vax.co.uk
Carpet Washer
Get Cleaning...
What’s your Vax’s model number?
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
VRS6W
V R S 6 W
– – – – –
User Guide
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 1
---
Machine Overview
Unit
Accessories
2
1
Handle
2
Clean water tank carry handle
3 Clean water tank release lever
4 Clean water tank
5
Dirty water tank release lever
6 Dirty water tank carry handle
7 Dirty water tank
8
Brushbar
(hidden)
9
Pre-motor filter
(
hidden)
10 Water/solution mix trigger
11 Cord storage hook
12 Upper cord storage
13 Power cord
14 Carry handle
15 Lower cord wrap clips
16 On/off button
17 Recline pedal
18 Vax carpet cleaning solution
19 Float chamber filter
(
hidden)
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Filter
1
2
3
4
7
8
9
1
0
13
11
12
14
15
16
17
18 19
5
6
19
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 2
General Safety Information
vax.co.uk
3
FOR HOUSEHOLD USE ONLY.
W
hen using thecarpet washer, basic safetyprecautionsshould
always beobserved, including the following:
1. Do not leave the carpet washer unattended when
p
lugged in. Unplug it from socket when not in use.
2
. To prevent electric shock do not use outdoors.
3. Not to be used as atoy. Children should be supervised to
e
nsure that they do not playwith theappliance.
4
. Thisappliance isnotintended foruseby persons (including
c
hildren)with reducedphysical, sensory or mental
capabilities, or lack of experienceandknowledge,
unless they have been given supervisionor instruction
concerning the useof the applianceby aperson
responsible for their safety.
5. Use only as described in this manual.
6. Do not use the carpet washer if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the carpet washer with a
damaged cord or plug. If the supply cord is damaged, it
must be replaced by the manufacturer or a
recommended Service Agent to avoid hazard and
invalidating the guarantee.
7. Do not pull or carry by cord. Do not use the cord as a
handle, close a door on the cord or pull cord around
sharp edges or corners. Do not run the carpet washer
over the cord. Keep the cord away from
heated surfaces.
8. Do not unplug by pulling on the cord.
9. Do not handle the plug or carpet washer with wet
hands.
10. Do not put any objects into openings or operate with
openings blocked, keep them free of anything that
may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not use the carpet washer on any glowing,
burning or smoking particles.
13. Do not use without the solution tank and dirty water
tank in place.
14. Turn off all controls before unplugging.
15. Do not use to pick up flammable or combustible
liquids such as petrol, or use in areas where they may
be present.
16. Keep the unit on the floor.
17. Do not use an extension cord.
18. Do not attempt to remove blockages with sharp
o
bjects as they may cause damage.
19. Store indoors put away after use to prevent tripping
a
ccidents.
20. Using improper voltage may result in damage to the
motor and possible injury to the user. The correct
voltage is listed on the rating label.
21. A hazard may occur if the carpet washer runs over
the power supply cord.
22. To prevent dirty water from running into the motor, do
not hold the appliance upside-down or lay on its side.
Use appliance in normal cleaning position.
23. Take extra care when cleaning on stairs.
24. Do not carry appliance while motor is running.
WARNING: Always switch off and unplug your
machine from the electrical outlet before filling and
emptying the clean water tank, emptying the dirty water tank,
before assembling, opening, before connecting/
disconnecting the attachments, or carrying out maintenance
or troubleshooting checks.
NOTE: Carpets should be dry vacuumed thoroughly
before washing.
IMPORTANT: If the hose or tools are blocked, switch
off the carpet washer and remove the blockage(s)
before re-starting your machine. See maintenance.
IMPORTANT: Cleaning filters maintains cleaning
performance. Vax recommends that your filters
should be checked and cleaned periodically. If your filters are
washable make sure they are completely dry before
inserting back into the machine.
This machine is intended for household use only, and
NOT for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR
FURTHER USE.
!!!
!
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 3
---
Operation
Assembling your carpet washer
4
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
NOTE: Do not over saturate your carpet.
• Vacuum thoroughly.
• Test for colourfastness - Wet a white absorbent cloth with the solution. In a small, hidden
area of your carpet, gently rub the surface with the dampened cloth. Wait ten minutes and
check for colour removal or bleed with white paper towel or cloth. If your carpet has more
than one colour, check all colours.
• When cleaning an entire room, move furniture out of the area to be cleaned. If the furniture is
too heavy to move, place aluminium foil or wax paper under legs. This will prevent wood
finishes from staining your carpet. Pin up furniture skirts and curtains.
Before you begin cleaning
Wrap cord to store.
!
Use a crosshead screwdriver.
Repeat on opposite
side of unit.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 4
Operation
vax.co.uk
5
Fill clean water tank
with solution mix and
re-fit the screw cap lid.
Pour required dose of
cleaning solution
(approx. 40ml per 1L
of water).
Mix solution with warm
water (max 40˚C).
Remove clean water
tank.
Unwrap power cord and plug unit in.
Operating your carpet washer
!
4
0° C
m
ax
Recline the machine. Press trigger to
release solution.
For best results apply solution
on the forward stroke and
recover solution on the
backward stroke.
!
IMPORTANT: Only use Vax carpet cleaning solution. Using other cleaning solution may
cause excess foaming and will prevent your machine from working effectively. Using other
solutions will invalidate the guarantee.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 5
---
Maintenance (Keep your Vax as good as new)
6
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Cleaning the float chamber filter
!
WARNING: To reduce the risk of electric shock, turn the machine off and unplug
from electrical outlet before performing maintenance/troubleshooting checks.
Emptying the dirty water tank
NOTE: Rinse out tank with clean water and leave to air dry before storing your machine.
Rinse under water to
remove debris (max
40ºC).
24hr
!
40° C
max
Allow to dry completely
before replacing or
storing away your
machine.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 6
Maintenance (Keep your Vax as good as new)
vax.co.uk
7
Removing blockages from the brushbar
To locate the brushbar turn
your machine upside down.
Threads caught in the
brushbar may be removed.
!
WARNING: To reduce the risk of electric shock, turn the machine off and unplug
from electrical outlet before performing maintenance/troubleshooting checks.
Cleaning the pre-motor filter
24hr
!
40° C
max
Rinse under water to
remove debris (max
40ºC).
Allow to dry completely
before replacing or
storing away your
machine.
The pre-motor filter
is located under the
dirty water tank.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 7
---
FAQs
8
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
!
WARNING: To reduce the risk of personal injury, unplug the carpet washer
before performing maintenance/troubleshooting checks.
Is there an accessory missing?
• Check the ‘Parts Overview’ page in this guide to
m
ake sure the part is definitely included in your
unit.
Why won’t the carpet washer turn on?
• It may not be plugged into the electrical outlet
correctly: ensure that the plug is pushed in
securely and switched on.
• The power button on the unit hasn’t been fully
depressed.
• If unit cuts out during use, disconnect the unit from
the wall socket, allow to cool for one hour, clean the
filter and empty the dirty water tank and check
hose, brushbar for blockages.
Why won’t the cleaner pick up solution/spills?
• The dirty water tank may be full and the auto shut
o
ff engaged. Empty the dirty water tank.
•
Ensure the dirty water tank is fitted correctly and the
tank cap is securely fitted.
• Check the brushbar for blockages.
Why won’t the solution/clean water dispense?
• Ensure the clean water tank is fitted securely.
• The solution/clean water tank may be empty.
• Ensure dirty water tank is fitted securely.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 8
Other Information
vax.co.uk
9
UK Service & Help
Vax Customer Careline:
(UK) 0844 412 8455
(ROI) 1-800 928 308
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
If you have any queries about using your carpet cleaner, call the Vax Careline. Please make a note of
the serial number and model number of the carpet cleaner before calling. For the nearest Service
Agent, please call the Vax Customer Careline or visit vax.co.uk
Consumables
To purchase spares and accessories, please visit vax.co.uk
Filter kit 1-1-130680-00
Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 500 W
Capacity: Clean water tank 2.1L
Dirty water tank 1.7L
Cord length: 6m
Weight: 5.6kg
Filter: Float chamber filter - foam
Pre-motor filter - foam
Subject to technical change without notice.
EEC Statement of Compliance
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
Powermax VRS6W is manufactured in compliance with the following Directives:
SSaaffeettyy
: 2006/95/EC Low Voltage Directive
EEMMCC
: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice.
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 9
---
10
Notes
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 10
Notes
vax.co.uk
11
VRS6W Carpet Washer User Guide v1.0.qxd:User guide 23/7/10 14:56 Page 11
---
Version 1.0
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: info@vax.co.uk - website: vax.co.uk
