1. Parts Overview
The Unit
1 Hose Inlet
Located on the top of the unit
2 On/Off Button
Insert the plug into the electrical outlet. Press the
on/off switch on the top of the vacuum cleaner, to
switch the vacuum cleaner on and press the button
again to turn the vacuum cleaner off.
3 Variable Power
Located between the on/off and cord rewind
buttons.There is a variable power dial, press the ‘+’
to increase suction power and ‘-’ to reduce suction
power.
4 Floor Tool Parking Slot
For convenience there is a parking slot located at the
rear of the vacuum cleaner where the Floor Tool can
be parked for carrying and storage.
5 Plug
6 Auto Cord Rewind
To rewind the power cord, press the cord rewind
button, located on the top of the vacuum cleaner.
7 Lid Release Button
The cup opens up the unit for access to the dirt
container.
8 Pre-Motor Filter
This is located inside the unit, behind the dust bag.
9 Post Motor Filter
This is located above the pre-motor filter, just under
the lid of the unit.
10 Disposable Dust Bag (1pc fitted, 1pc loose)
The dust bag compartment is located immediately
inside the unit, it can be easily lifted out for disposal.
11 Carry Handle
Use the carry handle at the front of the vacuum
cleaner to move from room to room.
12 Tool Storage
Crevice tool and 2-in-1 tool are stored under the lid.
Retain this guide for future reference.
Bagged cylinder
Vax model number: C91-MX SERIES
GB
instruction manual
Vax careline 0870 606 1248
www.vax.co.uk
What is your vax’s serial number?
Note this down in case you need it in future
(on the base of
your cleaner)
What is your vax’s model number?
C 9 1 M X
---
8
9
1
2
1
2
7
3
4
10
11
5
6
Vax C91-MX User Guide v5.qxd:C91-MX User Guide 18/12/08 18:16 Page 1
www.vax.co.uk
The Accessories
13 2-in-1 Tool
Dusting Brush: For delicate surfaces.
Upholstery Tool: For carpet, upholstery and stairs etc
14 Crevice Tool
For crevices, corners and cracks.
15 Combination Floor Tool
For carpet and rug cleaning: Press the rocker switch
on the Combination Floor Head to raise the brushes.
For hard floor cleaning: Press the rocker switch on the
Combination Floor Head to lower the brushes.
16 Telescopic Tube
The telescopic tube can be lengthened or shorted by
pushing the button in and sliding the tube apart or
together as required.
17 Hose and Handle.
18
19
Parts Overview
To replace or purchase parts for your vacuum
cleaner, please visit our website:
www.vax.co.uk
If your Vacuum Cleaner or Accessories are Damaged/Faulty
Please Call our Vax Careline on: 0870 6061248
!
Your Filters:
18 Fibre pre-motor filter
19 HEPA post-motor filter
IMPORTANT: The condition of the filters affects
the performance of your vacuum cleaner. Please
check and wash filters periodically (depending on level
of use). For full cleaning instructions see page 4-5.
IMPORTANT: Do not use the vacuum cleaner
without all the filters in place.
2
parts overview
Replacement filter kits are available at www.vax.co.uk
!
!
KEEP YOUR VAX LIKE NEW!
15
13
1
3
1
4
14
16
17
Vax C91-MX User Guide v5.qxd:C91-MX User Guide 18/12/08 18:16 Page 2
V
ax Careline 0870 606 1248
3
assembly / attachments / operation
2. Assembling your vacuum cleaner
3. Choose the attachments for the job
4. Operating the appliance
WARNING: Always switch off and unplug the vacuum cleaner from the electrical outlet before assembling,
opening or emptying the dirt container, or before connecting/ disconnecting the attachments.
5. Packing away and storage
NOTE: When rewinding the power cord, guide the cord
with one hand, This will prevent the cord from whipping
which could cause damage or injury.
NOTE: For convenience there is a parking slot located at
the rear of the vacuum cleaner where the floor tool and
hose can be parked for carrying and storage.
IMPORTANT: Always unplug the vacuum from the electrical
outlet and rewind the power cord as directed before storing.
!
!
NOTE: Fully unwind the
power cord. A yellow
mark on the power cord
indicates the
recommended cord
length. Do not exceed
the cord length beyond
the red mark.
CLICK!
13
14
15
Vax C91-MX User Guide v5.qxd:C91-MX User Guide 18/12/08 18:16 Page 3
www.vax.co.uk
4
dirt container / filters
6. Dirt Container: Maintenance
Removing the Dirt Bag
7. The Filters: Maintenance
Cleaning the Pre-Motor Filter
Fibre pre-motor filter
IMPORTANT : Always switch off and unplug the
vacuum cleaner from the electrical outlet before
removing the Dirt Container.
NOTE : When the dirt bag is full, dispose of it and insert a
new dirt bag. Click the bag into place then close the lid.
!
IMPORTANT : Do NOT use the vacuum without ALL
of the filters in place.
NOTE :
Vax recommends that the pre- and post-motor filter
should be checked and cleaned periodically depending on the
frequency of use and the volume of dirt being picked up on
each occasion.
IMPORTANT: Your vax vacuum cleaner is fitted with high performance filters it is essential that these are well
maintained and cleaned according to the following instructions.
!
!
24
Dispose
Tap
Vax C91-MX User Guide v5.qxd:C91-MX User Guide 18/12/08 18:16 Page 4
