Vax Essentials VEU-101 User Manual
User Guide
vax.co.uk
GB
Vax Careline 0844 412 8455
Bagless Upright
Get Cleaning...
What’s your Vax’s model number?
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
VEU-101
V E U
–
1 0 1
– – – – –
VEU-101 Series User Guide.qxd:User guide 12/11/09 16:44 Page 1
---
Machine Overview
Unit
Accessories
2
Vax Careline
0844 412 8455
Filters
1
8 Extension tube
9 Crevice tool
4 Central HEPA filter
13 Pre motor filter
8
10
9
2
3
4
5
6
7
8
1
Handle
2
Dirt bin release button
3 Cord
4 Central HEPA filter
5
Dirt Bin
6 Dirt release button
7 Carpet height adjust
8
Extenion tube
9
Crevice tool
10 Carry handle
11 Hose
12 On/off button
11
12
9
4
13
VEU-101 Series User Guide.qxd:User guide 12/11/09 16:44 Page 2
General Safety Information
vax.co.uk
3
FOR HOUSEHOLD USE ONLY.
W
hen using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
s
urfaces.
2. Turn off the vacuum cleaner controls before
d
isconnecting or connecting from the mains supply.
3
. Always unplug the vacuumcleaner before
c
onnectingor disconnecting the vacuum hose and
accessories.
4. Childrenshould be supervised to ensure that they
do not playwiththe appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord is
damaged return the vacuum cleaner to a Vax
Authorised Service Agent or contact the Vax Careline
on 0844 412 8455 for assistance.
8. Do not pull or carry by cord. Do not
use the cord as a handle, close a door on the cord or
pull cord around sharp edges or corners. Do not run
the vacuum cleaner over the cord. Keep the cord
away from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air-
flow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches
or any hot, smoking or burning objects.
13. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene etc.) or use
in the presence of explosive liquids or vapours.
1
4. Do not vacuum up harmful or toxic material
(chlorine, bleach, ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as
g
lass, nails, screws, coins, etc.
1
6. Do not use without ALL of the filters in place.
17. Take extra care when vacuuming on stairs.
1
8. Keep vacuuming area well lit.
1
9. Store the vacuum cleaner in a cool, dry area.
2
0. Turn off the on/off switch before unplugging the
v
acuum cleaner
21. Use only CE-approved 13 amp extension cords.
Non-approved cords may overheat. Care should
be taken to arrange the cord so that the cord
cannot be tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dust container, or
before connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical
outlet, make sure the switch is in the ‘off’ position.
IMPORTANT: If the inlet, hose or telescopic tube
is blocked, switch off the vacuum cleaner and
remove the blockage(s) before re-starting the vacuum
cleaner. See Maintenance: Clearing blockages.
IMPORTANT: Washing filters improves vacuum
performance. Vax recommends that they should
be checked and cleaned periodically (depending on the level
of use). Make sure all filters are completely dry before
inserting back into the vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason the unit should overheat,
the thermostat will automatically turn the unit off. Should this
occur, unplug the vacuum cleaner from the electrical outlet
and turn off the switch. Remove dust container and empty.
Clean filters. Allow the unit to cool for approximately one (1)
hour. To re-start, plug into an electrical outlet and switch back
on.
This vacuum cleaner is intended for household use
only and NOT for commercial or industrial use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
!!!!!
VEU-101 Series User Guide.qxd:User guide 12/11/09 16:44 Page 3
---
Operation
Assembling your vacuum cleaner
Operating the appliance
4
Vax Careline
0844 412 8455
Keep your Vax like new
IMPORTANT: The condition of the filters affects the
performance of your machine. Please check and clean
filters periodically (depending on the level of use). For full
cleaning instructions, see page 6.
!
IMPORTANT: Do not use the vacuum cleaner without
all of the filters in place.
!
12
Twist cord hook to
release cord.
Turn unit on. Recline unit.
1
10
11 11
Align arrows to
lock/unlock dirt bin.
VEU-101 Series User Guide.qxd:User guide 12/11/09 16:44 Page 4
