CORDLESS
Blade
CORDLESS SLIM VAC WITH
DETACHABLE HANDHELD
LET’S GET STARTED.
TBT3V1B1
TBT3V1P1
TBT3V1P2
TBT3V1B2
TBT3V1F1
TBT3V1H1
Let’s talk safety
This slim vac is intended for household use only and NOT for
commercial or industrial use.
Basic
safety
precautions
Don’ts
• This slim vac does not stay upright without constant support.
Between uses, lie at on the oor in a suitable location so that it
does not become a trip hazard or can be stepped on.
• Only use the slim vac indoors on dry surfaces and keep the area
you’re cleaning well lit.
• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the slim vac.
• Don’t charge the slim vac outdoors, or leave the charger connected
to the mains when not in use.
• Don’t use the slim vac if it has been dropped, damaged, immersed
in water or left outdoors.
• Don’t handle the charger plug or use the slim vac with wet hands.
• Don’t run over the charger cord or use the slim vac if the charger
cord or plug is damaged. Please contact our Customer Care Line on:
0330 026 8455.
• Don’t use the charger cord as a handle, pull the charger cord around
corners or sharp edges, or close a door over the charger cord.
• Don’t unplug the charger by pulling on the charger cord.
Do’s
• Always turn o and unplug the slim vac from the charger before
carrying out any maintenance. Please refer to the appropriate
section in the user guide to review necessary precautions.
• Always make sure the separator and lters are tted correctly
before using your slim vac.
• Always switch o the slim vac before disconnecting or connecting
the reach wand and accessories.
• Keep all openings clear and free from debris as this may aect the
airow/suction.
• Take extra care when using the slim vac on the stairs.
• This slim vac can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the slim vac in a safe way and understand the hazards involved. Children should
not play with the slim vac. Cleaning and user maintenance should not be made by
children without supervision.
• Only Vax recommended charger, tools and accessories should be used with this
slim vac.
• The battery must be removed from the appliance before it is scrapped.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws, coins, etc.
• Don’t attempt to remove blockages with sharp objects as this may cause damage
to your slim vac.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning items
or use in an area where there may be harmful uids (chlorine, bleach and ammonia
drain cleaner).
• Don’t use the slim vac with incorrect voltage or charger as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Don’t leave the slim vac in one spot for an extended period of time when the
brushbar is activated. This slim vac is tted with a rotating brushbar which, if left in
one place, may cause damage to the oor surface.
• If charging the slim vac through an extension cord, use only CE approved 13amp
extension cords, non-approved extension cords may overheat. Care should be taken
to arrange the extension cord as it can be a trip hazard.
• Always protect the power cable from heated surfaces and open ames.
• Store your slim vac in a cool, dry area. If lters have been cleaned as per user guide
instructions ensure they are thoroughly dry before storing away.
• Always use the charger supplied with the slim vac.
• The battery must be disposed of safely (for further information, read the ‘Getting
started’ section).
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Thank you for buying this Vax Cordless Blade.
Taking care of your carpets and hard oors
The Vax Cordless Blade series is designed to make vacuuming carpets and hard oors
regularly, as eective and ecient as possible and this user guide will help you get the
most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer
and Vax will help you take good care of them.
Taking care of your Vax Cordless Blade
Also inside this guide are instructions on maintaining your new machine, so that it’s ready
when you are to tackle your carpets and hard oors.
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit our online support:
vax.co.uk/support
Still need to get in touch?
Our UK based Customer Care Team are here to support you - for help with assembly,
operational/performance problems or buying and tting new accessories. Whether you wish to chat,
use Facebook, Twitter or call, you can nd all our contact details at vax.co.uk/contactus
This user guide can be found online at: vax.co.uk/support
Let us know what you think @VaxUK
Contents
Included with
your machine
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Cordless Blade 32V
Cordless Blade 24V
Crevice Tool
Dusting Brush
Cordless Blade 32V Pro
Cordless Blade 32V Ultra
Cordless Blade 24V Pro
Getting in touch
Notes
Cordless Blade 24V Ultra
Crevice Tool
Dusting Brush
Pet/Stair Tool
All models come with a charger, wall mount,
3 screws and user manual.
Getting to know your machine
Battery level indicator
Dirt container lid
Dirt container
Dirt release button
Charging port (hidden)
Handheld release button
Reach wand
Powered Head/
accessory release clip
Powered Head
Brushbar
Technical Specication
Name Vax Cordless Blade 24V
Battery voltage See product rating label
Run time 35 minutes
Charge time 4 hours
Weight 3kg
Dust bin capacity 0.6L
On/O button
Handle
Battery level gauge
Battery charging light
Boost mode on/o button
Brushbar on/o button
Wall bracket connection point
Name Vax Cordless Blade 32V
Battery voltage See product rating label
Run time 45 minutes
Charge time 4 hours
Weight 3kg
Dust bin capacity 0.6L
Filter cover
Accessories & Consumables
Foam lter
1-7-138744
Pre-motor lter
1-7-138743
Pet/Stair tool
1-9-138760
Subject to technical change without notice.
Images are illustrative only.
To purchase consumables and
accessories, please visit vax.co.uk
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Before you begin
CAUTION: Always switch o the slim vac before connecting or disconnecting the handheld/attachments or
removing and emptying the dirt container.
IMPORTANT: The slim vac is equipped with a thermal cut-out. If for any reason the slim vac does overheat, the
thermostat will automatically turn the slim vac o. If this happens empty the dirt container and check the slim vac
for blockages. Allow the slim vac to cool for approximately 1 hour (if you have cleaned the lter, wait 24 hours for
the lter to fully dry before putting back into the machine).
For best cleaning results, lters should be tapped over a bin every 4-6 uses to remove dirt and debris, and
washed every 3 months depending on the level of use.
Assembling your cordless slim vac
CAUTION: This slim vac is not free standing. Between uses or when carrying out any maintenance,
always lie at on the oor in a suitable location so that it does not become a trip hazard or can be stepped on.
Line up the connector on
the reach wand with the
Powered Head. Push the
reach wand down onto
the Powered Head until it
clicks into place.
Push the handheld down
onto the reach wand until
it clicks into place.
The slim vac is not free standing and between uses
must always be placed in the wall bracket or laid at
on the oor in a suitable location, so that it does not
become a trip hazard or can be stepped on.
Getting started
Fixing the wall bracket
Fully assemble
the slim vac.
Using a pencil, make
a mark to show the
required position of
the wall bracket. Lift
to remove the slim vac
from the wall bracket.
Line up the wall bracket with the back of the handheld.
Slot the bracket into the handheld and push upwards
to lock into place.
Align the bracket back
to the wall and make an
additional 3 small marks
for each screw.
Use the screws and wall
plugs to secure the wall
bracket to the wall.
Choose a location for the
slim vac to be stored,
preferably near to a
mains supply. Stand the
slim vac in the upright
position against the wall,
with the Powered Head
at on the oor.
Store the slim vac on the
wall bracket by lifting the
slim vac slightly above
the bracket and sliding
the back of the handheld
down and onto the
bracket. Always ensure
the slim vac is securely
locked into place.
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ BEFORE USE
CAUTION: The battery used in this device may present a risk of re or chemical burn if mistreated. Do not
disassemble or heat above manufacturer’s maximum temperature limit (60°C/140°F) or incinerate. Use of another
battery may present a risk of re or explosion. Dispose of used battery promptly. Keep away from children. Do not
disassemble and do not dispose of in a re. Do not attempt to disassemble the battery or remove any component
projecting from the battery terminals. The battery and charger have no user serviceable parts. Fire or injury may
result. Prior to disposal, protect exposed terminals with heavy insulating tape to prevent shorting. The battery is to
be disposed of safely at your local battery recycling centre.
Do not attempt to recharge non-rechargeable batteries. The battery must be removed from the appliance before it
is scrapped. The appliance must be disconnected from the charger/supply mains before use and when removing
or installing the battery into the machine. In case of battery leakages avoid any contact with the skin.
Contact our Customer Care Line on: 0330 026 8455.
Charging the cordless slim vac
NOTE: The initial charge is 4 hours and charging will be required before rst use. The slim vac can be charged as
a handheld with the reach wand and tools removed or as an upright attached to the wall bracket. Failure to fully
charge the battery before rst use (initial charge 4 hours) may result in poor battery performance. The machine
can remain on the battery charger once fully charged. The life expectancy of the battery will vary depending on
the usage of the slim vac.
WARNING: Do not use the slim vac when the machine is plugged in and charging.
To charge the machine
(as a handheld) detach
the reach wand and tools
and place the handheld
on a at, stable surface.
You can also charge as
an upright slim vac when
attached to the wall
bracket.
Insert the charger lead
into the charging port
located underneath the
nozzle on the handheld.
Plug the charging plug
into the mains.
Getting started
Charging the battery
When the charger is connected, both the battery charging light on the back of the handheld and battery indicator
light on the handle will illuminate:
Red light - the slim vac is charging White light - the slim vac is charged
The battery level gauge lights will illuminate in turn as the battery charges, until all four lights are illuminated.
Once fully charged, the gauge lights will go out and the central light will illuminate white.
If charging for the rst time the initial charge time is 4 hours.
When the slim vac is in use the battery level gauge lights
will illuminate indicating how much charge is remaining.
When only one light remains illuminated the central
charging light and battery level indicator will turn red
indicating the battery is running low (<25%).
Using your machine
NOTE: The slim vac has a constantly rotating brushbar when activated. Never leave the slim vac in one spot for an
extended period of time as this may damage the oor surface. Always turn the brushbar o when cleaning hard
oors. The brushbar should be ON for carpets and OFF for hard oors. To prevent any damage being sustained
test on an inconspicuous area of the ooring.
IMPORTANT: If the brushbar has been obstructed, the motor protection sensor may have been activated.
The brushbar will stop and the light on the Powered Head will illuminate red. To reset, remove the Powered Head
from the reach wand/handheld and clear any obstruction. Wait 1 minute before retting the Powered Head, switch
the slim vac on and press the brushbar on/o button.
Using the cordless slim vac
Place your foot on the Powered Head and pull
the handle backwards to recline.
To switch the brushbar on, press the brushbar on/o
button. The light on the Powered Head and the brushbar
on/o light will illuminate to indicate the brushbar is
on and the brushbar will constantly spin. To switch the
brushbar o press the brushbar button again.
The slim vac will always start with the brushbar o.
NOTE: Constant use of the boost mode and brushbar feature will reduce the battery run time.
To switch the slim vac
on, press the on/o
button located on the
back of the handle. The
battery level indicator
light on the handle and
battery charging light will
illuminate white.
When the slim vac is
switched on, the boost
on/o button will also
illuminate, conrming that
the boost mode is ‘On’.
The slim vac will always
start in boost mode.
Pressing the boost button
will deactivate/activate the
boost mode.
Boost mode increases
suction for particularly
dirty areas that require
additional cleaning.
TIP
Using your machine
Using the slim vac reach wand
The reach wand can be used for hard to reach places.
Press the Powered Head/
accessory release clip
and pull to remove the
Powered Head from the
reach wand.
To switch the slim vac on,
press the on/o button
located on the back of
the handle.
NOTE: Constant use of the boost mode will reduce the battery run time.
Choose an accessory
(pictures illustrated
depending on model).
When the slim vac is switched on, the boost on/o
button will also illuminate, conrming that the boost
mode is ‘On’. The slim vac will always start in boost
mode. Pressing the boost button will deactivate/activate
the boost mode.
Push the chosen
accessory into the
reach wand until it
clicks into place.
Boost mode increases
suction for particularly
dirty areas that require
additional cleaning.
TIP
The reach wand can be used for hard to reach places
and at dierent heights for above oor cleaning.
The slim vac is not free standing and in between uses
must always be placed in the wall bracket, or laid at on
the oor in a suitable location, so that it does not become
a trip hazard or can be stepped on.
Using your machine
Using the slim vac as a handheld
NOTE: The slim vac has a constantly rotating brushbar when activated. Never leave the slim vac in one spot for an
extended period of time as this may damage the oor surface. Always turn the brushbar o when cleaning hard
oors. The brushbar should be ON for carpets and OFF for hard oors. To prevent any damage being sustained
test on an inconspicuous area of the ooring. Always take extra care when using the slim vac on the stairs.
Press the handheld
release clip. Pull to
separate the handheld
from the reach wand.
All of the accessories,
including the Powered
Head, can be attached
directly onto the handheld.
The reach wand, when
attached to the Powered
Head/accessory, is not
free standing. Place safely
and securely to one side.
To switch the slim vac
on, press the on/o
button located on the
back of the handle. The
battery level indicator
light on the handle and
battery charging light will
illuminate white.
Choose an accessory
(pictures illustrated
depending on model).
When the slim vac is switched on, the boost on/o
button will also illuminate, conrming that the boost
mode is ‘On’. The slim vac will always start in boost
mode. Pressing the boost button will deactivate/activate
the boost mode.
To switch the brushbar on, press the brushbar on/o
button. The light on the Powered Head and the brushbar
on/o light will illuminate to indicate the brushbar is
on and the brushbar will constantly spin. To switch the
brushbar o press the brushbar button again.
The slim vac will always start with the brushbar o.
Push the chosen
accessory into the
handheld until it is
securely locked into place.
Boost mode increases
suction for particularly
dirty areas that require
additional cleaning.
TIP
Taking care of your machine
Emptying and cleaning the dirt container
CAUTION: Always switch o the slim vac and unplug from the charger and mains before carrying out any
maintenance or troubleshooting.
WARNING: Don’t over ll the dirt container to avoid blocking the air ow through the slim vac.
Press the handheld
release clip. Pull and
remove the reach wand
or the accessory that is
attached to the handheld.
The reach wand, when
attached to the Powered
Head/accessory, is not
free standing. Place safely
and securely to one side.
Hold the handheld over a bin and press the dirt release
button to allow dirt/debris to fall out.
Taking care of your machine
24hr
Cleaning the lters and separator
CAUTION: Always remove the reach wand/accessories from the handheld and empty the dirt container before
cleaning the lters and separator. DO NOT use the slim vac without both the lters in place.
For best cleaning results, the lters should be tapped over a bin every 4-6 uses to remove dirt and debris and
washed every 3 months depending on the level of use.
Cleaning the lters
Press the handheld
release clip. Pull and
remove the reach wand
or the accessory that is
attached to the handheld.
Pull the tab on the lter to remove from the cover. On the handheld, pinch the
Twist the lter cover
anticlockwise to unlock.
Pull and remove the lter
cover from the handheld.
round foam lter inside the
separator and pull to remove.
Tap both lters over a bin to
remove any dirt/debris.
24hr
Wash the lters under
running water (40°C max).
Leave for 24hrs or until
fully dry before replacing.
24hr
Taking care of your machine
Cleaning the separator
Press the handheld
release clip. Pull and
remove the reach wand
or the accessory that is
attached to the handheld.
Twist the lter cover
anticlockwise to unlock.
Hold the handheld over a bin and press the dirt release
button to allow dirt/debris to fall out.
Pull and remove the lter
cover from the handheld.
Press the dirt release
button to open the
dirt container.
To release the separator,
push from inside the dirt
container and pull out the
separator to remove.
Pinch the round foam
lter inside the top of
the separator and pull to
remove. Tap both parts
over a bin to remove
dirt/debris.
Wash the foam lter
and the separator under
running water (40°C max).
24hr
Leave for 24hrs or until
fully dry before retting
the lter back into the
slim vac.
Removing blockages from the handheld and reach wand
Let’s talk technical
Press the handheld
release button and
remove the reach wand.
Check and clear any
dirt and debris from this
connection point.
To test for a blockage in the reach wand, drop a small
ball of paper into the wand. The paper will drop through
if the wand is clear. Use a broom handle or similar blunt
object to remove any blockage.
Removing blockages from the Powered Head
IMPORTANT: If the brushbar has been obstructed, the motor protection sensor may have been activated.
The brushbar will stop and the light on the Powered Head will illuminate red. To reset, remove the Powered Head
from the reach wand/handheld and clear any obstruction. Wait 1 minute before retting the Powered Head, switch
the slim vac on and press the brushbar on/o button.
Press the Powered Head/
accessory release clip
and pull to remove the
Powered Head from the
reach wand.
Check the Powered Head
for any blockages and use
a blunt object to remove
the blockage.
Using scissors, remove
any threads or hair from
around the brushbar and
clear any dirt or debris
from the Powered Head.
Let’s talk technical
Removing and replacing the brushbar
A
On the base of the
oorhead, nd letter A
to indicate the side of
the brushbar cover that
needs to be removed.
To re-t the brushbar, rstly push the brushbar onto
the brushbar cover, then slide the brushbar and cover
back into the brushbar housing. Make sure the end of
the brushbar sits securely in place. Ret and tighten
the screws to secure.
Using a cross head
screwdriver, unscrew the
three screws and remove
the brushbar cover.
Removing and replacing the belt
Slide the brushbar out
from the brushbar housing.
Clear any threads or
hair from around the
brushbar and any dirt/
debris inside the housing
of the Powered Head.
B
On the base of the
oorhead, nd letter B
to indicate the side of
the belt cap that needs
to be removed.
Using a cross head
screwdriver, unscrew the
three screws and remove
the cover.
If the belt is broken,
remove this and slide the
new belt onto the cogs.
Ret the belt cover and
tighten the screws to
secure.
Accessories
Also available Vax Cordless Blade Tools
Order at: www.vax.co.uk/spares-and-solutions
Refer to ‘Using your machine’ section for tool assembly instructions.
Vax Cordless Blade tools
Crevice Tool
1-9-138758
The crevice tool is ideal for use all around the home.
It’s perfect for those tricky corners and crevices.
Dusting Brush
1-9-138759
The dusting brush is ideal for dusting furniture
and hard surfaces such as sofas and shelving.
Pet/Stair Tool
1-9-138760
An ideal tool to help tackle those pet hairs! Simply clip this
tool onto the handheld and begin cleaning. The rubber
teeth are designed to agitate ne hair on both carpets and
hardoor. This tool is also great for stair cleaning!
What to do if it goes wrong
SolutionProblem
There is an
accessory missing
Why does my slim vac
have no power?
Why isn’t my slim vac
charging?
Why won’t the slim vac
pick up?
Why is the red light on?
• Check the contents panel on the box to make sure the part is included
with your slim vac.
• The battery may not be charged. Go to ‘Getting Started’.
• The motor thermostat may have tripped. If this has happened, switch o the slim vac.
Empty the dirt container and check for blockages. Clean the lters and allow the slim
vac to cool for approximately 1 hour (if you have washed the lters you will need to wait
24 hours for the lters to fully dry before putting them back into the slim vac).
• Check the battery charger is plugged in. Go to ‘Getting started’.
• The slim vac may be warm from use. Allow the slim vac to fully cool before retrying.
• The lters or separator are not correctly tted. Go to ‘Taking care of your machine’.
• The lters may be clogged, clean the lters. Go to ‘Taking care of your machine’.
• The dirt container may be blocked, empty the dirt container. Go to ‘Taking care of your
machine’.
• The brushbar on the Powered Head has not been activated. Go to ‘Using your machine’.
• There maybe a blockage in the reach wand. Disconnect from the slim vac and carefully
remove any blockages. Go to ‘Let’s talk technical’.
• Low suction has been selected. Activate the boost mode to increase suction. Go to
‘Using your machine’.
• The Powered Head may be blocked. Go to ‘Taking care of your machine’.
• Battery charge is running low (<25%). Go to ‘Getting started’.
• If the brushbar has been obstructed the motor protection sensor may have been
activated. The brushbar will stop and the light on the Powered Head will illuminate
red. To reset, remove the Powered Head from the reach wand/handheld and clear any
obstruction. Wait 1 minute before retting the Powered Head, switch the slim vac on and
press the brushbar on/o button. Go to ‘Lets talk Technical’.
Why won’t the Powered
Head brushbar turn?
Why is dust escaping
from the slim vac?
• The Powered Head brushbar has not been activated. Go to ‘Using your machine’.
• If the brushbar has been obstructed the motor protection sensor may have been
activated. The brushbar will stop and the light on the Powered Head will illuminate
red. To reset, remove the Powered Head from the reach wand/handheld and clear any
obstruction. Wait 1 minute before retting the Powered Head, switch the slim vac on and
press the brushbar on/o button. Go to ‘Lets talk Technical’.
• The slim vac, oorhead and reach wand may not be correctly tted. Reassemble and
retry. Go to ‘Getting started’.
• The Powered Head may be obstructed. Go to ‘Let’s talk technical’.
• The lters may be clogged, clean the lters. Go to ‘Taking care of your machine’.
Getting in touch
†
Registration required. Terms and conditions apply, see vax.co.uk for details.
Notes
Notes
GET IN TOUCH
0330 026 8455 VaxVacuumsinfo@vax.co.uk vax.co.uk @Vax UK
EU Statement of Compliance: Manufacturer/EU importer: Vax Limited, hereby on our own responsibility, declare that the
TBT3V1B1/ TBT3V1P1/TBT3V1P2/TBT3V1B2/TBT3V1F1/TBT3V1H1 are manufactured in compliance with the following Directives:
Safety: 2014/35/EU Low Voltage Directive. EMC: 2014/30/EU Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
© 2016 Vax Limited. All rights reserved. The VAX trade mark and Vax lozenge are the property of Techtronic Floor Care
Technology Ltd and are registered in the EU and may be pending or registered in other countries.
This marking on the product(s) and/or accompanying documents means that used electrical and electronic equipment (WEEE)
should not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to
designated collection points where it will be accepted free of charge. Disposing of this product correctly will help save valuable
resources and prevent any potential negative eects on human health and the environment, which could otherwise arise from
inappropriate waste handling. Please contact your local authority for further details of your nearest designated collection point.
Loading...
