Vax Steam Clean Multi S85-CM Let's Get Started

SteamClean

MU LTI

MULTIFUNCTION STEAMER

S85-CM

LET’S GET STARTED.

Basic
safety
precautions

Don’ts

Do’s

This STEAMER is intended for household use only and NOT
for commercial or industrial use.

WARNING: Danger of scalding

• Only use the steamer indoors and keep the area you’re
cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the steamer.

• This steamer can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.

• Don’t touch any hot areas/accessories on your steamer. It’s
normal for the steamer and accessories to heat up during use,
always allow them to cool down before handling.

• Don’t leave the steamer turned on when unattended.

• Don’t use the steamer if it has been dropped, damaged,
immersed in water or left outdoors.

• Don’t run over the power cord or use steamer if the power cord
or plug is damaged. Please contact our Customer Care Line.

• Don’t handle the plug or use the steamer with wet hands. Don’t
pull or carry the steamer by the power cord.

• Always ll the water tank with water only. Never add perfume,
stain remover or products containing alcohol. Filling the water
tank with hot or boiling water will damage the steamer and
invalidate the guarantee.

• Always vacuum your carpets thoroughly and ensure hard oor
areas are free from grit and debris before using your steamer.

• Always unplug the steamer and allow to cool before carrying
out any maintenance.

• Turn o all controls on the steamer before disconnecting or
connecting the power cord, after use always wrap the power
cord around the cord clips.

Let’s talk safety

Children shall not play with the steamer. Cleaning and user maintenance
shall not be performed by children without supervision.

• Please refer to oor manufacturer’s care recommendations before use, and
test your ooring/carpet/rugs by running the steamer over a small hidden
area, if no pile distortion or no damage occurs continue cleaning. Not suitable
for use on wax polished oors or furniture, acrylic surfaces and synthetic,
velvet or steam/water sensitive materials.

• This steamer should not be used to clean electrical appliances such as
microwaves, televisions and electrical heating systems etc.

• Only Vax recommended cloths and accessories should be used with
this steamer. This steamer is a water only product, using detergents will
invalidate the guarantee.

• Don’t use the power cord as a handle, don’t pull the power cord around
corners or sharp edges or close a door over the power cord. Don’t unplug
the steamer by pulling on the power cord.

• Don’t attempt to remove blockages with sharp objects as this may cause
damage to the steamer, remove blockages only as instructed in this guide.

• Don’t aim the steamer at people, animals, plants and electrical components
or wires. Never touch the steam jet (there is a risk of scalding).

• Don’t use the steamer with incorrect voltage as this may result in damage
or injury to the user. The correct voltage is listed on the ratings label.

• Don’t use the steamer to clean or refresh any items of clothing that are still
being worn on the body.

• Take extra care when cleaning on the stairs.

• Always replace the fuse in the plug with a British 13amp fuse. Always protect
the power cord from heated surfaces and open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords
can overheat. Care should be taken to arrange the extension cord as it could
be a trip hazard.

• Store the steamer in a cool, dry area away from children. Before storing the
steamer please make sure the water tank is thouroughly clean and empty.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY
AS INSTRUCTED IN THIS GUIDE.

Thank you for buying this Steam Clean Multi

Taking care of your sealed hard oors and surfaces

The Steam Clean Multi is designed to make steam cleaning your hard oors and surfaces
regularly, as eective and ecient as possible, and this user guide will help you get the most
out of your machine.

Maintaining your hard oors and surfaces with the Steam Clean Multi will ensure they
keep looking beautiful and are hygienically clean.

Taking care of your Multifunction Steamer

Also inside this guide are instructions on maintaining your new machine, so that
it’s always ready when you are to tackle your hard oors and surfaces.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back
to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,
Worcestershire, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

What to do if it goes wrong

Getting in touch

Accessories

Notes

Carpet Glider

Grout Brush

Small Round Brush

Squeegee

Measuring Jug

Concentration Nozzle

Microbre Pad

Utility Head Pad

Utility Head

Steam Clean Multi

Included with
your machine

Contents

Handheld steam trigger (hidden)

Handle

Handheld handle

Subject to technical change without notice.

*To purchase consumables and accessories, please visit vax.co.uk

Handle release button

On / o & steam control dial

Floorhead

Quick cord release hook

Accessory oorhead
release button

Power on indicator

Water tank cap

Water tank (Part of unit)

Carpet glider

Quick cord release hook

Getting to know your machine

Name Steam Clean Multi S85-CM
Voltage 220-240v˜50Hz
Wattage 1300w
Cord length 5m
Weight 2.5kg

Technical Specication

Microbre Cleaning Pads
(Type 1)

1-1-131448-00

Pro Cleaning Pads (Type 6)

1-1-132319-01

Coral Cleaning Pads (Type 3)

1-1-131643-00

Carpet Glider (Type 3)

1-1-133527-00

Accessories & Consumables

Push the main body down into the
oorhead until it clicks into place.

Stand the steamer upright by pushing the
main body forward to lock into position.

Push the handle into main body until it
clicks into place. The collar should be gripped
when connecting or releasing the handle.

Assembling your steamer

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Before you Begin
WARNING

• The steamer and accessories get very hot during use, always allow them to cool down before handling.

• Always unplug and switch o the steamer when assembling or disassembling.

• Always switch o the steamer before emptying the water tank or changing the cloths/accessories.

IMPORTANT

• Please refer to oor manufacturer’s care recommendations before use and test the steamer on a hidden area of ooring

to begin with.

• Test for colour fastness in a small hidden area of upholstery/fabric to check for colour removal before use.

• When using the steamer, basic safety precautions should always be observed.

• Don’t aim the steamer at people, animals, plants and electrical components or wires. Never touch the steam jet or oorhead

from a short distance (there is a risk of scalding).

• The steamer is equipped with a thermostat and a thermal cut-out. If for any reason the steamer overheats it will switch o.

If this happens turn o and unplug the steamer, allow to cool for at least 2 to 4 hours and re-try.

• Don’t use hot or boiling water to ll or clean water tank

Getting started

Remove oorhead and handle
and place steamer on at
surface. Twist water tank
cap anti clockwise and lift
to remove.

Correct

Incorrect

Do not ll directly from tap
or over sink. Keep steamer
on at surface. Use the
measuring jug and ll the
tank with 330ml (2 x 165ml)
of water.

Replace cap, align tabs
and twist clockwise

to tighten.

IMPORTANT

• Never turn the steamer over when water is in the tank, as some water may leak through the air valve.
It is normal for the water tube to make a rattling sound inside the water tank during use.

Filling water tank

Cleaning hard oors

Place the microbre pad on the
oor white side facing up. Place the
oorhead onto microbre pad making
sure the microbre pad covers the
entire oorhead.

Plug into mains, turn dial to ‘ON’;
the red light will illuminate to indicate power
on. The steamer will be ready after
approximately 30 seconds. There will be no
sounds for the rst 30 seconds whilst it is
heating up.

To steam your oors twist the steam
control dial to desired setting. Steam
is activated automatically. Take
care when changing settings
during cleaning.

Place foot onto the oorhead and
pull handle backwards to recline.

Turn dial to ‘OFF’ position and allow
steamer to cool, the amber light will
switch o. Hold corner of pad down with
your foot and lift steamer to peel away.

IMPORTANT

• Never use the steamer without a microbre cleaning pad attached to the oorhead.

• Never leave the steamer on one spot for an extended period of time or with a damp or wet microbre pad attached as this

may damage the oor surface.

Move the steamer slowly backwards
and forwards across the oor paying
particular attention to high trac areas.

Using your machine

TIP

The water tank cap
has lock and unlock
padlock symbols.

IMPORTANT: When using on carpets, always make sure the microbre cleaning pad is used and covers the oorhead entirely
before using the carpet glider. Only use the carpet glider when refreshing carpets.

Place the microbre pad on
the oor white side facing
up. Place steamer onto pad
making sure the entire pad
covers the oorhead.

Twist the steam control dial
to desired setting.

With microbre pad
attached, push steamer
into front of the carpet
glider, then place back
of the oorhead into the
clip. The carpet glider
should only be used
when refreshing carpets.

Plug into mains, turn dial to
‘ON’ position, the red light will
illuminate to indicate power on.
There will be no sounds for
the rst 30 seconds whilst it is
heating up.

Place your foot on
oorhead and pull handle
backwards to recline.

Refreshing carpets

Move the steamer slowly
backwards and forwards
across the carpet paying
particular attention to high
trac areas.

To release the carpet glider,
place your foot on clip and
push down. Lift steamer to
remove.

Steam is activated automatically.
Take care when changing
settings during cleaning.

Using your machine

Switch OFF and allow
to cool rst. Steam is
automatic in stick mop
mode.

CAUTION

Using the machine as a handheld

IMPORTANT: The handheld is to be used with water only, putting detergent into the water tank can cause damage.

Always check the tools are clean and free from debris, don’t use if damaged, broken or worn.

Push handle release button and lift
handle to remove . The collar should be
gripped with one hand when releasing
the handle with the other hand.

Push concentration nozzle into steamer
until it clicks into place.

Press accessory release button and lift
steamer to release oorhead.

Plug into mains, turn the dial to ‘on’
position. The red light will illuminate to
indicate power on.

To produce steam squeeze the trigger in short bursts. Don’t hold the trigger
continuously to prevent over wetting. Allow 30 seconds for steamer to
warm up. No sound will be heard until trigger is pressed. No steam will be
visible until after 30 seconds.

Twist the steam control dial to
desired setting.

Using your machine

Always switch OFF the
steamer before attaching
the concentration tool and
accessories.

CAUTION

WARNING: Never use the squeegee on cold glass/windows as it may cause damage.

Stretch utility pad over
utility head.

Push utility head and pad into steamer until
secure. It will not lock into place. Pull test
to check it is secure.

Small tools can be attached via the
concentration nozzle. Push together to
click into position and secure. Push hard
and ensure click is heard. Add pull test on
brushes to check tools are secure.

Push utility head and squeegee
into steamer until secure. It will
not lock into place but should sit
rmly against steamer.

Attaching accessories

Attaching brushes Attaching utility head

Attaching squeegee

Align the tab on the squeegee with the
utility head and utility pad, push together
to lock into position. Please note that the
utility pad must be attached to the utility
head before the squeegee can be tted
on. Squeegee will not connect without
the pad on rst.

To remove, pull squeegee down
on tab.

Using your machine

TIP

After attaching your
chosen accessory
gently pull to make
sure it’s locked into
place or feels secure.

IMPORTANT: Taps should be turned o when steaming around them. Don’t steam clean ovens, oven surfaces or grills when hot,
allow to cool to room temperature rst.

Ideal for any surface from tiles, sinks,
toilets and oven tops.

Use to remove soap scum in baths and
shower enclosures and to clean heavily
soiled areas in kitchens.

Using the accessories

Lifts embedded dirt from inbetween tiles.

Attach utility pad to utility head for
use on upholstery and clothes.
Do not use detergent on fabrics
and upholstery.

Great for leaving your windows, tiles
and mirrors gleaming.

Concentration nozzle Small brush Grout brush

Utility head and pad Squeegee

Test for colour fastness in
a small hidden area of
upholstery/fabric to check
for colour removal
before use.

CAUTION

Using your machine

Unplug, remove oorhead and handle place
steamer on at surface. Twist water tank
cap anti clockwise and lift to remove.

Emptying the water tank

Empty any excess water
over an empty sink.

IMPORTANT: Don’t use bleach or fabric softener when washing the microbre cleaning pad. Always allow the steamer
to fully cool down before removing the microbre cleaning pad.

IMPORTANT: Never remove the water tank cap with the product upright as water could leak out–always remove the oorhead
and handle and place on a at surface before removing the water tank cap.

The microbre/utility cleaning pad are machine
washable (Max 40⁰C) allow to fully dry
before use. Utility head pad is hand wash only.

Cleaning the microbre/utility cleaning pad

MAX

40˚C

24hr

Ensure steamier is
unpluged before
emptying water tank.

CAUTION

Taking care of your machine

Clearing blockages

IMPORTANT: Turn dial on steamer to ‘OFF’ position, switch o at mains and unplug safely.
Allow to fully cool down before performing maintenance or troubleshooting checks.

Use a small thin object such as a
paperclip to insert into the nozzle and
clear any blockage.

To clear a blockage in the oorhead,
remove the microbre pad from the
oorhead, insert a small thin object,
such as a paperclip, into the steam
holes to remove any blockage.

Push the accessory oorhead
release button and lift the main
body from the oorhead to remove.
Also remove the handle.

Let’s talk technical

Don’t forget your accessories!

Order at: www.vax.co.uk/spares-and-solutions

2x Microbre Cleaning Pads (Type 1)
1-1-131448-00

Microbre cleaning pads, ideal to remove dirt and
grime. These cleaning pads attach to the base of the
steamer so it’s quick and easy to t and remove.

Pro Cleaning Pads (Type 6)
1-1-132319-00

3x pro cleaning pads. Ideal for stubborn stain
removal throughout your home. These cleaning
pads attach to the base of the steamer
so it’s quick and easy to t and remove.

Steam Mop Cleaning Pads
1-1-131864-00

2x microbre cleaning pads, ideal to
remove dirt and grime.
2x coral cleaning pads for your steamer.
Super absorbent and ideal for removing stubborn stains.

Total Home
1-1-132528-00

8x microbre cleaning pads. Avoid cross contamination
between dierent areas of your home with this Total Home
Cleaning Kit. Kit contains 8 x coloured microbre cleaning
pads for all areas of your home. Kit also contains a free wash
bag worth £9.99.

3x Microbre Cleaning Pads (Type 2)
1-1-133071-00

3 washable microbre cleaning pads for everyday
hard oor cleaning. Drawstring attachment ideal for
everyday cleaning. Washing machine washable for
continuous use.

Coral Cleaning Pad Kit (Type 3)
1-1-131643-00

2 coral cleaning pads – super absorbent washable
pads, ideal for subborn stains and cleaning uneven
surfaced such as slate.

Accessories

WARNING: Always unplug the steamer before performing maintenance/troubleshooting checks.

What to do if it goes wrong

• Check the ‘This pack contains’ panel on the box to make sure the part
is included with your steamer.

• Check the on/o control dial position

• Check the amber light is illuminated

• The plug may not be fully pushed into the electrical socket

• Check the fuse in the plug if this needs replacing, always replace with
a British 13amp fuse

• The microbre pad may already be saturated or dirty. Wash the
microbre cleaning pad, go to ‘Taking care of your machine’.

• There may be no water in water tank, check the water tank has water

• Check the water tank cap is securely tted onto the water tank

• The water may not yet be at temperature . The steamer will take approximately
30 seconds to heat up

• Steam path may be blocked. Go to ‘Let’s talk technical’

• Check steam control dial has been turned to ‘on’

• Water tank level may be low, rell with water

• If using as a stick mop - handle may not be fully inserted. Release handle,
press handheld trigger to check steam is working. Re-insert handle until
it clicks into place.

SolutionProblem

Is there an accessory
missing?

The steamer has
no power?

Why is the steamer
not producing steam?

Why won’t the microbre
pad pick up dirt?

†

†

Registration required. Terms and conditions apply, see vax.co.uk for details.

* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.

Getting in touch

Notes

Notes

GET IN TOUCH

0330 026 8455 [e-mail] vax.co.uk @VaxUK

EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
S85-CM manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive.
EMC: 2004/108/EC Electromagnetic Compatibility Directive.

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.

© 2015 All rights reserved. VAX®, VAX Logo, are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
