Let’s talk safety
Basic
safety
precautions
Don’ts
Please keep instructions for further use and use
only as instructed in this guide. This vacuum
cleaner is intended for household use only and NOT
for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces
and keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped, damaged
or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the
power cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455 (Mon-Fri: 8:30am to 6:30pm,
Sat: 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the power
cord. Don’t unplug vacuum cleaner by pulling on the power cord.
• Don’t vacuum up hard or sharp objects such as glass, nails,
screws or coins etc.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Only Vax recommended tools should be used with this vacuum cleaner.
• Don’t vacuum up any ammable or combustible materials (lighter uid,
petrol, kerosene etc.) or use the vacuum cleaner in an area with explosive
vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t use the vacuum cleaner with incorrect voltage as this may result
in damage or injury to the user. The correct voltage is listed on the ratings label.
• Don’t wash the post-motor lter.
Do’s
• Turn o all controls on the vacuum cleaner before disconnecting
or connecting the power cord.
• Always keep the power cord away from the brushes whilst
using your vacuum cleaner. After use always wrap the power
cord around the cord clips provided.
• Always make sure both the pre-motor/post motor lters
are in place before use.
• Always make sure the brushbar is set to hard oor when using
your vacuum on the stairs and take extra care when positioning
the vacuum cleaner on the stairs.
• Always switch o the vacuum cleaner before disconnecting or connecting
the hose and accessories.
• Keep all openings clear and free from debris as this may aect
the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
• Always protect the power cable from heated surfaces and open ames.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it could
be a trip hazard.
• Store the vacuum cleaner in a cool, dry area. If lters have been cleaned as per
user the guide instructions ensure they are thoroughly dry before storing away.
Thank you for buying this Air™ vacuum cleaner.
Contents
Air™ (Included in all models)
Taking care of your carpets and hard oors
The Air™ is designed to make vacuuming carpets and hard oors regularly, as eective and
ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you
take good care of them.
Taking care of your Air™
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you are to tackle your carpets and hard oors.
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,
Worcestershire, WR9 0LW, UK
This user guide can be found online at: vax.co.uk/support
Let us know what you think @VaxUK
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Accessories
What to do if it goes wrong
Getting in touch
Initial setup for normal operation
1. Use the base accessories.
– Shortest hose
– Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All air vents must be closed.
5. Floor heads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Included with
your machine*
3-in-1 Crevice, Dust and
Upholstery Tool
Pre-motor Filter
Post-motor Filter
Air™ Pet
TurboTool
Air™ Pet & Family
Fur ‘n’
TurboTool
Air™ Total Home
Flexi Crevice Tool
TurboTool
2.3 m Stretch Hose
Air™ Reach
2.3 m Stretch Hose
Air™ Living
Flat
Upholstery
Tool
Tool Connector
* Some parts may vary according to model.
Please check inside of box for more details.
Flu Tool
Tool Connector
TurboTool
TurboTool
Handle
Getting to know your machine
Hose to extension tube connector
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Assembling your upright
Handle height adjuster
Dirt container
release button
Carry handle
Separator
Dirt container
Post-motor lter release button
Post-motor lter cover
Brushbar blockage indicator
Rotating brushbar
Telescopic extension tube
Upper handle release button
Power on/o button
Brushbar on/o button
Quick release
cord hook
Power cord
Hose to
machine connector
Hose
Wheels
Insert the handle.
How to use
Twist the quick release cord
hook to release the power cord.
Place the 3-in-1 tool onto
the on board storage area.
Plug in your machine and push
ON/OFF button to switch on.
Adjust handle up
or down to select
the desired height.
Technical Specication
Name Air™
Voltage See rating label on machine for details
Wattage See rating label on machine for details
Capacity 1.5L
Cord length 6-12m
Weight 4.9kg
Subject to technical change without notice.
Accessories & Consumables
Filter Kit (Type 90)*
1-1-134227
TurboTool (Type 6)*
1-1-134419
Belt (Type 26)*
1-1-134530
3-in-1 tool
1-1-129167
*To purchase consumables and accessories, please visit vax.co.uk
Fur ‘n’ Flu tool
1-1-131392
Flexi Crevice tool
1-1-131393
Flat Upholstery tool
1-1-131394
Brushbar on — carpets
Brushbar o — hard oors
Recline the unit.
NOTE: The brushbar will not spin until the machine is reclined.
IMPORTANT: Switching the brushbar on whilst cleaning hard oors may damage ooring.
Using your machine
!
!!!
Taking care of your machine
Before you begin cleaning
• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing
and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat
will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug from electrical
socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to
cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry before putting
back into the vacuum).
• Pre motor lters require cleaning at least every 3 months.
• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
• When using the accessories always make sure the machine is stood in the upright position.
NOTE: The brushbar will not spin until the machine is reclined.
Using accessories
NOTE: The TurboTool, 3-in-1 crevice tool, dusting brush and upholstery tool can all be attached to the telescopic tube
or directly to the hose.
Use the tool connector when attaching the exi crevice or at upholstery tool (some models only).
Attaching the hose
a
b
c
How to use the air vent
Slide vent cover open to decrease suction,
if required on high piled carpets.
NOTE: For most ecient results the air vent should be closed.
Emptying and cleaning the dirt container
Press the dirt container release button and pull
to remove the dirt container.
Cleaning the HEPA pre-motor lter
Close the vent cover to increase suction,
for maximum cleaning on hard oors.
Hold dirt container over a bin and press the dirt
container release button allowing dirt to fall out.
Remove hose end
from the oorhead.
Telescopic extension tube
Remove telescopic
extension tube.
Choose an accessory. Attach accessory
Attach hose to telescopic
extension tube.
3-in-1 tool converts into:
a = Crevice tool
b = Upholstery tool
c = Dusting brush
Attach accessory to
telescopic extension tube.
to hose end.
Turn the dirt container lid
anti-clockwise…
tap
Tap the lter over a bin
to release any dirt.
…and lift to remove.
40°C max
Wash the lter under
running water (40°C max).
Grasp tab on lter
and pull to remove.
24hr
Leave to fully dry for at
least 24 hours before
putting back into the
vacuum cleaner.
Taking care of your machine
Taking care of your machine
Cleaning the shroud
tap
Turn the dirt container lid
anti-clockwise and lift to remove.
Tap over a bin to remove
dirt and debris.
Brush dirt from the shroud.
HEPA post-motor lter maintenance
IMPORTANT:
The exhaust lter is designed to oer long life with no maintenance. The lter should be
checked periodically and when heavily discoloured it should be replaced. Please do not
wash, scrub or brush the lter as this will damage the delicate lter media.
CAUTION: To reduce the risk of electric shock, turn the vacuum cleaner o and unplug from the electrical outlet
before performing maintenance/troubleshooting checks.
Removing debris from the brushbar
A RED light will indicate
a jammed brushbar.
Switch o your vacuum cleaner
at the main socket. Using a pair
of scissors cut any hair or debris
free from around the brushbar.
Turn the vacuum cleaner back on.
GREEN light will indicate that the
A
brushbar is clear and ready for use.
Changing the brushbar
IMPORTANT: Unplug and switch o vacuum cleaner before maintenance or troubleshooting checks
Press button on post motor
lter cover and remove.
Remove the post motor lter
from the lter cover.
Check the post-motor lter
for discolouration.
Using a crosshead screwdriver,
remove 3 screws from the side
of the oorhead.
Replace the old belt, ensuring the
teeth are fully engaged with the cogs.
Remove the end cap belt cover. Remove the brushbar location
plate to gain access to the belt.
PULL
Pull brushbar through brushbar
side cover to remove.
Taking care of your machine
Accessories
Removing blockages from the TurboTool
Turn the TurboTool over and
slide o the locking ring.
Detach lower housing
and remove.
Using a pair of scissors,
cut any hair or debris free
from around the brushes.
Changing the belt
IMPORTANT: Unplug and switch o vacuum cleaner before maintenance or troubleshooting checks.
To re-assemble the
TurboTool, ensure that the
tabs are engaged and pivot
the lower housing closed.
Slip the locking ring over the
neck of the TurboTool and
into the groove to nish.
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
TurboTool (Type 6)
1-1-134419
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for
picking up stubborn pet hair.
3-in-1 Tool
1-1-129167
3-in-1 tool includes crevice tool for awkward
areas and corner, dusting brush for areas
such as skirting and an upholstery tool for
cleaning sofas, curtains, chair seats and
car interiors.
Using a crosshead screwdriver,
remove 3 screws from the side
of the oorhead.
Replace the old belt, ensuring the teeth
are fully engaged with the cogs.
Remove the end cap belt cover. Remove the brushbar location plate
to gain access to the belt.
Pro cleaning kit
1-1-133326
All our best tools all in one kit that makes
cleaning your home quicker, easier and with
even better results. We’ve taken care of
cleaning all of the hard to reach areas such
as on top of cupboards and in between blinds
to the dust that collates behind and within
the radiator.
What to do if it goes wrong
SolutionProblem
• Check the ‘This pack contains’ panel on the box to make sure
the part is included with your machine.
There is an
accessory missing.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with
Why does my vacuum
cleaner have no power?
a British 13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug
the vacuum cleaner. Remove and empty the dirt container and check
the hose for blockages.
• Clean the lters and allow the vacuum cleaner to cool for approximately
1 hour (if you have washed the lters you will need to wait 24 hours for
the lters to fully dry before putting them back into the vacuum cleaner).
Getting in touch
• There may be a blockage in the hose. Please remove the hose from
the vacuum cleaner, check and clear any blockages.
Why won’t the vacuum
cleaner pick up?
My brushbar
• Empty the dirt container and clean lters. Go to the ‘Taking care
of your machine’.
• The brushbar may not be turning. Go to my ‘My brushbar isn’t turning’ below.
• If the accessory/tool will not pick up, check and clear any blockages.
• Air vent may be open, close vent. Go to ‘Using your machine’
• The brushbar may be clogged, check the brushbar and clear
any hair or debris. Go to ‘Let’s talk technical’.
• The belt may be broken. Go to ‘Let’s talk technical’.
isn’t turning.
IMPORTANT: To reduce the risk of personal injury, unplug the vacuum before performing
maintenance/troubleshooting checks.
†
Registration required. Terms and conditions apply, see vax.co.uk for details.
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
GET IN TOUCH
0330 026 8455 VaxVacuumsinfo@vax.co.uk vax.co.uk @VaxUK
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the U91-MA-Be, U87-MA-Pe, U90-MA-Re, U89-MA-Le, U89-MA-PFe, U89-MA-Te, VRS115 and VRS116
are manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
© 2015 Vax Limited. All rights reserved. The VAX trade mark and Vax lozenge is the property of Techtronic Floor Care
Technology Ltd and is registered in the EU and may be pending or registered in other countries.
Loading...
