Vax Grime Pro, Grime Pro S4S Series User Manual

vax.co.uk

S4S series

Vax Careline: (UK) 0844 412 8455

(ROI) 1-800 928 308

User Guide

Grime Pro

1 2

1 3

1 4

1 5

1 6

1 7

1 8

1 9

20 21 22

24 26 27 2823 25

Machine Overview

2

1 Water tank
2 Steam nozzle

3

Detergent/ Solution control dial

4

Safety pressure indicator

5 Water tank lid
6 Steam trigger
7 Carry handle
8 Detergent tank
9 Power button

1 0 Power indicator light

(water heating)

(

blue LED)

1 1 Steam ready indicator light

(green LED)

1 2 Measuring jug
1 3 Window/upholstery tool
1 4 Upholstery tool cloth
1 5 Concentration nozzle
1 6 Small plastic brush
1 7 Large plastic brush
1 8 Scraper tool
1 9 Bending nozzle
20 Gap brush with bristles/ Grout brush
21 Accessory Adapter
22 Hose
23 1 x 4 Finger fork
24 1 x 4 Finger fork cloth
25 1 x 2 Finger fork
26 1 x 2 Finger fork cloth
27 Vax Steam detergent
28 Accessory bag

2

5

4

3

6

1

1 0

1 1

9

8

7

General Safety Information

vax.co.uk

3

FOR HOUSEHOLD USE ONLY.

W

hen using the steam cleaner, basic safety precautions should always be

observed, including the following:

I

MPORTANT: Please refer to the upholstery/surface manufacturer’s
care recommendations before use and test the steamer on a discrete
surface to begin with.

WARNING: The steam cleaner unit and accessories get very
hot during operation.

DANGER OF SCALDING: Avoid contact with the steam.

1. Do not leave the steam cleaner unattended when plugged in.

U

nplug it from socket when not in use.

2. To prevent electric shock do not use outdoors.

3. Not to be used as a toy. Close supervision is necessary when

used near children or the infirm.

4. Use only as described in this manual.

5. Do not use the steam cleaner if it has been dropped, damaged,

left outdoors or dropped into water. Do not use the steam
cleaner with a damaged cord or plug. If the supply cord is
damaged, call the Vax customer careline on 0844 412 8544

6. Do not pull or carry by the cord, use the cord as a handle, allow

the cord to come into contact with hot or sharp surfaces or
close a door on the cord.

7. Do not unplug by pulling on the cord.

8. Do not handle the plug or steam cleaner with wet hands.

9. Do not put any objects into openings or operate with

openings blocked.

10. Do not use without the tank cap in place.

11. Turn off all controls before unplugging.

12. Do not use an extension cord.

13. Do not attempt to remove blockages with sharp objects as they

may cause damage.

14. Store indoors, put away after use to prevent tripping accidents.

15. Using improper voltage may result in damage to the steam

cleanerand possible injury to the user. The correct voltage is
listed on the rating label.

16. A hazard may occur if the steam cleaner runs over the power

supply cord.

17. The steam cleaner must be kept level during operation.

18. Never immerse the steam cleaner in water or other liquids.

19. Keep the steam cleaner away from rain and moisture. The

steam cleaner is not suitable for outdoor use.

20. Do not operate the steam cleaner without water in the tank.

Always top up with water in good time.

21. Empty the water tank when the steamer is not in use.

22. Never fill the tank with anything other than water. Never put

additives (such as perfume, stain remover or products

containing alcohol) in the water as they may damage the steam
cleaner or make it dangerous to use.

23. Always remove the mains plug from the socket and allow this
s

team cleaner to cool down completely before topping up

with water.

24. Do not overfill the tank. Do not exceed the maximum prescribed
filling level. Please use the measuring jug included.

25. Ensure that the water tank cap has been screwed down fully
b

efore use.

26. Only carry the steam cleaner by the carry handle.

27. Do not touch any hot areas on the steam cleaner. It is normal
for the steam cleaner to heat up during operation.

28. Do not use the steam cleaner to treat any items of clothing that
a

re still being worn on the body.

2

9. The force and heat of the steam may have an adverse effect on
some materials. Always check whether a surface is suitable for
treatment with the steam cleaner by carrying out a test
beforehand on a concealed area.

31. Always include these operating instructions if passing the steam
cleaner on to a third party.

32. Never aim the steam cleaner at people, animals or plants (risk
of scalding)! Do not aim the steam cleaner at electrical systems
or wires.

33. Please always switch the appliance off and remove the mains
plug from the socket if leaving the work area.

34. The steam cleaner is fitted with a thermostat and a thermal cut­out as protection against overheating.

35. Accessories become hot during use - allow them to cool down
before handling.

36. Please ensure all parts are correctly fitted before using
the product.

39. Do not use your steam cleaner if damaged/faulty. Please call
our Vax Careline on 0844 412 8455.

40. Do not use unit on leather, wax polished furniture or floors,
synthetic fabrics, velvet or other delicate steam or water
sensitive materials.

NOTE: The liquid or steam must not to be directed towards equipment
containing electrical components.

This steamer is for household use only and NOT for commercial or
industrial use.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Getting Started

Operating your steam cleaner

4

Squeeze tabs on side of detergent tank
to slide tank out of steamer.

Remove cap from detergent tank and fill with
maximum 120ml of Vax detergent. Replace cap
firmly and slide solution tank back into steamer
NOTE: For best results, fill with 120ml of detergent.
Alternatively dilute the mixture with 50ml detergent
and 70ml water

NOTE: Whilst in use do not recline unit more than 45 degrees.

Place steamer on a level surface and ensure
steamer is switched off and is cool. To remove
lid push down and twist anti clockwise.

Ensure the lid is securely fastened by
turning in a clockwise direction.

Slowly pour water into water tank.
Do not overfill the water tank. Allow
space to be left at the top.

Fill measuring jug with maximum 300ml.

C

AUTION: Do not use hot or boiling water to fill water compartment. Do not open the water tank lid when using the steamer. Your steamer is

pressurised, do not completely remove the lid when tank is hot. Fill tank only when cool. Do not overfill the water or detergent tank
compartments.

Filling the detergent tank

Filling the water tank

I

MPORTANT: After use, switch off the machine, compress the trigger to release all remaining steam. Allow machine to cool for a

minimum of 10 minutes before refilling or storing.
