This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
READ ALL THE INSTRUCTIONS BEFORE USING
THIS APPLIANCE
safety
precautions
Don’ts
• Only use the vacuum cleaner indoors and keep the area you’re
cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and
openings whilst using the vacuum cleaner.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Do not pull or carry by cord, use cord as a handle, close a door
on cord, or pull cord around sharp edges or corners. Do not
place product on cord. Do not run appliance on cord.
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t use the vacuum cleaner with incorrect voltage as this may
result in damage or injury to the user. The correct voltage is
Do’s
listed on the rating label.
• Don’t vacuum up hot coals, cigarette butts, ash, matches or
smoking hot burning items or use in an area where there may be
harmful uids (chlorine, bleach, and ammonia drain cleaner).
• Always make sure the lter and dirt container are tted
correctly before using your vacuum cleaner.
• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the battery.
• Take extra care when cleaning on the stairs.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Always protect the charger cord from heated surfaces
or near open ames.
Children should not play with the vacuum cleaner. Cleaning and user
maintenance should not be made by children without supervision
• Only Vax recommend tools and accessories should be used with this
vacuum cleaner
• Vax recommends the use of a Residual Current Device rating of 30 mA or less.
• If the supply cord is damaged, it must be replaced by the manufacturer,
or similarly qualied person in order to avoid a hazard, or invalidating
the warranty.
• IMPORTANT: The motor is equipped with a thermal cut-out. If for any
reason the unit should overheat, the thermostat will automatically turn the
unit o. Should this occur, unplug the vacuum cleaner from the electrical
outlet and turn o the switch. Remove dirt container and empty. Clean
lters. Allow the unit to cool for approximately one (1) hour. To re-start,
plug into an electrical outlet and switch back on.
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to the vacuum cleaner.
• Do not vacuum hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t not vacuum plaster dust, concrete dust or any other building
or vitreous material.
• Do not vacuum our, baking soda or any other powder-based carpet
refresher or deodoriser.
• Don’t use this vacuum cleaner if it has been dropped, damaged or left outdoors.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Use only SAA approved 10amp extension cords. Care should be taken to
arrange the extension cord as it can be a trip hazard.
• Always carry the vacuum cleaner by the handle.
• Store your vacuum cleaner in a cool, dry area.
• Always keep the power cord away from the brushes whilst using your
vacuum cleaner.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Thank you for buying this Pet Pro Barrel Vacuum.
Taking care of your carpets and hard oors
The Pet Pro Barrel Vacuum is designed to make vacuuming carpets and hard oors regularly
as eective and ecient as possible and this user guide will help you get the most out of your
machine. Maintaining your carpets will ensure they keep their appearance for longer. You’ve
chosen the carpets and hard oors for your home for a reason and Vax will help you take good
care of them.
Taking care of your Pet Pro Barrel Vacuum
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you are to tackle your carpets and hard oors.
*Monday – Friday: 8:30am -5:00pm
Calls are charged at the standard local rate. Please make note of the serial
number and model number of the product before calling.
Contents
Pet Pro Barrel Vacuum
Included with
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
What to do if it goes wrong
your machine
Hose and handle
TurboTool
Dusting brush
Crevice tool
Getting in touch
Accessories
Notes
Filters
Pre-motor lter
Upholstery tool
Combination oor head
Turbobrush
TurboTool connector
Hard oor tool
HEPA anti-bacterial
post-motor lter
Extension tube
and tool caddy
Double
Insulated
This product
meets applicable
regulatory
requirements
Indoor
Use
Read
Instructions
Carry handle
Dirt container
Getting to know your machine
Cyclone separator and shroud
Hose connector
Dirt bin release button
Cord rewind button
Wheel
Floor head parking slot
Variable power dial
On/o button
Technical Specication
Name Pet Pro Barrel Vacuum
Voltage 220-240V ~ 50Hz
Wattage 2400W
Cord length 8m
Weight 6.3kg
Subject to technical change without notice.
Accessories & Consumables
Filter pack*
VCP7PTFLT2
*To purchase consumables and accessories, please visit vax.com.au
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the hose/attachments,
or removing and emptying the dirt container.
Keep you Vax like new
IMPORTANT: The condition of the lters aects the performance of your machine. Please check, clean and replace
lters periodically (depending on the level of use). For full cleaning instructions, see “Cleaning the pre-motor lter”
and “Cleaning the post-motor lter”.
IMPORTANT: Do not use the vacuum cleaner with blocked lters and without all of the lters in place.
Assembling your vacuum cleaner
NOTE: The Turbobrush, hard oor tool, crevice tool, upholstery tool and dusting brush can all be attached directly
to the telescopic tube or hose handle. The TurboTool should be attached via the supplied connector.
Hard oors
Carpets
Using your machine
Operating the appliance
1
Fully unwind the power cord.
A yellow mark on the cord
indicates the recommended cord
length. Do not exceed the cord
length beyond the yellow mark.
2
Adjust the variable power dial to
increase or decrease the suction.
Taking care of your machine
WARNING: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container or before connecting/disconnecting the attachments.
IMPORTANT: Filters need to be cleaned everytime you empty the dirt container for best cleaning results.
Do not use your vacuum cleaner with blocked lters and without ALL the lters in place.
Packing away and storage
1
NOTE: For convenience there is a parking slot located at the rear of the vacuum cleaner where the oor head
and tubes can be attached for storage and carrying.
2
Emptying and cleaning the dirt container
1
2
Taking care of your machine
24hr
!
!
Cleaning the pre-motor lter
IMPORTANT: Water temperature should not exceed 40°C when washing the pre-motor lter. Allow to dry
completely before replacing in the vacuum cleaner.
Tap to remove excess dirt for
a quick clean.
40�C max
Wash when a deeper clean
is needed.
Taking care of your machine
24hr
!
!
NOTE: The shroud isaccessed by removing the dirt container lid and is located underneath the pre-motor lter.
IMPORTANT: Water temperature should not exceed 40°C when washing the shroud. Allow to dry completely
before replacing in the vacuum cleaner.
Cleaning the shroud
40�C max
tap
Taking care of your machine
Cleaning the post-motor lter
WARNING: Do not wash post-motor lter.
tap
Tap to clean.
Clearing blockages
WARNING: To reduce the risk of electric shock, the power cord must be disconnected before performing
maintenance/troubleshooting checks. Turn the vacuum cleaner o and unplug from the electrical socket.
Hose blockages
The exible hose may be disconnected from the vacuum
cleaner. Carefully remove any blockages found and
reconnect the hose securely.
Accessory blockages
Remove accessory from the hose/telescopic tube.
Carefully remove the blockage and return to the cleaner.
Operating the appliance
Tabs
Locking ring
Taking care of your machine
Turn the TurboTool over and slide
o the locking ring.
Detach lower housing and
remove blockage.
Removing blockages from the Turbobrush
To re-assemble the TurboTool,
ensure that the tabs are engaged
and pivot the lower housing
closed. Slip the locking ring over
the neck of the TurboTool and into
the groove to nish.
Switch the vacuum cleaner o
and disconnect the power plug
from the electrical outlet.
Lay the Turbobrush on a at
surface and turn over to expose
the brushbar. Using a pair of
scissors, cut through any threads
or hairs caught around the
brushes and brushbar.
What to do if it goes wrong
There is an
accessory missing.
Why won’t the vacuum
cleaner pick up?
Why is dust escaping
from the vacuum?
SolutionProblem
• Check the ‘Contents’ page in this guide to make sure the part is
denitely included in your unit.
• If it is missing, we’re here to help. Simply call us on
AUS: 1300 361 505 / NZ: 0800 800 900
• The dirt container may be incorrectly installed; remove the dirt container
from the unit by pressing the dirt container release catch and then reattaching it to the unit, ensuring it is locked rmly back into place.
• The lter may be clogged; refer to ‘Taking care of your machine’.
• The dirt container may be blocked; refer to ‘Taking care of your
machine – Cleaning the shroud’.
• The lter may be clogged; refer to ‘Cleaning the pre/post lter’.
• The dirt container may be blocked; refer to ‘‘Taking care of your
machine – Cleaning the shroud’.
• The dirt container may be incorrectly installed; remove the dirt container
from the unit by pressing the dirt container release catch and then
re-attaching it to the unit, ensuring it is locked rmly back into place.
What do I do if the unit/
an accessory becomes
damaged or broken?
Why won’t the accessories
pick up properly?
Why will the vacuum
cleaner not run?
• We’re here to help. Simply call AUS: 1300 361 505
/ NZ: 0800 800 900 or visit vax.com.au
• Hose blockages: remove the hose from the unit. Carefully remove any
blockages found and reconnect hose securely.
• Accessory blockages: remove accessory from handle/tube. Carefully
remove blockage and re-attach to the vacuum cleaner.
• The accessory may be faulty. Simply call us on AUS: 1300 361 505 / NZ: 0800 800 900 for assistance.
• It may not be plugged into the electrical outlet correctly; ensure that
the plug is pushed in securely.
• The electrical outlet may not be working properly; check the fuse
or breaker, or consult an electrician.
• The motor thermostat may have tripped; switch o and unplug the
vacuum cleaner, and leave for one hour before switching the cleaner
back on.
CAUTION: To reduce the risk of personal injury, unplug the product before performing
maintenance/troubleshooting checks.
Getting in touch
* Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.
Accessories
Don’t forget your accessories!
Order at:www.vax.com.au / www.vax.co.nz
Pro Cleaning Kit
Model no. VPCK
Crevice tool
For awkward gaps and crevices.
Upholstery attachment
Gently cleans large areas of upholstery, curtains,
sofas and chairs.
Pet hair removal attachment
Tackles stubborn pet hair on furniture, rugs and carpets.
Stubborn dust brush attachment
Removes built up dust from skirting, banisters and corners.
Radiator Tool
Long slim design, is perfect for cleaning behind
and inside the radiator.
Up Top Tool
Ideal for reaching those hard to reach
high areas.
Filter Pack
Model no. VCP7PTFLT2
Includes pre-motor lter and pre-motor lter.
Mattress Tool
Quickly and easily removes
embedded dust from mattresses.
Soft Brush
Gently removes dust and dirt
from delicate surfaces such
as tiles and glass without
scratching.
Notes
Notes
Notes
Distributed by Techtronic Industries Australia Pty. Ltd.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
Careline AU: 1300 361 505 www.vax.com.au
Careline NZ: 0800 800 900 www.vax.co.nz
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
