FlipOut
CORDLESS HAND VAC
POWER & VERSATILITY
FOR ON-THE-GO CLEANING
LET’S GET STARTED.
VX47
Let’s talk safety
Basic safety precautions
This vacuum cleaner is intended for household use
only and NOT for commercial or industrial use.
READ ALL THE INSTRUCTIONS BEFORE USING
THIS APPLIANCE
• It is a battery-operated appliance, the battery being
charged inside the appliance.
• Only use the vacuum cleaner indoors and keep the
area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts
and openings whilst using the vacuum cleaner.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge unless they have been given supervision
or instruction concerning use of the appliance by
a person responsible for their safety. Children should
not play with the vacuum cleaner. Cleaning and
user maintenance should not be made by children
without supervision
• Only Vax recommend tools and accessories should
be used with this vacuum cleaner
• Keep the charger and vacuum cleaner in a dry place,
and use them indoors only.
• Do not use charger with damaged cord or plug.
If appliance or charger is not working as it should,
has been dropped, damaged, left outdoors or dropped
into water, take it to a Vax authorised repair agent prior
to continuing use. Please contact our Customer Care
Line on: AU: 1300 361 505 / NZ: 0800 800 900
(Mon-Fri 8.30am to 5.00pm) or visit www.vax.com.au
/ vax.co.nz for your nearest Vax authorised repair agent.
Please keep instructions for further use.
Battery Safety Precautions:
• Do not place vacuum or batteries near re or heat. This
will reduce the risk of explosion and possible injury.
• Do not crush, drop or damage battery pack. Do not use
a battery pack or charger that has been dropped or
received a sharp blow. A damaged battery is subject to
explosion. Properly dispose of a dropped or damaged
battery immediately.
• Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open ame. An exploded battery
can propel debris and chemicals. If exposed, ush with
water immediately.
• Do not charge vacuum in a damp or wet location.
Following this rule will reduce the risk of electric shock.
• For best results, charge the battery tool in a location
where the temperature is more than 10°C but less than
37°C. To reduce the risk of serious personal injury,
do not store outside or in vehicles.
• Under extreme usage or temperature conditions, battery
leakage may occur. If liquid comes in contact with the skin,
wash immediately with soap and water, then neutralize
with lemon juice or vinegar. If liquid gets into the eyes,
ush them with clean water for at least 10 minutes, then
seek immediate medical attention. Following this rule will
reduce the risk of serious personal injury.
• Store the battery pack where the temperature is
below 27°C.
• The battery must be removed from the appliance
before it is scrapped by a qualied person.
• The appliance must be disconnected from the supply
mains when removing the battery.
• The battery is to be disposed of safely.
• The battery must be removed from the appliance
before it is scrapped by a qualied person.
• The appliance must be disconnected from the supply
mains when removing the battery.
• The battery is to be disposed of safely.
Basic safety precautions
Charger Safety Precautions:
• The charger must not be damp, and should never
be used in a damp environment.
• The charger is for indoor use only.
• Do not use the product if it has suered any heavy
shock or jolting, or is damaged in any other way.
• Do not conduct charging in a position which may
become exposed to sunlight or other heat source.
Recommended temperature range at charging vicinity
is 10° to 25° C.
• Do not conduct charging operations in the vicinity
of ammable materials. Example: Cloth, packaging
materials, paint, spray paint or aerosols, lubricant,
thinners, petrol containers, gas containers or gas
appliances.
• Do not cover any ventilating slots and provide
adequate ventilation during operation.
• Never modify, disassemble or attempt to repair the
product yourself.
• Do not allow the charger or batteries to become
contaminated with any material which could be
conductive.
• Remove the plug of the product from the power
socket when it is not in use or when cleaning it.
• Protect battery contacts to avoid a short circuit
caused by metallic objects which could cause a re
or explosion!
• Do not charge batteries which show signs they have
leaked electrolyte. Dispose of them properly.
• Never charge a damaged battery
Let’s talk safety
3 Use only as described in this manual. Use only
manufacturer’s recommended attachments.
3 Keep hair, loose clothing, ngers, and all parts of
body away from openings and moving parts.
3 Use extra care when cleaning on stairs. Do not place
cleaner on stairs or furniture, as it may result in
injury or damage.
3 Turn power switch o before removing or installing
powered nozzle.
Do’s
3 The charger is for indoor use only. Be sure to always
keep the battery and charger in a dry place.
3 Put product away after use to prevent tripping accidents.
3 Unplug the charger from the outlet before any routine
cleaning or maintenance.
Don’ts
8 Do not use the unit, store, or charge battery outdoors
or on wet surfaces. Do not allow to get wet.
8 Do not allow to be used as a toy. Not intended for
use by children age 12 and under. Close supervision
is necessary when used by or near children. To avoid
injury or damage, keep children away from product,
and do not allow children to place ngers or other
objects into any openings.
8 Do not use charger with damaged cord or plug.
If appliance or charger is not working as it should,
has been dropped, damaged, left outdoors, or dropped
into water, take it to a service centre prior to
continuing use.
8 Do not pull or carry charger by cord, use cord
as handle, close a door on cord, or pull cord around
sharp edges or corners. Do not place product
on cord. Do not run appliance over cord. Keep cord
away from heated surfaces.
8 Do not unplug charger by pulling on cord. To unplug
charger, grasp the plug, not the cord.
8 Do not handle charger, including charger plug, and
charger terminals with wet hands.
8 Do not put any objects into openings. Do not use
with any opening blocked; keep free of dust, lint, hair,
and anything that may reduce air ow.
8 Do not use to pick up ammable or combustible
liquids, such as gasoline, or use in areas where they
may be present.
8 Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
8 Do not use without lters and/or dirt cup in place.
8 Do not incinerate the charger, battery, or appliance
even if it is severely damaged. The batteries can
explode in a re.
8 This product includes rechargeable lithium-ion
batteries. Do not expose batteries to high temperatures,
as they may catch re and/or explode.
8 Do not expose battery to crushing, incineration
or similar actions.
8 Do not attempt to disassemble battery.
8 Do not attempt to short circuit the battery or charger
terminals.
8 CAUTION: Not to be used for grooming a pet.
Thank you for buying this FlipOut.
Contents
Taking care of small cleaning tasks
The FlipOut Handheld is designed to make cleaning as quick and convenient as possible and
this user guide will help you get the most out of your machine. The FlipOut is perfect for small
cleaning tasks on surfaces and upholstery.
Taking care of your FlipOut Handheld
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you need to tackle those small jobs.
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Notes
What to do if it goes wrong
Getting in touch
FlipOut
Included with
your machine
Flip Out Crevice Tool
Charger
We’re here if you need us
For troubleshooting simply visit or call:
Australia: 1300 361 505* New Zealand: 0800 800 900*
vax.com.au vax.co.nz
*Monday – Friday: 8:30am -5:00pm
Calls are charged at the standard local rate. Please make note of the serial
number and model number of the product before calling.
Getting to know your machine Getting started
Double
Insulated
This product
meets applicable
regulatory
requirements
Indoor
Use
Read
Instructions
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Handle
Assembling your vacuum cleaner
On/O button
Handle release button
Dirt container release button
Technical Specication
Name FlipOut
Model No VX47
Voltage 16V DC Li-ion
Wattage 100W
Weight 4.5kg
Charger Specication
Charger Model No YLSXA-A182030
Charger Input 100-240V~50/60Hz
Charger Output 18.2V
300mA
Battery Specication
Battery type Lithuim-Ion
Battery capacity 1.5Ah
Dust separator
and shroud
Quick ip
crevice tool
Accessories & Consumables
Pre-motor lter
Model No VX47F
Remove from carton & Review the instruction manual.
Press the handle release button to pivot handle for
easy cleaning.
Plug in & Charge unit until the charge indicator
light goes out (Charging may take up to 6 hours).
To purchase consumables and accessories, please visit vax.com.au/vax.co.nz
Subject to technical change without notice. Images are illustrative only.
Using your machine Using your machine
Turning your machine On and O
Slide the power switch to the ON position. When completed, slide the power switch to the
OFF position.
NOTE: Empty and clean the unit and lter after
each use or after large pickups when the unit
becomes full.
TIP: The power switch must be in the OFF
position for the unit to charge.
Quick-ip crevice tool
FLIP
PULL
Charging
NOTE: Use only the charger supplied by the manufacturer to recharge.
TIP: For a better experience, fully charge the unit before rst use.
Power switch must be in the OFF position. The charge indicator light will pulse when
NOTE: The unit can only charge when the
switch is in the OFF position.
NOTE: If the unit is running and the charger
plug is connected to the unit, the unit will shut
o to prevent damage to the charger or unit.
charging and the indicator will turn o when
charging is complete.
NOTE: The charge indicator will only turn
on while charging. Once the battery is fully
charged, the indicator will not go on again. The
charger will be warm while charging.
TIP: The unit will charge only for as long as
needed. It may take up to 6 hours for full charge.
PUSH
Flip crevice tool out to line up with nozzle then
push in until secured in place.
FLIP
To store crevice tool: gently pull the tool away from
the dust cup and ip the tool up towards the unit
& press down until you feel it lock into place.
Using your machine Taking care of your machine
Dusting tool
NOTE: Use only the charger supplied by the manufacturer to recharge.
TIP: For a better experience, fully charge the unit before rst use.
Position 1 - Easy cleaning for upholstery, stairs
and crevices.
Position 2 - Easy cleaning for higher surfaces.
Filter removal and replacement
TIP: To maintain performance, lter should be changed every 3-6 months, or as needed.
WARNING: To reduce the risk of personal injury, turn power switch o before cleaning or servicing.
While holding the dirt cup and handle, press dirt
cup release button.
Remove the dirt cup to access lter.
and more.
Remove lter assembly from dirt cup & separate
the white lter from the lter housing. Tap lter
over a trash can to remove debris. Be sure to also
Position 4 - Compact storage.Position 3 - Great for cleaning shelves, cabinets
wipe debris from the lter housing.
NOTE: Do not discard lter or lter housing.
NOTE: For replacement lter VX47F visit vax.com.au / vax.co.nz or call us at AU: 1300 361 505 / NZ: 0800 800 900.
Place lter back into the lter housing. Place dirt
cup back onto the body of the hand vac until you
hear it click.
NOTE: Filter is rinseable with water. Do not
use soap/detergent. Must be completely dry
before use.
What to do if it goes wrong Getting in touch
Cleaner won’t run
Cleaner won’t pick up
or low suction
Dust escaping
from cleaner
SolutionProblem
• Battery not charged – Charge battery up to 6 hours. The indicator light will
pulse until the battery is fully charged and then will turn o.
• Battery dead - won’t hold charge – Contact customer service. Visit our
website at www.vax.com.au / www.vax.co.nz or call AU 1300 361 505
/ NZ 0800 800 900.
• Needs service – Contact customer service. Visit our website at
www.vax.com.au / www.vax.co.nz or call AU 1300 361 505 /
NZ 0800 800 900.
• Dirt Cup not installed correctly – Review Filter Removal & Replacement.
• Dirt Cup is full – Empty dirt cup.
• Battery charge is getting weak – Charge battery.
• Filter is dirty – Clean or replace lter.
• Clogged lter – Remove lter and clean.
• Nozzle/dirt passage clogged – Turn o the unit and then disconnect the nozzle
to remove debris.
• Filter/Filter Frame missing – Contact customer service. Visit our website at
www.vax.com.au / www.vax.co.nz or call AU 1300 361 505 / NZ 0800 800 900.
• Dirt cup is full – Turn o unit and remove debris.
• Dirt cup not installed correctly – Review Filter Removal & Replacement.
• Filter not installed correctly – Review Filter Removal & Replacement.
Charger indicator
ashes then goes out
• Problem with the charging circuit – Contact customer service.
Visit our website at www.vax.com.au / www.vax.co.nz or call
AU 1300 361 505 / NZ 0800 800 900.
* Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.
Distributed by Techtronic Industries Australia Pty. Ltd.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
Careline AU: 1300 361 505 www.vax.com.au
Careline NZ: 0800 800 900 www.vax.co.nz
Loading...
