Performance
Floors & All
Pets & Family
User Guide
vax.com.au
vax.co.nz VX6
Contents
Contents
Machine Overview
General Safety Information
Getting Started
How To Use
Looking After Your Machine
FAQ s
1
2
3
5
6
8
13
Other Information
1
14
Machine Overview
Handle
1
Extension tube
2
Main body release button
3
Dirt container release button
4
Three way on/o switch
5
Separator
6
Dirt container
7
Post motor lter
8
Hose to machine connector
9
Hose to handle connector
10
Hose
11
Extension tube release button
12
Quick release cord hook
13
Power Cord
14
TurboTool
15
Pre-motor lter
16
2 in 1 tool
17
Post-motor lter
18
1
2
3
4
5
6
7
10
11
vax.com.au
vax.co.nz
17
17
15
18
16
12
8
9
13
14
2
General Safety Information
This vacuum cleaner is intended for household use only and NOT for commercial or industrial use.
When using the vacuum cleaner basic safety precautions should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces.
2. Turn o the on/o switch on the vacuum cleaner controls before disconnecting or connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do not play with the appliance.
5. This appliance is not intended for use by children and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance in a safe way and understands the hazards involved.
6. Cleaning and maintenance shall not be made by children.
7. The appliance should only be used as described in this user guide.
8. Only Vax recommended attachments should be used with this appliance.
9. Do not use this vacuum cleaner if it has been dropped, damaged, left outdoors or dropped into water. Do not use
this vacuum cleaner with a damaged cord or plug.
10. Do not pull or carry this appliance by the cord. Do not use the cord as a handle, close a door on the cord or
pull the cord around sharp edges or corners. Do not run the vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
11. Do not handle the plug or the vacuum cleaner with wet hands.
12. Keep hair, loose clothing, ngers and all parts of the body away from openings and moving parts.
13. Do not pick up any hot coals, ash, cigarette butts, matches or any hot, smoking or burning objects.
14. Do not pick up any ammable or combustible materials (lighter uid, petrol, kerosene etc.) or use in the presence of
explosive liquids or vapours.
15. Do not vacuum harmful or toxic material (chlorine, bleach, ammonia, drain cleaner etc.).
16. Do not vacuum hard or sharp objects such as glass, nails, screws, coins etc.
17. Do not vacuum plaster dust, concrete dust or any other building or vitreous materials.
18. Do not vacuum our, baking soda or any other powder-based carpet refresher or deodoriser.
19. Store the vacuum cleaner in a cool, dry area.
20. Use only SAA approved 10amp extension cords. Non-approved cords may overheat. Care should be taken to
arrange the cord so that the cord cannot be tripped over.
21. Do not put any objects into openings. Do not use with any openings blocked and do not restrict airow.
Keep all openings free of dust, lint, hair or anything that might reduce airow.
22. Do not use the vacuum cleaner with blocked lters and without all of the lters in place.
23. Take extra care when positioning the vacuum cleaner on the stairs.
24. Keep vacuuming area well lit.
3
General Safety Information
WARNING: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container, or before connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful unit. Before plugging the cord into the electrical socket,
make sure the switch is in the ‘o’ position.
IMPORTANT: If the inlet, hose or telescopic tube is blocked, switch o the vacuum cleaner and remove the
blockage(s) before re-starting the vacuum cleaner.
IMPORTANT: Vax recommends the use of Residual Current Device Rating of 30mA or less.
IMPORTANT: It is very important that lters are kept clean to obtain maximum performance from your vacuum
cleaner. Not cleaning and not replacing your lters regularly can reduce the suction power and cause overheating
and permanent damage to the vacuum cleaner.
NOTE: If the supply cord is damaged it must be replaced by the manufacturer, or a similarly qualied person
in order to avoid hazard, or invalidating the warranty.
IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the unit should overheat
(eg. from blocked nozzles, a full dust container or unclean lters), the thermostat will automatically turn o the
switch. Should this occur, unplug the vacuum cleaner from the electrical socket and turn o the switch. Remove
dirt container and empty. Clean lters. Allow the unit to cool for approximately one (1) hour. To re-start, plug into
an electrical socket and switch back on.
DAMAGE TO THE VACUUM CLEANER CAUSED AS A DIRECT RESULT OF NOT ADHERING TO THE GENERAL
SAFETY INFORMATION AND THE INSTRUCTIONS IN THIS USER GUIDE INVALIDATES THE WARRANTY.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Taking care of your carpets and hard oors
The Performance Floors & All is designed to make vacuuming carpets and hard oors regularly, as eective and
ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer. You’ve chosen carpets and
hard oors for your home for a reason and Vax will help you take good care of them.
Taking care of your Performance Floors & All
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready when you are to
tackle your carpets and hard oors.
vax.com.au
vax.co.nz
4
Getting Started
Assembling your upright
Place the dirt container onto the
main body and click into position.
Insert the extension tube into the top of
the main body and click into place.
Align the main body with the oor head
and push into place.
Push the hose into the hose clips
on the machine.
Push the hose into the hose to machine
connector and twist to lock into position.
Wrap the power cord around the quick
release cord hook and the lower cord
hook, continue wrapping the power
cord until it is secure.
5
How To Use
Before you begin cleaning
• Always switch off and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and
emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will
automatically turn the vacuum cleaner o . If this happens, switch the vacuum cleaner o and unplug from electrical socket. Remove
and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool for approximately 1
hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry before putting back into the vacuum).
• For best cleaning results lters require cleaning at least every 3 months.
• If the vacuum cleaner is blocked, switch off and unplug before removing the blockage.
• When using the accessories always make sure the brushbar is switched to the off position.
Twist the quick release
cord hook to release the
power cord.
Plug in the machine.
Press the three way on/o
switch to turn on.
Place your foot gently
onto the oorhead and pull
the handle back to recline
the machine.
To release the handle with
extension tube press the
extension tube release
button and lift the handle
to remove.
vax.com.au
vax.co.nz
6
How To Use
Using the fl oorhead without the main body
To remove the canister
from the main body of the
vacuum cleaner: Hold the
dirt container handle, press
the main body release
button and lift to remove.
Put the main body to one
side, use oorhead for
di cult to reach places.
Press extension tube release
button and lift the handle to
remove.
Attaching accessories to telescopic tube or handle
WARNING: Turn o brush bar when using the wand or hose.
Press handle release button,
pull extension tube to
remove.
Press extension tube release
button and lift handle to
remove extension tube.
Choose an accessory. Always hold the vacuum
7
Attach accessories to the
end of extension tube
or handle.
cleaner when using the
hose or extension tube.
Looking After Your Machine
Emptying and cleaning the dirt container
NOTE: Don’t over ll the dirt container to avoid clogging the lter.
Press the dirt container release button
and pull to remove the dirt container.
Hold dirt container over a bin and press
the dirt container release button to open,
allowing dirt to fall out.
When re-attaching the dirt container,
align the base rst then push until you
hear an audible click. The dirt container
is now locked in place.
vax.com.au
vax.co.nz
8
Looking After Your Machine
NOTE: For best cleaning results lters require cleaning at least every three months.
Cleaning the pre-motor lter
Turn the dirt container lid anti-clockwise
and lift to remove.
Wash the lter under running water
o
(40
C max).
Grasp tab on lter and pull to remove.
Leave to fully dry for at least 24 hours
before putting back into the
vacuum cleaner.
Tap the lter over a bin to release
any dirt.
9
Looking After Your Machine
NOTE: Always make sure the shroud is fully dry and correctly tted before replacing back into the machine.
Cleaning the shroud
Turn the dirt container lid anti-clockwise
and lift to remove.
Lift the shroud from the dirt container
and tap over a bin to remove dirt
and debris.
Grasp tab on lter and pull to remove.
Wash the shroud under running water
(Max 40
at least 24 hours before replacing back
into the dirt container.
o
C) and leave to fully dry for
Grasp the centre of the shroud and pull
to remove.
vax.com.au
vax.co.nz
10
Looking After Your Machine
Cleaning the post motor lter
Press button on post motor
lter cover and remove.
Pull the post motor lter from
the machine.
Removing debris from the brushbar
Tap the post motor lter over a bin to
remove any dirt and debris and replace
it into the machine.
Switch o your vacuum cleaner at the
main socket. Using a pair of scissors,
cut any hair or debris free from around
the brushbar.
11
Looking After Your Machine
Removing blockages from the TurboTool
Remove the rubber ring. Push both buttons to open
the turbo tool.
Changing the belt
Switch o and unplug your
vacuum cleaner. Recline
the vacuum and lie it on its
front, remove 5 screws to
release brushbar cover.
Remove the brushbar cover
and push the oor head
into reclined position.
Lift the brushbar out of the
oor head and remove the
drive belt.
Using a pair of scissors, cut any hair or
debris free from around the brushes.
Remove the drive belt and
any debris from the spindle.
Loop new drive belt around
the spindle rst and then
onto the brushbar. Insert the
brushbar back into oor
head and replace the
brushbar cover, insert 5
screws to secure.
vax.com.au
vax.co.nz
12
FAQs
Warning: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance/troubleshooting checks.
There is an accessory missing
• Check the ‘This pack contains’ panel on the box to make sure the part is included with your machine.
Why does my vacuum cleaner have no power?
• The plug may not be fully pushed into the electrical socket.
• The motor thermostat may have tripped. If this has happened, unplug the vacuum cleaner. Remove and empty the dirt container and
check the hose for blockages Clean the lters and allow the vacuum cleaner to cool for approximately 1 hour (if you have washed the
lters you will need to wait 24 hours for the lters to fully dry before putting them back into the vacuum cleaner).
Why won’t the vacuum cleaner pick up?
• The dirt container may not be installed correctly, remove the dirt container and re-attach making sure it is clicked rmly into place.
• There may be a blockage in the hose. Please remove the hose from the vacuum cleaner, check and clear any blockages.
• Dirt container may be blocked, empty the dirt container and clean lters. Go to ‘Looking after your machine’, pages 8-10.
• If the accessory/tool will not pick up, check and clear any blockages.
• The brushbar may not be turning. Go to ‘My brushbar isn’t turning’ below.
My brushbar isn’t turning?
• The brushbar may be clogged, check the brushbar and clear any hair or debris.
• The belt may be broken, go to ‘Looking after your machine – changing the belt’, on page 12.
we’re here to help
For troubleshooting please
call or visit our website:
AU: 1300 361 505
vax.com.au
13
NZ: 0800 800 900
vax.co.nz
Other Information
Insulated
Use
Instructions
Vax Service & Help
Vax Careline:
Australia 1300 361 505
New Zealand 0800 800 900
Monday-Friday 8.30am to 5.00pm
If you have queries or concerns about using your Vax, call the Vax Careline. Calls are charged at the standard
local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling.
For the nearest Service Agent, please call the Vax Customer Careline or visit vax.com.au in Australia
or vax.co.nz in New Zealand.
Technical Specication
Model no.: VX6
Voltage: 220-240V ~50Hz
Wattage: 1200W
Capacity: 2L
Cord length: 10m
Weight: 7.5kg
Subject to technical change without notice.
Double
Indoor
Read
vax.com.au
vax.co.nz
14
Distributed by Techtronic Industries Australia Pty. Ltd.
Performance is everything.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
www.vax.com.au Careline AU: 1300 361 505
www.vax.co.nz Careline NZ: 0800 800 900
vax.com.au
vax.co.nz
Loading...
