User Guide
AirPowerhead
Designed in the UK
VCAPH1500
Performance is everything.
vax.com.au
Contents
Machine Overview
General Safety Information
Getting Started
Maintenance
Looking After Your Machine – Filters
Looking After Your Machine – Advanced cleaning
Looking After Your Machine – Removing blockages
FAQs
Other Information
1
2
3
5
6
7
9
10
12
13
Contents
1
1. Hose connector
2. Dirt container
3. Cyclone separator and shroud
4. Carry handle
5. Dirt container release button
6. Cord rewind button (hidden)
7. Floor head parking slot
8. On/off button
9. Post-motor lter cover
10. Primary separator
11. Antibacterial HEPA media
post-motor lter
(Note: Post-motor lter is housed
in the left wheel)
12. Pre-motor lter
13. Motorised powerhead
14. Hardfl oor tool
15. Telescopic extension tube
16. Dusting brush
17. Crevice tool
18. Flexible hose and handle
19. Upholstery tool
20. Mini turbo tool
Machine Overview
2vax.com.au
10
7
6
5
4
16
18
3
2
9
8
12
1
11
14
13
15
17
20
19
This vacuum cleaner is intended for household use only and NOT for commercial or industrial use.
When using the vacuum cleaner basic safety precautions should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces. Do not handle the plug or vacuum cleaner with wet hands.
Do not use outdoors or on wet surfaces.
2. Turn off the vacuum cleaner controls before disconnecting or connecting from the electrical socket.
3. Always unplug the vacuum cleaner before connecting or disconnecting the hose and accessories.
4. Children should be supervised to ensure that they do not play with the appliance.
5. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
6. Only use as described in this manual. Only use Vax recommended attachments.
7. Do not use the vacuum cleaner if it has been dropped, damaged, left outdoors or dropped into water. Do not use
the vacuum cleaner with a damaged cord or plug. If the supply cord is damaged, it must be replaced by the
manufacturer or a recommended Service Agent to avoid hazard and invalidating the warranty.
8. Do not pull or carry by cord. Do not use the cord as a handle, close a door on the cord or pull cord around sharp
edges or corners. Do not run the vacuum cleaner over the cord. Keep the cord away from heated surfaces.
9. Do not put any objects into openings. Do not use with any openings blocked and do not restrict air flow. Keep all
openings free of dust, lint, hair or anything that might reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of the body away from openings and moving parts.
11. Do not pick up hot coals, cigarette butts, ash, matches or any hot, smoking or burning objects.
12. Do not pick up flammable or combustible materials (lighter fluid, petrol, kerosene etc.) or use in the presence
of explosive liquids or vapours.
13. Do not vacuum harmful or toxic materials (chlorine, bleach, ammonia, drain cleaner etc.).
14. Do not vacuum hard or sharp objects such as glass, nails, screws, coins, etc.
15. Do not vacuum plaster dust, concrete or any other building or vitreous material.
16. Do not vacuum baking soda or any other powder-based carpet deodoriser.
17. Do not use without ALL of the filters in place.
18. Take extra care when vacuuming on stairs.
19. Keep vacuuming area well lit.
20. Store the vacuum cleaner in a cool, dry area.
21. Turn off the on/off switch before unplugging the vacuum cleaner.
22. Use only SAA-approved 10 amp extension cords. Non-approved cords may overheat. Care should be taken
to arrange the cord so that the cord cannot be tripped over.
General Safety Information
3
WARNING: Always switch off and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container, or before connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful unit. Before plugging the cord into the electrical socket, make
sure the switch is in the ‘off’ position.
IMPORTANT: If the inlet, hose or telescopic tube is blocked, switch off the vacuum cleaner and remove the
blockage(s) before re-starting the vacuum cleaner. See Maintenance:
Clearing blockages.
IMPORTANT: Cleaning filters and replacing them when discoloured/damaged maintains vacuum performance and
prevents damage to the vacuum cleaner. Vax recommends that they should be checked, cleaned and
replaced periodically (depending on the level of use). Make sure all filters are completely dry before
inserting back into the vacuum cleaner.
NOTE: If the supply cord is damaged it must be replaced by the manufacturer, or a similarly qualified person in
order to avoid a hazard, or invalidating the warranty.
IMPORTANT: Vax recommends the use of a Residual Current Device with a Residual Current Rating.
IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the
thermostat will automatically turn the unit off. Should this occur, unplug the vacuum cleaner from the
electrical socket and turn off the switch. Remove dirt container and empty. Clean filters. Allow the unit
to cool for approximately one (1) hour. To re-start, plug into an electrical socket and switch back on.
CAUTION: This hose contains electrical connections:
– do not use to suck up water (for vacuum cleaners only);
– do not immerse in water for cleaning;
– the hose should be checked regularly and must not be used if damaged.
DAMAGE TO THE VACUUM CLEANER CAUSED AS A DIRECT RESULT OF NOT ADHERING TO THE GENERAL
SAFETY INFORMATION AND THE INSTRUCTIONS IN THIS USER GUIDE INVALIDATES THE WARRANTY
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
General Safety Information
4vax.com.au
Keep your Vax like new
Assembling your vacuum cleaner
Operating the appliance and accessories
IMPORTANT: The condition of the lters aff ects the
performance of your machine. Please check, clean and
replace lters periodically (depending on the level of use).
For full cleaning instructions, see pages 7-8.
IMPORTANT: Do not use the vacuum cleaner without all
of the lters in place.
NOTE: The crevice tool, upholstery tool and dusting brush
can all be attached to the telescopic tube or hose handle.
NOTE: Fully unwind the power cord. The yellow mark on the
cord indicates the recommended cord length. Do not exceed
the cord length beyond the yellow mark.
The motorised powerhead is
used for cleaning carpets.
There is an option to switch
the brushbar on the
motorised powerhead off
when using on carpets.
The on/off switch is located
on the hose handle.
This tool is for safely
cleaning hard fl oor surfaces
such as fl oorboards, laminate,
stone and tiled fl oors.
5
Getting Started
Packing away and storage
Emptying and cleaning the dirt container
NOTE: For convenience there is a parking slot located at the rear of the vacuum cleaner
where the fl oor head and tubes can be attached for storage and carrying.
Press dirt container release
button and lift.
Press the dust release lever
to empty dirt.
Packing away and storage
6
Maintenance
vax.com.au
Cleaning the pre-motor lter
tap
NOTE: Clean regularly and replace the lter when discoloured or damaged (frequency will depend on level of use).
WARNING: Water temperature should not exceed 40°C when washing the pre-motor lter.
WARNING: Ensure lter is completely dry before inserting back into the vacuum cleaner.
WARNING: For best cleaning results fi lters require cleaning at least every three months. Do not use your
vacuum cleaner without all of the lters in place.
7
Looking After Your Machine - Filters
NOTE: Clean regularly and replace the lter when discoloured or damaged (frequency will depend on level of use).
WARNING: Do not wash the post-motor lter.
WARNING: For best cleaning results fi lters require cleaning at least every three months. Do not use your
vacuum cleaner without all of the lters in place.
Cleaning the Antibacterial HEPA media post-motor lter
8
Looking After Your Machine - Filters
vax.com.au
Advanced cleaning - cyclone separator
WARNING: Always switch off and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container, or before connecting/disconnecting the attachments.
WARNING: For best cleaning results fi lters require cleaning at least every three months. Do not use your
vacuum cleaner without all of the lters in place.
Advanced cleaning - primary separator
24hr
tap
WARNING: Ensure separator is completely dry before
inserting back into the vacuum cleaner.
9
Looking After Your Machine
- Advanced Cleaning
Hose blockages
Accessory blockages
Removing blockages from the Powerhead
WARNING: To reduce the risk of electric shock, the power cord must be disconnected before performing
maintenance/troubleshooting checks. Turn the vacuum cleaner off and unplug from the electrical socket.
IMPORTANT: If the air inlet, hose or telescopic tube is blocked, switch off the vacuum cleaner and remove
the blockage(s) before re-starting the vacuum cleaner.
The fl exible hose may be disconnected from the vacuum cleaner. Carefully remove any blockages found and
reconnect the hose securely.
Remove accessory from the hose/telescopic tube. Carefully remove the blockage and return to the cleaner.
Open clips at either side of
the Powerhead.
Lift top up to reveal brushbar. Cut away tangled hairs with
a pair of scissors. Be careful
not to cut the bristles on the
brush bar.
10
Looking After Your Machine
- Removing Blockages
vax.com.au
Removing blockages from the Turbo tool
Press the two side buttons
together & pull sides apart.
Carefully use scissors to cut
out the blockage.
Realign turbo brush sides
& press together.
NOTE: Switch the cleaner off and disconnect the power plug from the electrical outlet.
11
Looking After Your Machine
- Removing Blockages
FAQs
Warning: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance/troubleshooting checks.
Is there an accessory missing?
• Check the ‘Machine Overview’ page in this guide to make sure that the part is denitely included in your unit.
• If it is missing, we’re here to help. Simply call us on AU 1300 361 505 / NZ 0800 800 900
Why won’t the vacuum cleaner pick up?
• The dirt container may be incorrectly installed; remove the dirt container from the unit by pressing the dirt container release catch
and then reattaching it to the unit, ensuring it is locked rmly back into place.
• The lter may be clogged; refer to ‘Maintenance: Cleaning the lters’ on pages 7-8 and ‘Looking after your machine - Advanced cleaning’
on page 9.
• The dirt container may be blocked; refer to ‘Maintenance: Emptying and cleaning the dirt container’ on page 6.
• There may be a blockage in the tube/hose. Disconnect from the vacuum cleaner, carefully remove any blockages found
and reconnect securely.
Why is dust escaping from the vacuum?
• The lter may be clogged; refer to ‘Maintenance: Cleaning the lters’ on pages 7-8.
• The dirt container may be blocked; refer to ‘Maintenance: Emptying and cleaning the dirt container’ on page 6.
• The dirt container may be incorrectly installed; remove the dirt container from the unit by pressing the dirt container
release catch and then reattaching it to the unit, ensuring it is locked rmly back into place.
What do I do if the unit/an accessory becomes damaged or broken?
• We’re here to help. Simply call AU 1300 361 505 / NZ 0800 800 900 or visit vax.com.au
Why won’t the accessories pick up properly?
• Hose blockages: remove the hose from the unit. Carefully remove any blockages found and reconnect hose securely.
• Accessory blockages: remove accessory from handle/tube. Carefully remove blockage and re-attach to the vacuum cleaner.
• The accessory may be faulty. Simply call us on AU 1300 361 505 / NZ 0800 800 900 for assistance.
Why will the vacuum cleaner not run?
• It may not be plugged into the electrical socket correctly; ensure that the plug is pushed in securely.
• The electrical socket may not be working properly; check the fuse or breaker, or consult an electrician.
• The motor thermostat may have tripped; switch o and unplug the vacuum cleaner, and leave for one hour before switching
the cleaner back on.
12vax.com.au
13
Other Information
Vax Service & Help
Vax Careline:
Australia 1300 361 505
New Zealand 0800 800 900
Monday-Friday 8.30am to 5.00pm
If you have queries or concerns about using your Vax, call the Vax Careline. Calls are charged at the standard local rate. Please
make a note of the serial number and model number of the vacuum cleaner before calling.
For the nearest Service Agent, please call the Vax Customer Careline or visit vax.com.au / vax.co.nz
Technical Specication
Wattage: 1500W
Voltage: 220-240V ~50Hz
Capacity: 2.5L
Filters: Pre-motor lter – washable
Post-motor lter – Antibacterial HEPA H12 lter (not washable - tap to clean)
Cord length: 6m
Weight: 5.6 kg
Motorised Powerhead
Wattage: 35W
Voltage: 220-240V ~50Hz
Subject to technical change without notice.
Double
Insulated
Indoor
Use
Read
Instructions
Notes
14vax.com.au
Distributed by Techtronic Industries Australia Pty. Ltd.
Level 1, 660 Doncaster Road, Doncaster, Australia 3108.
Service Line: AU: 1300 361 505 / NZ: 0800 800 900
Performance is everything.
vax.com.au
Loading...
