate the dirt container from the handheld.

Don’t over ll the dirt container to avoid blocking the air  ow through the vacuum cleaner and replace

Pull to remove the pre-motor  lter out of the dirt container.

Hold dirt container over a bin allowing dirt/debris to fall out.

 lters every 6-9 months.

Cleaning the ﬁ lter

CAUTION: For best cleaning results  lters require cleaning every 4-6 uses or as needed depending upon use.

Do not use your vacuum cleaner without the  lter in place.

TIP

Press the handheld release button.

Lift to remove the handheld from the main body.

Press the dirt container release button to remove the dirt container.

Pull to separate the dirt container from the handheld.

Taking care of your machine

Pull to remove the pre-motor  lter out of the dirt container.

Wash foam  lter under running water (max 40’C).

Cleaning the terminals

Tap the  lter over a bin to remove any dust and debris. Do not wash the

ﬁ lter frame.

24hr

Leave for at least 24 hours or until fully dry before replacing into the machine.

Pull the foam  lter to separate and remove from of  lter frame.

CAUTION: For best performance all terminals must be free from dust and dirt.

Using a dry cloth or soft dusting brush, remove any dust or debris from terminals on main body and handheld.

Let’s talk technical

Cleaning blockages

CAUTION: Use a blunt instrument such as a broom handle or something similar when removing a blockage from

the main body or  oorhead.

Press the handheld release button.

Lift the main body o the  oor with the  oor head unlocked.

Lift to remove the handheld from the main body.

Use a blunt instrument such as a broom handle to clear any blockage in the hose connecting to the  oorhead.

Place foot on the  oor head and pull the handle backwards to recline the main body.

Replacing and cleaning a blockage from the brushbar

CAUTION: If the brushbar has been obstructed, the Motor Protection Sensor may have been activated. Remove the

handheld from the main body and clear any obstruction from the brushbar. Wait 30 minutes for the vacuum cleaner to reset itself. Return the handheld to the main body and retry.

Using a pair of scissors remove any threads or hair caught around the brushbar.

To release the brushbar pull and lift the release lock located underneath the  oorhead.

Remove the brushbar lifting the side of the brushbar nearest the release lock  rst.

Replace the brushbar. Fit the inverted round end of the brushbar  rst, then line up and push the other side of brushbar into the  oorhead. Re t the release lock.

Accessories

Don’t forget your accessories!

AU: www.vax.com.au / NZ: www.vax.co.nz

Reach mode tools

Pre-Motor Filter VX62F

What to do if it goes wrong

Why does my vacuum cleaner have no power?

Why isn’t my vacuum cleaner charging?

SolutionProblem

• Check the vacuum cleaner is fully charged. Go to ‘Using your machine’.

• Check the charger is plugged into the mains and correctly connected to the vacuum cleaner. Go to ‘Getting started’.

• Check the handheld has been correctly tted into the main body.

• Check terminals on the main body and handheld are clean. Go to ‘Let’s talk technical’.

• If the brushbar has been obstructed, the Motor Protection Sensor may have been activated. Remove the handheld and clear any obstruction from the brushbar. Wait 30 minutes for the vacuum cleaner to reset itself. Replace the handheld and retry.

• Check the charger is plugged into the mains and correctly connected to the vacuum cleaner. Go to ‘Getting started’.

• Check the charger cable for damage. If damaged please contact our Customer Care Line on: AU 1300 361 505 / NZ 0800 800 900

Why won’t the vacuum cleaner pick up?

Why won’t the brushbar turn?

• Empty the dirt container and clean lters. Go to ‘Taking care of your machine’.

• There may be a blockage in the vacuum cleaner. Go to ‘Let’s talk technical’.

• The brushbar may not be turning. Go to ‘Why won’t the brushbar turn?’ below.

• The vacuum cleaner may need recharging. Go to ‘Getting Started’.

• Low suction has been selected, increase to high suction. Go to ‘Using your machine’.

• The brushbar may be blocked. Go to ‘Let’s talk technical’.

• If the brush bar has been obstructed, the Motor Protection Sensor may have been activated. Remove the handheld and clear any obstruction from the brush bar. Wait 30 minutes for the vacuum cleaner to reset itself. Replace the handheld and retry.

• The brushbar may be obstructed. Go to ‘Let’s talk technical’.

Why is the LED light Continually ashing?

• The red light will ash when the vacuum needs recharging. Go to ‘Getting started’.
