Vax TBTSV1B1 User Manual

TBTSV1B1

LET’S GET STARTED.

HIGH PERFORMANCE
CORDLESS VACUUM

Arrow

20V

Let’s talk safety

Basic
safety
precautions

This vacuum cleaner is intended for household use only
and NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors and keep the area
you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the vacuum cleaner.

• Only Vax recommended tools and accessories should be used
with this vacuum cleaner.

Don’ts

• Don’t charge the vacuum cleaner outdoors, or leave the charger
connected to the mains when not in use.

• Don’t use the vacuum cleaner with the charger plugged into
the mains supply and connected to the vacuum cleaner.

• Don’t use this vacuum cleaner if it has been dropped, damaged,
immersed in water or left outdoors.

• Don’t handle the charger plug or use the vacuum cleaner
with wet hands.

• Don’t run over the charger cord or use the vacuum cleaner if the
charger cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455.

Do’s

• Always make sure the lter and dirt container are tted
correctly before using your vacuum cleaner.

• Always turn o and unplug the vacuum cleaner from the
charger before carrying out any maintenance.

• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the charger.

• Take extra care when cleaning on the stairs.

• Always protect the charger cord from heated surfaces
or when near open ames.

• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the vacuum cleaner in a safe way and
understand the hazards involved. Children should not play with the vacuum
cleaner. Cleaning and user maintenance should not be made by children
without supervision.

• Don’t use the charger cord as a handle, pull the charger cord around corners
or sharp edges or close a door over the charger cord. Don’t unplug charger
by pulling on the charger cord.

• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.

• Don’t use this vacuum cleaner to vacuum up liquids.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).

• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.

• Always carry the vacuum cleaner by the carry handle.

• Store your vacuum cleaner in a cool, dry area.

Please keep instructions for further use.

Thank you for buying this Cordless vacuum.

Taking care of your carpets and hard oors

This user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer

and Vax will help you take good care of them.

Taking care of your cordless vacuum

Also inside this guide are instructions on maintaining your new machine, so that it’s ready
when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back
to the shop, simply visit our online support:

vax.co.uk/support

Still need to get in touch?

Our UK based Customer Care Team are here to support you - for help with assembly,
operational/performance problems or buying and tting new accessories. Whether you wish to chat,
use Facebook, Twitter or call, you can nd all our contact details at vax.co.uk/contactus

This user guide can be found online at: vax.co.uk/support

Contents

Arrow 20V

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Accessories

Notes

What to do if it goes wrong

Getting in touch

Included with
your machine

Battery

Charger

Wall Clip

Getting to know your machine

Name Arrow 20V
Battery voltage See product rating label
Run time 35 minutes

*

Charge time 4 hours
Weight 2.56 kg
Dust bin capacity 0.6l

Technical Specication

Subject to technical change without notice. Images are illustrative only. * Tested in low speed mode on hardoor.

Pre-motor lter

1-7-138168

Accessories & Consumables

To purchase consumables and
accessories, please visit vax.co.uk

On/o and suction control switch

Handle

Dirt container release button

Dirt container

LED indicator charge light

Battery cover

Battery cover release button

Machine charging port

Floorhead release button

Floorhead

Brushbar
