www.vax.co.uk
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
Vax careline
0870 6061248
instruction manual
Bagged cylinder
Vax model number:
VEC-31
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:58 Page 1
VEC-31
1. Diagram
www.vax.co.uk
2
parts overview
8
1
2
9
10
3 4 5 6 7
12
Fig.1/1
1 Lid opening clip
2 Hose inlet
3 Blockage indicator
4 Auto cord rewind button
5 Variable power
6 Power light
7 Floor tool parking slot
8 On/off button
9 Wheel
10 Disposable paper dust bag (x3)
11 Pre-motor filter and case
12 Post-motor filter
13 Flexible hose
14 Dusting brush
15 Telescopic extension tube
16 Crevice tool
17 Combination floor head
18 Upholstery tool
19 Turbo Tool
13
15
16
14
17
18
19
1
1
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 2
3
V
ax Careline 0870 606 1248
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
connecting or disconnecting from the mains supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual.
Use only the manufacturer’s recommended
attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord or plug is
damaged, return the vacuum cleaner to a Vax
Authorised Service Agent or suitably qualified
person for examination, repair or adjustment.
8. Do not pull or carry by the cord. Do not use the cord
as a handle, close a door on the cord or pull the cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air
flow. Keep all openings free of dust, lint, hair or
anything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches or
any hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material (chlorine
bleach, ammonia, drain cleaner, etc).
15. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16. Do not use without the filters in place.
17. Take extra care when vacuuming stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner indoors in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner.
21. Use only CE-approved 13 amp extension cords. Nonapproved extension cords may overheat. Care should
be taken to arrange the cord so that the cord cannot
be pulled or tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet
before assembling, opening or emptying the dirt
container, or before connecting/disconnecting the
attachments.
CAUTION: The vacuum cleaner is a very
powerful unit. Before plugging the cord into
the electrical outlet, make sure the switch is in the
‘off’ position.
IMPORTANT: If the inlet, hose or telescopic
tube is blocked, switch off the vacuum cleaner
and remove the blockage(s) before re-starting the
vacuum cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Make sure all the filters are
completely dry before inserting back into the vacuum
cleaner.
This vacuum cleaner is intended for household use only
and not for commercial or industrial use.
!!!
!
Motor Thermostat
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason, the vacuum cleaner should
over-heat, the thermostat will automatically turn the
unit off. Should this occur, unplug the vacuum cleaner
from the electrical outlet and turn off the switch.
Remove the dirt container and empty. Clean the
filters. Allow the cleaner to cool for approximately one
(1) hour. To re-start, plug into an electrical outlet and
switch back on.
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 3
www.vax.co.uk
4
assembly / operation
3. How to Assemble
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before assembling or
removing the accessories.
Insert the flexible hose into the inlet on the main body of
the vacuum cleaner. Push in until it clicks into position
(Fig.3/1).
Push the telescopic extension tube on to the end of the
handle (Fig.3/2).
The telescopic extension tube can be lengthened or
shortened by pushing the button in and sliding the tube
apart or together as required (Fig.3/3).
Fit the combination floor head by pushing onto the
extension tube (Fig. 3/4).
4. How to Operate
Cord Release
Fully unwind the power cord. A yellow mark on the power
cord indicates the recommended cord length. Do not
exceed the cord length beyond the red mark.
On/off Button
1. Insert the power plug into the electrical outlet. Make
sure the vacuum cleaner is switched off.
2. Press the on/off switch located on the top of the
vacuum cleaner, to switch on the vacuum cleaner
and press the button again to turn the vacuum
cleaner off.
Carpet Cleaning
For carpet and rug cleaning, press the rocker switch on
the combination floor head to raise the brushes.
Hard Floor Cleaning
For hard floor cleaning, press the rocker switch on the
combination floor head to lower the brushes.
Cord Rewind
To rewind the power cord, press the cord rewind button,
located on the top of the vacuum cleaner, and guide the
power cord with one hand. This will prevent the cord from
whipping which could cause damage or injury.
Variable Power
Located between the on/off and cord rewind buttons
there is a variable power switch. Slide this forwards and
backwards to adjust the suction power.
Carry Handle
Use the carry handle located at the front of the vacuum
cleaner to move from room to room.
Hose Storage
For convenience, there is a slot located at the back of the
vacuum cleaner where the floor tool and hose can be
parked for storage.
!
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/4
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 4
5
V
ax Careline 0870 606 1248
accessories / dirt container & filters
5. Accessories
1. The accessories can be attached directly to the
handle by removing the telescopic tubes and
pushing in the desired accessory.
2. The accessories can also be attached to the
telescopic extension tube for extra reach. Remove
the combination floor head and push on the desired
accessory.
Crevice tool: for crevices, corners and cracks, etc.
Dusting brush: for delicate surfaces.
Upholstery tool: for carpet, upholstery, stairs, etc.
TurboTool
For pet hair, stair and upholstery cleaning (NOTE: Do not
use the TurboTool on suede and leather surfaces)
6. Dirt Containers & Filters:
Removal & Replacement
IMPORTANT: Always unplug the vacuum
cleaner from the electrical outlet before
removing the dust bag.
IMPORTANT: Do NOT use the vacuum cleaner
without ALL of the filters in place.
IMPORTANT: The vacuum cleaner is equipped
with a blockage indicator. If the indicator turns
red, the bag will need to be changed or check for
blockages in the hose.
Turn off the vacuum cleaner and unplug from the
electrical outlet. Lift up the top cover to gain access to
the dust bag compartment. (Fig6/1)
Lift out the full bag as shown (Fig.6/2).
Dispose of the full dust bag in a rubbish bin and insert a
new dust bag. Slide into place, then close the top cover.
Pre Motor Filter:
1. Turn off the vacuum cleaner and unplug from the
electrical outlet. Lift up the top cover to gain access to
the dust bag compartment.
2. Lift out the pre-motor filter situated at the back of the
dirt bin compartment and separate the filter (Fig.6/3).
N.B. Vax recommend replacing the filter after 5 bag
changes or when it appears soiled.
Fig.6/1
Fig.6/2
!!!
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 5
www.vax.co.uk
6
dirt container & filters
The filter can then be tapped against the side of a
rubbish bin to remove excess dirt, and washed when
heavily soiled (Fig.6/4-5).
Post Motor Filter:
1. Turn off the vacuum cleaner and unplug from the
electrical outlet.
2. Located at the rear of the vacuum cleaner is the post-
motor filter. This can be removed by pressing down on
the cover (Fig.6/6).
Remove the filter by pulling away from the unit (Fig.6/7).
The post-motor filter can then be tapped against a dust
bin and washed (Fig.6/8).
Fig.6/6
Fig.6/4
Fig.6/5
Fig.6/7
Fig.6/8
Fig.6/3
Fig.7
Fig.7
24
24
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 6
7
V
ax Careline 0870 606 1248
clearing blockages / troubleshooting
7. Clearing Blockages
WARNING: To reduce the risk of electric shock,
the power cord must be disconnected before
performing maintenance/troubleshooting checks.
Switch the vacuum cleaner off and disconnect the power
plug from the electrical outlet.
The flexible hose can be disconnected from the vacuum
cleaner by pushing in the button on the hose and pulling
away from the machine. (Fig.7/1). Remove any blockages
found then reconnect the hose securely.
Removing debris from the TurboTool
Switch the vacuum cleaner off and disconnect the power
plug from the electrical outlet.
Rotate the locking ring 180º (Fig.7/2).
Lift the top cover off and remove any blockage (Fig.7/3).
To re-assemble, ensure that the tabs are engage. Pivot the
lower housing closed and rotate the locking ring 180º
(Fig.7/3).
8. Troubleshooting
WARNING: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: The cleaner won't run.
Cause: Not properly plugged into electrical outlet.
Solution: Plug in firmly.
Cause: No electricity in electrical outlet.
Solution: Check fuse or breaker.
Cause: On/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Blocked central filter.
Solution: Remove, clean and replace filters. See page 6.
Cause: Motor thermostat has tripped.
Solution: Switch off and unplug the vacuum cleaner.
Leave for (1) hour before switching the
vacuum cleaner back on.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause: Dust bag not installed correctly.
Solution: Review dust bag removal and replacement.
Cause: Dust bag full or blocked.
Solution: Replace dust bag.
Cause: Clogged filter.
Solution: Remove filter and clean.
Cause: Blockage in hose.
Solution: Disconnect hose, remove the obstruction
then re-fit.
PROBLEM: Dust escaping from the vacuum cleaner.
Cause: Dust bag full.
Solution: Dispose of dust bag and replace with a new
one.
Cause: Dust bag not installed correctly or burst.
Solution: Review dust bag removal and replacement.
Cause: Hose not installed correctly.
Solution: Review hose installation.
Cause: Filter not installed completely.
Solution: Review filter removal and replacement.
Cause: Turbo Tool is clogged.
Solution: Refer to section 7.
Fig.7/1
LOCKING RING
Fig.7/2
Fig.7/3
!
!
TABS
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 7
www.vax.co.uk
8
uk service & help / technical specification
9. UK Service & Help
Vax Care 0870 6061248
Monday-Friday 8.00am to 6.00pm.
Satuday-Sunday 9.00am to 5.00pm.
An answerphone is available outside of these hours. Any
queries or concerns about using the Vax, call the Vax
Careline. Calls are charged at the UK national rate.
Please make a note of the serial number and model
number of the carpet cleaner before calling. There are
over 400 approved Vax Service Agents in the UK. For the
nearest Service Agent, please call the Vax Careline.
www.vax.co.uk
10. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2000W
Capacity: 3.0 litres
Filters: Fibre pre-motor filter - washable
HEPA post-motor filter - washable
Cord length: 5.0m
Weight: 6.3kg
Subject to technical change without notice.
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 8
9
V
ax Careline 0870 606 1248
troubleshooting / uk service / technical specification
This page has been left intentionally blank.
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 9
www.vax.co.uk
10
This page has been left intentionally blank.
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 10
11
V
ax Careline 0870 606 1248
This page has been left intentionally blank.
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 11
---
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
VEC-31 Essentials by Vax Pet bagged cylinder is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Wasteelectrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: info@vax.co.uk - website: www.vax.co.uk
Vax VEC-31 User Guide v3.qxd:VEC-31 User Guide 22/7/08 15:59 Page 12
Loading...
