Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
Vax careline
0870 6061248
instruction manual
Bagless cylinder
Vax model number:
VEC-11
VEC-21
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:33 Page 1
VEC-11 / VEC-21
1. Diagram
www.vax.co.uk
2
parts overview
1
11
12
14
10
16
13
15
2
Fig.1/1
1 Hose inlet
2 Lid release button
3 Carry handle
4 Auto cord rewind button
5 Floor tool parking slot
6 On/off button
7 Wheel
8 Dirt container release button
9 Dirt container
10 Dusting brush
11 Telescopic extension tube
12 Crevice tool
13 Flexible hose
14 Combination floor tool
15 TurboTool
(Model: VEC-21 only)
16 Upholstery tool
4
3
5
6
7
8
9
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:33 Page 2
3
V
ax Careline 0870 606 1248
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
connecting or disconnecting from the mains supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual.
Use only the manufacturer’s recommended
attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord or plug is
damaged, return the vacuum cleaner to a Vax
Authorised Service Agent or suitably qualified
person for examination, repair or adjustment.
8. Do not pull or carry by the cord. Do not use the cord
as a handle, close a door on the cord or pull the cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord away
from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air
flow. Keep all openings free of dust, lint, hair or
anything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches or
any hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material (chlorine
bleach, ammonia, drain cleaner, etc).
15. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16. Do not use without the filters in place.
17. Take extra care when vacuuming stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner indoors in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner.
21. Use only CE-approved 13 amp extension cords. Nonapproved extension cords may overheat. Care should
be taken to arrange the cord so that the cord cannot
be pulled or tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet
before assembling, opening or emptying the dirt
container, or before connecting/disconnecting the
attachments.
CAUTION: The vacuum cleaner is a very
powerful unit. Before plugging the cord into
the electrical outlet, make sure the switch is in the
‘off’ position.
IMPORTANT: If the inlet, hose or telescopic
tube is blocked, switch off the vacuum cleaner
and remove the blockage(s) before re-starting the
vacuum cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Make sure all the filters are
completely dry before inserting back into the vacuum
cleaner.
This vacuum cleaner is intended for household use only
and not for commercial or industrial use.
!!!
!
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:33 Page 3
www.vax.co.uk
4
assembly / operation
3. How to Assemble
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before assembling or
removing the accessories.
1. Insert the flexible hose connector into the inlet on the
main body of the vacuum cleaner until it clicks into
place (Fig.3/1).
2. Push the telescopic extension tube on to the end of
the handle (Fig.3/2).
3. The telescopic extension tube can be lengthened or
shortened by pushing the button in and sliding the
tube apart or together as required (Fig.3/3).
4. Fit the combination floor head by pushing onto the
extension tube (Fig.3/4).
4. How to Operate
Cord Release
Fully unwind the power cord. A yellow mark on the power
cord indicates the recommended cord length. Do not
exceed the cord length beyond the red mark.
On/Off Button
Insert the power plug into the electrical outlet. Ensure the
vacuum cleaner is switched off.
Press the on/off button located on the top of the vacuum
cleaner and press the button again to turn the vacuum
cleaner off.
Carpet Cleaning
For carpet and rug cleaning press the rocker switch on the
combination floor head to raise the brushes.
Hard floor cleaning
For hard floor cleaning, press the rocker switch on the
combination floor head to lower the brushes.
Cord Rewind
To rewind the power cord, press the cord rewind button,
located on the top of the vacuum cleaner, and guide the
power cord with one hand. This will prevent the cord from
whipping which could cause damage or injury.
Carry Handle
Use the carry handle located on the top of the vacuum
cleaner to move the vacuum cleaner from room to room.
Hose Storage
For convenience there is a slot located at the rear of the
vacuum cleaner where the floor tool and hose can be
parked for storage.
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/4
!
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 4
5
V
ax Careline 0870 606 1248
accessories / dirt container & filter
5. Accessories
The accessories can be attached directly to the handle by
removing the telescopic tube and pushing in the desired
accessory.
The accessories can also be attached to the telescopic
tube for extra reach. Remove the combination floor head
and push on the desired accessory.
Crevice tool: for crevices, corners and cracks, etc.
Dusting brush: for delicate surfaces.
Upholstery tool: for carpet, upholstery, stairs, etc.
TurboTool
(
Model: VEC-21 only)
: For pet hair, stair and
upholstery cleaning (NOTE: Do not use the TurboTool on
suede and leather surfaces).
6. Dirt Container & Filter:
Removal and Replacement
NOTE: Before emptying the dirt container and
removing or replacing any filters the hose must be
removed from the vacuum.
WARNING: Always unplug the vacuum cleaner
from the electrical outlet before removing the
dirt container.
WARNING: Do NOT use the vacuum cleaner
without ALL of the filters in place.
NOTE: For best performance, replace filters annually.
Press and hold in the latch on the top of the hose
connector and remove the connector away from the
vacuum cleaner (Fig.6/1).
Emptying the Dirt Container
Lift the lid of the vacuum cleaner by pressing in the lid
release buttons on the vacuum cleaner (Fig.6/1).
Rotate the dirt container anti-clockwise and lift the
container out of the vacuum cleaner. (Fig.6/2)
Fig.6/1
Fig.6/2
!
!
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 5
www.vax.co.uk
6
dirt container & filter
Position the dirt container over a rubbish bin and press the
dirt container release catch (Fig.6/3)
When all the dirt has fallen close the dirt container base,
and return the dirt container to the vacuum cleaner.
Cleaning the Filters
NOTE: Do not use any detergents or boiling water to
wash the filters. Vax recommends checking the
filters every time the dirt container is emptied and
cleaning as instructed below.
NOTE: All filters must be in place before using the
vacuum cleaner.
Central Pre-motor Filter
Remove the dirt container as directed above.
Remove the central filter as shown (Fig.6/4).
The filter can be separated into three separate parts.
Gently tap the central filter, filter shroud and filter sleeve
against the side of a rubbish bin to remove excess dirt
(Fig.6/5).
The central filter, filter shroud, and filter sleeve can be
rinsed in warm water (max 40°C). Allow to air dry
completely before replacing (Fig.6/6).
Return the central filter, shroud and filter sleeve to the dirt
container. Replace the dirt container as directed, ensuring
that it locks into place rotating clockwise before the lid is
closed.
Post-motor Filter
NOTE: This is located on the back of the vacuum cleaner.
Release the post-motor cover by pressing down on the
catch at the top of the cover (Fig.6/7).
Remove the filter and case by pulling away from the casing,
then separate the filter from the case (Fig.6/8).
Fig.6/4
Fig.6/7
Fig.6/5
Fig.6/6
Fig.6/3
24
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 6
7
V
ax Careline 0870 606 1248
dirt container & filter / clearing blockages
The post-motor filter can be rinsed in warm water (max
40°C). Allow to air dry for at least 24 hours before
replacing (Fig.6/9).
Return the post-motor filter to the casing and re-fit to the
back of the vacuum cleaner.
7. Clearing Blockages
WARNING: To reduce the risk of electric shock,
the power cord must be disconnected before
performing maintenance or troubleshooting checks.
Turn the vacuum cleaner off and unplug from the electrical
outlet.
The flexible hose can be disconnected from the vacuum
cleaner by pressing the release latch and then pull away
from the machine. Remove any blockages found then reconnect the hose securely.
Removing debris from the TurboTool
(Model: VEC-21 only)
Switch the vacuum cleaner off and disconnect the power
plug from the electrical outlet.
Rotate the locking ring 180º (Fig.7/1).
Lift the top cover off and remove any blockage (Fig.7/2).
To re-assemble, ensure that the tabs are engage. Pivot the
lower housing closed and rotate the locking ring 180º
(Fig.7/2).
LOCKING RING
Fig.7/1
TABS
Fig.7/2
Fig.6/8
Fig.6/9
!
24
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 7
www.vax.co.uk
8
storage / troubleshooting
8. Storage
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet and rewind the power
cord as directed before storing.
NOTE: Always store the vacuum cleaner base down.
9. Troubleshooting
WARNING: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: Vacuum cleaner won't run
Cause: Not properly plugged into electrical outlet.
Solution: Plug in securely.
Cause: No electricity in the electrical outlet.
Solution: Check fuse or breaker.
Cause: On/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Blocked central filter.
Solution: Remove, clean and replace filters. See page 6.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause: Dirt container not installed properly.
Solution: Review dirt container replacement.
Cause: Dirt container full or blocked.
Solution: Empty dirt container.
Cause: Clogged filters.
Solution: Remove, clean and replace filters.
PROBLEM: Accessories won’t pick up.
Cause: Accessories are not attached correctly.
Solution: Refer to section 5.
Cause: TurboTool is clogged (Model: VEC-21 only).
Solution: Refer to section 7.
Cause: Hose is not installed correctly.
Solution: Refer to section 7.
!
!
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 8
PROBLEM: Dust escaping from the vacuum cleaner.
Cause: Dirt container full.
Solution: Empty dirt container.
Cause: Dirt container not installed correctly.
Solution: Review dirt container replacement.
Cause: Hose is not installed correctly.
Solution: Review installation.
Cause: Filter not installed completely.
Solution: Remove, clean and replace filters.
10. UK Service & Help
Vax Care 0870 6061248
Monday-Friday 8.00am to 6.00pm.
Saturday-Sunday 9.00am to 5.00pm.
An answerphone is available outside of these hours. Any
queries or concerns about using the Vax, call the Vax
Careline. Calls are charged at the UK national rate.
Please make a note of the serial number and model
number of the carpet cleaner before calling. There are
over 400 approved Vax Service Agents in the UK. For the
nearest Service Agent, please call the Vax Careline.
www.vax.co.uk
9
V
ax Careline 0870 606 1248
troubleshooting / uk service & help
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 9
www.vax.co.uk
10
11. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 1800W
Capacity: 2.8 litres approx
Filters: Central HEPA filter - washable
Central filter sleeve - washable
Central HEPA shroud - washable
Post-motor filter - washable
Cord length: 5m approx
Weight: 5.4kg
Subject to technical change without notice.
technical specification
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 10
11
V
ax Careline 0870 606 1248
This page has been left intentionally blank
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 11
---
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
VEC-11/VEC-21 Essentials by Vax range is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Wasteelectrical products should not be disposedof with household waste. Please recycle where
facilities exist. Check with your LocalAuthority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: info@vax.co.uk - website: www.vax.co.uk
Vax VEC-11&21 User Guide v3.qxd:VEC-11&21 User Guide 21/7/08 18:34 Page 12
Loading...
