Vax VCC-03 Instruction Manual
www.vaxcommercial.co.uk
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
R
e
tain f
or future reference.
Vax careline
0870 1129 145
instruction manual
Commercial bagged cylinder
Vax model number:
VCC-03
(UK only)
Vax VCC-03 User Guide.qxd 8/8/07 16:55 Page 1
Vax VCC-03
2
parts overview
VCC-03
1. Diagram
Fig.1/1
1 Hose inlet
2 Top cover
3 On/off button
4
Carry handle
5
P
o
wer cord storage hook
6 Parking slot
7 Retainer clips
8 Safety bleed valve
9 360° rotating castors
10
Combination floor tool
11
Fle
xible hose
12 Extension tubes
13 Crevice tool
14 Dusting brush
15 Disposable bags (x3)
14
3
1
2
4
5
13
1
2
1
1
1
0
6
9
7
15
8
Vax VCC-03 User Guide.qxd 8/8/07 16:55 Page 2
3
user guide
safety information
2. Safety Information
FOR COMMERCIAL USE ONLY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. This appliance is for dry use only and is not to be
used or stored outdoors or in wet conditions.
2. Turn off the vacuum cleaner controls before
connecting to or disconnecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or
disconnecting the vacuum hose.
4. Children should be supervised to ensure that they do not
play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
6. Use only as described in this manual. Use only the
manufacturer’s recommended attachments. This
appliance is suitable for commercial use, for example
in hotels, schools, hospitals, factories, shops, offices
and rental businesses.
7. Do not use the vacuum cleaner with a damaged cord
or plug. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Return the vacuum cleaner to a Vax
Authorised Service Agent or suitably qualified person
for examination, repair or adjustment.
Call 08701129 145 for your nearest service centre.
Regularly examine the power cord for damage, such
as cracking or ageing. If damage is found replace the
cord before further use.
8. Do not pull or carry by the cord. Do not use the cord
as a handle, close a door on the cord or pull the cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do no
t use outdoors or on wet surfaces.
10.
Do no
t put any objects into openings. Do not use
with an
y openings block
ed and do no
t r
estrict air
flow. Keep all openings free of dust, lint, hair or
an
ything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12.
Do no
t pick up hot coals, cigarette butts, matches or
any hot, smoking or burning objects.
13.
Do not pick up flammable, hazardous dust or
c
ombus
tible ma
t
erials (ligh
ter fluid, petrol, kerosene, etc)
or use in the presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material
(chlorine bleach, ammonia, drain cleaner, etc).
15. Do not vacuum up hard or sharp objects such as glass,
nails, screws, coins, etc.
16. Do not use without the filters in place.
17. Use extra care when vacuuming on stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner indoors in a cool, dry area.
20. Turn off the switch before unplugging.
21. Use only CE-approved 13 amp extension cords. Nonapproved extension cords may overheat. Care should
be taken to arrange the cord so that the cord cannot
be pulled or tripped over.
22. Regularly examine the supply cord for damage, such
as cracking or ageing. If damage is found replace the
cord before further use.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container, or
before connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the outlet
make sure the switch is in the ‘off’ position. Hold the
vacuum cleaner firmly when starting and in use.
IMPORTANT: If the inlet or hose is blocked,
switch off the vacuum cleaner and remove the
blockage(s) before re-starting the vacuum cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Make sure all filters are replaced
back into the vacuum cleaner before using. Vax
recommends replacing the pre-motor filter when it
becomes discoloured.
This appliance is suitable for commercial use.
PLEASE KEEP THESE INSTRUCTIONS
FOR FURTHER USE.
!!!
!
Motor Thermostat
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason, the vacuum cleaner should
over-heat, the thermostat will automatically turn the
unit off. Should this occur, unplug the vacuum cleaner
from the electrical outlet and turn off the switch.
Remove the dirt container and empty. Clean the
filt
ers. Allow the cleaner to cool for approximately one
(1) hour. To re-start, plug into an electrical outlet and
swit
ch back on.
Vax VCC-03 User Guide.qxd 8/8/07 16:55 Page 3
Vax VCC-03
4
assembly / operation
3. How to Assemble
1. Insert the flexible hose into the inlet on the main body
of the vacuum cleaner. Turn the hose clockwise until it
cannot be turned any further (Fig.3/1).
2. Push the extension tube on to the end of the handle.
The extension tubes can be used together to lengthen or
shortened by using one section of the extension tube as
required.(Fig.3/2).
3. Fit the c
ombina
tion floor head by pushing on
to the
e
xtension tube. (Fig.3/3).
4. How to Operate
On/Off Button
Insert the power plug into the electrical outlet. Ensure the
vacuum cleaner is switched off. Press the on/off button
located on the top of the machine to turn on and press the
button again to turn the vacuum cleaner off. (Fig.4/1)
Carpet Cleaning
For carpet and rug cleaning press the rocker switch on the
combination floor head to raise the brushes. (Fig.4/2 )
Hard Floor Cleaning
For hard floor cleaning, press the rocker switch on the
combination floor head to lower the brushes. (Fig.4/3)
Fig.4/1
Fig.4/2
Fig.4/3
Fig.3/3
Fig.3/2
Fig.3/1
Vax VCC-03 User Guide.qxd 8/8/07 16:55 Page 4
