Vax H85-GA-P18 Instruction manual

Gator

HANDHELD

CORDLESS CONVENIENCE FOR
QUICK EVERYDAY CLEAN UPS

LET’S GET STARTED.

H85-GA-B10
H85-GA-B15
H85-GA-P18

Let’s talk safety

Basic
safety
precautions

Don’ts

This handheld is intended for household use only and NOT for
commercial or industrial use.

• This handheld is for indoor use only.

• For dry debris use, not to be used on wet surfaces.

• Keep ngers, hair and loose clothing from moving parts
and openings whilst using the handheld.

• Don’t charge the handheld outdoors

• Don’t use this handheld if it has been dropped, damaged,
immersed in water or left outdoors.

• Don’t run over the charger cord or use handheld if the Charger
cord or plug is damaged. Please contact our Customer Care Line
on: 0844 4128 455 (Mon-Fri 8.30am to 6.30pm, Sat 9.00am
to 5.00pm).

• Don’t handle the plug or use the handheld with wet hands.

• Don’t throw the handheld into re or expose to high
temperatures, as the handheld contains a rechargeable nickel
cadmium battery which may cause damage or burst.

• Only Vax recommend charger, tools and accessories should be used with
this handheld.

• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.

• Don’t pull or carry this handheld by the charger cord. Don’t use the charger
cord as a handle, pull the charger cord around corners or sharp edges or
close a door over the charger cord. Don’t unplug handheld by pulling on the
charger cord.

• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your handheld.

• Don’t use the handheld charger with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).

Do’s

• Always make sure lter and dirt container are tted correctly
before using your handheld.

• Always turn o the Gator handheld vacuum and disconnect the
charger before carrying out any maintenance.

• Turn o all controls on the handheld before disconnecting
or connecting the charger.

• Take extra care when cleaning on the stairs.

• Always replace the fuse in the plug with a 13amp fuse.

• Always protect the charger cable from heated surfaces or near open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.

• Always carry the handheld by the handle.

• Store your handheld in a cool, dry area.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Thank you for buying this Gator.

Taking care of small cleaning tasks

The Gator range is designed to make cleaning as quick and convenient as possible and this user
guide will help you get the most out of your machine.

The Gator range is perfect for small cleaning tasks on surfaces and upholstery.

Taking care of your Gator

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you need to tackle those small jobs.

Handle

On/O switch

Charging indicator
(red LED)

Gator 10.8V & 15.6V

Included with
your machine

Filter

Charger

Gator 18V

Taking care of you

We’re here if you need us. Instead of taking me back
to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,
Worcestershire, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Let us know what you think @VaxUK

Filter release button

Dirt container
release button

Retractable crevice tool

Technical Specication

Name Gator Gator Gator

10.8V 15.6V 18V

Weight 1.24kg 1.8kg 1.8kg
Capacity 0.3L 0.3L 0.3L
Cleaning

Time 15 mins 18 mins 20 mins
Charging

Time 12 hrs 12 hrs 12 hrs

Motorised Tool

Accessories & Consumables*

Gator 10.8V

Charger
1-5-131865-00
Pre-motor
Filter (Type 67)
1-7-131574-00

Gator 15.6V

Charger
1-5-132794-00
Pre-motor
Filter (Type 67)
1-7-131574-00

Gator 18v

Charger
1-5-132794-00
Pre-motor
Filter (Type 67)
1-7-131574-00
Motorised
Turbohead
1-2-132797-00

Subject to technical change without notice.

*To purchase consumables and accessories, please visit vax.co.uk
