www.vax.co.uk
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
R
e
tain f
or future reference.
instruction manual
Bagged cylinder
Vax model number:
V-102E
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 1
V-102E
1. Diagram
www.vax.co.uk
2
parts overview
Fig.1/1
1 Hose inlet
2 On/off button
3
V
ariable power
4 Parking slot
5 Auto cord rewind
6 Plug
7 Dirt container release clip
8 Pre-motor filter
9 Post-motor filter
10
Disposable dus
t bag
11 Carry handle
12
2-in-1 t
ool
13
Cr
e
vice t
ool
14 Combination floor tool
15 Hard floor tool
16 TurboTool
17
T
urboBrush
18 Telescopic extension tube
19
Hose and Handle
9
8
2
3
4
5
6
10
11
19
16
18
17
15
1
7
14
13
12
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 2
3
V-102E
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
connecting or disconnecting from the mains supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
6. Use only as described in this manual.
Use only the manufacturer’s recommended
attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord or plug is
damaged, return the vacuum cleaner to a Vax
Authorised Service Agent or suitably qualified
person for examination, repair or adjustment.
8. Do not pull or carry by the cord. Do not use the cord
as a handle, close a door on the cord or pull the cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air
flo
w. K
eep all openings fr
ee of dust, lint, hair or
anything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches or
any hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material (chlorine
bleach, ammonia, drain cleaner, etc).
1
5. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16. Do not use without the filters in place.
17. Take extra care when vacuuming stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner indoors in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner.
21. Use only CE-approved 13 amp extension cords.
Non-approved extension cords may overheat. Care
should be taken to arrange the cord so that the cord
cannot be pulled or tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet
before assembling, opening or emptying the dirt
container, or before connecting/disconnecting the
attachments.
CAUTION: The vacuum cleaner is a very
powerful unit. Before plugging the cord into
the electrical outlet, make sure the switch is in the
‘off’ position.
IMPORTANT: If the inlet, hose or telescopic
tube is blocked, switch off the vacuum cleaner
and remove the blockage(s) before re-starting the
vacuum cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Make sure all the filters are
completely dry before inserting back into the vacuum
cleaner.
This vacuum cleaner is intended for household use only
and not for commercial or industrial use.
!!!
!
Motor Thermostat
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason, the vacuum cleaner should
o
v
er-hea
t, the thermostat will automatically turn the
unit o
ff. Should this occur, unplug the vacuum cleaner
from the electrical outlet and turn off the switch.
Remove the dirt container and empty. Clean the
filters. Allow the cleaner to cool for approximately one
(1) hour. To re-start, plug into an electrical outlet and
switch back on.
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 3
www.vax.co.uk
4
assembly
3. How to Assemble
IMPORTANT: Always unplug the vacuum
cleaner from the electrical outlet before
assembling or removing the accessories.
Insert the flexible hose into the inlet on the main body of
the vacuum cleaner. Push in until it clicks into position
(Fig.3/1).
Push the telescopic extension tube on to the end of the
handle (Fig.3/2).
The telescopic extension tube can be lengthened or
shortened by pushing the button in and sliding the tube
apart or together as required (Fig.3/3).
Fit the combination floor head by pushing onto the
extension tube (Fig.3/4).
Fig.3/1
Fig.3/2
Fig.3/4
Fig.3/3
!
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 4
5
V-102E
operation / accessories
4. How to Operate
Cord Release
Fully unwind the power cord. A yellow mark on the power
cord indicates the recommended cord length. Do not
exceed the cord length beyond the red mark.
On/Off Button
Insert the power plug into the electrical outlet. Ensure the
vacuum cleaner is switched off.
Press the on/off button located on the top of the vacuum
cleaner and press the button again to turn the vacuum
cleaner off.
Combination Floor Tool
Carpet Cleaning:
For carpet and rug cleaning press the rocker switch
on the combination floor head to raise the brushes.
Hard floor cleaning:
For hard floor cleaning, press the rocker switch on the
combination floor head to lower the brushes.
Cord Rewind
To rewind the power cord, press the cord rewind button,
located at the rear of the vacuum cleaner, and guide the
power cord with one hand. This will prevent the cord from
whipping which could cause damage or injury.
Variable Power
Located between the on/off and cord rewind buttons
there is a variable power dial. Press the ‘+’ button to
increase suction power and the ‘-’ button to reduce the
suction power.
Carry Handle
Use the carry handle located at the front of the vacuum
cleaner to move from room to room.
Hose Storage
For convenience there is a slot located located on the back
and underside of the vacuum cleaner where the extension
tube can be parked for carrying and storage.
5. Accessories
The accessories can be attached directly to the handle by
removing the telescopic tube and pushing in the desired
accessory.
The accessories can also be attached to the telescopic
tube for extra reach. Remove the combination floor head
and push on the desired accessory.
NOTE: The crevice tool and 2-in-1 tool are stored in the
lid of the machine above the dust bag compartment.
Crevice tool:
for crevices, corners and cracks, etc.
2-in-1 tool:
Dusting brush:
for delicate surfaces.
Upholstery tool: for carpets, upholstery, stairs, etc.
TurboBrush: for large carpeted areas.
NOTE: The TurboBrush is not recommended for use on
hard floors
TurboTool:
for pet hair, stair and upholstery cleaning
NOTE: Do not use the TurboTool on suede and leather
surfaces.
Hard floor tool:
for hard floor, parquet and laminate
coverings.
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 5
www.vax.co.uk
6
dirt container &filters
6. Dust Bag and Filters:
Removal and Replacement
WARNING: Always unplug the vacuum cleaner
from the electrical outlet before removing the
dirt container.
W
ARNING: Do NOT use the vacuum cleaner
without ALL of the filters in place.
Emptying the Dust Bag
NOTE: The dust bag must be replaced every time the
bag full indicator remains permanently illuminated or
the bag is full.
Turn off the vacuum cleaner and unplug from the
electrical outlet. Lift up the top cover to gain access to
the dust bag compartment. Remove and dispose of the
full dust bag and insert a new dust bag (Fig.6/1).
Cleaning the Filters
NOTE: Do NOT use any detergents or boiling water to
wash the filters. Vax recommends checking the
filters every time you replace the dust bag.
Cleaning the pre-motor filter
Turn off the vacuum cleaner and unplug from the
electrical outlet. Lift up the top cover to gain access to
the dust bag compartment.
Lift out the pre-motor filter situated at the back of the
compartment (Fig.6/2.
Shake off excess dirt and dust over a dustbin. The premotor filter can be rinsed in cold water to clean. The premotor filter must be allowed to air dry completely before
being replaced back in the unit (Fig.6/3).
Removing the Post-motor filter
Open the lid to the dust bag as previously directed.
Lift up the latch of the post motor filter and pull towards
the front of the machine (Fig.6/4).
Tap the pre-motor filter gently on the side of the rubbish
bin to remove excess dirt and dust (Fig.6/5).
When the post-motor filter becomes clogged or
discoloured, it should be replaced. Vax recommends that
this filt
er is r
eplaced e
v
ery 9-12 mon
ths.
!
!
Fig.6/1
Fig.6/4
Fig.6/5
Fig.6/3
Fig.6/2
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 6
TABS
7
V-102E
clearing blockages
7. Clearing Blockages
WARNING: To reduce the risk of electric shock,
the power cord must be disconnected before
performing maintenance or troubleshooting checks.
Turn the vacuum cleaner off and unplug from the electrical
outlet.
The flexible hose can be disconnected from the vacuum
cleaner by pushing in the button on the hose and pulling
away from the machine. Remove any blockages found then
re-connect the hose securely.
Removing debris from the TurboTool
Switch the vacuum cleaner off and disconnect the power
plug from the electrical outlet.
Rotate the locking ring 180º (Fig.7/1).
Lift the top cover off and remove any blockage (Fig.7/2).
To re-assemble, ensure that the tabs are engage. Pivot the
lower housing closed and rotate the locking ring 180º
(Fig.7/2).
R
emoving debris from the TurboBrush
The brushbar will stop rotating if it is blocked during
operation by vacuuming up foreign objects, or is strands of
carpet are wrapped around it.
Switch the vacuum cleaner off and disconnect the power
plug from the electrical outlet.
Lay the TurboBrush floor head on a flat surface and turn
over to expose the brushbar. Using a pair of scissors, cut
through any threads or hairs caught by the brushbar that
have wrapped around the guides (Fig.7/3).
NOTE: The brushbar will also stop rotating if the
central filter is clogged.
L
OCKING RING
Fig.7/1
Fig.7/2
!
Fig.7/3
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 7
www.vax.co.uk
8
storage / troubleshooting
8. Storage
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet and rewind the power
cord as directed before storing.
NOTE: Always store the vacuum cleaner base down.
9. Troubleshooting
WARNING: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: Vacuum cleaner won't run
Cause:
Not properly plugged into electrical outlet.
Solution: Plug in securely.
Cause: No electricity in the electrical outlet.
Solution: Check fuse or breaker.
Cause: On/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Motor thermostat has tripped.
Solution: Switch off and unplug the vacuum cleaner.
Leave for one (1) hour before switching the
vacuum cleaner back on.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause:
Dust bag not installed properly.
Solution: Review dust bag replacement.
Cause: Dust bag full or blocked.
Solution: Empty dust bag.
Cause: Clogged filters.
Solution: Remove, clean and replace filters.
PROBLEM: Accessories won’t pick up.
Cause:
Accessories are not attached correctly.
Solution: Refer to section 5.
Cause: TurboBrush / TurboTool is clogged.
Solution: Refer to section 7.
Cause: Hose is not installed correctly.
Solution: Refer to section 7.
!
!
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 8
9
V-102E
uk service & help
P
ROBLEM: Dust escaping from the vacuum cleaner.
Cause:
Dust bag full.
Solution: Empty dust bag.
Cause: Dust bag not installed correctly.
Solution: Review dust bag replacement.
Cause: Hose is not installed correctly.
Solution: Review installation.
Cause: Filter not installed completely.
Solution: Remove, clean and replace filters.
10. Service & Help
www.vax.co.uk
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 9
www.vax.co.uk
10
technical specification
11. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2000W
Capacity: 3.5 litres approx
Filters: Fibre pre-motor filter
HEPApleated post-motor filter
Cord length: 6.5m approx
Weight: 7.1kg approx
Subject to technical change without notice.
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 10
11
V-102E
This page has been left intentionally blank
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 11
---
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that
the V-102E SIRRUS bagless cylinder is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
W
aste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
www.vax.co.uk
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 12
Loading...
